From Restful to GraphQL

De RESTful a GraphQL: revolucionando la forma de comunicación entre cliente y servidor

GraphQL es el candidato predestinado a sustituir REST, sobre todo en el ecosistema móvil dónde los desarrolladores creamos productos cada vez más complejo más allá de un simple CRUD.

La migración de algunas de las APIs y servicios más populares está demostrando exponencialmente que el futuro de GraphQL está cada vez está más cerca. Facebook es su principal impulsor desde 2012 construyendo sus servicios en torno a ella, así como Github o Shopify

En esta charla vamos a repasar la evolución de API REST a GraphQL como un query language para escribir APIs, así como sus principios fundamentales: la introspection, type system o ejecución de query/mutation.

También veremos cómo añadir GraphQL a tu arquitectura tanto en server side como en cliente para aprovechar al máximo la tecnología. Repasaremos algunas de las herramientas que nos facilitarán la tarea de construir y usar APIs GraphQL.

La charla es una evolución del post introductorio que escribí en Genbeta Dev ¿Por qué deberíamos abandonar REST y empezar a usar GraphQL en nuestras APIs? y la charla que impartí en el pasado T3chfest sobre GraphQL.

Transcript

1. From RESTful to GraphQL José María Rodríguez Hurtado @durbon chema@durbon.com 1 #CodemotionMadrid
2. 2 I’m Chema Android Team Lead at @JobandtalentEng Editor Genbeta @durbon
3. 3 “Instead of working with rigid server-defined endpoints, you can send queries to get exactly the data you’re looking for in one request”
4. Agenda Reviewing RESTful Working on product teams with APIs GraphQL 4
6. ¿Using REST correctly? Nick Schrock. React London Meetup. 2015 6
7. Reviewing RESTful - Define separate resources. Fetch via URI - These resources are manipulated using HTTP requests where the method (GET, POST, PUT, PATCH, DELETE) has specific meaning. - Discover resources, thanks to HATEOAS (Hypertext As The Engine Of Application State). 7
8. 8 https://medium.com/@leeshapton/mental-maps-for-teaching-graphql-to-beginners-9db9b85ac957
9. Collections of API RESTFul Endpoint resources GET /posts - Retrieves a list of posts GET /posts/12 - Retrieves a specific post GET /posts/12/comments - Retrieves comments GET /posts/12/comments/42/ - Retrieve specific comment POST /posts - Creates a new post PUT /posts/12 - Updates post #12 with payload provided PATCH /posts/12 - Partially updates post #12 DELETE /posts/12 - Deletes post #12 9
10. Example Payload JSON { "name": "Luke Skywalker", "height": "172", "mass": "77", "hair_color": "blond", "skin_color": "fair", "eye_color": "blue", "birth_year": "19BBY", "gender": "male", "homeworld": "http://swapi.co/api/planets/1/", "films": [ "http://swapi.co/api/films/6/", "http://swapi.co/api/films/3/", "http://swapi.co/api/films/2/", "http://swapi.co/api/films/1/", "http://swapi.co/api/films/7/" ], "species": [ "http://swapi.co/api/species/1/" ], "vehicles": [ "http://swapi.co/api/vehicles/14/", "http://swapi.co/api/vehicles/30/" ], "starships": [ "http://swapi.co/api/starships/12/", "http://swapi.co/api/starships/22/" 10
11. Problems Working with APIs 11
13. 13 Where is my API? Where are my endpoints? Why does it not work? How many endpoint will be needed? How many changes should we do?
14. Excessive Round Trips Client - R 14
15. Payload and bandwidth 15
16. /filmsWithDirectorAndTag /filmsWithPrincipalsCharacter /filmSummaries/1 /filmsDetails/1 /filmSummaryWithActors/1 Custom Endpoints or BFF (aka “spaghettification”) 16
17. Versioning APIs: breaking changes 17 What is the correct way to version my API? - The URL way? /api/v1/post/12232 V2, v3, v4….?? - The Header way? GET /api/article/1234 HTTP/1.1 Accept: application/vnd.api.article+xml; version=1.0
18. Why not like REST? - Most REST API are really Ad-hoc RPC with custom endpoint definitions. Time spent maintaining many versioned endpoint - REST requires many requests (many Roundtrips) - With REST, you request too much or too little data REST often turns into a maze of poorly-documented endpoints - Weak Typing and Poor Metadata 18
20. GraphQL isn't a new technology. Facebook: It has been delivering data to mobile News Feed since 2012 20
23. GraphQL is a query language, like SQL? You don’t connect GraphQL directly to your backend or database. It’s an API layer, just like REST. GraphQL can be layered over multiple backends and databases, without the client being aware of where the data is coming from, just like REST. 23
24. “GraphQL is a query language designed to build client applications by providing an intuitive and flexible syntax and system for describing their data requirements and interactions.” - GraphQL Specification https://facebook.github.io/graphql/ 24
25. Single Endpoint /graphql 25
26. 26 https://medium.com/@leeshapton/mental-maps-for-teaching-graphql-to-beginners-9db9b85ac957
27. Query Language “hello world” Query { me { name } } { "me": { "name": "@durbon" } } 27
28. { speaker(id: 27) { name profilePics { width height url } } } { "speaker": { "name": "@durbon" "profilePics" : { "width": 250, "height": 250, "url": "http://avatarurl.com/250.jpg" } } } Ask for you want 28
29. { speaker(id: 27) { name twitter profilePics(size: 640) { width height url } } } { "speaker": { "name": "Txema Rodríguez" "twitter": "@durbon" "profilePics" : { "width": 640, "height": 640, "url": "http://avatar.com/640.jpg" } } } Ask for you want 29
