Progressive Image Rendering

Progressive Image Rendering

From my talk at Frontfest 2017 in Moscow, Russia.

43b3d09e5d13d076f5e120383702c04f?s=128

José M. Pérez

December 03, 2017
Tweet

More Decks by José M. Pérez

Other Decks in Technology

Transcript

  1. Progressive image rendering José M. Pérez · Web dev at

    Spotify @jmperezperez
  2. Привет! What will we see today? PROGRESSIVE IMAGE RENDERING @jmperezperez

  3. Improve perceived performance of images on the web PROGRESSIVE IMAGE

    RENDERING @jmperezperez
  4. by - not making requests - optimizing images - rendering

    previews PROGRESSIVE IMAGE RENDERING @jmperezperez
  5. PROGRESSIVE IMAGE RENDERING @jmperezperez About me

  6. Page Load Time PROGRESSIVE IMAGE RENDERING @jmperezperez

  7. Version A FrontFest 2017 Speakers & Schedule 0.0s 0.3s 0.6s

    0.9s 1.2s Version B FrontFest 2017 Speakers & Schedule 0.0s 0.3s 0.6s 0.9s 1.2s FrontFest 2017 Speakers & Schedule FrontFest 2017 FrontFest 2017 PROGRESSIVE IMAGE RENDERING @jmperezperez
  8. Source https://www.smashingmagazine.com/2015/11/why-performance-matters-part-2-perception-management/ PROGRESSIVE IMAGE RENDERING @jmperezperez

  9. PROGRESSIVE IMAGE RENDERING @jmperezperez SpeedIndex = 1 − ∫ 0

    end 100 V C end = end time in milliseconds VC = % visually complete
  10. PROGRESSIVE IMAGE RENDERING @jmperezperez WebPageTest

  11. PROGRESSIVE IMAGE RENDERING @jmperezperez

  12. Avoiding this: PROGRESSIVE IMAGE RENDERING @jmperezperez

  13. Techniques to improve perceived performance Server-side rendering Critical CSS Async

    JS Async fonts PROGRESSIVE IMAGE RENDERING @jmperezperez
  14. What about images? PROGRESSIVE IMAGE RENDERING @jmperezperez

  15. PROGRESSIVE IMAGE RENDERING @jmperezperez images 1,815kB (54%) scripts 457kB (14%)

    other 1,106kB (33%) source: http archive 1 nov 2017
  16. PROGRESSIVE IMAGE RENDERING @jmperezperez Minimalist | Flat Design

  17. PROGRESSIVE IMAGE RENDERING @jmperezperez Not that long ago

  18. Optimise your images PROGRESSIVE IMAGE RENDERING @jmperezperez TIP 1

  19. PROGRESSIVE IMAGE RENDERING @jmperezperez

  20. right format gif | png | jpg | webp |

    <the_next_thing> PROGRESSIVE IMAGE RENDERING @jmperezperez <picture> <source type="image/webp" srcset="2700x1209/my-image.webp 2700w, 1024x1024/my-image.webp 1024w, 600x600/my-image.webp 600w" sizes="100vw" /> <source srcset="2700x1209/my-image.jpg 2700w, 1024x1024/my-image.jpg 1024w, 600x600/my-image.jpg 600w" sizes="100vw" /> <img class="rsImg" src="600x600/my-image.jpg" alt="My beautiful image" /> </picture>
  21. compression PROGRESSIVE IMAGE RENDERING @jmperezperez · lossless · perceptual

  22. PROGRESSIVE IMAGE RENDERING @jmperezperez Responsive TIP 2 1 column 2

    columns 3 columns
  23. <img sizes="(max-width: 30em) 100vw, (max-width: 50em) 50vw, calc(33vw - 100px)"

    srcset="red-square-200.jpg 200w, red-square-400.jpg 400w, red-square-800.jpg 800w, red-square-1600.jpg 1600w" src="red-square-400.jpg" alt="Red Square"> PROGRESSIVE IMAGE RENDERING @jmperezperez Challenge: Keeping in sync markup and CSS Example R E S P O N S I V E I M A G E S
  24. Lazy-load images PROGRESSIVE IMAGE RENDERING @jmperezperez TIP 3

  25. <img> above the fold & Lazy below the fold PROGRESSIVE

    IMAGE RENDERING @jmperezperez
  26. Intersection Observer PROGRESSIVE IMAGE RENDERING @jmperezperez

  27. // load image when it's within 100px of the viewport

    const options = { rootMargin: '100px' } const callback = entries => { entries.forEach(entry => { if (entry.intersectionRatio > 0) { // load image } }); }; const observer = new IntersectionObserver(callback, options); observer.observe(document.querySelector('.lazy-img')); PROGRESSIVE IMAGE RENDERING @jmperezperez Example I N T E R S E C T I O N O B S E R V E R
  28. class LazyImage extends React.Component { constructor() { this.observer = new

