  1. Less is more
    Do more with less code in a serverless world
    Jerome Van Der Linden
    Geneva Serverless Meetup - 26/05/2020

    View Slide

  2. About me
    • In a previous life, ”Mr Cut Cut” (M. Coupe coupe)
    • Developer & software craftsman
    • And now, Solutions Architect @ AWS
    2
    linkedin.com/in/jeromevdl/
    Jerome Van Der Linden

    View Slide

  3. Few principles
    Clean Code

    View Slide

  4. SOLID
    4
    S Single Responsibility Principle
    O Open / closed Principle
    L Liskov substitution Principle
    I Interface segregation Principle
    D Dependency Inversion Principle

    View Slide

  5. Single Responsibility Principle
    5
    “A class or module should have one,
    and only one, reason to be changed”
    - Robert C. Martin, aka Uncle Bob

    View Slide

  6. YAGNI (You Ain’t Gonna Need It)
    6
    Just because you can,
    doesn’t mean you should…

    View Slide

  7. KISS
    7

    View Slide

  8. 8
    And many more…
    Clean Code
    DRY
    Don’t Repeat Yourself
    Law of Demeter
    Broken window
    theory
    Boy scout rule
    Not invented here

    View Slide

  9. How to apply those principles?
    In the serverless world

    View Slide

  10. Serverless World?
    10
    Serverless == FAAS
    Function As A Service

    View Slide

  11. Serverless World?
    11
    Serverless ⊃ FAAS
    Function As A Service

    View Slide

  12. AWS Serverless world
    12
    AWS
    Lambda
    AWS
    Fargate
    Amazon
    API Gateway
    Amazon
    SNS
    Amazon
    SQS
    COMPUTE
    DATA STORES
    INTEGRATION
    Amazon Aurora
    Serverless
    Amazon
    S3
    Amazon
    DynamoDB
    Amazon
    EventBridge
    FAAS
    AWS
    Step Functions
    AWS
    AppSync

    View Slide

  13. Single Responsibility Principle
    ü Do’s ✘ Don’ts *
    - Input validation
    - Business logic /!\
    - Transform data
    - Return result
    - Event/Input Filtering
    - Transport data
    - Orchestration & long
    transactions
    - Retry/Failure handling
    * Most of the time

    View Slide

  14. Event Filtering
    15
    SNS
    Topic
    Publisher
    if event_type == 'order_created’:
    lambda_client.invoke('OrderCreation', ...)
    elif event_type == 'order_placed’:
    lambda_client.invoke('OrderPlacement', ...)
    elif event_type == 'order_cancelled’:
    lambda_client.invoke('OrderCancelation', ...)
    OrderCreation
    OrderPlacement
    OrderCancellation
    {
    "event_type": "order_placed",
    "order": {
    "id": "232134",
    "amount": "2341,45",
    "stock_ref": "AMZN”
    }
    }
    the wrong way
    function code
    Input event
    OrderFiltering

    View Slide

  15. Event Filtering with SNS
    16
    OrderCreation
    OrderPlacement
    OrderCancellation
    Publisher
    OrderCreationEvent:
    Type: AWS::SNS::Subscription
    Properties:
    TopicArn: 'arn:aws:sns:eu-central-1:123456789:OrdersTopic’
    Protocol: lambda
    Endpoint: 'arn:aws:lambda:eu-central-1:123456789:function:OrderCreation’
    FilterPolicy:
    event_type:
    - order_created
    SNS
    Topic
    https://docs.aws.amazon.com/sns/latest/dg/sns-subscription-filter-policies.html
    Cloudformation template
    {
    "event_type": [
    "order_created"
    ]
    }
    Filter policy

