Android functional testing made easy with Kotlin
Level: Intermediate
by Marc-Antoine Sauvé, Hopper

This talk will walk you through how Hopper leveraged Kotlin to build clean DSL based functional testing that separates the “what” from the “how”.

https://gdgmontreal.com/2019/07/26/kotlin-everywhere/

GDG Montreal

August 28, 2019
Tweet

More Decks by GDG Montreal

Other Decks in Programming

Transcript

  1. Android functional testing
    made easy with Kotlin
    Marc-Antoine Sauvé

    View Slide

  2. Hello to GDG Sofia!
    Special thanks to Boris Strandjev, organiser at GDG Sofia,
    for the help with this talk

    View Slide

  3. #1 Mobile Travel App in North America
    Downloads to date
    30M+
    Trips planned in our app
    60M+
    Sold from 126 countries
    $900M

    View Slide

  4. Functional testing
    according to Wikipedia
    Functional testing is [...] a type of black-box testing that bases its test cases on the
    specifications of the software component under test.
    Functional testing is conducted to evaluate the compliance of a system or
    component with specified functional requirements.
    Functional testing usually describes what the system does.

    View Slide

  5. Why UI testing?
    Test their functionalities
    according to the specs of
    the different features
    Test main funnels
    We were not setup to test
    the business logic in
    isolation
    Not “testing ready”
    UI testing is not
    implementation
    dependant
    Legacy code

    View Slide

  6. Goals
    Separate the what and
    the how
    Clean tests
    We want to improve our
    detection of regressions
    in our most used funnels
    Test features
    Generate clear reports to
    help identify the failures
    easily
    Clear failures

    View Slide

  7. Concepts
    They know how do to the
    stuff, where the tests
    using them know what to
    do
    Robot pattern
    Its presence in a screen
    signify that the screen is
    ready to be used
    Proof object
    Allow simple logging to
    help understand where a
    test failed and allow to
    define optional steps in a
    funnel
    Steps

    View Slide

  8. Lets see it in action

    View Slide

  9. Test reports

    View Slide

  10. Steps
    Starting test com.hopper.mountainview.debug.BookingTest#searchTripWhenLoggedOut
    Ensuring the user is logged out
    The page HomeScreenRobot is loaded
    Test step Open home page started
    Optional test step OnboardingRobot skipped
    The page HomeScreenRobot is loaded
    Test step Open home page finished
    ...
    Test step Loading after signin page started
    The page ChooseTravelersRobot is loaded
    Test step Loading after signin page finished
    The traveler exists
    Test step Select traveler started
    The page RunningBunnyRobot is loaded
    The page BookingChoosePaymentRobot is not loaded
    Failed to load page object BookingChoosePaymentRobot in time
    Taking screenshot of 'searchTripWhenLoggedOut'
    Screenshot taken

    View Slide

  11. Steps
    Starting test com.hopper.mountainview.debug.BookingTest#searchTripWhenLoggedOut
    Ensuring the user is logged out
    The page HomeScreenRobot is loaded
    Test step Open home page started
    Optional test step OnboardingRobot skipped
    The page HomeScreenRobot is loaded
    Test step Open home page finished
    ...
    Test step Loading after signin page started
    The page ChooseTravelersRobot is loaded
    Test step Loading after signin page finished
    The traveler exists
    Test step Select traveler started
    The page RunningBunnyRobot is loaded
    The page BookingChoosePaymentRobot is not loaded
    Failed to load page object BookingChoosePaymentRobot in time
    Taking screenshot of 'searchTripWhenLoggedOut'
    Screenshot taken

    View Slide

  12. Steps
    Starting test com.hopper.mountainview.debug.BookingTest#searchTripWhenLoggedOut
    Ensuring the user is logged out
    The page HomeScreenRobot is loaded
    Test step Open home page started
    Optional test step OnboardingRobot skipped
    The page HomeScreenRobot is loaded
    Test step Open home page finished
    ...
    Test step Loading after signin page started
    The page ChooseTravelersRobot is loaded
    Test step Loading after signin page finished
    The traveler exists
    Test step Select traveler started
    The page RunningBunnyRobot is loaded
    The page BookingChoosePaymentRobot is not loaded
    Failed to load page object BookingChoosePaymentRobot in time
    Taking screenshot of 'searchTripWhenLoggedOut'
    Screenshot taken

