Building Android Apps with Gradle

See some of the features of the Android plugin for Gradle in action.

Transcript

1. Building Android Apps
   with Gradle


   View Slide

2. Gradle
   • Build automation tool, builds upon Maven and
   Ant
   • Uses build.gradle files for configuration
   !
   PROTIP
   • Use the gradle wrapper
   http://www.gradle.org/


   View Slide

3. Gradle android plugin
   Build with `./gradlew clean assemble`
   !
   Android Tasks
   • assemble
   • clean
   • connectedCheck
   • deviceCheck
   • check
   • build
   !
   ./gradlew tasks --all
   http://tools.android.com/
   tech-docs/new-build-system/
   user-guide


   View Slide

4. Basic App Structure
   Project
   ├── app
   │ ├── build.gradle
   │ ├── keystore
   │ ├── libs
   │ │ └── *.jar
   │ └── src
   └── build.gradle


   View Slide

5. Top level build file
   Project
   ├── app
   │ ├── build.gradle
   │ ├── keystore
   │ ├── libs
   │ │ └── *.jar
   │ └── src
   └── build.gradle
   Add configuration
   options common to all
   sub-projects/modules.
   !
   task wrapper(type: Wrapper) {
   gradleVersion = '1.8'
   }


   View Slide

6. Module build file
   Main application build
   file. It would contain
   information such as
   dependencies, plugins,
   etc.
   With the Android plugin,
   you can define
   additional properties for
   your application, such
   as package name,
   version code, etc.
   Project
   ├── app
   │ ├── build.gradle
   │ ├── keystore
   │ ├── libs
   │ │ └── *.jar
   │ └── src
   └── build.gradle


   View Slide

7. Sample build.gradle for
   an Android app
   https://github.com/f2prateek/android-device-frame-
   generator/blob/master/app/build.gradle


   View Slide

8. Basic App Structure
   My build.gradle is
   configured to pick up all jars
   in this folder. Use this for
   dependencies not available
   via published repositories.
   !
   compile fileTree(dir: 'libs', include: '*.jar')
   .
   ├── app
   │ ├── build.gradle
   │ ├── keystore
   │ ├── libs
   │ │ └── *.jar
   │ └── src
   └── build.gradle


   View Slide

9. Sources
   Project
   ├── app
   │ ├── build.gradle
   │ ├── keystore
   │ ├── libs
   │ │ └── *.jar
   │ └── src
   └── build.gradle


   View Slide

10. Sources
    │ └── src
    │ ├── debug
    │ │ └── AndroidManifest.xml
    │ ├── instrumentTest
    │ │ ├── AndroidManifest.xml
    │ │ └── java
    │ ├── main
    │ │ ├── AndroidManifest.xml
    │ │ ├── java
    │ │ └── res
    │ └── release
    │ ├── AndroidManifest.xml
    │ └── res
    │ └── values
    │ └── analytics.xml


    View Slide

11. Main Source Set
    │ └── src
    │ ├── debug
    │ │ └── AndroidManifest.xml
    │ ├── instrumentTest
    │ │ ├── AndroidManifest.xml
    │ │ └── java
    │ ├── main
    │ │ ├── AndroidManifest.xml
    │ │ ├── java
    │ │ └── res
    │ └── release
    │ ├── AndroidManifest.xml
    │ └── res
    │ └── values
    │ └── analytics.xml
    The default source set.
    Stick to this if you want
    no build customization.


    View Slide

12. Instrument Tests Source Sets
    │ └── src
    │ ├── debug
    │ │ └── AndroidManifest.xml
    │ ├── instrumentTest
    │ │ ├── AndroidManifest.xml
    │ │ └── java
    │ ├── main
    │ │ ├── AndroidManifest.xml
    │ │ ├── java
    │ │ └── res
    │ └── release
    │ ├── AndroidManifest.xml
    │ └── res
    │ └── values
    │ └── analytics.xml


    View Slide

13. Build Types
    │ └── src
    │ ├── debug
    │ │ └── AndroidManifest.xml
    │ ├── instrumentTest
    │ │ ├── AndroidManifest.xml
    │ │ └── java
    │ ├── main
    │ │ ├── AndroidManifest.xml
    │ │ ├── java
    │ │ └── res
    │ └── release
    │ ├── AndroidManifest.xml
    │ └── res
    │ └── values
    │ └── analytics.xml
    The Android plugin
    gives you release and
    debug configurations
    for free. Simply create
    a source folder for
    each configuration
    and get started with
    basic build
    customization.


    View Slide

14. Build Types
    Some added tasks:
    • assembleDebug
    • assembleRelease
    !
    ./gradlew assembleRelease
    OR
    ./gradlew aR
    Each configuration
    creates some
    appropriate
    corresponding tasks.


    View Slide

15. Android Configuration
    defaultConfig {

    minSdkVersion 14

    targetSdkVersion 19

    packageName "com.f2prateek.dfg"

    versionCode versionMajor * 10000 + versionMinor * 1000 + versionPatch * 100 + versionBuild

    versionName "${versionMajor}.${versionMinor}.${versionPatch}"

    buildConfig """\

    public static final int VERSION_MAJOR = ${versionMajor}.;

    """

    }
    def versionMajor = 2

    def versionMinor = 0

    def versionPatch = 0

    def versionBuild = 1


    View Slide

16. Android Configuration
    This sample :
    • Defines minSdkVersion and maxSdkVersion
    • Defines package name
    • Defines version code and version name
    • Adds version name to BuildConfig (access it with
    BuildConfig.VERSION_MAJOR, no need for a
    Context!). Next version of the build tools will have
    more information out of the box, such as package
    name, version name, version code, etc.