    View Slide

  16. Event Filtering with SNS
    17
    OrderCreation
    OrderPlacement
    OrderCancellation
    Publisher
    OrderPlacementEvent:
    Type: AWS::SNS::Subscription
    Properties:
    TopicArn: 'arn:aws:sns:eu-central-1:123456789:OrdersTopic’
    Protocol: lambda
    Endpoint: 'arn:aws:lambda:eu-central-1:123456789:function:OrderPlacement’
    FilterPolicy:
    event_type:
    - order_placed
    SNS
    Topic
    Cloudformation template

    View Slide

  17. Event Filtering with SNS
    18
    OrderCreation
    OrderPlacement
    OrderCancellation
    Publisher
    OrderCancellationEvent:
    Type: AWS::SNS::Subscription
    Properties:
    TopicArn: 'arn:aws:sns:eu-central-1:123456789:OrdersTopic’
    Protocol: lambda
    Endpoint: 'arn:aws:lambda:eu-central-1:123456789:function:OrderCancellation’
    FilterPolicy:
    event_type:
    - order_cancelled
    SNS
    Topic
    Cloudformation template

    View Slide

  18. Event Filtering with EventBridge
    19
    https://aws.amazon.com/blogs/compute/reducing-custom-code-by-using-advanced-rules-in-amazon-eventbridge/
    {
    "Source": "custom.myATMapp",
    "EventBusName": "default",
    "DetailType": "transaction",
    "Time": "Wed Jan 29 2020 08:03:18 GMT-0500",
    "Detail":{
    "action": "withdrawal",
    "location": "NY-NYC-001",
    "amount": 300,
    "result": "approved",
    "transactionId": "123456",
    "cardPresent": true,
    "partnerBank": "Example Bank",
    "remainingFunds": 722.34
    }
    }
    {
    "source": [ "custom.myATMapp" ],
    "detail-type": [ "transaction" ],
    "detail": {
    "amount": [ { "numeric": [ ">", 300 ] } ]
    }
    }
    {
    "source": [ "custom.myATMapp" ],
    "detail-type": [ "transaction" ],
    "detail": {
    "location": [ { "prefix": "NY-NYC-" } ]
    }
    }
    {
    "source": [ "custom.myATMapp" ],
    "detail-type": [ "transaction" ],
    "detail": {
    "partnerBank": [ { "exists": true } ]
    }
    }
    {
    "source": [ "custom.myATMapp" ],
    "detail-type": [ "transaction" ],
    "detail": {
    "result": [ "approved" ],
    "partnerBank": [ { "exists": false } ],
    "location": [ { "anything-but": "NY-NYC-002" }]
    }
    }

    View Slide

  19. Orchestration
    20
    the wrong way
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…

    View Slide

  20. Simple orchestration with Lambda destinations
    21
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    Lambda Destinations

    View Slide

  21. Simple orchestration with Lambda destinations
    22
    Amazon SNS
    Amazon
    EventBridge
    Amazon
    Cloudwatch Logs
    Amazon S3
    Amazon SES
    AWS Config
    Amazon
    CloudFormation
    AWS
    CodeCommit
    A
    S
    Y
    N
    C
    "DestinationConfig": {
    "onSuccess": {
    "Destination": "arn:aws:lambda:..."
    },
    "onFailure": {
    "Destination": "arn:aws:sqs:..."
    }
    }
    Cloudformation template
    Amazon SNS
    Amazon
    EventBridge
    Amazon
    SQS
    AWS Lambda
    if success:
    return {...}
    else:
    raise Exception(‘Failure', {...})
    function code
    Lambda function
    A
    S
    Y
    N
    C

    View Slide

  22. Advanced orchestration with Step Functions
    23
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…

    View Slide

  23. Advanced orchestration with Step Functions
    24
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    {
    "StartAt": "SimpleInvocation",
    "States": {
    "SimpleInvocation": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:eu-central-
    1:123456789012:function:HelloFunction",
    "Next": "Choose1or2"
    },

