Integrating Kotlin/JS in a KMP library

Presented at Droidcon NYC, 2022

https://nyc.droidcon.com/jigar-brahmbhatt/

Javascript is one of the supported targets for a Kotlin Multiplatform project. One can add Kotlin/JS target to an existing Kotlin Multiplatform Mobile library to output a JS library code.

There are various aspects to consider for the Kotlin/JS integration,
• Supporting JavaScript or Typescript
• Gradle configuration
• Exposing Kotlin code to JavaScript and writing JS-specific code
• JS Library size and impact of third-party libraries
• Architectural decisions around shared code across platforms, networking, storage, serialization, etc.

This talk discusses how to deal with the issues mentioned above and more.

Transcript

1. Integrating Kotlin/JS


   in a Kotlin Multiplatform library
   Jig
   a
   r Br
   a
   hmbh
   a
   tt (@sh
   a
   ktim
   a
   n_droid) | Droidcon NY 2022


   View Slide

2. View Slide

3. A bit of history
   • Started integrating Kotlin/JS in production in late 2021
   • Started bumpy Kotlin/JS ride with Kotlin 1.5.32
   • Not many online resources to refer
   • Kotlin docs & Kotlin Slack #Javascript channel ❤
   • Kotlin 1.6.20 & 1.7.10 made things easier
   • Still long way to go!


   View Slide

4. What is Kotlin/JS


   View Slide

5. Kotlin/JS => Kotlin for JavaScript
   • JavaScript - One of the supported platforms in Kotlin ecosystem


   • Kotlin code transpiles into JS (Write in Kotlin = Output in JS)
   • Supports
   • Does lot of heavy lifting behind the scene (npm, yarn, webpack etc.)
   • Newbie approved 👍
   • Solid gradle plugin


   View Slide

6. Set up Kotlin/JS


   View Slide

7. Set up Kotlin/JS
   sh
   a
   red/build.gr
   a
   dle.kts
   🤔


   View Slide

8. Set up Kotlin/JS
   Most likely next error!


   View Slide

9. Set up Kotlin/JS
   Most likely next error!
   //
   root
   - >
   build.gradle.kts


   tasks.register("clean", Delete
   ::
   class) {


   delete(rootProject.buildDir)


   }
   Remove this!


   View Slide

10. Set up Kotlin/JS
    sh
    a
    red/build.gr
    a
    dle.kts
    (Option
    a
    l Step if hier
    a
    rchic
    a
    l project structure support en
    a
    bled)


    View Slide

11. Set up Kotlin/JS
    sh
    a
    red/src


    View Slide

12. Set up Kotlin/JS
    sh
    a
    red/src


    View Slide

13. Set up Kotlin/JS
    Existing Kotlin Multiplatform Mobile Project?
    Build would likely fail!


    View Slide

14. One more step - Two options!
    Set up Kotlin/JS


    View Slide

15. Set up Kotlin/JS
    Option 1:


    • Refactor code in commonMain so that it’s compatible with JS


    • What if a some code or library doesn’t support JS target?


    View Slide

16. Set up Kotlin/JS
    It can be overwhelming with a lot of upfront work!”
    Option 1:


    • Refactor code in commonMain so that it’s compatible with JS


    • What if a some code or library doesn’t support JS target?


    View Slide

17. Set up Kotlin/JS
    Option 2:


    • Introduce a common sourceSet for mobile platforms
    • JS/web on the other hand can be somewhat di
    ff
    erent
    • mobileMain allows separation of features & dependencies
    • Native mobile platforms has similar needs and capabilities
    mobileMain
    iosMain
    androidMain


    View Slide

18. Set up Kotlin/JS
    Option-2 steps:


    • Add mobileMain sourceSet
    • Move entire commonMain to mobileMain
    • Now slowly add JS support for existing features 👶🪜


    View Slide

19. sourceSets {


    val commonMain by …


    val commonTest by …


    val androidMain by …


    val androidTest by …


    val iosMain by …


    val iosTest by …


    + val mobileMain by creating {


    dependsOn(commonMain)


    + androidMain.dependsOn(this)


    + iosMain.dependsOn(this)


    }


    + val mobileTest by creating {


    dependsOn(commonTest)


    + androidTest.dependsOn(this)


    + iosTest.dependsOn(this)