    View Slide

  13. Steps
    Starting test com.hopper.mountainview.debug.BookingTest#searchTripWhenLoggedOut
    Ensuring the user is logged out
    The page HomeScreenRobot is loaded
    Test step Open home page started
    Optional test step OnboardingRobot skipped
    The page HomeScreenRobot is loaded
    Test step Open home page finished
    ...
    Test step Loading after signin page started
    The page ChooseTravelersRobot is loaded
    Test step Loading after signin page finished
    The traveler exists
    Test step Select traveler started
    The page RunningBunnyRobot is loaded
    The page BookingChoosePaymentRobot is not loaded
    Failed to load page object BookingChoosePaymentRobot in time
    Taking screenshot of 'searchTripWhenLoggedOut'
    Screenshot taken

    View Slide

  14. Steps
    Starting test com.hopper.mountainview.debug.BookingTest#searchTripWhenLoggedOut
    Ensuring the user is logged out
    The page HomeScreenRobot is loaded
    Test step Open home page started
    Optional test step OnboardingRobot skipped
    The page HomeScreenRobot is loaded
    Test step Open home page finished
    ...
    Test step Loading after signin page started
    The page ChooseTravelersRobot is loaded
    Test step Loading after signin page finished
    The traveler exists
    Test step Select traveler started
    The page RunningBunnyRobot is loaded
    The page BookingChoosePaymentRobot is not loaded
    Failed to load page object BookingChoosePaymentRobot in time
    Taking screenshot of 'searchTripWhenLoggedOut'
    Screenshot taken

    View Slide

  15. Steps
    Starting test com.hopper.mountainview.debug.BookingTest#searchTripWhenLoggedOut
    Ensuring the user is logged out
    The page HomeScreenRobot is loaded
    Test step Open home page started
    Optional test step OnboardingRobot skipped
    The page HomeScreenRobot is loaded
    Test step Open home page finished
    ...
    Test step Loading after signin page started
    The page ChooseTravelersRobot is loaded
    Test step Loading after signin page finished
    The traveler exists
    Test step Select traveler started
    The page RunningBunnyRobot is loaded
    The page BookingChoosePaymentRobot is not loaded
    Failed to load page object BookingChoosePaymentRobot in time
    Taking screenshot of 'searchTripWhenLoggedOut'
    Screenshot taken

    View Slide

  16. How did we do it?

    View Slide

  17. The Robot pattern
    ▪ Each screens have a Robot class
    ▪ Defines the elements on the screen you can interact with
    ▪ Defines the actions you can take on those elements
    ▪ Test data should be provided, not hardcoded

    View Slide

  18. The Robot pattern
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    // 1- List all elements that can be interacted with
    private val signUpOrLoginButton = selectObject(
    viewIdSelector = ViewIdSelector(R.id.signup_button),
    textSelector = TextSelector(R.string.sign_up_log_in)
    )
    // 2- Expose functions to interact with them
    fun clickSignUp(): LoginOnboardingRobot {
    signUpOrLoginButton.click()
    Return LoginOnboardingRobot(testContext)
    }
    fun fillInUsername(user: User): NoProfileRobot {
    usernameField.text = user.username
    }
    }

    View Slide

  19. The Robot pattern
    @Test
    fun signIn() {
    HomeScreenRobot(testContext)
    .openTrips()
    val loginOnboardingRobot = NoProfileRobot(testContext)
    .clickSignUp()
    val signInRobot = loginOnboardingRobot
    .swipeThroughAllTabs()
    .goToSignin()
    signInRobot
    .enterPhoneNumber(DEFAULT_TEST_USER.userData)
    assertPageLoaded(TripsRobot(testContext))
    }

    View Slide

  20. The Robot pattern
    @Test
    fun signIn() {
    HomeScreenRobot(testContext)
    .openTrips()
    NoProfileRobot(testContext)
    .clickSignUp()
    .swipeThroughAllTabs()
    .goToSignin()
    .enterPhoneNumber(DEFAULT_TEST_USER.userData)
    assertPageLoaded(TripsRobot(testContext))
    }

    View Slide

  21. The Robot pattern
    fun noProfileRobot(testContext: TestContext, func: NoProfileRobot.() -> Unit = {}) =
    NoProfileRobot(testContext).apply(func)
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    }

