Reactive Programming on Android with RxJava

An introduction to Reactive Programming on Android using RxJava and RxAndroid

Transcript

1. Reactive Programming on Android with RxJava Faiçal Tchirou andela-ftchirou ftchirou
2. Why Reactive Programming?
3. Why Reactive Programming? Traditional programming paradigms are showing their limits when it comes to building modern web and mobile apps.
4. Sample app: Github Search
5. Sample app: Github Search
6. Sample app: Github Search
7. Sample app: Github Search
8. Sample app: Github Search
9. Without Reactive Programming
10. Without Reactive Programming Github API 1 public interface GithubAPI { 2 3 void search(String query, Callback callback); 4 5 void loadNextPage(Callback callback); 6 7 void cancel(); 8 9 interface Callback { 10 11 void onSuccess(List<GithubRepository> repositories); 12 13 void onError(GithubError error); 14 15 void onLimitExceeded(); 16 17 void onCancelled(); 18 19 void onFailure(Throwable t); 20 } 21 }
11. Without Reactive Programming Listening to text changes on the search edit text 1 searchEditText.addTextChangedListener(new TextWatcher() { 2 @Override 3 public void afterTextChanged(final Editable s) { 4 if (query == null || query.trim().isEmpty()) { 5 header.setText(R.string.no_repository_found); 6 adapter.setRepositories(new ArrayList<GithubRepository>()); 7 return; 8 } 9 10 header.setText(R.string.searching); 11 searchProgressBar.setVisibility(View.VISIBLE); 12 recyclerView.setVisibility(View.INVISIBLE); 13 14 throttleSearchRequest(s.toString()); 15 } 16 });
12. Without Reactive Programming Throttling and sending the search request 1 private void throttleSearchRequest(String query) { 2 this.searchQuery = query; 3 4 cancelThrottledSearchRequests(); 5 6 throttler.schedule(new TimerTask() { 7 @Override 8 public void run() { 9 if (searchQuery.trim().isEmpty()) { 10 return; 11 } 12 13 callback.isSearching = true; 14 callback.isLoadingNextPage = false; 15 16 githubAPI.search(searchQuery, callback); 17 } 18 }, 300); 19 }
13. Without Reactive Programming Github API Callback 1 class GithubSearchServiceCallback implements GithubSearchService.Callback { 2 3 private boolean isSearching; 4 private boolean isLoadingNextPage; 5 6 @Override 7 public void onSuccess(List<GithubRepository> repositories) { 8 if (isSearching) { 9 adapter.setRepositories(repositories); 10 } else if (isLoadingNextPage) { 11 adapter.addRepositories(repositories); 12 } 13 14 updateUI(); 15 } 16 17 // ...
14. Without Reactive Programming Github API Callback 1 private void updateUI() { 2 if (isSearching) { 3 searchProgressBar.setVisibility(View.INVISIBLE); 4 } else if (isLoadingNextPage) { 5 loadNextPageProgressBar.setVisibility(View.GONE); 6 } 7 8 int count = adapter.getItemCount(); 9 10 header.setText(count == 0 11 ? getResources().getString(R.string.no_repository_found) 12 : getResources().getString(R.string.repositories_found, count)); 13 14 recyclerView.setVisibility(View.VISIBLE); 15 }
15. Without Reactive Programming Github API Callback 17 // ... 18 19 @Override 20 public void onError(GithubError error) { 21 // ... 22 } 23 24 @Override 25 public void onLimitExceeded() { 26 // ... 27 displayRateLimitMessageAndWaitForDelay(); 28 } 29 21 // ...
16. Without Reactive Programming Handling the rate limit 1 private void displayRateLimitMessageAndWaitForDelay() { 2 searchEditText.setEnabled(false); 3 recyclerView.setLayoutFrozen(true); 4 5 final Snackbar snackbar = Snackbar.make(root, 6 getResources().getString(R.string.rate_limit_exceeded, 60), 7 Snackbar.LENGTH_INDEFINITE); 8 9 snackbar.show(); 10 11 // ...