    }


    val jsMain by getting


    val jsTest by getting


    }


    Set up Kotlin/JS
    sh
    a
    red/build.gr
    a
    dle.kts


    View Slide

20. Set up Kotlin/JS
    sh
    a
    red/src


    View Slide

21. JS build output


    View Slide

22. JS build output


    View Slide

23. compiler
    LEGACY - not recommended
    JS build output


    View Slide

24. # Browser as JS Target
    # Likely usage: Web App/Module
    # kotlin-stdlib-js
    JS build output


    View Slide

25. # Node.js as JS Target
    # Likely usage: Node Application/Module
    # kotlinx-nodejs:0.0.7 (experimental)
    JS build output


    View Slide

26. # Outputs JS as an executable
    # Dead code elimination (DCE)
    JS build output
    # bundle
    fi
    le


    View Slide

27. # Outputs JS as a library module
    # Experimental Typescript support (.d.ts)
    # https://github.com/mpetuska/npm-publish
    JS build output


    View Slide

28. JS build output
    bin
    a
    ries.execut
    a
    ble()
    ./gradlew jsBrowserDistribution (production)
    ./gradlew jsBrowserDevelopmentWebpack (faster, no dce)


    View Slide

29. JS build output
    bin
    a
    ries.libr
    a
    ry()
    ./gradlew jsBrowserProductionLibraryDistribution (production)


    View Slide

30. How to expose Kotlin to JS?


    View Slide

31. //
    commonMain


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().name}!"


    }


    }
    //
    jsMain


    actual class Platform actual constructor() {


    actual val name: String


    get() = "JS"


    }


    How to expose Kotlin to JS?


    View Slide

32. //
    commonMain


    @JsExport


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().name}!"


    }


    }
    How to expose Kotlin to JS?


    View Slide

33. / /
    commonMain


    @JsExport


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().name}!"


    }


    }
    export namespace shaktiman.droid.nydroidcon22 {


    class Greeting {


    constructor();


    greeting(): string;


    }


    }


    export as namespace kmp_js_lib;


    .d.ts
    fi
    le
    function Greeting() {


    }


    Greeting.prototype.greeting = function () {


    return 'Hello, ' + (new Platform()).a() + '!';


    };


    Greeting.$metadata$ = classMeta('Greeting');


    function Platform() {


    }


    Platform.prototype.a = function () {


    return 'JS';


    };


    Platform.$metadata$ = classMeta('Platform');


    .js
    fi
    le
    How to expose Kotlin to JS?


    View Slide

34. Us
    a
    ge
    //
    JavaScript usage


    import sdk from 'kmp-lib';


    const greeting = new sdk.shaktiman.droid.nydroidcon22.Greeting()


    console.log(greeting.greeting())
    //
    TypeScript usage


    import * as sdk from 'kmp-lib';


    let greeting = new sdk.shaktiman.droid.nydroidcon22.Greeting()


    console.log(greeting.greeting())


    How to expose Kotlin to JS?


    View Slide

35. @JsExport
    data class Address(val address1: String, val city: String)
    How to expose Kotlin to JS?
    All references needs to be export
    a
    ble


    View Slide

36. @JsExport
    Challenges:


    • Not everything is JsExportable yet, or still buggy!
    How to expose Kotlin to JS?
    • No support for exporting collections API (Map/List)


    • In common code, you would have to use Array In public API
    • Suspended functions cannot be exported (use Promise)


    View Slide

37. @JsExport
    Challenges:


    • Not everything is JsExportable yet, or still buggy!


    • No support for collections API (Map/List)


    • In common code, you would have to use Array In public API


    • Suspended functions cannot be exported (use Promise)
    How to expose Kotlin to JS?


    View Slide

38. How to expose Kotlin to JS?
    @JsExport
    Positives:


    • Kotlin 1.6.20 - Enum and interfaces got 100% supported
    • Experimental Typescript support has improved over last two releases
    • Kotlin wrappers lib is great for providing wrappers around JS objects


    (https://github.com/JetBrains/kotlin-wrappers/tree/master/kotlin-js)
    • KustomExport library uses KSP to provide missing functionality


    (https://github.com/deezer/KustomExport)


    View Slide

39. How to expose Kotlin to JS?
    @JsN
    a
    me
    @JsExport


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().platform}!"


