The never ending REST API design debate

What should a good REST API look like? Should you use verbs or nouns in your resource paths? How do you handle versioning of APIs? How to deal with partial responses and pagination? Which status codes should I make use of? What about sorting, filtering, and searching? Have you thought about content negotiation, and hypermedia?

Guillaume will got through all these topics, offering advice on the best approaches to those questions, and opening up the debate on the various options available, so as to make your Web API at REST, as clean and elegant as possible.

Transcript

1. The never-ending REST
   API design debate
   Guillaume Laforge
   Restlet — the Web API platform
   Chair of the Apache Groovy PMC
   @glaforge


   View Slide

2. We know
   about
   APIs!
   http://restlet.com


   View Slide

3. We know
   about
   APIs!
   http://restlet.com


   View Slide

4. ROY FIELDING
   REST
   DISSERTATION


   View Slide

5. ROY FIELDING
   REST
   DISSERTATION
   Principled design
   of the modern
   Web architecture


   View Slide

6. 4
   Representational State Transfer
   Architectural properties
   • Performance
   • Scalability
   • Simplicity
   • Modifiability
   • Visibility
   • Portability
   • Reliability
   Architectural constraints
   • Client-server
   • Stateless
   • Cacheable
   • Layered system
   • Code on demand (optional)
   • Uniform interface


   View Slide

7. 5
   REST — Uniform interface
   • Identification of resources
   • Manipulation of resources

   through representations
   • Self-descriptive messages
   • HATEOAS

   (Hypermedia As The Engine

   Of Application State)


   View Slide

8. 5
   REST — Uniform interface
   • Identification of resources
   • Manipulation of resources

   through representations
   • Self-descriptive messages
   • HATEOAS

   (Hypermedia As The Engine

   Of Application State)
   Resource as URIs
   http://api.co/cars/123


   View Slide

9. 5
   REST — Uniform interface
   • Identification of resources
   • Manipulation of resources

   through representations
   • Self-descriptive messages
   • HATEOAS

   (Hypermedia As The Engine

   Of Application State)
   Resource as URIs
   http://api.co/cars/123
   JSON, XML…


   View Slide

10. 5
    REST — Uniform interface
    • Identification of resources
    • Manipulation of resources

    through representations
    • Self-descriptive messages
    • HATEOAS

    (Hypermedia As The Engine

    Of Application State)
    Resource as URIs
    http://api.co/cars/123
    JSON, XML…
    HTTP GET, POST, PUT, DELETE
    media types, cacheability…


    View Slide

11. 5
    REST — Uniform interface
    • Identification of resources
    • Manipulation of resources

    through representations
    • Self-descriptive messages
    • HATEOAS

    (Hypermedia As The Engine

    Of Application State)
    Resource as URIs
    http://api.co/cars/123
    JSON, XML…
    HTTP GET, POST, PUT, DELETE
    media types, cacheability…
    Hypermedia APIs
    HAL, JSON-LD, Siren…


    View Slide

12. 6
    HTTP methods / URIs for collection/item
    GET
    POST
    PUT
    DELETE
    http://api.co/v2/cars/ http://api.co/v2/cars/1234
    List all the cars Retrieve an individual car
    Create a new car Error
    Replace the entire collection
    with a whole new list of cars
    Replace or create
    an individual car
    Delete all the cars Delete an individual car


    View Slide

13. NOUNS
    ARE GOOD
    VERBS
    ARE BAD


    View Slide

14. 8
    Nouns are good, verbs are bad!
    • Prefer nouns to verbs
    • nouns refer to resources
    • resources are handled with HTTP verbs
    • Verbs can be used for actions or calculations
    • /login, /logout
    • /convertTemperature
    • /repositories/123/star


    View Slide

15. View Slide

16. 10
    Singular or plural resources?
    • Prefer plural forms
    • /tickets/234 vs /ticket/234
    • Avoid confusing odd singular vs plural forms
    • /person vs /people, or /goose vs /geese
    • Easier for URL routing (same prefix)
    • Think of it as:

    ‘This is the 234th item of the tickets collection’


    View Slide

17. Camel
    case?


    View Slide

18. Camel
    case?
    Snake
    case!


    View Slide

19. 12
    Different casing in the wild
    • UpperCamelCase or lowerCamelCase
    • snake_case or dashed-snake-case
    • Prefer lowercase
    • Prefer snake_case
    • Underscores seem more common in APIs
    • But chose one casing and be consistent!


