Why your configuration needs a schema

Talk from Configuration Management Camp 2018, all about the high cost of current configuration management approaches, why that leads to serialisation formats like YAML and JSON being edited directly, and how schemas and auto-generation can help.

Transcript

1. Why your configuration
   needs a schema
   Gareth Rushgrove


   View Slide

2. @garethr


   View Slide

3. View Slide

4. - The proliferation of config file formats
   - The high cost of config management
   - Why configuration needs a schema
   - Auto-generate everything


   View Slide

5. The proliferation of
   configuration file formats
   The state of things


   View Slide

6. XML, INI, JSON, YAML, EDN,
   HOCON, TOML, CSON, Java
   Properties, internal DSLs, ...


   View Slide

7. Everyone has opinions about
   config file formats


   View Slide

8. Don’t use JSON as a Config File Format


   View Slide

9. View Slide

10. View Slide

11. Some formats are associated with
    certain languages or frameworks


    View Slide

12. Others become the default for
    communities of practice


    View Slide

13. Apart from the parsing bit, to the
    application being configured it’s
    just a data structure


    View Slide

14. For the operator all of the different
    formats are separate user interfaces


    View Slide

15. This is one of the reasons for
    higher-level configuration
    management tools


    View Slide

16. The cost of configuration
    management
    A barrier to entry to good tooling


    View Slide

17. Multiple configuration management
    tools is not a bad thing, but it does
    mean lots of reinventing the wheel


    View Slide

18. Everyone ends up with a way to
    manage packages, services,
    files, users and groups


    View Slide

19. Worse, everyone ends up with a
    way to manage Apache


    View Slide

20. sous-chef/apache2
    1498 commits, 116 contributors, 46 releases
    puppetlabs/puppetlabs-apache
    2992 commits, 342 contributors, 39 releases
    Ansible Galaxy
    298 results for apache


    View Slide

21. Managing files is a big part of
    managing most systems


    View Slide

22. Using BigQuery on 7.5 million lines of Puppet


    View Slide

23. What types are used the most?


    View Slide

24. More than 30% of Puppet
    resources where files


    View Slide

25. Option 1: Templates
    None of the benefits of your chosen
    tool, and you’re exposed to all the
    configuration file formats directly


    View Slide

26. template '/etc/app/config.yaml' do
    source 'config.yaml.erb'
    mode '0755'
    owner 'web'
    group 'web'
    end
    You need a separate templating language


    View Slide

27. How can you reason about a system
    when the configuration is spread
    across an explosion of templating
    languages, file formats and templates?


    View Slide

28. Option 2: Format-specific resources
    You can now use your chosen tool,
    but the tool has no context for the
    application, it’s just data, and the
    format still bleeds through


    View Slide

29. ini_setting { "sample setting":
    ensure => present,
    path => '/tmp/foo.ini',
    section => 'bar',
    setting => 'baz',
    value => 'quux',
    }
    Manage an INI file with Puppet


    View Slide

30. A PowerShell DSC Resource for INI files


    View Slide

31. Import-DscResource -ModuleName DSCR_IniFile
    cIniFile Apple {
    Path = "C:\Test.ini"
    Section = ""
    Key = "Fruit_A"
    Value = "Apple"
    }
    Manage an INI file with DSC


    View Slide

32. Ansible module for INI files


    View Slide

33. Chef resources for JSON and YAML files


    View Slide

34. Option 3: App-specific resources
    You get all the power of your
    chosen tool, but at the cost of
    bespoke development


    View Slide

35. webapp "cfgmgmtcamp" do
    static_url_path "/my_project/static"
    mysql_database_user "project_user_name"
    show_settings_route "/show-settings"
    debug True
    end
    A bespoke application in Chef


    View Slide

36. How can we lower the cost of native
    resources for configuration?


    View Slide

37. What have schemas got to
    do with this?
    Moving on to talk about solutions


    View Slide

38. Most Chef cookbooks or Ansible or
    Puppet modules are not written by
    the developers of the application
    being managed


    View Slide

39. Most configuration is informally
    specified via implementation, and
    often not versioned like an API


    View Slide

40. What if instead applications provided
    a schema for their configuration?


    View Slide

41. Examples and
    demonstrations
    Experiments in auto generating tools


    View Slide

42. Kubernetes has a well-defined set of
    configuration primitives; Pods,
    Deployments, Services,
    ReplicationControllers, etc.


    View Slide

43. Kubernetes uses OpenAPI to describe the API


    View Slide

44. OpenAPI uses JSON Schema internally


    View Slide

45. Kubernetes JSON Schema


    View Slide

46. That’s a lot of JSON
    PS> Get-Content -Path swagger.json | Measure-Object -line).Lines
    85340
    PS> (Get-ChildItem -Path v*/*.json -Recurse | Measure-Object).Count
    26181
    PS> (Get-ChildItem -Path v*/*.json -Recurse | Get-Content | Measure-Object -line).Lines
    7296392


    View Slide

47. Generated Puppet types and providers


    View Slide

48. Generated jsonnet templates


    View Slide

49. Generated ICL templates


    View Slide

50. Validation tools


    View Slide

51. Programming language clients


    View Slide

52. Could we have this for any
    application?


    View Slide

53. A simple example application from the internet


    View Slide

54. {
    "STATIC_URL_PATH": "/my_project/static",
    "MYSQL_DATABASE_USER": "project_user_name",
    "SHOW_SETTINGS_ROUTE": "/show-settings",
    "DEBUG": true
    }
    Our application has a configuration file