    View Slide

  24. Advanced orchestration with Step Functions
    25
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "Choose1or2": {
    "Type": "Choice",
    "Choices": [
    {
    "Variable": "$.foo”,
    "NumericEquals": 1,
    "Next": "Lambda1"
    },
    {
    "Variable": "$.foo",
    "NumericEquals": 2,
    "Next": "ParallelInvocation"
    }
    ],
    "Default": "Unmatched"
    },

    View Slide

  25. Advanced orchestration with Step Functions
    26
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "Lambda1": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:eu-
    central-1:123456789012:function:Lambda1",
    "Next": "SuccessOrFailure"
    },

    View Slide

  26. Advanced orchestration with Step Functions
    27
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "SuccessOrFailure": {
    "Type": "Choice",
    "Choices": [
    {
    "Variable": "$.status",
    "StringEquals": "SUCCESS",
    "Next": "SendNotification"
    },
    {
    "Variable": "$.status",
    "StringEquals": "FAILURE",
    "Next": "QueueError"
    }
    ],
    "Default": "Unmatched"
    }

    View Slide

  27. Advanced orchestration with Step Functions
    28
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "SendNotification": {
    "Type": "Succeed"
    },
    "QueueError": {
    "Type": "Fail"
    },

    View Slide

  28. Advanced orchestration with Step Functions
    29
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "ParallelInvocation": {
    "Type": "Parallel",
    "Branches": [
    {
    "StartAt": "SendApprovalRequest",
    "States": {
    "SendApprovalRequest": {
    // ...
    }
    },
    {
    "StartAt": "Loop",
    "States": {
    "Loop": {
    // ...
    }
    }
    }

    View Slide

  29. Advanced orchestration with Step Functions
    30
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "SendApprovalRequest": {
    "Type": "Task",
    "Resource":
    "arn:aws:states:::lambda:invoke.waitForTaskToken",
    "Parameters": {
    "FunctionName": "sendMailForApprovalFunction",
    "Payload": {
    "step.$": "$$.State.Name",
    "model.$": "$.data",
    "token.$": "$$.Task.Token"
    }
    },
    "ResultPath": "$.output",
    "Next": "Approved",
    "Catch": [
    {
    "ErrorEquals": [ "rejected" ],
    "ResultPath": "$.reason",
    "Next": "Rejected"
    }
    ]
    }
    SendTaskSuccess
    SendTaskFailure

    View Slide

  30. Advanced orchestration with Step Functions
    31
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…
    "Loop": {
    "Type": "Map",
    "ItemsPath": "$.loopItems",
    "Iterator": {
    "StartAt": "LoopLambda",
    "States": {
    "LoopLambda": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:us-east-
    1:123456789012:function:LoopFunction",
    "End": true
    }
    }
    },
    "End": true
    }

    View Slide

  31. Advanced orchestration with Step Functions
    32
    invoke
    invoke
    if (…
    )
    invoke //
    else
    if (success)
    Notify with SNS
    n * invoke
    if (failure)
    Enqueue error
    notify with SNS
    need approval
    App…

    View Slide

  32. TL;DR Single Responsibility Principle
    33
    èKeep your code focused on the business
    This is not the responsibility of a to do orchestration

    View Slide

  33. You ain’t gonna need it
    34
    Welcome in the “functionless” world !

    View Slide

  34. API Gateway Service Proxy
    35

    View Slide

  35. Ex: insert data in DynamoDB
    36
    Resource: /comments
    HTTP Method: POST
    HTTP Request Body: {
    "pageId": "example-page-id",
    "userName": "ExampleUserName",
    "message": "Example comment to be added."
    }
    Table: Comments
    commentId: String
    userName: String
    message: String
    pageId: String
    PK: commentId
    API Gateway DynamoDB
    Lambda
    var AWS = require('aws-sdk');
    var ddb = new AWS.DynamoDB({apiVersion: '2012-08-10'});
    exports.handler = async function(event, context) {
    var params = {
    TableName: 'Comments’,
    Item: {
    'commentId' : {
    S: 'randomid’
    },
    'pageId' : {
    S: event.pageId
    },
    'userName' : {
    S: event.userName
    },
    'message' : {
    S: event.message
    }
    }
    };
    ddb.putItem(params, function(err, data) {
    if (err) {
    console.log("Error", err);
    } else {
    console.log("Success", data);
    }
    });
    }