    View Slide

20. 13
    Dealing with relations in your URLs
    • /tickets/123/messages/4
    • a ticket could be a group of messages
    • /usergroups/234/users/67
    • a user could belong to different usergroups
    • user should have a URL of its own, referenced from the
    usergroup payload


    View Slide

21. API PARAMETERS
    RULE OF THUMBS


    View Slide

22. 15
    API parameters — rule of thumbs
    • Path
    • required, resource identifier
    • Query
    • optional, query collections
    • Body
    • resource specific logic
    • Header
    • global, platform-wide


    View Slide

23. 16
    HTTP Status Code Map http://bit.ly/stcode


    View Slide

24. 17
    Common HTTP status codes
    • Use appropriate HTTP status codes when answering
    requests:
    • 1xx: Hold on…
    • 2xx: Here you go!
    • 3xx: Go away!
    • 4xx: You fucked up :-D
    • 5xx: I fucked up :-(


    View Slide

25. 18
    Common HTTP Status Codes — 1xx


    View Slide

26. 19
    Common HTTP Status Codes — 2xx


    View Slide

27. 19
    Common HTTP Status Codes — 2xx


    View Slide

28. 19
    Common HTTP Status Codes — 2xx


    View Slide

29. 19
    Common HTTP Status Codes — 2xx


    View Slide

30. 19
    Common HTTP Status Codes — 2xx


    View Slide

31. 19
    Common HTTP Status Codes — 2xx


    View Slide

32. NOT
    JUST
    200
    201
    202
    204
    206


    View Slide

33. Anti-pattern:
    returns 200
    for everything,
    even errors!


    View Slide

34. 22
    Not just 200 OK! — 201 Created
    • Specify a Location header, pointing at the location of the
    newly created resource
    POST /cars ...
    HTTP/1.1 201 Created
    Location: http://cars.co/v2/cars/5959


    View Slide

35. API navigation is
    important to make the
    API more discoverable


    View Slide

36. 24
    DHC by Restlet: API testing tool


    View Slide

37. 25
    Not just 200 OK! — 202 Accepted
    • Request accepted but will be handled asynchronously
    • a job might be running later and yield a result later on
    POST /jobs ...
    HTTP/1.1 202 Accepted
    No payload
    returned


    View Slide

38. 26
    Not just 200 OK! — 204 No content
    • The resource was deleted and no payload is returned
    • but could return 200 OK

    & provide the payload of the deleted element
    DELETE /tickets/654
    HTTP/1.1 204 No content


    View Slide

39. 27
    Not just 200 OK! — 206 Partial content
    • A partial list of meteorites is returned, using pagination
    • add a Link header to facilitate navigation
    GET /meteorites?page=4
    HTTP/1.1 206 Partial content
    Link: ; rel="first",

    ; rel="prev",
    ; rel="next",

    ; rel="last"
    ...


    View Slide

40. 28
    Not just 200 OK! — 304 Not modified
    • When HTTP caching headers are in play
    • the client should have a version in cache already
    GET /meteorites/654
    HTTP/1.1 304 Not modified


    View Slide

41. Caching!


    View Slide

42. 30
    Last-Modified
    GET /users/123
    Modified-Since: Fri, 13 Nov 2015 02:13:11 GMT
    HTTP/1.1 200 OK
    Last-Modified: Sun, 15 Nov 2015 04:58:08 GMT


    View Slide

43. 31
    ETag
    GET /users/123
    If-None-Match: a456ef544eeb7333af
    HTTP/1.1 200 OK
    ETag: 686897696a7c876b7e
    GET /users/123
    If-None-Match: 686897696a7c876b7e
    HTTP/1.1 304 Not modified