17. Without Reactive Programming Rate Limit Countdown 11 // ... 12 13 final Timer timer = new Timer(); 14 int seconds = 60; 15 16 timer.scheduleAtFixedRate(() -> { 17 seconds--; 18 runOnUiThread(() -> { 19 if (seconds <= 0) { 20 snackbar.dismiss(); 21 timer.cancel(); 22 23 searchEditText.setEnabled(true); 24 recyclerView.setLayoutFrozen(false); 25 return; 26 } 27 snackbar.setText(…getString(R.string.rate_limit_exceeded, seconds); 28 }); 29 }, 1000, 1000); 30 }
18. Without Reactive Programming Pagination 1 repositoriesView.addOnScrollListener(new RecyclerView.OnScrollListener() { 2 @Override 3 public void onScrolled(RecyclerView recyclerView, int dx, int dy) { 4 super.onScrolled(recyclerView, dx, dy); 5 6 int lastItemPosition = layoutManager.findLastCompletelyVisibleItemPosition(); 7 8 if (isLastVisibileRepository(lastItemPosition)) { 9 loadNextPageProgressBar.setVisibility(View.VISIBLE); 10 11 callback.isLoadingNextPage = true; 12 callback.isSearching = false; 13 14 githubAPI.loadNextPage(callback); 15 } 16 } 17 });
19. Without Reactive Programming Issues
20. What is Reactive Programming?
21. What is Reactive Programming? Reactive Programming is programming with asynchronous sequences of data.
22. Principles of Reactive Programming
23. Principles of Reactive Programming 1. Everything is a sequence*
24. Principles of Reactive Programming 1. Everything is a sequence* 2. A sequence can be transformed into or combined with another sequence using reactive operators.
25. Principles of Reactive Programming 1. Everything is a sequence* 2. A sequence can be transformed into or be combined with another sequence using reactive operators. 3. A sequence can be observed or subscribed to and the observers can run some action when the sequence is updated.
26. What is RxJava?
27. What is RxJava? Reactive Programming is a programming pattern. RxJava is the implementation in Java of that pattern.
28. What is RxJava? RxJava is a Java library that • Provides an abstraction of the concept of sequence named Observable.
29. What is RxJava? RxJava is a Java library that • Provides an abstraction of the concept of sequence named Observable. • Provides an implementation of reactive operators used to transform and combine Observables.
30. What is RxJava? RxJava is a Java library that • Provides an abstraction of the concept of sequence named Observable. • Provides an implementation of reactive operators used to transform and combine Observables. • Provides an abstraction for objects which can subscribe to Observables named Observer.
31. Observable Marble Diagram
32. RxJava Operators • Creating observables • Transforming observables • Filtering observables • Combining observables
33. Creating Observables
34. Creating Observables 1 Observable.create((subscriber) -> { 2 if (!subscriber.isUnsubscribed()) { 3 for (int i = 1; i <= 10; ++i) { 4 subscriber.onNext(i); 5 } 6 7 subscriber.onCompleted(); 8 } 9 }); 10 11 // => { 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 } create
35. Creating Observables 1 Integer[] items = new Integer[] { 1, 2, 3, 4, 5 }; 2 Observable observable = Observable.from(items); 3 4 // => { 1, 2, 3, 4, 5 } from
36. Creating Observables 1 Observable observable = Observable.just(42); 2 // { 42 } just
37. Transforming Observables
38. Transforming Observables 1 Observable 2 .from(new Integer[] { 1, 2, 3, 4, 5 }) 3 .map((integer) -> return integer * integer); 4 5 // => { 1, 4, 9, 16, 25 } map
39. Transforming Observables 1 Observable 2 .from(new Integer[] { 1, 2, 3, 4, 5 }) 3 .flatMap(integer -> return Observable.just(integer).repeat(integer)); 4 5 // => { 1, 2, 2, 3, 3, 3, 4, 4, 4, 4, 5, 5, 5, 5, 5 } flatMap
40. Filtering Observables
41. Filtering Observables 1 Observable 2 .from(new Integer[] { 1, 2, 3, 4, 5 }) 3 .filter(integer -> return integer % 2 == 0) 4 5 // => { 2, 4 } filter
42. Filtering Observables 1 Observable 2 .from(new Integer[] { 1, 2, 3, 2, 1, 3, 4, 5 }) 3 .distinct() 4 5 // => { 1, 2, 3, 4, 5 } distinct
43. Filtering Observables debounce
44. Combining Observables