    View Slide

  36. Ex: insert data in DynamoDB
    37
    Resource: /comments
    HTTP Method: POST
    HTTP Request Body: {
    "pageId": "example-page-id",
    "userName": "ExampleUserName",
    "message": "Example comment to be added."
    }
    Table: Comments
    commentId: String
    userName: String
    message: String
    pageId: String
    PK: commentId
    API Gateway DynamoDB

    View Slide

  37. Ex: insert data in DynamoDB
    38
    Resource: /comments
    HTTP Method: POST
    HTTP Request Body: {
    "pageId": "example-page-id",
    "userName": "ExampleUserName",
    "message": "Example comment to be added."
    }
    Table: Comments
    commentId: String
    userName: String
    message: String
    pageId: String
    PK: commentId
    API Gateway DynamoDB

    View Slide

  38. Ex: insert data in DynamoDB
    39
    Resource: /comments
    HTTP Method: POST
    HTTP Request Body: {
    "pageId": "example-page-id",
    "userName": "ExampleUserName",
    "message": "Example comment to be added."
    }
    Table: Comments
    commentId: String
    userName: String
    message: String
    pageId: String
    PK: commentId
    API Gateway DynamoDB

    View Slide

  39. Ex: insert data in DynamoDB
    40
    Resource: /comments
    HTTP Method: POST
    HTTP Request Body: {
    "pageId": "example-page-id",
    "userName": "ExampleUserName",
    "message": "Example comment to be added."
    }
    Table: Comments
    commentId: String
    userName: String
    message: String
    pageId: String
    PK: commentId
    API Gateway DynamoDB

    View Slide

  40. Ex: insert data in DynamoDB
    41
    Resource: /comments
    HTTP Method: POST
    HTTP Request Body: {
    "pageId": "example-page-id",
    "userName": "ExampleUserName",
    "message": "Example comment to be added."
    }
    Table: Comments
    commentId: String
    userName: String
    message: String
    pageId: String
    PK: commentId
    API Gateway DynamoDB

    View Slide

  41. Use with caution
    42
    • Not a generic design pattern, not
    always applicable
    • Apply when the lambda is a
    passthrough (no business code, just
    mapping)
    • Mapping can sometimes be complex
    (Velocity Template Language)

    View Slide

  42. Step Function integrations
    43
    "QueueError": {
    "Type": "Task",
    "Resource": "arn:aws:states:::sqs:sendMessage",
    "Parameters": {
    "QueueUrl": "https://sqs.eu-central-1.amazonaws.com/123456789012/myQueue",
    "MessageBody.$": "$.input.message"
    },
    "End": true
    },
    "SendNotification": {
    "Type": "Task",
    "Resource": "arn:aws:states:::sns:publish",
    "Parameters": {
    "TopicARN": "arn:aws:sns:eu-central-
    1:123456789012:myTopic",
    "Subject": "Lambda1 has successfully finish its job",
    "Message.$" : "$.input.message"
    },
    "End": true
    },
    SQS
    SNS

    View Slide

  43. Step Function integrations
    44
    AWS Batch Amazon DynamoDB Amazon ECS / Fargate Amazon EMR AWS Glue
    Amazon SageMaker Amazon SNS Amazon SQS AWS Step Functions
    AWS Lambda
    AWS CodeBuild

    View Slide

  44. TL;DR You Ain’t Gonna Need It
    45
    è is not always needed
    You can save costs and
    optimize performance
    when functions are just passthrough/mapping

    View Slide

  45. Keep it simple stupid
    46
    Lighten your functions

    View Slide

  46. Keep your functions simple & stupid
    nano functions
    API GW
    /res1
    /res2
    /res3
    = 1 handler (1 function)
    = 1 file
    Not that stupid
    so they need
    sisters to do the job !

