Developer tooling for Kubernetes configurations

Talk from KubeCon in Austin, about learning from other programming environments and using tools to validate and test your configurations, whether you're writing them by hand or using higher level tools like ksonnet and Helm.

Transcript

1. Gareth Rushgrove
   Developer tooling for
   Kubernetes configuration
   Tools for developer-friendly workflows


   View Slide

2. View Slide

3. @garethr


   View Slide

4. - Infrastructure as code
   - Validation, linting and unit testing
   - Demos and examples


   View Slide

5. Testing infrastructure
   as code
   A bit of useful history


   View Slide

6. Infrastructure as code is the process
   of managing and provisioning
   computers through machine-readable
   definition files, rather than physical
   hardware configuration or interactive
   configuration tools
   https://en.wikipedia.org/wiki/Infrastructure_as_Code


   View Slide

7. rspec-puppet - originally written in 2011


   View Slide

8. Examples span communities
   ChefSpec, Puppet Lint, Puppet Syntax,
   Food Critic, Cookstyle


   View Slide

9. Why test a declarative configuration?


   View Slide

10. Increasingly configuration:
    - Contains logic
    - Takes arguments
    - Interfaces with other configuration
    - Spans multiple versions of software


    View Slide

11. Those points from a Puppet talk from 4 years ago


    View Slide

12. As the community adopts higher-level
    tools like Helm, ksonnet, Compose,
    Kedge, Kapitan, etc. this becomes
    more relevant to Kubernetes users


    View Slide

13. Take bitnami/kube-manifests as
    an example. It contains 7000+ lines
    of JSON in 159 files generated from
    2000 lines of Jsonnet.


    View Slide

14. Sidenote
    Brian Grant found 43 higher-levels
    tools for managing K8S configurations


    View Slide

15. Relevant discussion in the App Def Working Group


    View Slide

16. I posit that the lessons learnt applying
    testing practices to infrastructure as
    code apply to Kubernetes configs


    View Slide

17. Widely adopted tools break down into
    - Validation
    - Linting
    - Unit testing
    - Acceptance testing


    View Slide

18. What would tools to address these
    problems look like for Kubernetes?


    View Slide

19. Validation
    Using the type schemas when writing configs


    View Slide

20. apiVersion: v1
    kind: Service
    metadata:
    name: redis-master
    labels:
    app: redis
    role: master
    tier: backend
    spec:
    ports:
    - port: 6379
    targetPort: "6379"
    selector:
    app: redis
    role: master1
    tier: backend
    Is this a valid Kubernetes configuration file?


    View Slide

21. Is this a valid Kubernetes configuration file?
    apiVersion: v1
    kind: ReplicationController
    spec:
    replicas: none
    selector:
    app: nginx
    loadbalancer: lb-1
    templates:
    name: nginx
    labels: backend
    app: nginx
    spec:
    containers:
    - name: nginx
    image: nginx


    View Slide

22. Is this Helm template valid for Kubernetes?
    apiVersion: v1
    kind: Service
    metadata:
    name: {{ template "fullname" . }}
    labels:
    app: {{ template "fullname" . }}
    chart: "{{ .Chart.Name }}-{{ .Chart.Version }}"
    release: "{{ .Release.Name }}"
    heritage: "{{ .Release.Service }}"
    spec:
    ports:
    - name: memcache
    port: 11211
    targetPort: memcache
    selector:
    app: {{ template "fullname" . }}


    View Slide

23. Is this Puppet code valid for Kubernetes?
    kubernetes_pod { 'sample-pod':
    ensure => present,
    metadata => {
    namespace => 'default',
    },
    spec => {
    containers => [{
    name => 'container-name',
    image => 'nginx',
    }]
    },
    }


    View Slide

24. Kubernetes has a well-defined set of
    API primitives; Pods, Deployments,
    Services, ReplicationControllers, etc.


    View Slide

25. Kubernetes uses OpenAPI to describe the API


    View Slide

26. OpenAPI uses JSON Schema internally


    View Slide

27. Kubernetes JSON Schema


    View Slide

28. That’s a lot of JSON
    PS> Get-Content -Path swagger.json | Measure-Object -line).Lines
    85340
    PS> (Get-ChildItem -Path v*/*.json -Recurse | Measure-Object).Count
    26181
    PS> (Get-ChildItem -Path v*/*.json -Recurse | Get-Content | Measure-Object -line).Lines
    7296392


    View Slide

29. OpenShift JSON Schema


    View Slide

30. Validate directly using the schemas
    $ jsonschema -F "{error.message}" -i hello-nginx.json 1.6.6-standalone/deployment.json
    u'template' is a required property


