  1. #KubeDay
    Best Practices for Applications on Kubernetes
    to Achieve Both Frequent Updates and Stability
    Hiroshi Hayakawa | @hhiroshell
    Cloud Platform Developer & 12th Black Belt Engineer of CloudNative Stack,
    Yahoo Japan Corporation

    View Slide

  2. #KubeDay
    Requirements for modern applications

    View Slide

  3. #KubeDay
    Requirements for modern applications
    • Applications would be restarted for a variety of reasons
    – Frequent updates
    – Automatic / Manual scaling
    – Maintenance of infrastructure
    • We should consider restarts as something that can happen at any time
    • Need to be stable even with frequent restarts
    3

    View Slide

  4. #KubeDay
    Further challenges
    • Want to achieve frequent restarts, stability, and…
    – sufficient service level.
    – running a large number of pods.
    – sleep well at night.
    4

    View Slide

  5. #KubeDay
    So, What should we do?
    • Various events will happen in the Kubernetes pods
    5
    First deployment
    v1 Pods
    v2 Pods
    v3 Pods
    Rolling Update
    Restart for some reason
    Scale out under high loads

    View Slide

  6. #KubeDay
    So, What should we do?
    • To simplify the issue, let's break it down into three perspectives
    6
    v1 Pods
    v2 Pods
    v3 Pods
    Ensure that the pod starts safely
    with sufficient preparation Shut it down truly Graceful
    Eliminate unexpected crashes

    View Slide

  7. #KubeDay
    Ensure that pods start safely with sufficient
    preparation

    View Slide

  8. #KubeDay
    Ensure that pods start with sufficient preparation
    • “Pod is Ready” means user requests will come into the pod
    • Containers in the pod must be ready to receive actual requests before the
    pod’s status become “Ready.”
    8

    View Slide

  9. #KubeDay
    What should it be in our applications?
    • It depends on the application 😅
    • Examples:
    – Prepare connections of relational database
    – Allocate sufficient initial heap memory
    – Warm up the app and optimize it with JIT compilation
    9

    View Slide

  10. #KubeDay 10
    What happens in a pod at a startup
    time
    InitContainers run sequentially
    Containers starts and
    runs ENTRYPOINT command
    startup probe readiness probe
    liveness probe



    It also runs postStart lifecycle hook
    • On control plane nodes
    • A new pod is persisted to the
    API Server
    • The scheduler decides which
    Node to place the pod
    • On worker nodes
    • The kubelet on the Node
    starts to make an environment
    for containers in the pod
    Pre-start process Containers start up (Our Concern)

    View Slide

  11. #KubeDay 11
    What happens in a pod at a startup
    time
    InitContainers run sequentially
    Containers starts and
    runs ENTRYPOINT command
    startup probe readiness probe
    liveness probe



    It also runs postStart lifecycle hook
    • On control plane nodes
    • A new pod is persisted to the
    API Server
    • The scheduler decides which
    Node to place the pod
    • On worker nodes
    • The kubelet on the Node
    starts to make an environment
    for containers in the pod
    Pre-start process Containers start up (Our Concern)
    Service In
    Pod becomes “READY.”
    Requests come into the pod.
    Make containers ready here,

    View Slide

  12. #KubeDay
    How can we prepare before the pod becomes ready?
    • initContainers
    – Runs as separate containers from main containers
    – Performs pre-processing before main containers start (e.g., dynamically create
    configuration files for the main containers)
    • postStart lifecycle hook
    – Runs different commands in a main container than the startup command
    – Pod will not be ready until postStart lifecycle hook is finished
    – Can be used to prepare main containers before these accept requests (e.g., send
    warm up requests to the main container with curl)
    12

    View Slide

  13. #KubeDay 13
    Example - Warm up an application with postStart hook
    apiVersion: v1
    kind: Pod
    metadata:
    name: java-app
    spec:
    containers:
    - name: java-app
    image: java-app-image:v1.0.0
    ...(snip)...
    ports:
    - containerPort: 8080
    name: http
    readinessProbe:
    failureThreshold: 3
    httpGet:
    path: /health/readiness
    port: http
    periodSeconds: 1
    lifecycle:
    postStart:
    exec:
    command:
    - sh
    - -c
    - |-
    sleep 10
    for i in $(seq 10000); do
    curl -s http://localhost:8080/ ∖
    > /dev/null
    done
    preStop:
    ...(snip)...
    ✓Wait for the java-app to start.
    ✓Send requests to
    the app in the same pod.