    View Slide

55. {
    "definitions": {},
    "$schema": "http://json-schema.org/draft-06/schema#",
    "id": "app_config",
    "title": "app_config",
    "type": "object",
    "additionalProperties": false,
    "required": [
    "STATIC_URL_PATH",
    "MYSQL_DATABASE_USER"
    ],
    "properties": {
    "STATIC_URL_PATH": {
    "$id": "/properties/STATIC_URL_PATH",
    "type": "string",
    "title": "Static URL path",
    "description": "A filesystem path for static assets",
    Let’s write a (JSON) schema


    View Slide

56. "additionalProperties": false,
    Only allow the defined properties


    View Slide

57. "required": [
    "STATIC_URL_PATH",
    "MYSQL_DATABASE_USER"
    ],
    These properties are required


    View Slide

58. "STATIC_URL_PATH": {
    "$id": "/properties/STATIC_URL_PATH",
    "type": "string",
    "title": "Static URL path",
    "description": "A filesystem path for static assets",
    "examples": [
    "/my_project/static"
    ]
    },
    Describe each individual property


    View Slide

59. Validate config using the schemas
    $ jsonschema -F "{error.message}" -i app.json schema.json
    u'STATIC_URL_PATH' is a required property


    View Slide

60. We have a schema. Now what?


    View Slide

61. Validate arbitrary structures with JSON Schema
    import json
    import fastjsonschema
    data = {
    "STATIC_URL_PATH": "/my_project/static",
    "MYSQL_DATABASE_USER": "project_user_name",
    "SHOW_SETTINGS_ROUTE": "/show-settings",
    "DEBUG": True,
    }
    validate = fastjsonschema.compile(json.load(open('schema.json')))
    validate(data)
    print(json.dumps(data))


    View Slide

62. The JSON in JSON Schema refers to
    the syntax for the schema. It can be
    used to validate data in other formats


    View Slide

63. Generate browser-based user interfaces


    View Slide

64. Generate interactive documentation


    View Slide

65. Generate models in different languages


    View Slide

66. Quicktype generating Simple Types
    $ docker run -v ${PWD}:/pwd quicktype -l types -s schema /pwd/schemas/schema.json
    class Schema {
    staticURLPath: String
    mysqlDatabaseUser: String
    showSettingsRoute: Maybe
    debug: Maybe
    }


    View Slide

67. Quicktype generating Go
    $ docker run -v ${PWD}:/pwd quicktype -l go -s schema /pwd/schemas/schema.json
    // To parse and unparse this JSON data, add this code to your project and do:
    //
    // r, err := UnmarshalSchema(bytes)
    // bytes, err = r.Marshal()
    package main
    import "encoding/json"
    func UnmarshalSchema(data []byte) (Schema, error) {
    var r Schema
    err := json.Unmarshal(data, &r)
    return r, err
    }
    func (r *Schema) Marshal() ([]byte, error) {


    View Slide

68. Quicktype currently supports
    generating TypeScript, Elm, Java, C#,
    Go, Swift and C++


    View Slide

69. Python JSON Schema Objects


    View Slide

70. Dynamically build objects from schemas
    import python_jsonschema_objects as pjs
    import json
    schema = json.load(open('schema.json'))
    builder = pjs.ObjectBuilder(schema)
    ns = builder.build_classes()
    Config = ns.AppConfig
    config = Config(
    STATIC_URL_PATH="/static",
    MYSQL_DATABASE_USER="db",
    )


    View Slide

71. What if we could generate Puppet
    types, Chef resources, Libral
    providers, Ansible modules, etc.


    View Slide

72. Live Demo Klaxon


    View Slide

73. Generate Chef resource from schema
    $ ./to_chef.py
    resource_name :app_config
    property :path, String, name_property: true
    property :static_url_path, String, required: true
    property :mysql_database_user, String, required: true
    property :show_settings_route, String, default: '/settings'
    property :debug, Boolean
    action :create do
    file path do
    content "{
    STATIC_URL_PATH: "#{static_url_path}",
    MYSQL_DATABASE_USER: "#{mysql_database_user}",
    SHOW_SETTINGS_ROUTE: "#{show_settings_route}",
    DEBUG: #{debug}
    }"


    View Slide

74. Generate Libral provider from schema
    $ ./to_libral.py
    #! /usr/bin/python
    import json
    import sys
    import os
    METADATA="""
    ---
    provider:
    type: app_config
    invoke: json
    actions: [get,set]
    suitable: true
    attributes:
    path:
    desc: The filepath for the configuration file


    View Slide

75. Generate Puppet type from schema
    $ ./to_puppet.py
    Puppet::Type.newtype(:app_config) do
    ensurable
    validate do
    required_properties = [
    :static_url_path,
    :mysql_database_user,
    ]
    required_properties.each do |property|
    if self[property].nil? and self.provider.send(property) == :absent
    fail "You must provide a #{property}"
    end
    end
    end
    newparam(:path, namevar: true) do


    View Slide

76. Conclusions
    If all you remember is...


    View Slide

77. Schemas can allow for greater
    portability, and improved
    interoperability, between tools


    View Slide

78. If you’re building applications,
    consider writing a schema to
    describe your configuration


    View Slide

79. If you’re building configuration
    management tools consider relying a
    lot more on auto-generation


    View Slide

80. Any questions?
    And thanks for listening


    View Slide
