MVC 1.0 - Now Even Better!

MVC 1.0, as specified by JSR 371, may not be targeted for the upcoming Java EE 8 release, but the specification is still going on as a standalone specification. It is already possible to use the technology in a Java EE 7 environment and as Java EE 8 and 9 evolves, MVC 1.0 will be kept aligned to take advantage of the features provided by the platform.

This session will go through the fundamentals of this specification and explain the core concepts. We will show lots of code samples showing how to use the framework to build MVC 1.0 applications.

There will even be a demo of tooling support available and tips’n’tricks on how to extend the framework. After this session you will have everything you need to get started using the technology to quickly build secure, flexible, localized MVC Web applications.

Transcript

1. @ivar_grimstad
   jDays 2017 - #JSR371
   MVC 1.0 - Now Even Better!
   Ivar Grimstad
   Principal Consultant, Cybercom Sweden


   View Slide

2. @ivar_grimstad
   jDays 2017 - #JSR371
   @ivar_grimstad
   https://github.com/ivargrimstad
   https://www.linkedin.com/in/ivargrimstad
   http://lanyrd.com/profile/ivargrimstad/


   View Slide

3. @ivar_grimstad
   jDays 2017 - #JSR371
   JSR 371 Status
   MVC 1.0
   Demo and Samples


   View Slide

4. @ivar_grimstad
   jDays 2017 - #JSR371
   JSR 371 Status


   View Slide

5. @ivar_grimstad
   jDays 2017 - #JSR371


   View Slide

6. @ivar_grimstad
   jDays 2017 - #JSR371


   View Slide

7. @ivar_grimstad
   jDays 2017 - #JSR371


   View Slide

8. @ivar_grimstad
   jDays 2017 - #JSR371
   @Controller
   to the Community !


   View Slide

9. @ivar_grimstad
   jDays 2017 - #JSR371
   January 2017
   Transfer

   Ballot
   August 2014
   First Proposal
   September 2014
   Approved by JCP

   Executive Committee
   September 2014
   Expert Group starts

   discussions
   March 2015
   EDR 1
   October 2016
   October 2015
   EDR 2
   JavaOne
   Past Activities


   View Slide

10. @ivar_grimstad
    jDays 2017 - #JSR371
    Current Activities
    Transfer approved by the Executive Committee

    Thanks!
    Finalize Transfer

    Oracle Legal is working on the final details
    New Infrastructure Setup

    Started
    Licensing

    Investigating


    View Slide

11. @ivar_grimstad
    jDays 2017 - #JSR371
    Future Activities
    Formally move infrastructure from java.net

    Bring in Christian Kaltepoth as co spec-lead

    Revise the Schedule

    Adopt-a-JSR



    View Slide

12. @ivar_grimstad
    jDays 2017 - #JSR371
    Infrastructure Move


    View Slide

13. @ivar_grimstad
    jDays 2017 - #JSR371
    Infrastructure Setup Changes
    Code

    java.net -> GitHub (https://github.com/mvc-spec)
    Issue Tracker

    java.net -> GitHub (https://github.com/mvc-spec/mvc-spec/issues)
    Mailing Lists

    java.net -> Google Groups (jsr371-users@googlegroups.com)
    Web Site

    java.net -> GitHub Pages (http://www.mvc-spec.org/)


    View Slide

14. @ivar_grimstad
    jDays 2017 - #JSR371
    Adopt-a-JSR


    View Slide

15. @ivar_grimstad
    jDays 2017 - #JSR371
    Write Code!
    Blog
    Tweet
    Give us Feedback
    Create a Logotype


    View Slide

16. @ivar_grimstad
    jDays 2017 - #JSR371
    MVC 1.0 Talks
    DEVNEXUS (http://devnexus.com/)

    Atlanta, USA - February 22-24
    jDays (http://www.jdays.se/)

    Gothenburg, Sweden - Mars 7-8
    JavaLand (https://www.javaland.eu/)

    Brühl, Germany - Mars 28-30
    Developer Week (http://www.developer-week.de/)

    Nürnberg, Germany - June 26-29


    View Slide

17. @ivar_grimstad
    jDays 2017 - #JSR371
    MVC 1.0


    View Slide

18. @ivar_grimstad
    jDays 2017 - #JSR371
    Action-based MVC


    View Slide

19. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    Model View
    Request
    Update
    Update


    View Slide

20. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    Model View
    Request
    Update
    Update


    View Slide

21. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    Model View
    Request
    Update
    Update


