Android and the WebView

While the native widgets for Android are extremely powerful and cover most of the use cases we can imagine, there are still some areas where web content is our only option. That means we need to embed a WebView in our application and create a bridge between the native code and the JavaScript running on the web page we load.

In this session you will learn everything there is about how to deal with the WebView on Android. Learn how to properly load content, inject your own CSS or JavaScript, how to effectively communicate between JavaScript and Android, and how to make loading web content secure in Android applications. We will also look at how to implement some common use cases, like displaying ePub and other HTML-based e-books.

Transcript

1. Android and the WebView
   @ErikHellman
   speakerdeck.com/erikhellman/android-and-the-webview


   View Slide

2. If all you have is a hammer,
   everything looks like a
   nail!


   View Slide

3. What else would you really need?!?
   layout_height="match_parent"
   layout_width="match_parent">
   val webView = findViewById(R.id.webView)
   webView.loadUrl("https://dailykitten.com")


   View Slide

4. View Slide

5. Don't use the WebView!

   layout_height="match_parent"
   layout_width="match_parent">


   View Slide

6. Use Chrome Custom Tabs instead!


   View Slide

7. Chrome Custom Tabs
   Gradle:
   implementation 'androidx.browser:browser:x.y.z'
   Kotlin:
   val url = Uri.parse("https://dailykitten.com")
   CustomTabsIntent.Builder().build().launchUrl(this, url)


   View Slide

8. Customizing toolbar color
   val url = Uri.parse("https://dailykitten.com")
   CustomTabsIntent.Builder()
   .setToolbarColor(R.color.mainCoonGrey)
   .build().launchUrl(this, url)


   View Slide

9. Custom action button
   val icon = R.drawable.cat
   val description = R.string.send_to_cat
   val pendingIntent = PendingIntent.getActivity(...)
   val tint = true
   CustomTabsIntent.Builder()
   .setActionButton(icon, description, pendingIntent, tint)
   .build().launchUrl(this, url)


   View Slide

10. Customizing transitions
    CustomTabsIntent.Builder()
    .setStartAnimations(this, R.anim.fancy_in_anim, R.anim.fancy_out_anim)
    .setExitAnimations(this, R.anim.fancy_out_anim, R.anim.fancy_in_anim)
    .build().launchUrl(this, url)


    View Slide

11. Launch pages faster
    val connection = object : CustomTabsServiceConnection() {
    override fun onCustomTabsServiceConnected(name: ComponentName,
    client: CustomTabsClient) {
    client.warmup(0)
    client.newSession(CustomTabsCallback())
    .mayLaunchUrl(Uri.parse("https://dailykitten.com"), Bundle.EMPTY, emptyList())
    }
    override fun onServiceDisconnected(name: ComponentName) { }
    }
    CustomTabsClient.bindCustomTabsService(this, "com.android.chrome", connection)


    View Slide

12. android.webkit.WebView


    View Slide

13. Avoid WebView if possible!


    View Slide

14. When NOT to use WebView1
    — Displaying SVG images
    — Login dialogs (Except when you must)
    — Wrapping your mobile website in an APK
    1 Not a complete list...


    View Slide

15. When to use WebView2
    — Displaying local HTML formatted content
    — Web-only authentication
    2 Mostly complete list.


    View Slide

16. View Slide

17. View Slide

18. Getting Started
    1. Enable Chrome Dev tools
    // Enable Chrome Dev Tools with chrome://inspect
    WebView.setWebContentsDebuggingEnabled(BuildConfig.DEBUG)


    View Slide

19. Getting Started
    1.2 Chrome Dev Tools (chrome://inspect)


    View Slide

20. Getting Started
    1.3 Chrome Dev Tools


    View Slide

21. Getting Started
    2. Add compat library
    dependencies {
    ...
    implementation 'androidx.webkit:webkit:x.y.z'
    ...
    }


    View Slide

22. Getting Started
    3. Configure your WebView
    val webView = findViewById(R.id.webView)
    webView.settings.apply {
    ...
    }


    View Slide

23. Getting Started
    3.1 Basic settings
    // Enable if your content uses JavaScript
    javaScriptEnabled = true
    // For localStorage or sessionStorage
    domStorageEnabled = true
    // Web Database API support (IndexedDB)
    databaseEnabled = true
    // true if the WebView supports the viewport meta tag
    useWideViewPort = true
    // Support zooming
    displayZoomControls = false
    builtInZoomControls = false


    View Slide

24. Getting Started
    3.2 Caching
    // Overrides the way the cache is used
    cacheMode = WebSettings.LOAD_NO_CACHE


    View Slide

25. Getting Started
    3.3 File and content URLs
    // How to support file:/// URLs (Don't!)
    allowFileAccess = false
    allowFileAccessFromFileURLs = false
    allowUniversalAccessFromFileURLs = false
    // Allow access to ContentProvider URLs
    allowContentAccess = false


    View Slide

26. Getting Started
    4.1 Load your remote content3
    val webView = findViewById(R.id.webView)
    val url = "https://api.catz.com/news/content/12345"
    webView.loadUrl(url)
    3 Don't do this - see later slides.