45. Combining Observables 1 Observable odds = Observable.from(new Integer[] { 1, 3 }; 2 Observable evens = Observable.from(new Integer[] { 2, 4 }; 3 Observable.merge(odds, evens); 4 5 // => { 1, 2, 3, 4 } merge
46. Combining Observables 1 Observable strings = Observable.from(new String[] { “a”, “b” }; 2 Observable integers = Observable.from(new Integer[] { 1, 2, 3 }; 3 Observable.combineLatest(strings, integers, 4 (string, integer) -> return new Pair(string, integer)); 5 6 // => { (“a”, 1), (“b”, 2), (“b”, 3) } combineLatest
47. Combining Observables 1 Observable strings = Observable.from(new String[] { “a”, “b” }; 2 Observable integers = Observable.from(new Integer[] { 1, 2, 3 }; 3 Observable.zip(strings, integers, 4 (string, integer) -> return new Pair(string, integer)); 5 6 // => { (“a”, 1), (“b”, 2) } zip
48. Subscribing to an Observable
49. Subscribing to an Observable 1 Observable.from(new Integer[] { 1, 2, 3, 4, 5 }) 2 .subscribe(new Observer<Integer> { 3 @Override 4 public void onNext(Integer integer) { 5 System.out.println("Emitted " + integer); 6 } 7 8 @Override 9 public void onError(Throwable t) { 10 System.out.println(t); 11 } 12 13 @Override 14 public void onCompleted() { 15 System.out.println("Completed!"); 16 } 17 }); Emitted 1 Emitted 2 Emitted 3 Emitted 4 Emitted 5 Completed!
50. Subscribing to an Observable 1 Observable.from(new Integer[] { 1, 2, 3, 4, 5 }) 2 .subscribe( 3 (integer) -> { 5 System.out.println("Emitted " + integer); 6 }, 7 (error) -> { 8 System.out.println(error); 9 }, 10 () -> { 11 System.out.println(“Completed!”); 12 } 13 ); Emitted 1 Emitted 2 Emitted 3 Emitted 4 Emitted 5 Completed!
51. Rx-ifying Github Search
52. Rx-ifying Github Search Github API 1 import rx.Observable; 2 3 public interface GithubAPI { 4 5 Observable<List<GithubRepository>> search(String query); 6 7 Observable<List<GithubRepository>> loadNextPage(); 8 9 Observable<Boolean> cancel(); 10 }
53. Rx-ifying Github Search UI
54. Rx-ifying Github Search ViewModel The ViewModel holds properties representing the state of the Activity at any point in time.
55. Rx-ifying Github Search ViewModel 1 public class ViewModel { 2 3 private GithubAPI githubAPI; 4 5 Subject<String> searchQuery; 6 7 Subject<Boolean> searchRequested; 8 9 Subject<Boolean> nextPageRequested; 10 11 Subject<List<GithubRepository>> repositories; 12 13 Subject<Boolean> repositoriesFetched; 14 15 Subject<Boolean> rateLimitExceeded; 16 17 // ... 18 }
56. Rx-ifying Github Search Searching 1 public class ViewModel { 2 3 // ... 4 5 private void search(String query) { 6 githubAPI 7 .search(query) 8 .subscribe( 9 (repos) -> { 10 repositories.onNext(repos); 11 }, 12 (error) -> { 13 if (error instanceof GithubRateLimitError) { 14 rateLimitExceeded.onNext(true); 15 } 16 } 17 ); 18 } 19 20 // … 21 }
57. Rx-ifying Github Search Loading the next page 1 public class ViewModel { 2 3 // ... 4 5 private void loadNextPage() { 6 githubAPI 7 .loadNextPage() 8 .subscribe( 9 (repos) -> { 10 repositories.onNext(repos); 11 }, 12 (error) -> { 13 if (error instanceof GithubRateLimitError) { 14 rateLimitExceeded.onNext(true); 15 } 16 } 17 ); 18 } 19 20 // … 21 }
58. Rx-ifying Github Search Setting up the ViewModel subscriptions 1 public class ViewModel { 2 3 // ... 4 5 private void setupSubscriptions() { 6 searchQuery.subscribe((query) -> { search(query); }); 7 8 nextPageRequested.subscribe((requested) -> { loadNextPage(); }); 9 10 repositories.subscribe((repos) -> { repositoriesFetched.onNext(true); } ); 11 } 12 13 // ... 14 }
59. Rx-ifying Github Search MainActivity - Search 1 public class MainActivity extends AppCompatActivity { 2 3 ViewModel viewModel; 4 5 private void setupSubscriptions() { 6 RxTextView.afterTextChangeEvents(searchEditText) 7 .map((event) -> { return true; }) 8 .subscribe(viewModel.searchRequested); 9 10 RxTextView.afterTextChangeEvents(searchEditText) 11 .debounce(300, TimeUnit.MILLISECONDS) 12 .map((event) -> { return event.editable().toString(); }) 13 .subscribe(viewModel.searchQuery); 14 15 viewModel.searchRequested 16 .observeOn(AndroidSchedulers.mainThread()) 17 .subscribe(RxView.visibility(searchProgressBar)); 18 19 // ...