    IntersectionObserver(entries => { if (entries[0].intersectionRatio > 0) { // load! } }); this.element = null; /* render() will set it through a ref */ } componentDidMount() { this.observer.observe(this.element); } componentWillUnmount() { this.observer.unobserve(this.element); } ... } PROGRESSIVE IMAGE RENDERING @jmperezperez Encapsulating in React I N T E R S E C T I O N O B S E R V E R
  29. PROGRESSIVE IMAGE RENDERING @jmperezperez Using image.decode() I M A G

    E D E C O D I N G
  30. // Image loading with predecoding const img = new Image();

    img.src = "image.jpg"; img.decode().then(() => { document.body.appendChild(img); }).catch(() => { throw new Error('Could not load/decode big image.'); }); PROGRESSIVE IMAGE RENDERING @jmperezperez Using image.decode() I M A G E D E C O D I N G Add an image to the DOM without causing a decoding delay. Track the proposal on https://github.com/whatwg/html/issues/1920 TIP 4
  31. What to show while the image is loading PROGRESSIVE IMAGE

    RENDERING @jmperezperez
  32. Options PROGRESSIVE IMAGE RENDERING P L A C E H

    O L D E R S Nothing Placeholder Solid colour or gradient Progressive image loading or "Blur-up" @jmperezperez
  33. Examples of solid color PROGRESSIVE IMAGE RENDERING @jmperezperez

  34. PROGRESSIVE IMAGE RENDERING @jmperezperez

  35. PROGRESSIVE IMAGE RENDERING @jmperezperez

  36. PROGRESSIVE IMAGE RENDERING @jmperezperez

  37. Examples of Progressive Image Loading PROGRESSIVE IMAGE RENDERING @jmperezperez

  38. PROGRESSIVE IMAGE RENDERING @jmperezperez Medium

  39. PROGRESSIVE IMAGE RENDERING @jmperezperez Quartz (qz.com)

  40. PROGRESSIVE IMAGE RENDERING @jmperezperez Quora

  41. PROGRESSIVE IMAGE RENDERING @jmperezperez How it is done

  42. PROGRESSIVE IMAGE RENDERING @jmperezperez Markup - Eg Medium <figure> <div>

    <div/> <!-- this div keeps the aspect ratio so the placeholder doesn't collapse --> <img/> <!-- this is a tiny image with a small resolution (e.g. ~27x17) and low quality --> <canvas/> <!-- takes the above image and applies a blur filter --> <img/> <!-- the large image to be displayed --> <noscript/> <!-- fallback for no JS --> </div> </figure>
  43. PROGRESSIVE IMAGE RENDERING @jmperezperez Thumbnails

  44. PROGRESSIVE IMAGE RENDERING @jmperezperez Thumbnails

  45. Getting creative with SVGs PROGRESSIVE IMAGE RENDERING @jmperezperez

  46. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Edges Source: https://www.polygon.com/a/ps4-review

  47. PROGRESSIVE IMAGE RENDERING @jmperezperez Drawing edges with SVG Source: https://codepen.io/jmperez/pen/rxxRRg​

  48. PROGRESSIVE IMAGE RENDERING @jmperezperez Drawing bitmap images Canny Edge Detector

  49. PROGRESSIVE IMAGE RENDERING @jmperezperez <svg> <polyline points="51,1 61,1 61,2 56,4

    56,3"/> <polyline points="52,1 50,2 51,3 50,4 50,9 46,10 46,8 48,8 48,9"/> <polyline points="61,4 61,5 58,6"/> ... <polyline points="62,58 61,59 61,60 50,62 50,61 51,61"/> </svg> 1. Find edges with canny edge detector 2. Create lines 3. Use JS and SVG to animate How to draw bitmaps
  50. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Shapes Source: http://www.samcodes.co.uk/project/geometrize-haxe-web/

  51. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Shapes SVG - 10

    shapes SVG - 100 shapes Original 0.74kB 3.5kB 101kB
  52. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Shapes + Blur SVG

    - 10 shapes + Blur SVG 100 shapes + Blur (JPEG or WebP) + Blur 0.8kB 3.6kB 0.5kB (JPEG) 0.09 kB (WebP)
  53. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Silhouettes / Traces Source:

    https://codepen.io/ainalem/full/aLKxjm/
  54. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Silhouettes / Traces Source:

    https://www.npmjs.com/package/potrace
  55. PROGRESSIVE IMAGE RENDERING @jmperezperez SVG - Silhouettes / Traces Source:

    https://twitter.com/Tholle1234/status/920423596346019840
  56. PROGRESSIVE IMAGE RENDERING @jmperezperez Should we do this? Just because

    you can it doesn't mean you should
  57. PROGRESSIVE IMAGE RENDERING @jmperezperez Reduce requests Choose the right format

    and optimise Embrace responsive images Try to lazy load Think about placeholders Innovate! Summary
  58. The Web is fun. PROGRESSIVE IMAGE RENDERING @jmperezperez

  59. spotify.com/jobs talk with me for more info

  60. Thanks! @jmperezperez Slides on https://slides.com/jmperez