    View Slide

  14. #KubeDay
    Eliminate unexpected crashes of pods

    View Slide

  15. #KubeDay
    Eliminate unexpected crashes of pods
    • Pods unexpectedly stop for various reasons
    • If pods don’t stop safely, incoming requests will end with a failure
    • When a pod stops due to heavy load, other pods are overloaded and stop
    one after another
    15

    View Slide

  16. #KubeDay 16
    Crash scenarios of pods
    High Traffic High Memory Usage
    High CPU Usage
    Bottlenecks outside
    the pod
    Full GC
    Can‘t respond to
    liveness probe
    The kubelet
    terminates the pod
    OOM Kill
    * If the liveness probe depends on outside the pod

    View Slide

  17. #KubeDay 17
    Crash scenarios of pods
    Bottlenecks outside
    the pod
    Full GC
    * If the liveness probe depends on outside the pod
    High Traffic High Memory Usage
    High CPU Usage
    Can‘t respond to
    liveness probe
    The kubelet
    terminates the pod
    OOM Kill
    Enough Load testing and Tuning!

    View Slide

  18. #KubeDay
    A quick review of Kubernetes resource control
    • We can set “requests” and “limits” for each container in a Pod
    – .spec.containers[].resources.requests.[cpu|memory]:
    • quantity of resources guaranteed to be available to the container
    – .spec.containers[].resources.limits.[cpu|memory]:
    • limits for resource consumption beyond reqeusts
    18
    resources.limits
    resources.requests
    Actual resource consumption
    of the container

    View Slide

  19. #KubeDay
    A quick review of Kubernetes resource control
    • Behavior when a container is going to consume more than resource.limits
    – CPU: Throttling
    – Memory: OOM Kill
    • If an OOM Kill occurs, the application cannot handle OS signals and cannot
    shutdown gracefully
    19

    View Slide

  20. #KubeDay
    JVM memory under Kubernetes resource control
    • JVM memory consumption consists of multiple areas such as heap memory,
    thread stack, etc.
    • Tune JVM parameters to keep memory usage within resource limit
    20
    resource limit
    Total memory consumption of JVM
    = Heap + Thread Stack + Code Cache + Metaspace + Direct Memory + Native Memory
    resource request
    🤯
    Heap other areas

    View Slide

  21. #KubeDay
    Tips of JVM heap memory tuning
    • By default, in the JVM, the maximum heap memory is 20-30% of the
    resource limit. It often means that the resource requests/limits are left
    unused.
    Max size of heap memory
    21
    • You can write, for example, “-XX:MaxRAMPercentage=50.0” in JVM
    flags to specify heap memory as a percentage of the resource limit
    resources.limits
    resources.requests
    Heap other areas

    View Slide

  22. #KubeDay 22
    Crash scenarios of pods
    High CPU Usage
    Bottlenecks outside
    the pod
    OOM Kill
    * If the liveness probe depends on outside the pod
    High Traffic High Memory Usage
    Full GC
    Can‘t respond to
    liveness probe
    The kubelet
    terminates the pod
    Select an appropriate GC algorithm

    View Slide

  23. #KubeDay
    JVM garbage collection of containerized Java applications
    • In the container world, we often use Serial GC due to the small quantity of
    resources allocated
    • Serial GC takes a long time for Full GC, During Full GC, the application
    cannot respond to livenessProbe, and it increases the risk that pods restart
    unnecessarily
    23
    Java app container
    http livenessProbe request fails
    TERMINATE kubelet
    Stop the world
    (Full GC)

    View Slide

  24. #KubeDay
    JVM garbage collection of containerized Java applications
    • Consider using concurrent GC algorithms (e.g., G1GC) with two or more
    CPU cores
    • More heap memory will increase the time of full GC. Even just increasing
    the memory should not be done without testing
    24

    View Slide

  25. #KubeDay 25
    Crash scenarios of pods
    Bottlenecks outside
    the pod
    OOM Kill
    * If the liveness probe depends on outside the pod
    High Traffic High Memory Usage
    High CPU Usage
    Full GC
    Can‘t respond to
    liveness probe
    The kubelet
    terminates the pod
    Make livenessProbe stable

    View Slide

  26. #KubeDay
    livenessProbe
    • But few situations require a reboot 🤔
    26
    The kubelet uses liveness probes to know when to restart a container. For
    example, liveness probes could catch a deadlock, where an application is
    running, but unable to make progress.


