1. SmilesFormer: Language Model for
   Molecular Design
   Elix, Inc.
   Chem-Bio Informatics Society (CBI) Annual Meeting 2022, Tokyo Japan | October 26, 2022
   Joshua Owoyemi, Ph.D & Nazim Medzhidov, Ph.D


   View Slide

2. 2
   Introduction
   ● Generative models play a major role in discovering and designing new molecules, which is key to innovation in
   in-silico drugs discovery
   ● There is a vast amount of molecular data available, therefore generative models should be able to learn
   concepts of valid and desired molecules using a data-centric approach.
   Challenges:
   ● Model that can take advantage of vast available dataset to learn efficient molecular representations
   ● Need for methods to efficiently transverse possible chemical space in order to generate molecules that satisfy
   desired multi-objective.
   ● Demonstration of how proposed method can be utilized in a practical use case.


   View Slide

3. ● Language models can fill in an incomplete sentence.
   ● Recent language models can scale to vast amount of data.
   3
   Proposed Method: Language model for molecule generation
   The quick brown fox ___ __ the lazy dog
   Language
   Model
   The quick brown fox walks around the lazy dog
   The quick brown fox jumps over the lazy dog
   The quick brown fox bumps into the lazy dog
   *
   Common Crawl Dataset contains nearly 1 trillion words[+]
   [+] T. Brown et al., “Language Models are Few-Shot Learners,” in Advances in Neural Information Processing Systems,
   2020, vol. 33, pp. 1877–1901. [Online]. Available:
   https://proceedings.neurips.cc/paper/2020/file/1457c0d6bfcb4967418bfb8ac142f64a-Paper.pdf


   View Slide

4. ● Language models can fill in an incomplete sentence.
   ● Language models can scale to vast amount of data.
   4
   Proposed Method: Language model for molecule generation
   The quick brown fox ___ __ the lazy dog
   Language
   Model
   The quick brown fox walks around the lazy dog
   The quick brown fox jumps over the lazy dog
   The quick brown fox bumps into the lazy dog
   *
   Common Crawl Dataset contains nearly 1 trillion words[+]
   [+] T. Brown et al., “Language Models are Few-Shot Learners,” in Advances in Neural Information Processing Systems,
   2020, vol. 33, pp. 1877–1901. [Online]. Available:
   https://proceedings.neurips.cc/paper/2020/file/1457c0d6bfcb4967418bfb8ac142f64a-Paper.pdf
   Language
   Model
   *
   ZINC Dataset contains over 200 million compounds[^]
   [^] J. J. Irwin et al., “ZINC20—A Free Ultralarge-Scale Chemical Database for Ligand Discovery,” Journal of Chemical
   Information and Modeling, vol. 60, no. 12, pp. 6065–6073, 2020, doi: 10.1021/acs.jcim.0c00675.


   View Slide

5. ● We formulate the problem as a language modeling problem, where the model is able to generate a full
   sequence (sentence) from incomplete ones, or some prior knowledge.
   ● Employ a state-of-the-art language model to encode a molecular latent space by generating valid
   molecule (sequences) from fragments and fragment compositions.
   5
   Proposed Method: SmilesFormer Model
   E
   D
   *
   Reconstruction
   Inputs Transformer[1] + VAE[2]
   Query Sequence
   Backprop


   View Slide

6. ● Molecules are broken down into fragments using simple strategies
   ● Model inputs can be (i) full sequences, (ii) fragments, (iii) fragment compositions, and (iii) dummy
   fragments - “*”.
   ● Fragments can be ‘composed’ using the [COMP] token
   6
   Proposed Method: Model Inputs
   RECAP[+] Fragmentation
   Fragment-on-bonds
   Full sequence
   transformation
   [*]c1ccc(S(N)(=O)=O)cc1[COMP][*]c1cc(C(F)(F)F)nn1[*][COMP][*]c1ccc(C)cc1 Fragment Composition
   [+] X. Q. Lewell, D. B. Judd, S. P. Watson, and M. M. Hann, “RECAPsRetrosynthetic Combinatorial Analysis Procedure: A
   Powerful New Technique for Identifying Privileged Molecular Fragments with Useful Applications in Combinatorial
   Chemistry,” p. 12.