    }


    fun greeting(version: String): String {


    return "${greeting()} Version 1.7.10"


    }


    }




    View Slide

40. How to expose Kotlin to JS?
    @JsN
    a
    me
    @JsExport


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().platform}!"


    }


    fun greeting(version: String): String {


    return "${greeting()} Version 1.7.10"


    }


    }




    View Slide

41. How to expose Kotlin to JS?
    @JsN
    a
    me
    @JsExport


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().platform}!"


    }


    @JsName("greetingWithVersion")


    fun greeting(version: String): String {


    return "${greeting()} Version 1.7.10"


    }


    }


    View Slide

42. How to expose Kotlin to JS?
    @JsN
    a
    me
    @JsExport


    class Greeting {


    fun greeting(): String {


    return "Hello, ${Platform().platform}!"


    }


    @JsName("greetingWithVersion")


    fun greeting(version: String): String {


    return "${greeting()} Version 1.7.10"


    }


    }
    //
    Generated Typescript definition


    export namespace shaktiman.droid.kmptrial2 {


    class Greeting {


    constructor();


    greeting(): string;


    greetingWithVersion(version: string): string;


    }


    }


    View Slide

43. How to expose Kotlin to JS?


    View Slide

44. What about third party
    dependencies?


    View Slide

45. If a library is already Multiplatform with JS support
    val commonMain by getting {


    dependencies {


    implementation(“org.jetbrains.kotlinx:kotlinx-coroutines-core:x.x.x")


    }


    }


    If you want to use a JS speci
    fi
    c library
    val jsMain by getting {


    dependencies {


    implementation(npm("launchdarkly-js-client-sdk", “x.x.x"))


    }


    }


    third p
    a
    rty dependencies


    View Slide

46. You’d need to write external declarations to use an NPM module in Kotlin
    @JsModule("launchdarkly-js-client-sdk")


    external fun initialize(envKey: String, user: LDUser, options: LDOptions): LDClient


    Need help with generating external declarations?
    third p
    a
    rty dependencies


    View Slide

47. implementation(npm(“", “x.x.x”, generateExternals = true))
    third p
    a
    rty dependencies
    Looks for Typescript de
    fi
    nitions
    fi
    le
    Copy what you need → Paste in your module → Fix if required → Remove “generateExternal = true”


    View Slide

48. third p
    a
    rty dependencies


    View Slide

49. third p
    a
    rty dependencies


    View Slide

50. third p
    a
    rty dependencies


    View Slide

51. third p
    a
    rty dependencies


    View Slide

52. third p
    a
    rty dependencies


    View Slide

53. So far
    •Setting up Kotlin/JS ✅
    •JS output as an executable vs a library ✅
    •@JSExport and external declarations ✅


    View Slide

54. How to go about
    Multiplatform?


    View Slide

55. How to go about Multiplatform?
    • Coroutines | Serialization | Datetime (@Kotlinx)


    • Ktor (@ktorio)


    • SQLDelight (@cashapp)


    • Apollo Kotlin (@apollographql)


    • Multiplatform Settings (@russhwolf)


    • Kermit (@touchlab)


    • UUID (@benasher44)
    A lot of popul
    a
    r Multipl
    a
    tform libr
    a
    ries h
    a
    ve JS suport


    View Slide

56. But for JS, bundle size matters!


    View Slide

57. Size imp
    a
    ct comp
    a
    rison
    Without any libs


    (Just one method in commonMain)
    Kotlin 1.6.10
    780 bytes
    With Kotlinx.datetime


    (Adds Joda-Time)
    202 KB


    Version 0.3.2
    With Kotlinx.serialization


    (With one serializable class)
    With Kotlinx.serialization


    (With two serializable classes)
    With Kotlinx.coroutines
    With Kotlinx.Ktor


    (Includes coroutine-core)
    All combined


    (~ 50 lines of code)
    1.3 MB
    300 KB


    Version 1.3.2
    303 KB
    122 KB


    Version 1.6.1
    862 KB


    Version 2.00-beta-1
    - Ran ./gradlew jsBrowserDistribution (So after DCE sizes)


    - Code available at https://github.com/touchlab-lab/kotlin-js-droidcon-22
    Kotlin 1.6.20
    796 bytes
    204 KB