    View Slide

  22. The Robot pattern
    @Test
    fun signIn() {
    // 1- Create the HomeScreenRobot
    homeScreenRobot(testContext) { // this: HomeScreenRobot
    // 2- Actions to do on the robot
    openTrips()
    }
    // 3- The robots can be chained
    noProfileRobot(testContext)
    .clickSignUp { // this: LoginOnboardingRobot
    swipeThroughAllTabs()
    }.goToSignin { // this: SignInRobot
    enterPhoneNumber(DEFAULT_TEST_USER.userData)
    sendVerificationText()
    }
    tripsRobot(testContext)
    }

    View Slide

  23. The Robot pattern
    fun noProfileRobot(testContext: TestContext, func: NoProfileRobot.() -> Unit = {}) =
    NoProfileRobot(testContext).apply(func)
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    }

    View Slide

  24. The Robot pattern
    fun noProfileRobot(testContext: TestContext, func: NoProfileRobot.() -> Unit = {}) =
    NoProfileRobot(testContext).apply(func)
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    }

    View Slide

  25. The Robot pattern
    fun noProfileRobot(testContext: TestContext, func: NoProfileRobot.() -> Unit = {}) =
    NoProfileRobot(testContext).apply(func)
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    }

    View Slide

  26. The Robot pattern
    fun noProfileRobot(testContext: TestContext, func: NoProfileRobot.() -> Unit = {}) =
    NoProfileRobot(testContext).apply(func)
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    }
    public inline fun T.apply(block: T.() -> Unit): T {
    block()
    return this
    }

    View Slide

  27. The Robot pattern
    @Test
    fun signIn() {
    homeScreenRobot(testContext) { // this: HomeScreenRobot
    openTrips()
    }
    [...]
    }

    View Slide

  28. The Robot pattern
    @Test
    fun signIn() {
    homeScreenRobot(testContext) { // this: HomeScreenRobot
    this.openTrips()
    }
    [...]
    }

    View Slide

  29. The Robot pattern
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    fun clickSignUp(func: LoginOnboardingRobot.() -> Unit = {}): LoginOnboardingRobot
    {
    signUpOrLoginButton.click()
    return loginOnboardingRobot(testContext, func)
    }
    }

    View Slide

  30. The Robot pattern
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    fun clickSignUp(func: LoginOnboardingRobot.() -> Unit = {}): LoginOnboardingRobot
    {
    signUpOrLoginButton.click()
    return loginOnboardingRobot(testContext, func)
    }
    }

    View Slide

  31. The Robot pattern
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    fun clickSignUp(func: LoginOnboardingRobot.() -> Unit = {}): LoginOnboardingRobot
    {
    signUpOrLoginButton.click()
    return loginOnboardingRobot(testContext, func)
    }
    }

    View Slide

  32. The Robot pattern
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    [...]
    fun clickSignUp(func: LoginOnboardingRobot.() -> Unit = {}): LoginOnboardingRobot
    {
    signUpOrLoginButton.click()
    return loginOnboardingRobot(testContext, func)
    }
    }

    View Slide

  33. The Robot pattern
    @Test
    fun signIn() {
    homeScreenRobot(testContext) { // this: HomeScreenRobot
    openTrips()
    }
    noProfileRobot(testContext)
    .clickSignUp { // this: LoginOnboardingRobot
    swipeThroughAllTabs()
    }.goToSignin { // this: SignInRobot
    enterPhoneNumber(DEFAULT_TEST_USER.userData)
    sendVerificationText()
    }
    tripsRobot(testContext)
    }

    View Slide

  34. The Proof object
    ▪ uiObjects are not immediately resolved, only when interacted with
    ▪ we defined annotation @ProofObject
    ▪ we defined the method
    TestingRobot.waitForPageToLoad(testContext)
    ▪ The work of fetching and validating the ProofObject is done by
    TestContext
    This allows us to ensure that the screens are loaded appropriately

    View Slide

  35. The Proof object
    open class NoProfileRobot(testContext: TestContext) : TestingRobot(testContext) {
    @ProofObject
    private val signUpOrLoginButton = selectObject(
    viewIdSelector = ViewIdSelector(R.id.signup_button),
    textSelector = TextSelector(R.string.sign_up_log_in)
    )
    fun clickSignUp(func: LoginOnboardingRobot.() -> Unit = {}): LoginOnboardingRobot
    {
    signUpOrLoginButton.click()
    return loginOnboardingRobot(testContext, func).waitForPageToLoad()
    }
    }