   View Slide

7. 7
   Proposed Method: Molecule Optimization
   Encoder Output
   PLogP > 1.0
   QED > 0.8
   SA > 8.0
   ...
   Multi-objective
   History of good
   latent variables
   𝛼
   ᐧ
   PropNN[+]
   Gradients
   V
   t-1
   V
   t
   Decoder
   V
   t
   Proposed
   Samples
   Query Tokens
   CC1=
   0
   1
   2
   3
   4
   5
   6
   Optimization
   Steps
   V
   t-1
   V
   t-h
   Backtrack
   [+] J. Mueller, D. Gifford, and T. Jaakkola, “Sequence to Better Sequence: Continuous Revision of Combinatorial
   Structures,” in Proceedings of the 34th International Conference on Machine Learning, Aug. 2017, vol. 70, pp.
   2536–2544. [Online]. Available: https://proceedings.mlr.press/v70/mueller17a.html
   ● Molecules with desired properties can then be generated by exploring the latent space through a
   gradient-based strategy which guides the latent variables to the chemical space that satisfy desired
   objectives.
   Latent space revision


   View Slide

8. 8
   Experiments
   • Distribution-directed Benchmarks:
   • Guacamol, MOSES
   • Goal-directed Benchmarks (Multi-objective optimization)
   • JNK3 Inhibition: Inhibition against c-Jun N-terminal Kinases-3 (JNK3), belonging to the mitogen-activated
   protein kinase family, and are responsive to stress stimuli, such as cytokines, ultraviolet irradiation, heat
   shock, and osmotic shock.
   • GSK3β Inhibition: An enzyme associated with an increased susceptibility towards bipolar disorder.
   • Donepezil Rediscovery: Real use-case demonstration of drug rediscovery pipeline for Donepezil, a known
   acetylcholinesterase (AChE) inhibitor.
   • Backbone-constrained molecule optimization: Useful in lead optimization stages
   • Experiments with model parameters:
   • Model stochasticity
   • Fragmentation strategies
   • Full sequence suggestions
   • Start tokens constraints
   • Fragments analysis