    View Slide

22. @ivar_grimstad
    jDays 2017 - #JSR371
    Existing Java EE Technologies


    View Slide

23. @ivar_grimstad
    jDays 2017 - #JSR371
    Key Decisions


    View Slide

24. @ivar_grimstad
    jDays 2017 - #JSR371
    Key Decisions


    View Slide

25. @ivar_grimstad
    jDays 2017 - #JSR371
    Build MVC 1.0 on top of JAX-RS


    View Slide

26. @ivar_grimstad
    jDays 2017 - #JSR371
    Controllers


    View Slide

27. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    public class HelloController {
    }


    View Slide

28. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    @Path(“hello”)
    public class HelloController {
    }


    View Slide

29. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    @Controller
    @Path(“hello”)
    public class HelloController {
    }


    View Slide

30. @ivar_grimstad
    jDays 2017 - #JSR371
    Views


    View Slide

31. @ivar_grimstad
    jDays 2017 - #JSR371
    View
    @Controller
    @Path(“hello”)
    public class HelloController {
    }


    View Slide

32. @ivar_grimstad
    jDays 2017 - #JSR371
    View
    @Controller
    @Path(“hello”)
    public class HelloController {
    @GET
    public String hello() {
    return “hello.jsp”;
    }
    }


    View Slide

33. @ivar_grimstad
    jDays 2017 - #JSR371
    View
    @Controller
    @Path(“hello”)
    public class HelloController {
    @GET
    public Viewable hello() {
    return new Viewable(“hello.jsp”);
    }
    }


    View Slide

34. @ivar_grimstad
    jDays 2017 - #JSR371
    View
    @Controller
    @Path(“hello”)
    public class HelloController {
    @GET
    public Response hello() {
    return Response.status(OK).entity(“hello.jsp”).build();
    }
    }


    View Slide

35. @ivar_grimstad
    jDays 2017 - #JSR371
    View
    @Controller
    @Path(“hello”)
    public class HelloController {
    @View(“hello.jsp”)
    @GET
    public void hello() {
    }
    }


    View Slide

36. @ivar_grimstad
    jDays 2017 - #JSR371
    View
    @View(“hello.jsp”)
    @Controller
    @Path(“hello”)
    public class HelloController {
    @GET
    public void hello() {
    }
    }


    View Slide

37. @ivar_grimstad
    jDays 2017 - #JSR371
    Models


    View Slide

38. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    @Named(“greeting”)
    @RequestScoped
    public class Greeting {
    private String message;
    public void setMessage(String message) {
    this.message = message;
    }
    public void getMessage() { return message; }
    }


    View Slide

39. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    @View(“hello.jsp”)
    @Controller
    @Path(“hello”)
    public class HelloController {
    @GET
    public void hello() {
    }
    }


    View Slide

40. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    @View(“hello.jsp”)
    @Controller
    @Path(“hello”)
    public class HelloController {
    @Inject
    private Greeting greeting;
    @GET
    public void hello() {
    greeting.setMessage(“Hello Atlanta!”);
    }
    }


    View Slide

41. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    <%@page contentType=“text/html"
    pageEncoding="UTF-8"%>



    MVC 1.0 Hello Demo


    Hello ${greeting.message}




    View Slide

42. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    @View(“hello.jsp”)
    @Controller
    @Path(“hello”)
    public class HelloController {
    @GET
    public void hello() {
    }
    }


    View Slide

43. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    @View(“hello.jsp”)
    @Controller
    @Path(“hello”)
    public class HelloController {
    @Inject
    private Models model;
    @GET
    public void hello() {
    model.put(“message”, “Hello Atlanta!”);
    }
    }


    View Slide

44. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    <%@page contentType=“text/html"
    pageEncoding="UTF-8"%>



    MVC 1.0 Hello Demo


    Hello ${message}




    View Slide

45. @ivar_grimstad
    jDays 2017 - #JSR371
    Validation


    View Slide

46. @ivar_grimstad
    jDays 2017 - #JSR371
    @Controller
    @Path("form")
    public class FormController {
    @POST
    public Response formPost(@Valid @BeanParam FormDataBean f) {
    return Response.status(OK).entity(“data.jsp”).build();
    }
    }
    Validation
    ConstraintValidationException
    @Min, @NotNull
    etc.


    View Slide

47. @ivar_grimstad
    jDays 2017 - #JSR371
    Validation
    public class FormViolationMapper implements
    ExceptionMapper
    {
    public Response toResponse(ConstraintViolationException e) {
    Set> s= e.getConstraintViolations();
    // process violations ...
    return Response.status(BAD_REQUEST)
    .entity(“error.jsp”).build();
    }
    }


    View Slide

48. @ivar_grimstad
    jDays 2017 - #JSR371
    @Controller
    @Path("form")
    public class FormController {
    @Inject private BindingResult br;
    @POST
    public Response formPost(@Valid @BeanParam FormDataBean f) {
    if (br.isFailed()) {
    return Response.status(BAD_REQUEST)
    .entity(“error.jsp”).build();
    }
    return Response.status(OK).entity(“data.jsp”).build();
    }
    }
    Validation
    Allows for MVC Error Handling