    View Slide

  36. The TestContext
    ▪ Knows how to get the ProofObject for a screen
    ▪ Knows how to validate that the screen is loaded
    ▪ Knows if there is optional screens that can be skipped
    ▪ Each Robots have a TestContext that is shared for a given test
    ▪ The TestContext will timeout if the screen does not appear within
    reasonable time
    ▪ Holds the Android context
    ▪ Holds the Test logger
    ▪ Ui automator device
    ▪ Other things (e.g. whether ANR was encountered)

    View Slide

  37. Optional screens
    ▪ define their own proof objects
    ▪ also define skip steps
    ▪ each Robot can define optional before and optional after screens
    ▪ our framework automatically skips these screens
    Sometimes a test can not determine if a page will be shown or not

    View Slide

  38. Optional screens
    class OnboardingRobot(testContext: TestContext) : OptionalPage(testContext) {
    @ProofObject
    private val continueButton = selectObject([...])
    private val letsGetStartedButton = selectObject([...])
    override fun executeSkipSteps() {
    continueButton.click()
    letsGetStartedButton.click()
    loadThroughLoadingScreen(testContext, ::NavigationBarRobot) {
    openWatch()
    }
    }
    }

    View Slide

  39. Optional screens
    class OnboardingRobot(testContext: TestContext) : OptionalPage(testContext) {
    @ProofObject
    private val continueButton = selectObject([...])
    private val letsGetStartedButton = selectObject([...])
    override fun executeSkipSteps() {
    continueButton.click()
    letsGetStartedButton.click()
    loadThroughLoadingScreen(testContext, ::NavigationBarRobot) {
    openWatch()
    }
    }
    }

    View Slide

  40. Test structure

    View Slide

  41. Test steps
    Steps logs whenever they
    start and finish, with their
    name and relevant
    information
    Better logs
    An optional test will not
    fail the test if it is there or
    not
    Optional steps
    Allows to add optional
    steps before or after a
    given step
    Hooks

    View Slide

  42. Test step
    withTestStep(testContext, TestStep.OPEN_SETTINGS) {
    homeScreenRobot(testContext) {
    openTrips()
    }
    tripsRobot(testContext) {
    openSettings()
    }
    }
    A test is composed of multiple test steps

    View Slide

  43. Test step
    // Extension function on any Robot or Test
    fun T.withTestStep(
    testContext: TestContext,
    testStep: TestStep,
    stepBody: T.() -> U
    ): U {
    // Log & execute steps before (hooks)
    // Some more logs
    val returnValue = stepBody()
    // Some more logs & ANR check
    // Log & execute steps after (hooks)
    return returnValue
    }

    View Slide

  44. Test step
    fun signIn() {
    withTestStep(TestStep.OPEN_HOME) {
    homeScreenRobot(testContext)
    }.withTestStep(TestStep.OPEN_TRIPS) {
    // this: HomeScreenRobot
    openTrips()
    }
    withTestStep(TestStep.CLICK_LOGIN) {
    noProfileRobot(testContext)
    .clickSignUp()
    }.withTestStep(TestStep.SCROLL_SIGNIN_INTRO) {
    // this: LoginOnboardingRobot
    swipeThroughAllTabs()
    goToSignin()
    }
    [...]
    }

    View Slide

  45. And more

    View Slide

  46. Prerequisites
    @UserLoggedOut
    @Test
    fun searchTripWhenLoggedOut() {
    Other examples of prerequisites:
    @CreditCardPresent(UserDataSample.NO_MATTER, CardDataSamples.MASTERCARD1)
    @CreditCardNotPresent(UserDataSample.NO_MATTER, CardDataSamples.MASTERCARD1)
    @UserLoggedIn(UserDataSample.NO_MATTER)
    These are things you expect to hold true before you run the test

    View Slide

  47. Test against ANRs
    ▪ At one moment of time we had plenty
    ▪ We decided to use ANRWatchdog in our debug builds
    ▪ We also altered the tests to report failure on ANR

    View Slide

  48. Thank you!

    View Slide

  49. We’re
    on the
    Lookout for
    Talented
    People
    Check out current
    openings at
    hopper.com/jobs.

    View Slide