30. { speaker(id: 27) { name, licPic: profilePics (size: 90){ width, height, url }, bigPic: profilePics (size: 800){ width, height, url } } } "speaker": { "name": "Txema Rodríguez" "licPic" : { "width": 90, "height": 90, "url": "http://avatar.com/90.jpg" }, "bigPic" : { "width": 800, "height": 800, "url": "http://avatar.com/800.jpg" } } } Ask for you want 30
31. Nested connection resources { me { name talks { title } } } { "me": { "name": "@durbon" "talks" : [ { title: "GraphQL is cool" }, { title: "API REST is dead" }, { title: "Kotlin in Android" },.. 31
32. { latestTalk { title, speaker { name, twitter } }, allSpeakers { name } } { "data": { "latestTalk": { "title": "¿Por qué deberíamos abandonar REST?", "speaker": { "name": "Txema Rodríguez", "twitter": "@durbon", } }, "allSpeakers": [ { "name": "Txema Rodriguez" }, { "name": "David Bonilla" } ] } } 32 Combining Queries
34. Mutation: also you can write using GraphQL: mutation { writePost (input : { author: “durbon”, title: “graphql for beginners” content: "it's awesome." }) { id, title } } 34
35. GraphQL Core principles 35
36. Type System GraphQL schema language it's similar to the query language, and allows us to talk about GraphQL schemas in a language-agnostic way. 36
37. Schemas and types - Object types with fields: speakers, talks,... - Scalar types: Int, Float, String, Boolean, ID - Lists and Non-Null - Arguments: every field on a GraphQL object type can have zero or more arguments - Enumeration types: a special kind of scalar that is restricted to a particular set of allowed values 37
38. The GraphQL schema provides a clear contract for client-server communication Client Backend Possibilities GraphQL Type System GraphQL Schema Requirements GraphQL Languages Queries Mutation App Server View 38
39. Schema type Query { me: Speaker speaker (id: Int): Speaker! } type ProfilePicture { width: Int! height: Int! url: String! } type Speaker { name: String! profilePicture(size: Int = 50): ProfilePicture talks: [Talks!] } 39 input TalkInput{ content: String! author: Speaker! } type Mutation { createTalk: (input: TalkInput): Talk } type Talk { author: Speaker! content: String! }
40. Introspection Creating documentation, or rich IDE experiences 40
41. IntrospectionQuery { __type(name: "Speaker") { name description } } { "data": { "__type": { "name": "Speaker", "description": "The speaker of a talk.", } } } 41
42. IntrospectionQuery query IntrospectionQueryTypeQuery { __schema { queryType { name fields { name description type { name kind } } } } } { "data": { "__type": { "name": "Developer", “Description”: “Name developer” "fields": [ { "name": "id", "type": { "name": null, "kind": "NON_NULL" } }, { "name": "name", "type": { "name": null, "kind": "NON_NULL" } 42
43. Documentation by default Generates API documentation for our consumers, and prevents us from spending precious coding time on documentation. 43
45. Static validation & IDE Integration 45
46. Code Generation: write queries, not code 46
47. Execution After being validated, a GraphQL query is executed by a GraphQL server which returns a result that mirrors the shape of the requested query 47
49. Database “Microservices” Remote Services whatever your tech stack Your existing code GraphQL Execution 49
50. Object, consisting of two major components: • the schema definition • the actual implementation in the form of resolver functions 50 Structure vs Behaviour
51. Think in Graph, not endpoint Fields independently of each other. Apply different context in order to retrieve such data 51
52. Each field on each type is backed by a function called the resolver which is provided by the GraphQL server When a field is executed, the corresponding resolver is called to produce the next value. 52
53. 53 https://blog.graph.cool/graphql-server-basics-the-schema-ac5e2950214e
54. 54 Every feature you build first manifests itself in the GraphQL schema — then gets implemented through corresponding resolvers it allows frontend developers to start working against a mocked API, before it is actually implemented by backend developers Schema First development
55. 55 Catching
58. 58 Stitching in a gateway
59. 59 Stitching in a gateway
61. 61 GraphQL.org
62. Draft RFC Specification for GraphQL https://facebook.github.io/graphql/ 62
63. Reference implementation of GraphQL https://github.com/graphql/graphql-js 63
65. Javascript Python (graphene) Scala (sangria) Ruby Java Clojure Go PHP C# .NET Elixir Swift …. graphql.org/code/ 65
66. Client library 66 Relay React iOS Android
68. Public GraphQL APIs 68 Early Github GraphQL API https://developer.github.com/early-access/graphql/explorer/ Yelp https://www.yelp.es/developers/graphql/guides/intro SWAPI http://graphql.org/swapi-graphql/ More APIs https://github.com/APIs-guru/graphql-apis
69. Benefits of Exposing Data Through GraphQL - Boost your client development: combining and Querying Data and Picking Your Payload - Specification: the spec determines the validity, Strongly Typed, hierarchical with nested fields - Structure vs Behaviour. This allows you to focus on separation of concerns, not technologies. 69
70. @durbon 70 Thanks, #codemotionMadrid! We’re hiring candidates.jobandtalent.com/es/careers
