Integrating PostgreSQL with RabbitMQ

A talk given at PgConf NYC 2014 about RabbitMQ and PostgreSQL.

Transcript

1. Integrating PostgreSQL with RabbitMQ Gavin M. Roy April 4th, 2014
2. About Me VP of Architecture
 AWeber Communications ! Blog: http://gavinroy.com Twitter: @Crad GitHub: https://github.com/gmr ! RabbitMQ in Depth (MEAP) http://manning.com/roy
3. RabbitMQ Primer
4. About RabbitMQ • Message Oriented Middleware • Primary identity is defined by AMQP 0-9-1 • Supports other protocols with Plugins:

 AMQP 1.0, HTTP, MQTT, STOMP, XMPP, UDP, WebStomp, and more • Written in Erlang/OTP, is Open Source (MPL), and is developed/maintained by Pivotal
5. Why RabbitMQ? • Create loosely coupled architectures • Decouple database write operations • Communicate across application platforms • Tap into pre-existing message flow for new purposes • Scale-out clustering for growth, throughput & HA • Federation for WAN latencies & network partitions
6. Native AMQP Clients C Clojure Cobol Common Lisp Delphi Erlang Go Groovy Haskell Java JavaScript .NET OCaml Perl PHP Python Ruby Scala
7. Who Uses It? Agora Games Chef Google AdMob Instagram MeetMe Mercado Libre Mozilla Nasa New York Times NSF Openstack Reddit
8. RabbitMQ Concepts
9. AMQP Message Body Properties
10. Message Properties app-id content-encoding content-type correlation-id delivery-mode expiration headers message-id priority reply-to timestamp type user-id Body Properties
11. Publishers and Consumers C P
12. Multiple Publishers P C P P
13. Multiple Consumers P C C C
14. AMQ Model Exchange
 defines routing behavior Queue
 stores messages in memory and optionally on disk Binding
 defines relationship between exchanges and queues X Queue Binding
15. Routing Keys • Provided when publishing a message • Compared against binding keys by exchanges • Example uses of a Routing Key: • Connotate the type of message • Designate the destination of a message • Categorize the content in the message
16. Built-In Exchange Types Direct
 String matching on Routing Key Fanout
 No routing key, messages sent to all bound queues Topic
 Pattern matching in Routing Key Headers
 No routing key, string matching in the message headers property
17. Topic Exchange Binding Keys namespace.delimited.keys #
 Receive all messages namespace.#
 Receive all messages in the namespace namespace.delimited.*
 Receive all namespace.delimited messages namespace.*.keys
 Receive all namespace messages ending in keys
18. Example Exchange Plugins Consistent Hashing
 Distribute messages via routing key hashed value Pulse
 Publish internal RabbitMQ metrics via AMQP Random
 Distribute messages across all bound queues randomly Recent History
 Stores last 20 messages to any bound queue Riak Storage
 Store received messages in Riak" Script Exchange
 Calls out to external scripts for routing behavior
19. Exchange to Exchange Bindings X X X Queue Queue Queue
20. to RabbitMQ
21. pg_amqp • PostgreSQL Extension • User-defined functions to publish via AMQP • Developed by OmnTI • Invoke from user-defined function • Available on PGXN
22. Using pg_amqp • Has table of AMQP broker connections • Publishes body only AMQP messages • Transactional publishing via amqp.publish • Non-transactional via amqp.autonomous_publish • Needs some love for additional features
23. https://github.com/gmr/On-Rabbits-and-Elephants Example: SELECT amqp.publish(broker_id, 'name', 'routing-key', 'message'); Publishing a Message
24. PgSQL Listen Exchange • Exchange that issues LISTEN and publishes received notifications to bound queues • When routing messages, bindings are checked for the routing key to match the NOTIFY channel • Unobtrusive to PostgreSQL environment, native constructs for publishing messages • Requires PostgreSQL 9.0 and greater • Body only messages*
25. Sending a Notification psql (9.3.2) Type "help" for help. ! postgres=# \timing Timing is on. postgres=# NOTIFY channel_name,
 ‘Test notification'; NOTIFY Time: 0.160 ms
26. Receiving a Notification psql (9.3.2) Type "help" for help. ! postgres=# LISTEN channel_name; ! (after NOTIFY issued) ! Asynchronous notification "channel_name" with payload "Test notification" received from server process with PID 16749.
28. Example Notification Message
29. to PostgreSQL
30. No direct integrations yet
31. Chapter 14 Creating a pgsql-storage RabbitMQ plugin
32. Other ways? via Consumer apps in the language of your choice via Apache Flume with RabbitMQ Source, PostgreSQL Sink
33. Questions? rabbitmq-pgsql-listen-exchange
 https://github.com/aweber/rabbitmq-pgsql-listen-exchange pg_ampq
 http://pgxn.org/dist/pg_amqp/ RabbitMQ in Depth
 44% off code pgcf (includes other books as well)
 http://manning.com/roy/ Follow me on Twitter
 @Crad