   View Slide

9. 9
   Results: Distribution Benchmarks
   AAE Graph MCTS Random Sampler SMILES LSTM VAE ORGAN SmilesFormer
   Validity 0.822 1 1 0.959 0.87 0.379 1
   Uniqueness 1 1 0.997 1 0.999 0.841 1
   Novelty 0.998 0.994 0 0.912 0.974 0.686 0.9958
   KL divergence 0.886 0.522 0.998 0.991 0.982 0.267 0.8722
   Frechet ChemNet Distance 0.529 0.015 0.929 0.913 0.863 0 0.1537
   Model Valid (↑)
   Unique
   @1k (↑)
   Unique@
   10k (↑)
   FCD (↓) SNN (↑) Frag (↑) Scaf (↑)
   IntDiv (↑)
   IntDiv2
   (↑) Filters (↑) Novelty (↑)
   Test TestSF Test TestSF Test TestSF Test TestSF
   Train 1 1 1 0.008 0.4755 0.6419 0.5859 1 0.9986 0.9907 0 0.8567 0.8508 1 1
   HMM 0.076±0.0322
   0.623
   ±0.1224
   0.5671
   ±0.1424
   24.4661
   ±2.5251
   25.4312
   ±2.5599
   0.3876
   ±0.0107
   0.3795
   ±0.0107
   0.5754
   ±0.1224
   0.5681
   ±0.1218
   0.2065
   ±0.0481
   0.049
   ±0.018
   0.8466
   ±0.0403
   0.8104
   ±0.0507
   0.9024
   ±0.0489 0.9994±0.001
   CharRNN 0.9748±0.0264 1.0±0.0
   0.9994
   ±0.0003
   0.0732
   ±0.0247
   0.5204
   ±0.0379
   0.6015
   ±0.0206
   0.5649
   ±0.0142
   0.9998
   ±0.0002
   0.9983
   ±0.0003
   0.9242
   ±0.0058
   0.1101
   ±0.0081
   0.8562
   ±0.0005
   0.8503
   ±0.0005
   0.9943
   ±0.0034 0.8419±0.0509
   AAE 0.9368±0.0341 1.0±0.0
   0.9973
   ±0.002
   0.5555
   ±0.2033
   1.0572
   ±0.2375
   0.6081
   ±0.0043
   0.5677
   ±0.0045
   0.991
   ±0.0051
   0.9905
   ±0.0039
   0.9022
   ±0.0375
   0.0789
   ±0.009
   0.8557
   ±0.0031
   0.8499
   ±0.003
   0.996
   ±0.0006 0.7931±0.0285
   VAE 0.9767±0.0012 1.0±0.0
   0.9984
   ±0.0005
   0.099
   ±0.0125
   0.567
   ±0.0338
   0.6257
   ±0.0005
   0.5783
   ±0.0008
   0.9994
   ±0.0001
   0.9984
   ±0.0003
   0.9386
   ±0.0021
   0.0588
   ±0.0095
   0.8558
   ±0.0004
   0.8498
   ±0.0004
   0.997
   ±0.0002 0.6949±0.0069
   JTN-VAE 1.0±0.0 1.0±0.0
   0.9996
   ±0.0003
   0.3954
   ±0.0234
   0.9382
   ±0.0531
   0.5477
   ±0.0076
   0.5194
   ±0.007
   0.9965
   ±0.0003
   0.9947
   ±0.0002
   0.8964
   ±0.0039
   0.1009
   ±0.0105
   0.8551
   ±0.0034
   0.8493
   ±0.0035
   0.976
   ±0.0016 0.9143±0.0058
   LatentGAN 0.8966±0.0029 1.0±0.0
   0.9968
   ±0.0002
   0.2968
   ±0.0087
   0.8281
   ±0.0117
   0.5371
   ±0.0004
   0.5132
   ±0.0002
   0.9986
   ±0.0004
   0.9972
   ±0.0007
   0.8867
   ±0.0009
   0.1072
   ±0.0098
   0.8565
   ±0.0007
   0.8505
   ±0.0006
   0.9735
   ±0.0006 0.9498±0.0006
   SmilesFormer 1.0±0.0 1.0±0.0 1.0±0.0
   15.665
   ±0.04
   16.467
   ±0.001
   0.4025
   ±0.003
   0.3903
   ±0.005
   0.8373
   ±0.2
   0.8583
   ±0.0002
   0.1438
   ±0.004
   0.06336
   ±0.01 0.9144±0.0
   0.9020
   ±0.0
   0.4947
   ±0.003 0.99994±0.00001
   • Guacamol[+]
   • MOSES[^]
   [+] N. Brown, M. Fiscato, M. H. S. Segler, and A. C. Vaucher, “GuacaMol: Benchmarking Models for de Novo
   Molecular Design,” J. Chem. Inf. Model., vol. 59, no. 3, pp. 1096–1108, Mar. 2019, doi:
   10.1021/acs.jcim.8b00839.
   [^] D. Polykovskiy et al., “Molecular Sets (MOSES): A Benchmarking Platform for Molecular Generation
   Models,” arXiv:1811.12823 [cs, stat], Oct. 2020, Accessed: Nov. 21, 2021. [Online]. Available:
   http://arxiv.org/abs/1811.12823


   View Slide

10. 10
    Results: Goal-directed Benchmarks (Multi-objective optimization)
    [+] N. Brown, M. Fiscato, M. H. S. Segler, and A. C. Vaucher, “GuacaMol: Benchmarking Models for de Novo
    Molecular Design,” J. Chem. Inf. Model., vol. 59, no. 3, pp. 1096–1108, Mar. 2019, doi:
    10.1021/acs.jcim.8b00839.
    [^] D. Polykovskiy et al., “Molecular Sets (MOSES): A Benchmarking Platform for Molecular Generation
    Models,” arXiv:1811.12823 [cs, stat], Oct. 2020, Accessed: Nov. 21, 2021. [Online]. Available:
    http://arxiv.org/abs/1811.12823
    Single Objective Optimization Multi Objective Optimization
    Oracle Efficiency during molecule optimization
    Top molecules for
    QED+SA+JNK3+GSK3β.
    The scores are SA, QED,
    JNK3, and GSK3β
    respectively