    View Slide

44. PAGINATION


    View Slide

45. 33
    Pagination with query parameters
    • With a page number: ?page=23
    • can also specify a page size
    • might get odd results when insertions happen
    • With a cursor: ?cursor=34ea3fd6
    • insertion-friendly
    • With a semantic parameter: ?page=A
    • interesting when limited / discrete number of pages


    View Slide

46. 34
    Pagination with accept range header
    • Accept range header not just for bytes
    GET /users
    HTTP/1.1 206 Partial content
    Accept-Ranges: users
    Content-Range: users 0-9/200
    GET /users
    Range: users=0-9


    View Slide

47. Wrapped
    CollectionS


    View Slide

48. 36
    Wrapped collections
    • Prefer unwrapped collections
    • unless there’s specific collection payload metadata

    (example: photo album details)
    • pagination are better in HTTP headers
    GET /tickets
    Content-Type: application/json
    {
    data: [
    { id: 1, ... },
    { id: 2, ... }
    ]
    }
    GET /tickets
    Content-Type: application/json
    [
    { id: 1, ... },
    { id: 2, ... }
    ]


    View Slide

49. 37
    Common HTTP Status Codes — 3xx


    View Slide

50. 37
    Common HTTP Status Codes — 3xx


    View Slide

51. 37
    Common HTTP Status Codes — 3xx


    View Slide

52. 37
    Common HTTP Status Codes — 3xx


    View Slide

53. 37
    Common HTTP Status Codes — 3xx


    View Slide

54. 37
    Common HTTP Status Codes — 3xx


    View Slide

55. 38
    Common HTTP Status Codes — 4xx


    View Slide

56. 38
    Common HTTP Status Codes — 4xx


    View Slide

57. 38
    Common HTTP Status Codes — 4xx


    View Slide

58. 38
    Common HTTP Status Codes — 4xx


    View Slide

59. 38
    Common HTTP Status Codes — 4xx


    View Slide

60. 38
    Common HTTP Status Codes — 4xx


    View Slide

61. 39
    Provide helpful error payloads
    • No definitive standard yet
    • http problem proposal and vnd-error mime type
    HTTP/1.1 403 Forbidden
    Content-Type: application/problem+json
    Content-Language: en
    {
    "type": "https://example.com/probs/out-of-credit",
    "title": "You do not have enough credit.",
    "detail": "Your current balance is 30, but that costs 50.",
    "instance": "/account/12345/msgs/abc",
    "balance": 30,
    "accounts": ["/account/12345", "/account/67890"]
    }


    View Slide

62. 40
    Common HTTP Status Codes — 5xx


    View Slide

63. 40
    Common HTTP Status Codes — 5xx


    View Slide

64. 40
    Common HTTP Status Codes — 5xx


    View Slide

65. 40
    Common HTTP Status Codes — 5xx


    View Slide

66. 41
    Treating unknown status codes
    • An unknown status code should be treated

    as the first one of the family
    • 4xx — 400 generic client error
    • 5xx — 500 generic server error


    View Slide

67. RATE
    LIMITATION


    View Slide

68. 43
    Rate limitation
    HTTP/1.1 200 OK
    Date: Mon, 01 Jul 2013 17:27:06 GMT
    Status: 200 OK
    X-RateLimit-Limit: 60
    X-RateLimit-Remaining: 56
    X-RateLimit-Reset: 1372700873
    Total number of
    requests allowed
    Number of
    requests left
    remaining window before
    the rate limit resets in UTC
    epoch seconds


    View Slide

69. ONE
    SIZE
    FITS
    ALL
    Different payloads
    for different
    consumers


    View Slide

70. 45
    Selecting with query parameters
    • Only 5 stars Chinese restaurants
    • GET https://api.co/restaurants?type=chinese&stars=5


    View Slide

71. FIL
    TERING


    View Slide

72. 47
    Filtering
    • Specify fields you’re interested in:
    • GET https://api.co/users/123?fields=firstname,lastname,age
    • Specify excluded fields:
    • GET https://api.co/users/123?exclude=biography,resume
    • Specify a « style »:
    • GET https://api.co/users/123?style=compact


