Message-Driven Architecture is the foundation for building reactive microservices (responsive, resilient, elastic).
See why in this presentation and how to do it on AWS.

Jérôme Van Der Linden

January 27, 2021
Tweet

More Decks by Jérôme Van Der Linden

Other Decks in Technology

Transcript

  1. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Jerome Van Der Linden (@jeromevdl)
    Message-Driven Architecture with AWS
    Worldwide Software Architecture Summit
    26th of January 2021

    View Slide

  2. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Who am I ?
    Jérôme Van Der Linden
    Solutions Architect @ AWS (Geneva, Switzerland)
    Former consultant, developer, tech lead, agile &
    devops coach, architect @ OCTO Technology
    Husband and Dad of 3
    @jeromevdl

    View Slide

  3. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Agenda
    Monolith to Microservices
    Microservices to Reactive Microservices
    Message-Driven Architecture on AWS
    Wrap-up

    View Slide

  4. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Monoliths to Microservices

    View Slide

  5. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Monoliths
    Do not throw the baby out with the bath water…
    - Simple to develop and refactor
    - Simple to test (integration, end-to-end)
    - Single deployment process
    - Single application to monitor
    - Consistency
    https://martinfowler.com/bliki/MonolithFirst.html

    View Slide

  6. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Monoliths
    … but definitely some limits!
    - Strong coupling: less flexibility / agility
    - High impact of change
    - Redeploy everything
    - Risks of blast radius
    - Reliability
    - One failure can bring down the whole application
    - Rigid scaling
    - Often stateful
    - Limited to the database scalability
    - Development lifecycle is typically slow
    - Continuous deployment is difficult
    - Barrier to adopting new technologies

    View Slide

  7. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Microservices
    Microservices to the rescue…
    - Reduced coupling
    - Smaller impact of changes
    - Independent deployments
    - Better reliability
    - Independent scaling
    - Smaller unit of development:
    - Humanely understandable
    - More suitable for adopting new technologies

    View Slide

  8. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Microservices
    … but it is not that magic!
    - Reduced coupling
    - Smaller impact of changes
    - Independent deployments
    - Better reliability
    - Independent scaling
    - Smaller unit of development:
    - Humanely understandable
    - More suitable for adopting new technologies
    Are you sure?

    View Slide

  9. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Microservices to Reac8ve
    Microservices

    View Slide

  10. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Microservices communica=on
    Order
    Service
    Invoice
    Service

    View Slide

  11. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Synchronous communica=on
    Order
    Service
    Invoice
    Service

    201
    created
    201
    created

    View Slide

  12. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark

    Synchronous communica=on
    Order
    Service
    Invoice
    Service
    500
    internal
    server
    error
    503
    service
    unavailable

    View Slide

  13. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Synchronous communica=on
    What’s the problem ?
    - No isolation between services è still coupled
    - Risk of timeout or cascading failures è still unreliable
    - What if the signature of invoice API change ? è still dependent

    View Slide

  14. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Reac=ve Principles
    Responsive
    Resilient
    Elastic
    Message-Driven
    https://www.reactivemanifesto.org/

    View Slide

  15. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Message-Driven (Asynchronous) Communica=on
    Order
    Service
    Invoice
    Service

    202
    accepted

    order
    created

    View Slide

  16. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Message-Driven (Asynchronous) Communica=on
    Order
    Service
    Invoice
    Service

    202
    accepted

    order
    created

    View Slide

  17. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Message-Driven (Asynchronous) Communica=on
    Isolation between services:
    - Less risk of timeout è more responsive
    - No more cascading failure è more resilient è more responsive
    - What if the signature of invoice API change ? è No problem !

    View Slide

  18. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Message-Driven Architecture on AWS

    View Slide

  19. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    (Serverless) Messaging services on AWS
    Amazon SNS Amazon
    EventBridge
    Amazon SQS

    View Slide

  20. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple Queue Service (SQS)
    Producer SQS Queue
    Decouple
    producers from
    consumers.
    Messages polled
    by consumers
    Amazon SQS
    Fully managed
    Message Queuing
    service
    Consumers
    AWS Lambda
    Container
    Instance / VM
    Standard
    • At-least once delivery
    • Best-effort ordering
    Messages are stored
    up to 14 days.