    View Slide

17. Customizing Builds

    debug {

    packageNameSuffix ".debug"

    versionNameSuffix "-debug"

    }

    release {

    signingConfig signingConfigs.release

    }


    View Slide

18. Customizing Builds
    This sample :
    • Adds a suffix to the package name for debug
    build types
    • Adds a suffix to the version name for debug
    build types
    • Configures release build types to use a
    signing configuration that is shown in the next
    slide


    View Slide

19. Customizing Builds : Merging
    • All build types share code from the main
    source set
    • The manifest is merged into the app manifest
    • The code acts as just another source folder
    • The resources are overlayed over the main
    resources, replacing existing values


    View Slide

20. Customizing Builds : Uses
    • Permissions in debug mode only, but not in
    release mode
    • Custom implementation for debugging
    • Different resources for debug mode (for
    instance when a resource value is tied to the
    signing certificate)


    View Slide

21. Custom Build Types
    beta.initWith(buildTypes.release)

    beta {

    versionNameSuffix "-beta"

    }

    sourceSets.beta.setRoot('src/release')
    This creates a custom build
    type named ‘beta’, initializing
    it from the properties of the
    release build type.
    By default, it would have it’s
    source set under ‘src/beta’.
    Here I manually set the
    source set to be under ‘src/
    release’. The only difference
    between the two versions in
    my case is that beta has a
    suffix in it’s version name.


    View Slide

22. Signing packages
    signingConfigs {

    release {

    storeFile file("keystore")

    storePassword "notYourRealPassword"

    keyAlias "keystore"

    keyPassword "notYourRealPassword"

    }

    }
    task askForPasswords << {

    def storePassword = new String(System.console().readLine("\n\$ Enter keystore password: "))

    def keyPassword = new String(System.console().readLine("\n\$ Enter key alias password: "))

    android.signingConfigs.release.storePassword = storePassword

    android.signingConfigs.release.keyPassword = keyPassword

    }

    !
    tasks.whenTaskAdded { theTask ->

    if (theTask.name.equals("validateReleaseSigning")) {

    theTask.dependsOn "askForPasswords"

    }

    }


    View Slide

23. Signing packages
    This uses a file ‘keystore’ with an
    alias ‘keystore’. It asks for a
    password for both via the
    command line. Alternatively, you
    can make it pick up system
    properties, or pick them up in a
    file like signing.properties


    View Slide

24. Renaming the .apk file
    applicationVariants.all { variant ->

    apk = variant.packageApplication.outputFile;

    newName = apk.name.replace(".apk", "-v${defaultConfig.versionName}-${versionBuild}.apk");

    newName = newName.replace("app", "${defaultConfig.packageName}");

    variant.packageApplication.outputFile = new File(apk.parentFile, newName);

    if (variant.zipAlign) {

    variant.zipAlign.outputFile = new File(apk.parentFile, newName.replace("-unaligned", ""));

    }

    }


    View Slide

25. Renaming the .apk file
    Produces the following apk’s
    • com.f2prateek.dfg-beta-unaligned-v2.0.0-1.apk

    • com.f2prateek.dfg-beta-v2.0.0-1.apk

    • com.f2prateek.dfg-debug-unaligned-v2.0.0-1.apk

    • com.f2prateek.dfg-release-unaligned-v2.0.0-1.apk

    • com.f2prateek.dfg-release-v2.0.0-1.apk


    View Slide

26. Checkstyle (thank Jake Wharton!)
    apply plugin: 'checkstyle'

    !
    checkstyle {

    configFile project.file('../checkstyle.xml')

    showViolations true

    }

    !
    android.applicationVariants.all { variant ->

    def name = variant.buildType.name

    def checkstyle = project.tasks.create "checkstyle${name.capitalize()}", Checkstyle

    checkstyle.dependsOn variant.javaCompile

    checkstyle.source variant.javaCompile.source

    checkstyle.classpath = project.fileTree(variant.javaCompile.destinationDir)

    checkstyle.exclude('**/BuildConfig.java')

    checkstyle.exclude('**/R.java')

    project.tasks.getByName("check").dependsOn checkstyle

    }


    View Slide

27. Checkstyle for library projects
    apply plugin: 'checkstyle'

    !
    checkstyle {

    configFile project.file('../checkstyle.xml')

    showViolations true

    }

    !
    android.libraryVariants.all { variant ->

    def name = variant.buildType.name

    def checkstyle = project.tasks.create "checkstyle${name.capitalize()}", Checkstyle

    checkstyle.dependsOn variant.javaCompile

    checkstyle.source variant.javaCompile.source

    checkstyle.classpath = project.fileTree(variant.javaCompile.destinationDir)

    checkstyle.exclude('**/BuildConfig.java')

    checkstyle.exclude('**/R.java')

    project.tasks.getByName("check").dependsOn checkstyle

    }


    View Slide

28. Sample of Manifest in
    release, debug and
    main
    https://github.com/f2prateek/
    android-device-frame-generator


    View Slide