60. Rx-ifying Github Search MainActivity - Updating the UI 1 public class MainActivity extends AppCompatActivity { 2 3 ViewModel viewModel; 4 5 private void setupSubscriptions() { 6 // ... 7 8 viewModel.repositories 9 .observeOn(AndroidSchedulers.mainThread()) 10 .subscribe((repositories) -> { adapter.addRepositories(repositories); }); 12 13 viewModel.repositoriesFetched 14 .observeOn(AndroidSchedulers.mainThread()) 15 .subscribe(RxView.visibility(repositoriesView)); 16 17 viewModel.repositoriesFetched 18 .observeOn(AndroidSchedulers.mainThread()) 19 .map((fetched) -> { return !fetched; }) 20 .subscribe(RxView.visibility(searchProgressBar)); 21 22 // ... 23 }
61. Rx-ifying Github Search MainActivity - Pagination 1 public class MainActivity extends AppCompatActivity { 2 3 ViewModel viewModel; 4 5 private void setupSubscriptions() { 6 // ... 7 8 RxRecyclerView.scrollEvents(repositoriesView) 9 .map((event) -> { 10 int lastItemPosition = lastCompletelyVisibleItemPosition(); 11 12 return isLastVisibleRepository(lastItemPosition); 13 } 14 }) 15 .subscribe(viewModel.nextPageRequested); 16 17 // … 18 }
62. Rx-ifying Github Search MainActivity - Handling the rate limit 1 public class MainActivity extends AppCompatActivity { 2 3 ViewModel viewModel; 4 5 private void setupSubscriptions() { 6 // ... 7 8 viewModel.rateLimitExceeded 9 .subscribe(RxSnackbar.visible(snackbar)); 10 11 viewModel.rateLimitExceeded 12 .subscribe(RxEditText.disabled(searchEditText)); 13 14 viewModel.rateLimitExceeded 15 .subscribe(RxRecyclerView.disabled(repositoriesView)); 16 17 // … 18 }
63. Rx-ifying Github Search MainActivity - Rate Limit Countdown 1 public class MainActivity extends AppCompatActivity { 2 3 private void setupSubscriptions() { 4 viewModel.rateLimitExceeded 5 .filter((exceeded) -> { return exceeded; }) 6 .flatMap((exceeded) -> { 7 return Observable.zip( 8 Observable.range(0, 60), 9 Observable.interval(1, TimeUnit.SECONDS), 10 (count) -> { return 59L - count; } 11 ) 12 .doOnNext((seconds) -> { 13 if (seconds == 0) { 14 viewModel.rateLimitExceeded.onNext(false); 15 } 16 }) 17 }) 18 .map((seconds) -> { return ….getString(R.string.rate_limit_exceeded, seconds); } 19 .observeOn(AndroidSchedulers.mainThread()) 20 .subscribe(RxSnackbar.text(snackbar)); 21 }
64. That’s it!
65. Links http://reactivex.io/ https://github.com/ReactiveX/RxJava https://github.com/ReactiveX/RxJava/wiki https://github.com/ReactiveX/RxAndroid https://github.com/andela-ftchirou/rx-github-search http://reactivex.io/documentation/operators.html
