  1. jgs
    SER 431
    Advanced Graphics
    Lecture 17: Review
    Javier Gonzalez-Sanchez
    [email protected]
    PERALTA 230U
    Office Hours: By appointment

    View Slide

  2. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 1
    jgs
    Calendar

    View Slide

  3. jgs
    Noise (Procedural Texture/Surfaces Generation)

    View Slide

  4. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 3
    jgs
    Multi-scale Function
    Adding Noise over diverse frequencies and amplitudes
    ))
    *
    ,
    *
    ,
    *
    (
    *
    )
    ,
    ,
    (
    1
    r
    scale
    t
    scale
    s
    scale
    noise
    amplitude
    r
    t
    s
    f
    i
    i
    i
    bands
    i
    i
    å
    =
    -
    =

    View Slide

  5. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 4
    jgs
    Sum of Absolute Values
    Adding Noise over absolute values is Good for fire
    ))
    ,
    ,
    (
    (
    )
    ,
    ,
    (
    1
    r
    scale
    t
    scale
    s
    scale
    noise
    amplitude
    r
    t
    s
    f
    i
    i
    i
    bands
    i
    i
    å
    =
    -
    =

    View Slide

  6. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 5
    jgs
    Marble Principle
    )))
    ,
    ,
    (
    (
    *
    sin(
    )
    ,
    ,
    (
    4
    1
    r
    scale
    t
    scale
    s
    scale
    noise
    amplitude
    s
    r
    t
    s
    f
    i
    i
    i
    i
    i
    å
    =
    -
    =
    Using sin( ) function plus noise

    View Slide

  7. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 6
    jgs
    Marble Example
    § MarbleMap is from black to white
    § Scale scales [min, max] to [0,1]
    § u and v are in range [0,1]
    § Does not look that great, maybe a more complex color ramp is needed
    ))
    )
    5
    .
    11
    ,
    *
    2
    *
    5
    ,
    *
    2
    *
    5
    (
    *
    2
    *
    6
    *
    20
    sin
    (
    (
    )
    ,
    (
    4
    1
    ÷
    ø
    ö
    ç
    è
    æ
    +
    =
    å
    =
    -
    v
    u
    PNoise
    u
    Scale
    MarbleMap
    v
    u
    Texture
    i
    i
    i
    i

    View Slide

  8. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 7
    jgs
    Graphics
    https://www.youtube.com/watch?v=aviL3HX3UEc

    View Slide

  9. jgs
    Collision (Axis-aligned bounding box)

    View Slide

  10. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 9
    jgs
    §Axis-aligned Bounding Box (AABB)
    § An AABB is defined by its minimal and maximal positions in space
    Pmin=(xmin, ymin, zmin),
    Pmax = (xmax, ymax, zmax)
    § Calculate
    Initialize pmin to +infinite or the first vertex
    Initialize pmax to –infinite or the first vertex
    foreach vertex p do {
    if (p.x < pmin.x) then pmin.x = p.x
    if (p.y < pmin.y) then pmin.y = p.y
    if (p.z > pmax.z) then pmax.z = p.z
    }

    View Slide

  11. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 10
    jgs
    AABB
    Calculate AABB
    Draw AABB with lines

    View Slide

  12. jgs
    Shadows, Reflection, and Fog

    View Slide

  13. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 12
    jgs
    Concepts
    § What is the shadow matrix?
    § What is the stencil buffer?
    § What is double blending and how to
    avoid it?

    View Slide

  14. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 13
    jgs
    Step 2. init()
    void init() {
    // ...
    glClearStencil(0);
    }

    View Slide

  15. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 14
    jgs
    Step 3. display()
    void display(void) {
    glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT | GL_STENCIL_BUFFER_BIT);
    glEnable(GL_STENCIL_TEST);
    glColorMask(GL_FALSE, GL_FALSE, GL_FALSE, GL_FALSE);
    // glColorMask controls with Stencil or Color buffer?
    glStencilFunc(GL_ALWAYS, 1, 1);
    glStencilOp(GL_REPLACE, GL_REPLACE, GL_REPLACE);
    //

    View Slide

  16. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 15
    jgs
    glDisable(GL_DEPTH_TEST);
    glMatrixMode(GL_PROJECTION);
    glLoadIdentity();
    glOrtho(-50.0, 50, -50.0, 50.0, 1.0, -1.0);
    glMatrixMode(GL_MODELVIEW);
    glLoadIdentity();
    glPushMatrix();
    glTranslatef(0, 0, 0);
    glBegin(GL_TRIANGLES);
    glVertex2f(-20.0, -20.0);
    glVertex2f( 20.0, -20.0);
    glVertex2f( 0.0, 20.0);
    glEnd();
    glPopMatrix();
    glEnable(GL_DEPTH_TEST);