    View Slide

  47. Keep your functions simple & stupid
    nano functions
    API GW
    /res1
    /res2
    /res3
    = 1 handler (1 function)
    = 1 file
    function-lith
    API GW
    /{proxy}
    /res1
    /res2
    /res3
    That’s really not simple & stupid!
    = 1 handler (1 function)
    = 1 file

    View Slide

  48. Keep your functions simple & stupid
    nano functions
    API GW
    /res1
    /res2
    /res3
    function-lith
    API GW
    /{proxy}
    /res1
    /res2
    /res3
    = 1 handler (1 function)
    = 1 file
    fat functions
    API GW
    /res1
    /res2
    /res3
    = 3 handlers (3 functions)
    = 1 file
    = 1 handler (1 function)
    = 1 file

    View Slide

  49. Keep your functions simple & stupid
    50
    nano functions
    API GW
    /res1
    /res2
    /res3
    function-lith
    API GW
    /{proxy}
    /res1
    /res2
    /res3
    fat functions
    = 1 handler (1 function)
    = 1 file
    API GW
    = 3 handler (3 functions)
    = 1 file
    micro functions
    API GW
    /res1
    /res2
    /res3
    /res1
    /res2
    /res3
    = 1 handler (1 function)
    = 1 file
    = 1 handler (1 function)
    = 1 file

    View Slide

  50. Keep your functions simple & stupid
    https://github.com/cdk-patterns/serverless/tree/master/the-lambda-trilogy
    Potential duplicated code ++
    Cognitive burden ++
    Coupled functions
    Coupled deployments
    nano functions
    API GW
    /res1
    /res2
    /res3
    function-lith
    API GW
    /{proxy}
    /res1
    /res2
    /res3
    fat functions
    = 1 handler (1 function)
    = 1 file
    API GW
    = 3 handler (3 functions)
    = 1 file
    micro functions
    /res1
    /res2
    /res3
    = 1 handler (1 function)
    = 1 file
    API GW
    /res1
    /res2
    /res3
    = 1 handler (1 function)
    = 1 file
    Stupidity Complexity
    FAAS?
    Longer cold starts ++
    Risk of blast radius
    Framework dependent
    Longer cold starts
    Risk of blast radius
    Potential duplicated code
    Cognitive burden

    View Slide

  51. TL;DR Keep it simple stupid
    52
    Lighter functions
    =
    Easier to test and maintain
    Faster to start: less cold start
    More scalable: higher throughput
    More secure: less permission needed

    View Slide

  52. Conclusion
    No function is easier to manage
    than ‘no function’
    – me
    è If you can do better without a
    function, just do it
    è Else, apply software
    craftsmanship principles
    (clean code, tests, code reviews…)
    “No server is easier to
    manage than ‘no server’”
    – Werner Vogels