    View Slide

27. Getting Started
    4.2 Load generated content
    val html = """

    Cats!

    Cats are awesome!

    """
    val htmlBytes = html.toByteArray(charset("UTF-8"))
    val encodedHtml = Base64.encodeToString(htmlBytes, Base64.NO_WRAP)
    webView.loadData(encodedHtml, "text/html", "base64")


    View Slide

28. Getting Started
    4.3 Loading local content (the right way!)
    val url = "https://catz.androidplatform.net/index.html"
    val webView = findViewById(R.id.webView)
    webView.loadUrl(url)


    View Slide

29. WebViewClient


    View Slide

30. WebViewClient


    View Slide

31. WebViewClient


    View Slide

32. WebViewClient usage
    — Intercept WebView requests
    — Override network response with custom content
    — Always use WebViewClientCompat!


    View Slide

33. shouldOverrideUrlLoading()
    — Only for GET requests
    — Don't call WebView.loadUrl() or
    WebView.loadData() here
    — Useful for capturing auth tokens


    View Slide

34. Capturing OAuth 2 auth code
    val webView = findViewById(R.id.webView)
    webView.webViewClient = object : WebViewClientCompat() {
    override fun shouldOverrideUrlLoading(view: WebView,
    request: WebResourceRequest):
    Boolean {
    if (request.url.toString().startsWith(REDIRECT_URL)) {
    return handleLoginSuccess(request)
    }
    return false
    }
    }
    val loginUrl = ... // Login URL with redirect URL
    webView.loadUrl(loginUrl)


    View Slide

35. androidplatform.net
    One potential problem of hosting local resources on
    a http(s):// URL is that doing so may conflict with
    a real website...
    The androidplatform.net domain has been specifically
    reserved for this purpose and you are free to use
    it.
    — https://github.com/google/webview-local-server


    View Slide

36. Loading local content safely
    webView.webViewClient = object : WebViewClientCompat() {
    override fun shouldInterceptRequest(view: WebView?,
    request: WebResourceRequest?):
    WebResourceResponse? {
    // Read local content and return a WebResourceResponse
    return createResponse(request)
    }
    }
    webView.loadUrl("https://catz.androidplatform.net/index.html)


    View Slide

37. Loading local content safely
    fun createResponse(request: WebResourceRequest): WebResourceResponse {
    val path = request.url.path
    val file = fileFromUrlPath(path)
    if (!file.exists()) {
    return WebResourceResponse("text/plain", "utf-8",
    404, "Not Found",
    emptyMap(), ByteArrayInputStream(ByteArray(0)))
    }
    val (mimeType, encoding) = mimeTypeAndEncodingForFile(file)
    return WebResourceResponse(mimeType, encoding,
    200, "OK",
    emptyMap(), FileInputStream(file))
    }


    View Slide

38. WebViewServer.kt - http://bit.ly/2xkYMGD
    open class FileRequestHandler(file: File, private val requestPath: String,
    private val mimeType: String, private val encoding: String) : RequestHandler {
    private val bytes = FileInputStream(file).use { it.readBytes() }
    override fun shouldHandleRequest(request: Request): Boolean {
    val uri = Uri.parse(requestPath)
    return uri.path == request.path
    }
    override fun handleRequest(request: Request): Response {
    return Response(200, "OK", emptyMap(), mimeType,
    encoding, ByteArrayInputStream(bytes))
    }
    }


    View Slide

39. Bridging Android and JavaScript


    View Slide

40. Bridging Android and JavaScript (old version)
    class MyJavaScriptInterface(private val handler: Handler) {
    fun onEvent(data: String) {
    val json = JSONObject(data)
    Message.obtain(handler, JS_MSG, json).sendToTarget()
    }
    companion object {
    const val JS_MSG = 10
    }
    }


    View Slide

41. Bridging Android and JavaScript (old version)
    val webView = findViewById(R.id.webView)
    val jsInterface = MyJavaScriptInterface(jsHandler)
    webView.addJavascriptInterface(jsInterface, "android")