    View Slide

  17. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 16
    jgs
    // re-enable color and disable stencil
    glColorMask(GL_TRUE, GL_TRUE, GL_TRUE, GL_TRUE);
    glStencilFunc(GL_EQUAL, 1, 1);
    glStencilOp(GL_KEEP, GL_KEEP, GL_KEEP);
    // draw your colors here
    glDisable(GL_STENCIL_TEST);
    glutSwapBuffers();
    }

    View Slide

  18. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 17
    jgs
    Culling Face
    void display(void) {
    glEnable(GL_CULL_FACE);
    // checks all the faces that are front facing towards
    // the viewer and renders those while discarding all
    // the faces that are back facing
    // Improve performance also!
    glDisable(GL_CULL_FACE);
    }

    View Slide

  19. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 18
    jgs
    Fog
    glEnable(GL_FOG);
    // specifies the equation to be used to compute the fog blend factor.
    // GL_LINEAR, GL_EXP, and GL_EXP2.
    // initial fog mode is GL_EXP
    glFogi(GL_FOG_MODE, GL_LINEAR);
    // the fog color. Color components are in the range [0,1].
    // the initial fog color is (0, 0, 0, 0).
    GLfloat fogColor[4] = { 0.5, 0.5, 0.5, 1.0 };
    glFogfv(GL_FOG_COLOR, fogColor);
    //Used in exponential fog equations. The initial fog density is 1.
    // Only nonnegative densities are accepted.
    glFogf(GL_FOG_DENSITY, 0.25);
    // the near distance used in the linear fog equation. The initial near distance is 0
    glFogf(GL_FOG_START, 10.0);
    // the far distance used in the linear fog equation. The initial far distance is 1.
    glFogf(GL_FOG_END, 6000.0);

    View Slide

  20. jgs
    Particle Systems

    View Slide

  21. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 20
    jgs
    Particles
    § Emitter
    § Behavioral parameter of a particle (lifetime, initial velocity, spawning rate,
    color)
    § Equations

    View Slide

  22. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 21
    jgs
    Graphics
    https://www.youtube.com/watch?v=aviL3HX3UEc

    View Slide

  23. jgs
    Curves

    View Slide

  24. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 23
    jgs
    All about Curves

    View Slide

  25. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 24
    jgs
    Curves
    § What is a Curve?
    § What is Curvature?
    § Parametric Representation
    § Curve equation (general)
    § Control Graph
    § Control Point
    § Tangent

    View Slide

  26. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 25
    jgs
    Curves
    § Explain C0, C1, C2 continuity
    § Explain similarities and differences of: Bezier, Hermite, Chaikin and B-spline
    Curves
    § What is a Blending Function?
    § Explain A-frame

    View Slide

  27. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 26
    jgs
    Blending Functions
    Bezier
    § B0
    (t)=(1-t)3
    § B1
    (t)=3t(1-t)2
    § B2
    (t)=3t2(1-t)
    § B3
    (t)=(t)3
    Cubic B-Spline
    § B0
    (t)=((1-t)3)/ 6
    B1
    (t)=(3t3 -6t2 + 4)/ 6
    B2
    (t)=(-3t3 + 3t2 + 3t + 1) / 6
    B3
    (t)=(t)3 / 6

    View Slide

  28. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 27
    jgs
    Blending Functions
    Hermite
    § B0
    (t)= 2*t3 – 3*t2 + 1,
    § B1
    (t)= -2*t3 + 3*t2,
    § B2
    (t)= t3 - 2*t2 + t,
    § B3
    (t)= t3 – t2

    View Slide

  29. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 28
    jgs
    Apply Bezier Algorithm

    View Slide

  30. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 29
    jgs
    Apply B-spline Algorithm

    View Slide

  31. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 30
    jgs
    Apply Chaikin Algorithm
    Qi=3/4Pi + 1/4Pi+1
    Ri=1/4Pi + 3/4Pi+1

    View Slide

  32. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 31
    jgs
    Disclaimer
    This list of topics is not Comprehensive
    For a full list of topics review lectures 1 to 16

    View Slide

  33. jgs
    SER431 Advanced Graphics
    Javier Gonzalez-Sanchez
    [email protected]
    Fall 2018
    Disclaimer. These slides can only be used as study material for the class SER431 at ASU. They cannot be
    distributed or used for another purpose.
