Transforming Your APIs into Business Gold—Architecting a Real-Time API Usage Analytics Platform

In today's hyper-connected digital landscape, real-time API usage analysis and billing have become paramount. With the proliferation of APIs at the heart of modern applications and services, gaining real-time insights into their use is often mission-critical as it depends on critical factors such as latency, throughput, freshness, and the correctness of generated insights.

This talk discusses the architecture of a real-time API usage analytics system composed of Redpanda, Apache Flink, and Apache Pinot. Redpanda, as a scalable streaming data platform, enables high-volume, low-latency API volume data ingestion from API gateways in real time. The ingested data is streamed through Flink for streaming ETL, enabling operations like joins, aggregations, and transformations, feeding the final output of the pipeline to Apache Pinot for serving analytics at scale. In addition to that, we will use Flink for rate-limiting incoming API requests.

Having such a system enables businesses to make informed, agile decisions, addressing performance bottlenecks, security threats, and resource allocation issues in the API infrastructure promptly. Also, it ensures seamless user experiences by identifying usage patterns, issues, and opportunities as they occur, proactively enhancing the quality of your product.

Transcript

1. © 2024 REDPANDA DATA Transforming Your APIs into Business Gold Architecting a Real-Time API Usage Analytics Platform 1 RTA Summit 2024
2. © 2023 REDPANDA DATA About the presenter 2 Dunith Dhanushka Senior Developer Advocate, Redpanda Data • Event streaming, real-time analytics, and stream processing enthusiast • Frequent blogger, speaker, and an educator
3. © 2023 REDPANDA DATA My background Why I’m talking about this topic today? 3
4. © 2023 REDPANDA DATA This talk • Is a blueprint for solutions that be built by combining Kafka/Redpanda and Apache Pinot. • Not coupled to specific APIM vendor. • No demo. sorry! :( • Take the blueprint as a takeaway 4
5. © 2024 Redpanda Data 5 What is an API?
6. © 2024 REDPANDA DATA An API is a business capability delivered to consumers over a network. 6
7. © 2024 REDPANDA DATA In a digital business, APIs allow for programmatic access to business operations. 7
8. API Proxy
11. © 2024 Redpanda Data Making money with APIs 11
12. © 2024 REDPANDA DATA Use case 12
13. © 2024 REDPANDA DATA API enablement 13
14. © 2024 REDPANDA DATA Potential API consumers 14 • Real estate companies - Provide an accurate valuation figure for home buyers. • Banks - House valuation before approving a mortgage. • Insurance providers - Provide more accurate quotes for home and content insurances. • Government - Easily calculate property taxes.
15. © 2024 REDPANDA DATA API monetization model 15 https://cloud.google.com/apigee/docs/api-platform/monetization/overview
16. © 2024 REDPANDA DATA The need? 16 Find an efficient and reliable way to measure API usage for each consumer
17. © 2024 Redpanda Data Planning 17
18. © 2024 Redpanda Data What metrics to derive? 1. API usage - API invocations over time per consumer 2. API latency - End to end latency 3. Unique users 4. Geographical usage distribution 5. Error count 18
19. © 2024 Redpanda Data What metrics to derive? 19 Photo credits https://www.atatus.com/blog/api-analytics-tools/
20. © 2024 Redpanda Data For whom? 20
21. © 2024 REDPANDA DATA Batch or real-time insights? We prefer real-time actionable insights. - Real-time usage alerts for consumers - Real-time API traffic metrics for the product team - Real-time API health information for operations teams Complemented with batch processing: - Monthly usage-based billing reports. - Weekly API health reports - Daily API traffic reports 21
22. © 2024 Redpanda Data Implementation 22
24. © 2024 REDPANDA DATA API Management System Architecture 24 https://community.denodo.com/
25. © 2024 REDPANDA DATA Data collection 25
26. Analytics data store
27. © 2024 REDPANDA DATA Sample payload 27
28. © 2024 REDPANDA DATA Write path: API Gateway to datastore Directly writing to the analytics datastore is not recommended: - APIM system and the analytics infrastructure is coupled - Avoid synchronous writes - Support scalable ingestion 28
29. © 2024 REDPANDA DATA So, we need a buffer in between! 29
30. © 2024 REDPANDA DATA What is Redpanda? 30
31. © 2024 REDPANDA DATA Redpanda is a Kafka API compatible streaming data platform 31 • Written in C++ • Thread-per-core architecture • Designed for modern hardware
32. © 2024 REDPANDA DATA Simple to deploy, use and manage Single binary Kafka-compatible APIs Easy Day 2 Ops Dev-friendly interface
33. © 2024 REDPANDA DATA 33
34. Analytics data store Streaming data platform
35. © 2024 REDPANDA DATA Apache APISIX Kafka sink 35
36. © 2024 REDPANDA DATA Analytics datastore 36
37. © 2024 REDPANDA DATA Expectations 37 • Streaming data ingestion - Higher data freshnes • Low-latency queries - User-facing queries • High query throughput - efficiently handle query spikes
38. © 2024 REDPANDA DATA So, we need a real-time OLAP database. 38
39. © 2024 REDPANDA DATA What is Apache Pinot? 39
40. © 2024 REDPANDA DATA Apache Pinot is a real-time distributed OLAP database, designed to serve OLAP workloads on streaming data with extreme low latency and high concurrency. 40
41. https://dev.startree.ai/
42. © 2024 REDPANDA DATA Data ingestion pipe 42
43. © 2024 REDPANDA DATA Need a Stream processor? 43 • Not mandatory, but nice to have based on the need. • Data cleansing - Redpanda’s WASM transforms can do this • A stateful stream processor like Apache Flink will add more value to the pipeline when: ◦ Real-time joins and enrichment is needed. ◦ Trigger alerts and fire up downstream workflows.
44. © 2024 REDPANDA DATA Serving insights 44
46. © 2024 REDPANDA DATA Visualization and BI • Integrates with Python clients through Pinot Python driver. - PinotDB • Integrates with popular BI products via JDBC and ODBC interfaces. 46
47. © 2024 REDPANDA DATA Ad-hoc querying 47
48. © 2024 REDPANDA DATA Ad-hoc querying - Jupyter notebook 48 Hubert Dulay’s meetup talk https://www.youtube.com/watch?v=viZc_1nPNnI
49. © 2024 REDPANDA DATA Batch workloads • Pinot can work with query federators like Trino and Presto for running batch reports. 49
50. © 2024 REDPANDA DATA Implementation plan 1. Provision a Redpanda cluster, create topics, set ACLs. 2. Configure the Kafka sink in APISIX. 3. Create Pinot schemas and tables. 4. Massage data as needed. 5. Create/plug dashboards. 50
51. © 2024 Redpanda Data Recap 51
53. © 2024 REDPANDA DATA Redpanda University Free, self-paced online learning https://university.redpanda.com • Learn the fundamentals of data streaming and Redpanda • Install Redpanda and use the rpk CLI to configure it • Create producers and consumers in Java, Python and NodeJS • Sign up today for free! 53
54. © 2023 Redpanda Data Thanks for joining! Let’s keep in touch 54 @redpandadata redpanda-data redpanda-data hello@redpanda.com