    View Slide

42. Bridging Android and JavaScript (old version)
    function emitEventToAndroid(data) {
    if (android && typeof android.onEvent === 'function') {
    android.onEvent(JSON.stringify(data));
    }
    }


    View Slide

43. Bridging Android and JavaScript (old version)
    // JavaScript function we will call from Android
    function performAction(name, age) {
    return `${name} is ${age} years old!`
    }
    val name = Erik
    val age = 42
    webView.evaluateJavascript("performAction($name, $age)") { value ->
    // value will be "Erik is 42 years old!"
    }


    View Slide

44. Bridging Android and JavaScript (old version)
    — Threading
    — Binding native objects
    — Calling function by strings


    View Slide

45. Better solution:
    MessageChannel!


    View Slide

46. Bridging Android and JavaScript (new version)
    // Creates two MessageChannel ports
    val (port1, port2) = WebViewCompat.createWebMessageChannel(webView)
    port1.setWebMessageCallback(object: WebMessagePortCompat.WebMessageCallbackCompat() {
    override fun onMessage(port: WebMessagePortCompat, message: WebMessageCompat?) {
    message?.data?.also{
    val data = JSONObject(it)
    handleWebEvent(data);
    }
    }
    })
    // Send init message to JS side
    val initMsg = WebMessageCompat("""{type: "init"}""", arrayOf(port2))
    WebViewCompat.postWebMessage(webView, initMsg, Uri.parse("*"))


    View Slide

47. Bridging Android and JavaScript (new version)
    let nativePort = null;
    window.addEventListener('message', message => {
    if (e.data) {
    val msg = JSON.parse(e.data);
    if (msg.type === 'init') {
    nativePort = e.ports[0];
    } else {
    onNativeMessage(msg);
    }
    }
    });
    function sendMessageToNative(data) {
    nativePort.postMessage(JSON.stringify(data));
    }


    View Slide

48. Customizing local web
    content


    View Slide

49. ePub standard


    View Slide

50. ePub in 1 slide
    — W3C standards (2.0, 3.x)
    — ZIP file (or directory) structure
    — Self-contained web content
    — Requires custom JS and CSS for rendering


    View Slide

51. ePub structure


    View Slide

52. ePub structure


    View Slide

53. Package document



    The Dark World
    ...


    media-type="application/xhtml+xml"/>
    href="images/cover.png"
    media-type="image/png"/>
    href="css/page.css"
    media-type="text/css"/>
    ...






    ...

    ...



    View Slide

54. ePub scrolling


    View Slide

55. Wrapping web content (HTML)


    View Slide

56. Wrapping web content (HTML)


    ePub Reader











    View Slide

57. Injecting CSS
    fun loadEpub(spineItems) {
    const resourceRoot = document.querySelector('#resourceRoot');
    spineItems.forEach(item => {
    const iframe = document.createElement('iframe');
    iframe.addEventListener('load', () => {
    const cssLink = document.createElement('link');
    cssLink.rel = 'stylesheet';
    cssLink.type = 'text/css';
    cssLink.addEventListener('load', () => {
    console.log('Chapter loaded with custom CSS!');
    });
    cssLink.href = '/chapter.css'
    // Add custom CSS to this chapter
    const head = iframe.contentDocument.querySelector('head')
    head.appendChild(cssLink);
    });
    resourceRoot.appendChild(iframe);
    // Start loading chapter in iframe
    iframe.src = item.href;
    });
    }


    View Slide

58. Injected CSS
    :root {
    column-gap: 20px;
    column-width: 45em;
    column-count: 1;
    column-fill: auto;
    will-change: transform;
    }
    body {
    overflow: hidden !important;
    column-span: none !important;
    box-sizing: border-box !important;
    break-inside: avoid !important;
    }


    View Slide

59. Demo!


    View Slide

60. Dos and Donts
    1. Don't run a local web server for local web
    content
    2. Don't scroll web content from native
    3. Avoid multiple WebViews
    4. Use MessageChannel for bridging
    5. Use WebViewClientCompat for loading local content
    6. WebView is auto-updated with Chrome (except on
    Android 5!)


    View Slide

61. WebView resources
    - Native Bridge Android
    A lightweight and efficient bridge between webview
    and native apps (Android & iOS).
    github.com/nrkno/nativebridge-android
    - WebViewServer.kt
    A customizable "server" for Android WebView:
    http://bit.ly/2xkYMGD
    - WebView Local Server from Google
    A simple implementation for loading local content.


    View Slide

62. Thank you for listening!
    @ErikHellman
    speakerdeck.com/erikhellman/android-and-the-webview


    View Slide