    View Slide

  21. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple Queue Service (SQS)
    Producer Consumers
    AWS Lambda
    Amazon SQS
    Fully managed
    Message Queuing
    service
    SQS Queue
    Decouple
    producers from
    consumers
    Messages polled
    by consumers
    Container
    Instance / VM
    FIFO
    • Exactly once delivery
    • Keep ordering
    1
    2
    3

    View Slide

  22. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple Queue Service (SQS)
    Producer Consumers
    AWS Lambda
    Amazon SQS
    Fully managed
    Message Queuing
    service
    SQS Queue
    Decouple
    producers from
    consumers
    Long Polling
    Container
    Instance / VM

    View Slide

  23. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple Queue Service (SQS)
    Producer Consumers
    AWS Lambda
    Amazon SQS
    Fully managed
    Message Queuing
    service
    SQS Queue
    Decouple
    producers from
    consumers
    Messages polled
    by consumers
    Container
    Instance / VM
    Dead-letter Queue
    If a message can’t be processed successfully
    it can be held in a queue

    View Slide

  24. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Common paIern with SQS: Storage-first
    Amazon API Gateway Amazon SQS Queue
    Dead letter Queue
    AWS Lambda
    Client

    View Slide

  25. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple No=fica=on Service (SNS)
    Amazon SNS
    Fully managed
    publish & subscribe
    messaging service
    SNS Topic
    Decouple message
    publisher from
    subscribers with topics
    Publisher
    Messages pushed to
    subscribers
    Subscribers
    AWS Lambda
    Amazon SQS
    HTTP/S
    Email / SMS
    Amazon Kinesis
    Data Firehose

    View Slide

  26. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple No=fica=on Service (SNS)
    Amazon SNS
    Fully managed
    publish & subscribe
    messaging service
    SNS Topic
    Decouple message
    publisher from
    subscribers with topics
    Publisher
    FIFO
    Subscribers
    AWS Lambda
    Amazon SQS
    FIFO
    HTTP/S
    Email / SMS
    Amazon Kinesis
    Data Firehose
    1
    2

    View Slide

  27. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple No=fica=on Service (SNS)
    Fan Out
    Publisher Amazon SNS
    Fully managed
    publish & subscribe
    messaging service
    SNS Topic
    Decouple message
    publisher from
    subscribers with topics
    Subscribers
    AWS Lambda
    Amazon SQS
    HTTP/S
    Email / SMS
    Amazon Kinesis
    Data Firehose

    View Slide

  28. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple No=fica=on Service (SNS)
    Publisher Amazon SNS
    Fully managed
    publish & subscribe
    messaging service
    SNS Topic
    Decouple message
    publisher from
    subscribers with topics
    Message
    Filtering
    Filter messages
    according to
    subscription
    filter policies
    Subscribers
    AWS Lambda
    Amazon SQS
    HTTP/S
    Email / SMS
    Amazon Kinesis
    Data Firehose

    View Slide

  29. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon Simple No=fica=on Service (SNS)
    Publisher Amazon SNS
    Fully managed
    publish & subscribe
    messaging service
    SNS Topic
    Decouple message
    publisher from
    subscribers with topics
    Message
    Filtering
    Filter messages
    according to
    subscription
    filter policies
    Dead-letter Queue
    If a subscriber is unavailable,
    messages can be held in a queue
    Subscribers
    AWS Lambda
    Amazon SQS
    HTTP/S
    Email / SMS
    Amazon Kinesis
    Data Firehose

    View Slide

  30. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Common paIern with SNS & SQS: Topic-Queue Chaining
    Amazon SQS
    Queue A
    Backend A
    Publisher Amazon SNS
    Topic
    Amazon SQS
    Queue B
    Backend B
    Amazon SQS
    Queue C
    Backend C

    View Slide

  31. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon EventBridge
    Amazon
    EventBridge
    Fully managed
    event bus to
    connect applications
    Event Sources
    AWS Services
    Custom events
    SaaS events Events pushed
    to targets
    Rules
    Rules filter
    and send events
    to target
    Event Bus
    Default event bus
    Custom event bus
    SaaS event bus
    Decouple event
    sources and targets
    Targets (20+)
    AWS Lambda
    Amazon SQS
    Amazon SNS
    AWS Step
    Functions
    Amazon Kinesis
    AWS Batch
    Amazon API
    Gateway
    Amazon EC2
    Instance
    Amazon ECS
    Task

