  1. jgs Compilers Lecture 11: Parser II Dr. Javier Gonzalez-Sanchez [email protected]

  2. jgs Next

  3. Dr. Javier Gonzalez-Sanchez | Compilers | 3 jgs Programming Assignment

    2 Level 3 The complete grammar for our language

  4. Dr. Javier Gonzalez-Sanchez | Compilers | 4 jgs KEYWORD {return,

    print} STRING Language Actions Expressions (operators) Instructions Control Structures ARITHMETIC OPERATORS { +, -, *, /, =} LOGIC OPERATORS { &, |, ! } RELATIONAL OPERATORS {<, >, ==, !=} KEYWORD { if, else, while, switch, case } Data INTEGER FLOAT HEXADECIMAL CHAR KEYWORD { void, int, char, string, float, boolean } KEYWORD { true, false } BINARY Delimiter : ; , ( ) { } [ ] Assignment 2 | Language OCTAL IDENTIFIER

  5. Dr. Javier Gonzalez-Sanchez | Compilers | 5 jgs Grammar <PROGRAM>

    à '{' <BODY> '}’ <BODY> à {<PRINT>';'|<ASSIGNMENT>';'|<VARIABLE>';’|<WHILE>|<IF>|<RETURN>';'} <ASSIGNMENT> à identifier '=' <EXPRESSION> <VARIABLE> à ('int'|'float'|'boolean'|'char’|'string'|'void')identifier <WHILE> à 'while' '(' <EXPRESSION> ')' <PROGRAM> <IF> à 'if' '(' <EXPRESSION> ')' <PROGRAM> ['else' <PROGRAM>] <RETURN> à 'return' <PRINT> à ’print’ ‘(‘ <EXPRESSION> ‘)’ <EXPRESSION> à <X> {'|' <X>} <X> à <Y> {'&' <Y>} <Y> à ['!'] <R> <R> à <E> {('>'|'<'|'=='|'!=') <E>} <E> à <A> {(’+'|'-’) <A>} <A> à <B> {('*'|'/') <B>} <B> à ['-'] <C> <C> à integer | octal | hexadecimal | binary | true | false | string | char | float | identifier|'(' <EXPRESSION> ')'

  6. Dr. Javier Gonzalez-Sanchez | Compilers | 6 jgs Grammar <PROGRAM>

    à '{' <BODY> '}’ <BODY> à {<PRINT>';'|<ASSIGNMENT>';'|<VARIABLE>';’|<WHILE>|<IF>|<RETURN>';'} <ASSIGNMENT> à identifier '=' <EXPRESSION> <VARIABLE> à ('int'|'float'|'boolean'|'char’|'string'|'void')identifier <WHILE> à 'while' '(' <EXPRESSION> ')' <PROGRAM> <IF> à 'if' '(' <EXPRESSION> ')' <PROGRAM> ['else' <PROGRAM>] <RETURN> à 'return' <PRINT> à ’print’ ‘(‘ <EXPRESSION> ‘)’ <EXPRESSION> à <X> {'|' <X>} <X> à <Y> {'&' <Y>} <Y> à ['!'] <R> <R> à <E> {('>'|'<'|'=='|'!=') <E>} <E> à <A> {(’+'|'-’) <A>} <A> à <B> {('*'|'/') <B>} <B> à ['-'] <C> <C> à integer | octal | hexadecimal | binary | true | false | string | char | float | identifier|'(' <EXPRESSION> ')'

  7. jgs New Rules

  8. Dr. Javier Gonzalez-Sanchez | Compilers | 8 jgs Assignment 2

    | Code ------------ program(root);

  9. Dr. Javier Gonzalez-Sanchez | Compilers | 9 jgs Assignment 2

    | Code public static void RULE_PROGRAM() { if (tokens.get(currentToken).getWord().equals(“{”)) { currentToken++; else error(1); RULE_BODY(); if (tokens.get(currentToken).getWord().equals(“}”)) currentToken++; else error(2); } PROGRAM

  10. Dr. Javier Gonzalez-Sanchez | Compilers | 10 jgs Assignment 2

    | Code public static void RULE_BODY() { while (!tokens.get(currentToken).getWord().equals(“}”)) { if (tokens.get(currentToken).getToken().equals(“identifier”)) { RULE_ASSIGNMENT(); if (tokens.get(currentToken).getWord().equals(“;”)) { currentToken++; else error(3); } else if (tokens.get(currentToken).getToken().equals(“int”) | ...) { RULE_VARIABLE(); if (tokens.get(currentToken).getWord().equals(";")) { currentToken++; else error(3); } else if (tokens.get(currentToken).getWord().equals(“while”)) { RULE_WHILE(); } else if (tokens.get(currentToken).getWord().equals(“if”)) { RULE_IF(); } else if (tokens.get(currentToken).getWord().equals(“return”)) { RULE_RETURN(); if (tokens.get(currentToken).getWord().equals(“;”)) { currentToken++; else error(3); } else error(4); } } BODY

  11. Dr. Javier Gonzalez-Sanchez | Compilers | 11 jgs Assignment 2

    | Code public static void RULE_ASSIGNMENT() { } ASSIGNMENT

  12. Dr. Javier Gonzalez-Sanchez | Compilers | 12 jgs Assignment 2

    | Code public static void RULE_VARIABLE() { } VARIABLE

  13. Dr. Javier Gonzalez-Sanchez | Compilers | 13 jgs Assignment 2

    | Code public static void RULE_WHILE() { } WHILE

  14. Dr. Javier Gonzalez-Sanchez | Compilers | 14 jgs Assignment 2

    | Code public static void RULE_IF() { } IF

  15. Dr. Javier Gonzalez-Sanchez | Compilers | 15 jgs Assignment 2

    | Code public static void RULE_RETURN() { } RETURN

  16. Dr. Javier Gonzalez-Sanchez | Compilers | 16 jgs Assignment 2

    | Code public static void RULE_PRINT () { } PRINT

  17. Dr. Javier Gonzalez-Sanchez | Compilers | 17 jgs Assignment 2

    | Code public static void RULE_C() { } C

  18. Dr. Javier Gonzalez-Sanchez | Compilers | 18 jgs Questions

  19. Dr. Javier Gonzalez-Sanchez | Compilers | 19 jgs Homework Start

    Working on a Parser (version 2)

  20. Dr. Javier Gonzalez-Sanchez | Compilers | 20 jgs Homework Review

    Recursion

  21. jgs Compilers Javier Gonzalez-Sanchez, Ph.D. [email protected] Spring 2024 Copyright. These

    slides can only be used as study material for the Compilers course at Universidad Panamericana. They cannot be distributed or used for another purpose.