    -- Kubernetes documentation

    View Slide

  27. #KubeDay
    livenessProbe
    • Setting up a livenessProbe requires careful consideration
    – A livenesspProbe that becomes unresponsive under high load will cause a pod to
    restart when you want it to be running
    – Sometimes default (it judges success if the application process is running) is still
    better
    27
    Java app container
    http livenessProbe request fails
    too many requests
    (and some of them fails)
    TERMINATE kubelet
    users

    View Slide

  28. #KubeDay 28
    Crash scenarios of pods
    High Memory Usage
    High CPU Usage
    Full GC
    OOM Kill
    High Traffic
    Bottlenecks outside
    the pod
    Can‘t respond to
    liveness probe
    The kubelet
    terminates the pod
    * If the liveness probe depends on outside the pod
    Make the livenessProbe depends
    only on inside the pod

    View Slide

  29. #KubeDay
    livenessProbe
    • Results of livenessProbe should not depends on outside of the pod
    – Situations outside of the Pod cause the Pod to be terminated
    – If the cause is not in the Pod, restarting the Pod will not make the situation better
    29

    View Slide

  30. #KubeDay
    Shutdown pods truly graceful

    View Slide

  31. #KubeDay
    Shutdown pods truly graceful
    • Two things happen in the shutdown process of a pod
    – kubelet terminates containers
    – kube-proxy stops traffic to the pod
    • If containers start to be terminated before traffic stops, requests will result
    in errors
    31

    View Slide

  32. #KubeDay 32
    What happens in a pod at a shutdown
    preStop lifecycle hook starts
    kube-proxy stops traffic to the pod
    deletionGracePeriodSeconds (default: 30s)
    kubelet sends SIGKILL
    to the container
    Some kube-apiserver client adds a
    deletionTimestamp annotation to the pod
    kubelet sends SIGTERM
    to the container
    Service Out
    There is no incoming traffic to the pod from here.

    View Slide

  33. #KubeDay 33
    What happens in a pod at a shutdown
    preStop lifecycle hook starts
    kube-proxy stops traffic to the pod
    deletionGracePeriodSeconds (default: 30s)
    kubelet sends SIGKILL
    to the container
    Some kube-apiserver client adds a
    deletionTimestamp annotation to the pod
    kubelet sends SIGTERM
    to the container
    Service Out
    There is no incoming traffic to the pod from here.
    Handle SIGTERM and
    shutdown gracefully
    Wait for service out

    View Slide

  34. #KubeDay
    How can we make a pod achieve a truly graceful shutdown?
    • Wait for service out
    – kubelet sends a SIGTERM OS signal to the container after preStop lifecycle hook exits
    – Wait until kube-proxy stops traffic to the pod by running the ”sleep xx” command
    in the preStop hook
    • Handle SIGTERM signal in the application and shutdown gracefully
    – The application returns all responses to in-flight requests before it exits
    – In many languages, SDKs or frameworks supports it
    34

    View Slide

  35. #KubeDay 35
    Example - Wait for kube-proxy to stop requests
    apiVersion: v1
    kind: Pod
    metadata:
    name: java-app
    spec:
    containers:
    - name: java-app
    image: java-app-image:v1.0.0
    ...(snip)...
    ports:
    - containerPort: 8080
    name: http
    readinessProbe:
    failureThreshold: 3
    httpGet:
    path: /health/readiness
    port: http
    periodSeconds: 1
    lifecycle:
    postStart:
    ...(snip)...
    preStop:
    exec:
    command:
    - sh
    - -c
    - sleep 10
    ✓Wait for kube-proxy to stop
    requests

    View Slide

  36. #KubeDay
    Example - SIGTERM handling with Spring Boot
    • You can enable SIGTERM Handling by simply adding some properties to the
    application.properties
    36
    server.shutdown=graceful
    spring.lifecycle.timeout-per-shutdown-phase=15s

    View Slide

  37. #KubeDay
    Conclusion
    • Three perspectives for application stability
    37
    v1 Pods
    v2 Pods
    v3 Pods
    Ensure that the pod starts safely
    with sufficient preparation Shut it down truly Graceful
    Eliminate unexpected crashes

    View Slide

  38. #KubeDay
    Thank you
    • I hope you sleep well 😴
    38

    View Slide