    Version 0.3.2
    1.1 MB
    332 KB


    Version 1.3.2
    336 KB
    127 KB


    Version 1.6.4
    683 KB


    Version 2.0.3
    Kotlin 1.7.10
    1277 bytes
    202 KB


    Version 0.4.0
    803 KB
    238 KB


    Version 1.4.0
    303 KB
    92 KB


    Version 1.6.4
    465 KB


    Version 2.1.0
    (~40% reducation 😍)


    View Slide

58. Size Issue - Work
    a
    round - D
    a
    tetime
    //
    commonMain


    expect class Instant : Comparable {


    val epochSeconds: Long


    val nanosecondsOfSecond: Int


    override operator fun compareTo(other: Instant): Int


    override fun toString(): String


    fun toEpochMilliseconds(): Long


    companion object {


    fun parse(isoString: String): Instant


    fun fromEpochMilliseconds(epochMilliseconds: Long): Instant


    }


    }


    //
    mobileMain


    actual typealias Instant = kotlinx.datetime.Instant


    //
    jsMain


    import kotlin.js.Date


    actual class Instant(


    actual val epochSeconds: Long,


    actual val nanosecondsOfSecond: Int


    ) : Comparable {


    //
    Implementation


    }




    View Slide

59. Size Issue - Work
    a
    round - Seri
    a
    liz
    a
    tion
    //
    commonMain - Serializable.kt


    @OptIn(ExperimentalMultiplatform
    ::
    class)


    @OptionalExpectation


    @Target(AnnotationTarget.PROPERTY, AnnotationTarget.CLASS, AnnotationTarget.TYPE)


    @Retention(AnnotationRetention.RUNTIME)


    expect annotation class Serializable()


    //
    mobileMain - Serializable.kt


    actual typealias Serializable = kotlinx.serialization.Serializable
    //
    commonMain


    @Serializable


    data class Person(val id: String, val address: Address)


    //
    commonMain


    expect inline fun encodeThisToString(value: T): String


    expect inline fun decodeThisFromString(value: String): T


    View Slide

60. Size Issue - Work
    a
    round - HttpClient
    //
    commonMain


    internal interface KmpHttpClient {


    suspend fun request(url: String, block: suspend KmpRequestBuilder.()
    - >
    Unit): KmpHttpResponse


    }


    internal data class KmpHttpResponse(val body: String?)


    internal interface KmpRequestBuilder {


    var method: String


    val headersBuilder: Map


    var body: Any


    }


    //
    jsMain - Using window.fetch API


    internal class JsHttpClient : IdentityHttpClient {


    //
    Implementation


    }
    //
    mobileMain - Using ktor API


    internal class KtorHttpClient(engine: HttpClientEngine) : IdentityHttpClient {


    //
    Implementation


    }




    View Slide

61. Size Issue - Work
    a
    round - Api Impl
    //
    commonMain - AstrosApi.kt


    @Serializable


    @JsExport


    data class AstrosApiResponse(val number: Int, val people: Array, val message: String)


    @Serializable


    @JsExport


    data class People(val name: String, val craft: String)


    internal class AstrosApi(private val httpClient: KmpHttpClient) {


    suspend fun getAstros(): AstrosApiResponse? {


    val response = httpClient.request(BASE_URL) {


    method = "GET"


    }.body


    return response
    ?
    .
    let {decodeThisFromString(it) }


    }


    }




    View Slide

62. Size Issue - Work
    a
    round - Api Impl
    //
    jsMain


    @JsExport


    object AstrosApiWrapper {


    private val astrosApi = AstrosApi(JsHttpClient())


    fun getAstros(): Promise = GlobalScope.promise {


    astrosApi.getAstros()


    }


    }


    View Slide

63. How to go about Multiplatform?
    • Re-think about architecture with JS in mind
    Things to keep in mind
    • Keep checking on JS library size
    • Write JS only facade layer
    • Be prepared for surprises and disappointment


    View Slide

64. Buzz
    (Kotlin Slack)


    View Slide

65. View Slide

66. Thank you


    Droidcon NYC
    Jig
    a
    r Br
    a
    hmbh
    a
    tt


    @sh
    a
    ktim
    a
    n_droid (Kotlin Sl
    a
    ck & Twitter)


    View Slide