    View Slide

73. 48
    Prefer… the prefer header
    GET /users/123 HTTP/1.1
    Content-Type: application/json
    Prefer: return=minimal
    Vary: Prefer,Accept,Accept-Encoding
    HTTP/1.1 200 OK
    Content-Type: application/json; charset=utf-8
    Vary: Prefer,Accept,Accept-Encoding
    Preference-Applied: return=minimal
    Define different
    profiles: minimal,
    mobile, full…


    View Slide

74. 49
    Expanding referenced resources
    • Use the dot notation to explicit you want sub-resources
    • GET https://api.co/users/123?fields=address.zip
    • user
    • name
    • address
    • zip
    • country
    • …
    • …


    View Slide

75. SORTING


    View Slide

76. 51
    Sorting
    • SQL-style
    • GET https://api.co/books?sort=title+DESC
    • GET https://api.co/books?sort=title+DESC,author+ASC
    • Sort + asc/desc combo
    • GET https://api.co/books?sort=title&desc=title
    • GET https://api.co/books?
    sort=title,author&desc=title&asc=author


    View Slide

77. SEARCHING


    View Slide

78. 53
    Searching
    • Combien various filtering fields
    • Or provide a full-blown query language


    View Slide

79. v1


    View Slide

80. 55
    Different approaches for API versioning
    • Most frequent, in the URL:
    • https://api.com/v2/restaurants/1234
    • Custom header:
    • X-API-Version: 2
    • Less frequent, with an accept header
    • clients don’t have to change endpoint, but update headers
    GET /restaurants
    Accept: application/vnd.restaurants.v2+json


    View Slide

81. hypermedia


    View Slide

82. 57
    Richardson maturity model


    View Slide

83. 58
    Pros & Cons of hypermedia
    • Pros
    • more generic clients
    • can palliate the need for API versioning
    • Cons
    • heavier payload (think mobile devices w/ bad connectivity)
    • clients still need to understand what links are about and
    how to represent them in their UI


    View Slide

84. C
    H
    A
    N
    G
    E
    IS
    U
    N
    A
    V
    O
    ID
    A
    B
    L
    E


    View Slide

85. 60
    Lots of choice
    • HAL
    • JSON-LD
    • Collection+JSON
    • SIREN
    • …
    • Which to chose from?
    • no real consensus yet
    • but HAL seems quite common


    View Slide

86. 61
    A word about IDs for linked resources
    • If you’re tempted to go your own way for hypermedia…
    • Be sure to define direct links to resources
    • photos: [http://news.co/articles/123/photos/654,

    http://news.co/articles/123/photos/659]
    • Not mere IDs for which API clients need to figure out the
    exact resource location (error-prone)
    • photos: [654, 659]


    View Slide

87. 62
    Another word about IDs
    • Usually avoid counter-type IDs: 1, 2, 3, 4…
    • Prefer UUIDs
    • makes it harder for malignant users

    to scan & discover existing resources
    • auto-incrementing IDs might not be unique

    in distributed systems


    View Slide

88. HAL
    I’m sorry Dave, I
    can do Hypermedia


    View Slide

89. 64
    HAL approach
    GET https://api.com/player/1234567890
    HTTP/1.1 200 OK
    {
    "_links": {
    "self": { "href": "https://api.com/player/1234567890" },
    "friends": { "href": "https://api.com/player/1234567890/friends" }
    },
    "playerId": "1234567890",
    "name": "Kevin Sookocheff",
    "alternateName": "soofaloofa",
    "image": "https://api.com/player/1234567890/avatar.png"
    }
    Special _links property


    View Slide

90. Resources


    View Slide

91. 66
    API design resources
    • http://www.vinaysahni.com/best-practices-for-a-pragmatic-restful-api
    • https://github.com/paypal/api-standards/blob/master/api-style-guide.md
    • http://blog.octo.com/en/design-a-rest-api/
    • https://github.com/interagent/http-api-design/blob/master/SUMMARY.md
    • http://sookocheff.com/post/api/on-choosing-a-hypermedia-format/
    • http://www.troyhunt.com/2014/02/your-api-versioning-is-wrong-which-is.html


    View Slide

92. Thanks for your attention


    View Slide

93. Questions & Answers


    View Slide