    View Slide

  53. Thank You
    @jeromevdl
    https://tinyurl.com/ydeowzut
    2-minutes survey:

    View Slide

  54. Appendix

    View Slide

  55. AWSTemplateFormatVersion: 2010-09-09
    Resources:
    API:
    Type: AWS::ApiGateway::RestApi
    Properties:
    Name: !Sub ${AWS::StackName}-api-
    ${AWS::AccountId}
    APIDeployment:
    Type: AWS::ApiGateway::Deployment
    Properties:
    RestApiId: !Ref API
    StageName: prod
    DependsOn:
    - ListBucketAPI
    APIBucketResource:
    Type: AWS::ApiGateway::Resource
    Properties:
    ParentId: !GetAtt API.RootResourceId
    PathPart: "{bucket}"
    RestApiId: !Ref API
    ListBucketAPI:
    Type: AWS::ApiGateway::Method
    Properties:
    HttpMethod: GET
    ResourceId: !Ref APIBucketResource
    RestApiId: !Ref API
    AuthorizationType: NONE
    Integration:
    Credentials: 'arn:aws:iam::1234567890:role/role-demo-api-gw-s3-integration’
    IntegrationHttpMethod: GET
    IntegrationResponses:
    - StatusCode: "200"
    PassthroughBehavior: WHEN_NO_MATCH
    RequestParameters:
    integration.request.header.Content-Type: method.request.header.Content-Type
    integration.request.header.x-amz-acl: "'authenticated-read’”
    integration.request.path.bucket: method.request.path.bucket
    Type: AWS
    Uri: !Sub arn:aws:apigateway:${AWS::Region}:s3:path/{bucket}
    MethodResponses:
    - StatusCode: "200"
    RequestParameters:
    method.request.path.bucket: true
    method.request.header.Content-Type: false
    API Gateway & S3 sample
    https://docs.aws.amazon.com/apigateway/latest/developerguide/integrating-api-with-aws-services-s3.html

    View Slide

  56. 57
    Advanced orchestration with Step Functions
    {
    "StartAt": "SimpleInvocation",
    "States": {
    "SimpleInvocation": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:eu-central-1:123456789012:function:HelloFunction",
    "Next": "Choose1or2"
    },
    "Choose1or2": {
    "Type": "Choice",
    "Choices": [
    {
    "Variable": "$.foo",
    "NumericEquals": 1,
    "Next": "Lambda1"
    },
    {
    "Variable": "$.foo",
    "NumericEquals": 2,
    "Next": "ParallelInvocation"
    }
    ],
    "Default": "Unmatched"
    },
    "Lambda1": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:eu-central-1:123456789012:function:Lambda1",
    "Next": "SuccessOrFailure"
    },
    "SuccessOrFailure": {
    "Type": "Choice",
    "Choices": [
    {
    "Variable": "$.status",
    "StringEquals": "SUCCESS",
    "Next": "SendNotification"
    },
    {
    "Variable": "$.status",
    "StringEquals": "FAILURE",
    "Next": "QueueError"
    }
    ],
    "Default": "Unmatched"
    },
    "SendNotification": {
    "Type": "Succeed"
    },
    "QueueError": {
    "Type": "Fail"
    },
    "ParallelInvocation": {
    "Type": "Parallel",
    "Branches": [
    {
    "StartAt": "SendApprovalRequest",
    "States": {
    "SendApprovalRequest": {
    "Type": "Task",
    "Resource": "arn:aws:states:::lambda:invoke.waitForTaskToken",
    "Parameters": {
    "FunctionName": "sendMailForApprovalFunction",
    "Payload": {
    "step.$": "$$.State.Name",
    "model.$": "$.data",
    "token.$": "$$.Task.Token"
    }
    },
    "ResultPath": "$.output",
    "Next": "Approved",
    "Catch": [
    {
    "ErrorEquals": [ "rejected" ],
    "ResultPath": "$.reason",
    "Next": "Rejected"
    }
    ]
    },
    "Approved": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:eu-central-1:123456789012:function:Lambda1",
    "End": true
    },
    "Rejected": {
    "Type": "Fail"
    }
    }
    },
    {
    "StartAt": "Loop",
    "States": {
    "Loop": {
    "Type": "Map",
    "ItemsPath": "$.loopItems",
    "Iterator": {
    "StartAt": "LoopLambda",
    "States": {
    "LoopLambda": {
    "Type": "Task",
    "Resource": "arn:aws:lambda:us-east-1:123456789012:function:LoopFunction",
    "End": true
    }
    }
    },
    "End": true
    }
    }
    }
    ],
    "End": true
    },
    "Unmatched": {
    "Type": "Fail",
    "Error": "DefaultStateError",
    "Cause": "No Matches!"
    }
    }
    }

    View Slide