    View Slide

31. Validation is useful for
    - Catching typos
    - Fast feedback
    - Missing properties
    - Checking against multiple K8 versions


    View Slide

32. Introducing Kubeval


    View Slide

33. A nice CLI for validating K8S configurations
    $ kubeval --help
    Validate a Kubernetes YAML file against the relevant schema
    Usage:
    kubeval [file...] [flags]
    Flags:
    -h, --help help for kubeval
    -v, --kubernetes-version string Version of Kubernetes to validate against
    --openshift Use OpenShift schemas instead of upstream Kubernetes
    --schema-location string Base URL used to download schemas. Can also be
    specified with the environment variable
    KUBEVAL_SCHEMA_LOCATION
    --version Display the kubeval version information and exit


    View Slide

34. Validate YAML files on the command line
    $ kubeval my-invalid-rc.yaml
    The document my-invalid-rc.yaml contains an invalid ReplicationController
    --> spec.replicas: Invalid type. Expected: integer, given: string
    $ echo $?
    1
    $ cat my-invalid-rc.yaml | kubeval
    The document my-invalid-rc.yaml contains an invalid ReplicationController
    --> spec.replicas: Invalid type. Expected: integer, given: string
    $ echo $?
    1


    View Slide

35. Validate multiple resources in the same file
    $ kubeval multi.yaml
    The document fixtures/multi.yaml contains a valid Service
    The document fixtures/multi.yaml contains an invalid Deployment
    --> spec.template.spec.containers.0.env.0.value: Invalid type. Expected: string, given: integer
    The document fixtures/multi.yaml contains an invalid ReplicationController
    --> spec.replicas: Invalid type. Expected: integer, given: string
    The document fixtures/multi.json contains a valid Deployment
    The document fixtures/multi.yaml contains a valid ReplicationController


    View Slide

36. Validate against multiple versions of Kubernetes
    $ kubeval --v 1.7.9 my-invalid-rc.yaml
    The document my-invalid-rc.yaml contains an invalid ReplicationController
    --> spec.replicas: Invalid type. Expected: integer, given: string
    $ kubeval --v 1.8.1 my-invalid-rc.yaml
    The document my-invalid-rc.yaml contains an invalid ReplicationController
    --> spec.replicas: Invalid type. Expected: integer, given: string


    View Slide

37. Use as a library in other Go tools
    import (
    "github.com/garethr/kubeval/kubeval"
    )
    results, err := kubeval.Validate(fileContents, fileName)


    View Slide

38. Unit testing
    Custom business rules for configuration


    View Slide

39. Validation says something is valid,
    not that it’s what you intended


    View Slide

40. Lots of teams have a script to
    check certain properties of their
    K8S configurations against
    internal policies


    View Slide

41. Our internal tooling includes a
    linter that renders helm charts and
    validates the resources produced
    pass certain internal rules.


    View Slide

42. - Podspec needs resource requests
    - Ensure certain labels are set
    - Prevent usage of latest images
    - Prohibit privileged containers
    - Enforce naming conventions


    View Slide

43. Introducing kubetest


    View Slide

44. Run tests against your configurations
    $ kubetest rc.yaml --verbose
    INFO rc.yaml should not use latest images
    WARN rc.yaml ReplicationController should have at least 4 replicas


    View Slide

45. Tests are written in Skylark


    View Slide

46. Skylark is a dialect of Python. It is
    an untyped dynamic language
    with high-level data types,
    first-class functions with lexical
    scope, and garbage collection


    View Slide

47. A Skylark interpreter is typically
    embedded within an application
    which may define additional
    domain-specific functions and
    data types beyond those provided
    by the core language


    View Slide

48. Example tests for kubetest
    #// vim: set ft=python:
    def test_for_latest_image():
    if spec["kind"] == "ReplicationController":
    for container in spec["spec"]["template"]["spec"]["containers"]:
    tag = container["image"].split(":")[-1]
    assert_not_equal(tag, "latest", "should not use latest images")
    def test_minimum_replicas():
    if spec["kind"] == "ReplicationController":
    test = spec["spec"]["replicas"] >= 4
    assert_true(test, "ReplicationController should have at least 4 replicas")
    test_for_latest_image()
    test_minimum_replicas()


    View Slide

49. Tests enforcing a team label
    #// vim: set ft=python:
    def test_for_team_label():
    if spec["kind"] == "Deployment":
    labels = spec["spec"]["template"]["metadata"]["labels"]
    assert_contains(labels, "team", "should indicate which team owns the deployment")
    test_for_team_label()