    View Slide

11. 11
    Results: Donepezil Rediscovery
    Model Pretraining
    ● Training on large scale
    dataset
    ● Objective: Learn Smiles
    vocabulary of possible
    chemical space
    ● Dataset
    ○ ChEMBL (2.1M mols)
    ○ Post-donepezil-disco
    very AChE-active
    molecules were
    excluded
    Model
    Fine-tuning on
    selected
    dataset
    ● Dataset curation for
    active molecules on
    AChE.
    ● Exclusion of
    donepezil scaffold
    and relevant
    molecules
    Molecule
    generation and
    optimization
    ● Generate molecules
    and optimize with
    multi-property
    objectives
    (1) SA < 1, Target = 0; (2) QED > 0,
    Target = 1; (3) PLogP > 0, Target = 40;
    (4) Molecular Weight 250 < > 750; (5)
    Number of Hydrogen Bonds 5 < > 10; (6)
    Topological Polar Surface Area (TPSA)
    75 < > 150; (7) Number of Rotatable
    Bonds 5 < > 10; (8) Similarity to tacrine
    Ci < 1, Target = 0; (9) Similarity to
    physostigmine < 1, Target = 0 (10)
    Similarity to rivastigmine Ci < 1, Target =
    0; and (11) AChE inhibitor activity pIC50
    (negative log IC50), determined by a
    trained predictive model on AChE
    Inhibitor active compounds Ci > 1,
    Target = 1
    Molecules
    post-processing
    and analysis
    ● Novelty ranking
    ● Activity ranking
    ● Scaffold analysis
    Stage 1 Stage 2


    View Slide

12. 12
    Results: Donepezil Rediscovery
    Top 10 scaffolds from the
    generated molecules. The
    numbers signify how
    many times the scaffold
    appears out of 10
    experiment runs.
    Donepezil Donepezil Scaffold Identified Molecule
    (Compound 14 from the
    original Donepezil paper[+])
    [+] H. Sugimoto, H. Ogura, Y. Arai, Y. Iimura, and Y. Yamanishi, “Research and Development of Donepezil
    Hydrochloride, a New Type of Acetylcholinesterase Inhibitor,” Japanese Journal of Pharmacology, vol. 89, no.
    1, pp. 7–20, 2002, doi: 10.1254/jjp.89.7.


    View Slide

13. 13
    Results: Backbone-constrained molecule generation
    Our model is able to learn the generation of molecules with constrained backbones.
    The molecule in the green box is the input backbone. The generated SMILES
    string and Tanimoto similarity score to the input backbone is shown


    View Slide

14. 14
    Results: Backbone-constrained molecule generation
    Our model is able to learn the generation of molecules with constrained backbones.
    The molecule in the green box is the input backbone. The generated SMILES
    string and Tanimoto similarity score to the input backbone is shown


    View Slide

15. 15
    Results: Experiments with model parameters
    .
    Molecule generation without fragmentation
    Molecule generation with fragmentation


    View Slide

16. 16
    Conclusions
    ● We proposed and demonstrated a language model that learns SMILES vocabulary in order to generate novel
    compounds
    ● The trained model can be used in molecular optimization task using customizable parameters
    ● We demonstrated the application of our model in various de novo molecular design tasks include a real use
    case of donepezil rediscovery
    Future Directions:
    ● Property-aware molecule generation
    ● Matching molecular pairs generation


    View Slide

17. www.elix-inc.com


    View Slide

18. 18
    Appendix


    View Slide

19. 19
    Input Tokenization
    • Smiles strings are tokenized based on a predefined dictionary.[+]
    • A dictionary of 591 tokens is used.
    • Tokens are characters or group of characters that form a single unit.
    Token Dict ID
    C 16
    [C@H] 33
    [N+] 41
    [SiH2] 127
    [PAD] 0 special, for padding
    [COMP] 6 special, for composition
    [BOC] 9 special, for Beginning of Compound
    [EOC] 10 special, for End of Compound
    [UNK] 11 special, for unknown tokens
    [+] P. Schwaller et al., “Molecular Transformer: A Model for Uncertainty-Calibrated Chemical Reaction Prediction,” ACS
    Cent. Sci., vol. 5, no. 9, pp. 1572–1583, Sep. 2019, doi: 10.1021/acscentsci.9b00576.


    View Slide

20. 2
    Model Training and Evaluation Details
    Model parameters
    12 Layers
    12 heads
    latent space embedding
    dimension: 288,
    0.15 dropout
    Training:
    Dataset constraints:
    ● Max molweight 900,
    ● Max token length 100
    Datasets collection
    Name Size Description
    Small Datasets 872,557 Small datasets from
    predictive model
    benchmarks
    ChEMBL 3.0 3,429,071 Elix Small + Guacamol
    (train) + Molsets (train)


    View Slide

21. 21
    Results: Experiments with model parameters
    .


    View Slide