    View Slide

  32. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon EventBridge
    Event Sources
    Amazon
    EventBridge
    Fully managed
    event bus to
    connect applications
    Event Bus
    Targets (20+)
    AWS Lambda
    Amazon SQS
    AWS Services
    Custom events
    SaaS events
    Default event bus
    Custom event bus
    SaaS event bus
    Rules
    Amazon SNS
    AWS Step
    Functions
    Amazon Kinesis
    AWS Batch
    Amazon API
    Gateway
    Amazon EC2
    Instance
    Amazon ECS
    Task
    Dead-letter
    Queue
    If a target is unavailable,
    events can be held in a queue

    View Slide

  33. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon EventBridge
    Event Sources
    Amazon
    EventBridge
    Fully managed
    event bus to
    connect applications
    Event Bus
    Targets (20+)
    AWS Lambda
    Amazon SQS
    AWS Services
    Custom events
    SaaS events
    Default event bus
    Custom event bus
    SaaS event bus
    Rules
    Amazon SNS
    AWS Step
    Functions
    Amazon Kinesis
    AWS Batch
    Amazon API
    Gateway
    Amazon EC2
    Instance
    Amazon ECS
    Task
    Event Archive
    Store all events
    and enables replays

    View Slide

  34. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Amazon EventBridge
    Event Sources
    Amazon
    EventBridge
    Fully managed
    event bus to
    connect applications
    Event Bus
    Targets (20+)
    AWS Lambda
    AWS Services
    Custom events
    SaaS events
    Default event bus
    Custom event bus
    SaaS event bus
    Rules
    AWS Step
    Functions
    AWS Batch
    Amazon API
    Gateway
    Amazon EC2
    Instance
    Amazon ECS
    Task
    Schema Registry
    Collection of event
    structures (schema)

    Code Binding
    Schema
    Discovery
    Schema
    Publication

    View Slide

  35. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Common paIern with EventBridge: Microservices Choreography

    View Slide

  36. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Wrap-up

    View Slide

  37. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Services Comparison
    Amazon SQS Amazon SNS
    Amazon
    EventBridge
    Type Queue (Pull) Publish / Subscribe (Push) Publish / Subscribe (Push)
    Persistence
    Yes
    (Up to 14 days, default: 4 days)
    No
    (retry up to 23 days + DLQ)
    No
    (retry up to 24h + DLQ + Archives)
    Ordering FIFO FIFO No
    Delivery Standard: at least once
    FIFO: exactly once
    Standard: at least once
    FIFO: exactly once
    At least once
    Filtering Yes Yes
    No
    Consumers Millions 5 per rule
    /
    Target services Lambda (+ compute & SDK) 2 (+ HTTP/SMS/Email/Push) 20+
    Throughput *
    Price *
    Standard: Almost unlimited
    FIFO: 3 000 TPS (soft)
    Standard: 30 000 TPS (soft)
    FIFO: 300 TPS (soft)
    10 000 TPS (soft)
    $ per million API requests
    Standard ≤ 0.4 / FIFO ≤ 0.5
    $ per million API requests: 0.5 $ per million events: 1
    * depends on the region (us-east-1)

    View Slide

  38. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Conclusion
    Message-Driven architectures drive resilience and elas3city è responsiveness
    Asynchronous Events
    Improve responsiveness
    and reduce dependencies
    Event Stores
    Buffer messages until services
    are available to process
    Event Routers
    Abstract producers and
    consumers from each other

    View Slide

  39. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Resources

    View Slide

  40. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    • Building event-driven applications with Amazon EventBridge
    • https://virtual.awsevents.com/media/1_w2mhd582
    • Scalable serverless event-driven architectures with SNS, SQS & Lambda
    • https://virtual.awsevents.com/media/1_o5hp8egy
    • Decoupling serverless workloads with Amazon EventBridge
    • https://virtual.awsevents.com/media/1_upe6mtew
    • Choosing the right event-routing service for serverless: EventBridge, SNS, or SQS
    • https://lumigo.io/blog/choosing-the-right-event-routing-on-aws-eventbridge-sns-or-sqs

    View Slide

  41. © 2021, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    © 2019, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Thank you
    @jeromevdl

    View Slide