    View Slide

50. Linting
    Building common community assertions


    View Slide

51. Organisation-specific assertions
    are useful, but require you to
    write the tests yourself


    View Slide

52. Many assertions are common,
    they are the result of emerging
    community best-practice


    View Slide

53. I’d like to build an out-of-the-box
    experience for kubetest


    View Slide

54. Integration with K8 tools
    Demos and examples


    View Slide

55. Using kubeval with Helm
    $ git clone https://github.com/kubernetes/helm.git
    $ cd helm/docs/examples
    $ ls
    alpine nginx README.md
    $ helm template nginx | kubeval
    The document stdin contains a valid Secret
    The document stdin contains a valid ConfigMap
    The document stdin contains a valid Service
    The document stdin contains a valid Pod
    The document stdin contains a valid Deployment
    The document stdin contains a valid Job


    View Slide

56. Tests for our Helm Chart
    #// vim: set ft=python:
    def test_for_latest_image():
    if spec["kind"] in ["Job", "Deployment"]:
    for container in spec["spec"]["template"]["spec"]["containers"]:
    tag = container["image"].split(":")[-1]
    assert_not_equal(tag, "latest", spec["kind"] + " should not use latest images")
    test_for_latest_image()


    View Slide

57. Using kubetest with Helm
    $ helm template nginx | kubetest --verbose
    INFO stdin Deployment should not use latest images
    INFO stdin Job should not use latest images


    View Slide

58. Using kubeval with ksonnet
    $ cat deployment.jsonnet
    local k = import "ksonnet.beta.2/k.libsonnet";
    local deployment = k.apps.v1beta1.deployment;
    local container = deployment.mixin.spec.template.spec.containersType;
    local containerPort = container.portsType;
    // Create nginx container with container port 80 open.
    local nginxContainer =
    container.new("nginx", "nginx:1.13.0") +
    container.ports(containerPort.newNamed("http", 80));
    // Create default Deployment object from nginx container.
    deployment.new("nginx", 5, nginxContainer, {app: "nginx"})


    View Slide

59. Using kubeval with ksonnet
    $ cat deployment.jsonnet
    local k = import "ksonnet.beta.2/k.libsonnet";
    local deployment = k.apps.v1beta1.deployment;
    local container = deployment.mixin.spec.template.spec.containersType;
    local containerPort = container.portsType;
    // Create nginx container with container port 80 open.
    local nginxContainer =
    container.new("nginx", "nginx:1.13.0") +
    container.ports(containerPort.newNamed("http", 80));
    // Create default Deployment object from nginx container.
    deployment.new("nginx", 5, nginxContainer, {app: "nginx"})
    $ jsonnet deployment.jsonnet | kubeval
    The document stdin contains a valid Deployment


    View Slide

60. Using kubetest with ksonnet
    $ jsonnet deployment.jsonnet | kubetest --verbose
    INFO stdin should not use latest images
    WARN stdin ReplicationController should have at least 7 replicas


    View Slide

61. Using kubeval with Puppet
    $ cat guestbook.pp
    kubernetes_service { 'frontend':
    ensure => 'present',
    metadata => {
    'labels' => {'app' => 'guestbook', 'tier' => 'frontend'},
    'namespace' => 'default',
    },
    spec => {
    'type' => 'LoadBalancer',
    'ports' => [
    {'port' => 80, 'protocol' => 'TCP'}
    ],
    'selector' => {
    'app' => 'guestbook',
    'tier' => 'frontend'
    },
    },


    View Slide

62. Using kubeval with Puppet
    $ puppet kubernetes convert --manifest guestbook.pp | kubeval
    The document stdin contains a valid ReplicationController
    The document stdin contains a valid Service
    The document stdin contains a valid ReplicationController
    The document stdin contains a valid Service
    The document stdin contains a valid ReplicationController
    The document stdin contains a valid Service


    View Slide

63. Using kubetest with Puppet
    $ puppet kubernetes convert --manifest guestbook.pp | kubetest --verbose
    INFO stdin should not use latest images
    INFO stdin should not use latest images
    INFO stdin should not use latest images


    View Slide

64. kubeval is a great tool to validate your
    Kubernetes configuration files as part
    of your CI pipeline


    View Slide

65. Using kubeval and kubetest in CI


    View Slide

66. Conclusions
    If all you remember is...


    View Slide

67. The community is still exploring
    ways to describe Kubernetes
    configuration in code


    View Slide

68. The Configuration Complexity Clock is real


    View Slide

69. Some of the current tools lend
    themselves to native testing,
    others are just data and templates


    View Slide

70. Having testing tools that work
    with different configuration
    approaches can make moving
    between tools easier


    View Slide

71. Lots more interesting opportunities
    around testing Kubernetes configs


    View Slide

72. And lots of inspiration we can take
    from other communities and tools


    View Slide

73. Any questions?
    And thanks for listening


    View Slide