    View Slide

49. @ivar_grimstad
    jDays 2017 - #JSR371
    BindingResult


    View Slide

50. @ivar_grimstad
    jDays 2017 - #JSR371
    View Engines


    View Slide

51. @ivar_grimstad
    jDays 2017 - #JSR371
    Bring Your Own View Engine


    View Slide

52. @ivar_grimstad
    jDays 2017 - #JSR371
    ViewEngine
    public interface ViewEngine {
    boolean supports(String view);
    void processView(ViewEngineContext context)
    throws ViewEngineException;
    }


    View Slide

53. @ivar_grimstad
    jDays 2017 - #JSR371
    View Engine Conflicts
    @Priority(OUTRAGEOSLY_HIGH)

    @ApplicationScoped

    public class FreemarkerViewEngine extends ViewEngineBase {
    …
    }


    View Slide

54. @ivar_grimstad
    jDays 2017 - #JSR371
    Events


    View Slide

55. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    Model View
    Request
    BeforeControllerEvent
    AfterControllerEvent
    BeforeProcessViewEvent
    AfterProcessViewEvent
    ControllerRedirectEvent


    View Slide

56. @ivar_grimstad
    jDays 2017 - #JSR371
    Events Example
    @ApplicationScoped
    public class EventObserver {
    void onBeforeController(@Observes BeforeControllerEvent e) {
    println("URI: " + e.getUriInfo().getRequestURI());
    }
    void onAfterController(@Observes AfterControllerEvent e) {
    println("Controller: " +
    e.getResourceInfo().getResourceMethod());
    }
    }


    View Slide

57. @ivar_grimstad
    jDays 2017 - #JSR371
    Security


    View Slide

58. @ivar_grimstad
    jDays 2017 - #JSR371
    Cross Site Request Forgery
    @Controller
    @Path(“csrf”)
    public class HelloController {
    @CsrfValid
    @POST
    public Response post(@FormParam(“greeting") String greet {
    }
    }


    View Slide

59. @ivar_grimstad
    jDays 2017 - #JSR371
    Cross Site Request Forgery
    <%@page contentType=“text/html" pageEncoding="UTF-8"%>



    MVC 1.0 Hello Demo




    value="${mvc.csrf.token}"/>





    View Slide

60. @ivar_grimstad
    jDays 2017 - #JSR371
    Internationalization


    View Slide

61. @ivar_grimstad
    jDays 2017 - #JSR371
    Controller
    @Controller
    @Path(“hello”)
    public class HelloController {
    @Inject
    private MvcContext mvc;
    @GET
    public String get() {
    Locale locale = mvc.getLocale();
    }
    }


    View Slide

62. @ivar_grimstad
    jDays 2017 - #JSR371
    Scopes


    View Slide

63. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    ReservationCtl
    Update
    confirmation
    reservation
    OK
    Browser
    POST


    View Slide

64. @ivar_grimstad
    jDays 2017 - #JSR371
    Model
    ReservationCtl
    Access
    Update
    ConfirmationCtl
    GET
    confirmation
    reservation
    OK
    Redirect
    Browser
    POST


    View Slide

65. @ivar_grimstad
    jDays 2017 - #JSR371
    Tired of slides?


    View Slide

66. @ivar_grimstad
    jDays 2017 - #JSR371
    Show me the CODE !


    View Slide

67. @ivar_grimstad
    jDays 2017 - #JSR371
    Summary


    View Slide

68. @ivar_grimstad
    jDays 2017 - #JSR371
    Action-based MVC


    View Slide

69. @ivar_grimstad
    jDays 2017 - #JSR371
    Existing Java EE Technologies


    View Slide

70. @ivar_grimstad
    jDays 2017 - #JSR371
    Build MVC 1.0 on top of JAX-RS


    View Slide

71. @ivar_grimstad
    jDays 2017 - #JSR371
    Tool Support


    View Slide

72. @ivar_grimstad
    jDays 2017 - #JSR371
    JPA Modeler
    jpamodeler.github.io
    Gaurav Gupta
    @jGauravGupta


    View Slide

73. @ivar_grimstad
    jDays 2017 - #JSR371
    Project Page
    https://www.mvc-spec.org
    GitHub
    https://github.com/mvc-spec
    Reference Implementation
    https://ozark.java.net


    View Slide

74. @ivar_grimstad
    jDays 2017 - #JSR371
    Samples
    https://github.com/ivargrimstad/mvc-samples
    Blog
    http://www.agilejava.eu/


    View Slide

75. @ivar_grimstad
    jDays 2017 - #JSR371
    cybercom.com


    View Slide
