  1. システム改善・育成のための障害対応訓練
    September 22, 2023
    Matsumoto Hiroki
    Marketing Cloud Platform Department
    Rakuten Group, Inc.

    View Slide

  2. 2
    Profile
    松本宏紀 ( Matsumoto Hiroki )
    • Reliability Engineering Team
    • Software Engineer
    • Joined Rakuten in 2020
    • Published
    • OSS: Passenger Go Exporter
    • Presentation: デプロイメント⼿法を選択する ~ Flagger/Argo Rollouts ~
    • GKE + Java + Cassandra → Ruby + Go + Kubernetes ( Private Cloud / AKS )
    • Twitter : @hirokimatsumo13

    View Slide

  3. 3
    経験値を引き継ぐ

    View Slide

  4. 4
    Table of Contents
    1. Assets
    2. Training
    3. Examples

    View Slide

  5. 5
    Assets
    RunBook
    障害発⽣時の取り扱い説明書。リカバリ⼿順などをアラートに対してリンク、またはアラート⾃体に埋め込
    まれる。
    Incident Report Template
    障害発⽣時の報告⽤テンプレート。ユーザー視点で、どこにどのような影響が発⽣したのかを展開するため
    の形式。
    Training
    過去の障害発⽣や、システムの構成要素から障害を実際に発⽣させ、リカバリーまでを実際に経験し、シス
    テム上の問題や⼈の成⻑ポイントを確認する。

    View Slide

  6. 6
    Training
    Trainee
    ☑ 基本的な事は⾃⼰学習で⾜りる
    ☑ 新卒1-3年⽬
    ☑ 役割: Developer + Operator
    Trainer
    ☑ 運⽤経験3年以上
    ☑ 対象プロダクト有識者
    Manager
    ☑ レポート先
    Training Environment
    ☑ トレーニング専⽤環境
    Conductor
    ☑ 運⽤経験3年以上
    ☑ 対象プロダクト有識者
    擬似障害発⽣
    検知・影響範囲確認・原因特定・復旧
    協⼒
    報告

    View Slide

  7. 7
    Example 1: 応答遅延
    Load Balancer Istio App
    Nginx Proxy
    Pattern A
    Nginx
    request_time : 10
    upstream_response_time : 10
    App
    elpased_time : 10
    Pattern B
    Nginx
    request_time : 10
    upstream_response_time : 10
    App
    elpased_time : 0.1
    Pattern C
    Nginx
    request_time : 10
    upstream_response_time : 0.1
    App
    elpased_time : 0.1
    https://nginx.org/en/docs/http/ngx_http_log_module.html
    https://nginx.org/en/docs/http/ngx_http_upstream_module.html
    Pattern A~Cはそれぞれどこで問題が発⽣してる︖

    View Slide

  8. 8
    Example 1: 応答遅延
    Nginx: request_time
    request processing time in seconds with a milliseconds resolution; time elapsed between the first bytes were
    read from the client and the log write after the last bytes were sent to the client.
    引⽤元︓https://nginx.org/en/docs/http/ngx_http_log_module.html

    View Slide

  9. 9
    Example 1: 応答遅延
    Load Balancer Istio App
    Nginx Proxy
    障害発⽣⽅法
    専⽤PGにてクライアントからパケ
    ット送信箇所に遅延を⼊れて再現
    単純に⾼負荷にする
    ( CPU/Packet送受信 )
    Istio fault-injectionの利⽤
    単純に⾼負荷にする
    ( CPU/Packet送受信 )

    View Slide

  10. 10
    Example 1: 応答遅延
    それぞれ計測される時間がどこからどこまでかを正確に把握する
    これを理解していないと、システムの問題であるかどうかも正確に把握できない状況に陥る可能性がある。
    SLI (Service Level Indicator)として、どの部分がより適切であるかを理解する
    APMなどでアプリケーション側だけの応答速度を計測するだけでは不⼗分である事を理解する。

    View Slide

  11. 11
    Example 2: PromQLの正確性
    sum(rate(istio_requests_total{reporter="destination", response_code=~"5.*"}[5m])) /
    sum(rate(istio_requests_total{reporter="destination"}[5m])) * 100 > 5
    実際のシステムに反映する場合、どのような点に考慮すべきか︖

    View Slide

  12. 12
    Example 2: PromQLの正確性
    rate/irateの違い
    Range全体 / 最後2点での計算の差異。
    https://prometheus.io/docs/prometheus/latest/querying/functions/
    counter resetへの考慮
    https://github.com/prometheus/prometheus/issues/1673
    そもそもcounterは0から始まるとは限らない。
    定期的にリセットされる。
    ※バージョンによって期間、動きの差異有り

    View Slide

  13. 13
    Example 2: PromQLの正確性
    reporter=destination or source
    destination側はretry分も含まれてしまう場合がある。また逆にmetricsが取れていない場合もある
    のでsource側での計測結果を主に利⽤している。
    https://istio.io/latest/docs/reference/config/metrics/
    response_flag
    response_flagを⾒て、istio側でどのような問題が発⽣してそのエラーを返したのか確認。
    https://istio.io/latest/docs/reference/config/metrics/
    https://www.envoyproxy.io/docs/envoy/latest/configuration/observability/access_log/usage#config-access-
    log-format-response-flags
    Istio App
    Nginx Proxy
    destination
    source

    View Slide

  14. 14
    理論と実践
    ⾒て学び、経験を得て⾃分のものにしていく。
    「わからないけど、そうなってる」ではなく、なぜそうなってるかを理解していく。
    ただ基本的にはそういった要素がなくなるように、システムを改善できると良い。

    View Slide
