1. Developing modular
   (Web) Applications
   Using the Fenix Framework
   Luis Cruz & João Carvalho
   April 2014


   View Slide

2. Outline
   • FenixEdu
   • What does modular mean?
   • Benefits
   • Challenges


   View Slide

3. View Slide

4. View Slide

5. View Slide

6. 12 Years Ago


   View Slide

7.
   Presentation Tier — Based on Struts
   Application Tier
   POJO’s
   Persistence Tier — Based on OJB
   XML Configuration
   Service Manager
   Services
   Filters
   XML!
   Configuration
   DTO’s
   XML!
   Configuration
   Data Repository
   JDBC
   JSP!
   Views
   Actions
   SQL Statements


   View Slide

8. The 11 "simple" steps
   1. Create a POJO to represent the domain object;
   2. Write the SQL schema to store the domain object;
   3. Write the xml configuration to map the POJO against the SQL
   schema;
   4. Write SQL statements for custom reading of the domain object
   (in case something other than a read by ID or a read all was
   necessary);
   5. Create data transfer objects for passing information to the
   presentation tier;
   6. Write services at the application level for creating, reading,
   updating and deleting the domain object;
   7. Write access control filters to limit who can invoke services;
   8. Write service and filter configurations in a xml file;
   9. Create JSP views for presenting information to the users;
   10. Write Actions to handle user requests;
   11. Configure struts xml files to specify the application flow.


   View Slide

9. Fenix Framework


   View Slide

10.
    Presentation Tier — Based on Struts
    Application Tier
    Persistence Tier — Fenix Framework Based
    Service Manager
    Services
    Filters
    XML!
    Configuration
    Domain!
    Objects
    XML!
    Configuration
    Data Repository
    JDBC
    JSP!
    Views
    Actions
    DML Configuration


    View Slide

11. This allowed the
    application to grow


    View Slide

12. User
    Person


    View Slide

13. Domain Model Complexity


    View Slide

14. Quickly grew out of
    control


    View Slide

15. • Long compilation times
    • Large memory requirements
    • Poor expansibility
    • Poor encapsulation
    • It becomes easy to break domain constraints


    View Slide

16. Solution?


    View Slide

17. Modularisation


    View Slide

18. What is modularisation?


    View Slide

19. Divide and conquer


    View Slide

20. Breaking your application
    into smaller parts


    View Slide

21. Clear boundary
    definition


    View Slide

22. Build your application
    from the small modules


    View Slide

23. Persistence Tier — Fenix Framework Based
    Data Repository
    Fenix Application
    Request Controller
    Module 1
    Presentation Tier
    Application Tier
    Domain
    Objects
    Module 2
    Presentation Tier
    Application Tier
    Domain
    Objects
    ...
    Module N
    Presentation Tier
    Application Tier
    Domain
    Objects


    View Slide

24. Benefits


    View Slide

25. Separation of
    Concerns


    View Slide

26. Greater Cohesion


    View Slide

27. Abstraction


    View Slide

28. Encapsulation


    View Slide

29. Independent roadmaps


    View Slide

30. Improved
    development process


    View Slide

31. Reusability


    View Slide

32. Pluggability


    View Slide

33. DOT!
    IST
    DOT !
    IST-ID
    FENIX !
    IST
    DOT !
    ADIST
    DOT !
    Reitoria!
    UL
    SOTIS
    JobBank
    SIADAP!
    Processes
    SnailMail!
    Tracking
    Domain!
    Browser
    Renderers
    Organizationa
    l!
    Module
    Fenix!
    Framework
    Regulation!
    Dispatch
    Financial!
    Projects
    Workflow
    File!
    Manage-ment
    Working!
    Capital
    Expenditure
    s
    Messaging
    Inst.!
    Protocols
    Bennu !
    Framework
    WebServic
    e
    Scaffolding
    Authentica-
    tion
    i18n
    Groups &
    ACLs
    WebApp
    Scaffolding
    Scheduler
    Persistent
    IO
    Indexing
    Support


    View Slide

34. Challenges


    View Slide

35. Thinking in modules
    (Or thinking inside the box)


    View Slide

36. Choosing your build
    tool


    View Slide

37. Versioning


    View Slide

38. Versioning
    • What’s the difference between:
    • v1.1.3 and v1.1.4?
    • v1.2.3 and v1.3.5?
    • v1.3.5 and v2.0.0?


    View Slide

39. Semantic Versioning
    • Major Version (2.0.0)
    • API Disruption
    • Minor Version (1.2.0)
    • New (backward-compatible) API
    • Revision (1.2.3)
    • Bug fixes and internal changes
    http://semver.org/


    View Slide

40. You must explicitly declare
    your dependencies
    (and their versions)


    View Slide

41. A @
    1.0.0
    B @
    2.3.1


    View Slide

42. Dependency Nightmare
    org.fenixedu:bennu-portal:jar:2.3.0-SNAPSHOT
    +- org.fenixedu:bennu-core:jar:2.3.0-SNAPSHOT:compile
    | +- org.jasig.cas.client:cas-client-core:jar:3.3.0:compile
    | \- org.antlr:antlr-runtime:jar:3.5.2:compile
    +- org.fenixedu:fenixedu-commons:jar:1.0.0:compile
    +- com.google.guava:guava:jar:15.0:compile
    +- joda-time:joda-time:jar:2.3:compile
    +- com.google.code.gson:gson:jar:2.2.4:compile
    +- javax.ws.rs:javax.ws.rs-api:jar:2.0:compile
    +- com.mitchellbosecke:pebble:jar:1.0.0:compile
    | \- com.coverity.security:coverity-escapers:jar:1.1:compile
    +- pt.ist:fenix-framework-core-api:jar:2.4.0:compile
    | +- pt.ist:fenix-framework-core-dml:jar:2.4.0:compile
    | | +- commons-lang:commons-lang:jar:2.6:compile
    | | \- antlr:antlr:jar:2.7.7:compile
    | +- javax.transaction:jta:jar:1.1:compile
    | +- pt.ist.esw:advice-runtime:jar:1.8:compile
    | \- org.jgroups:jgroups:jar:3.2.7.Final:compile
    +- pt.ist:fenix-framework-core-consistency-predicates:jar:2.4.0:compile
    | +- jvstm:jvstm-fenix:jar:1.4:compile
    | \- pt.ist:fenix-framework-core-adt-bplustree:jar:2.4.0:compile
    +- javax.servlet:javax.servlet-api:jar:3.0.1:provided
    +- org.slf4j:slf4j-api:jar:1.7.5:compile
    \- junit:junit:jar:4.11:test
    \- org.hamcrest:hamcrest-core:jar:1.3:test


    View Slide

43. Managing dependencies
    can be chaotic!


    View Slide

44. Inconsistencies
    A @
    1.0.0
    C @
    2.3.1
    B @
    2.3.5
    C @
    3.4.0
    YourApp @
    1.0.0
    Conflict!


    View Slide

45. Circular Dependencies
    A @
    1.0.0
    C @
    2.3.1
    B @
    2.3.5


    View Slide

46. Managing Graph
    Complexity


    View Slide

47. Source Management


    View Slide

48. One branch per
    feature


    View Slide

49. Tagging every release


    View Slide

50. Distributed tools help
    a lot…


    View Slide

51. Artifact Management


    View Slide

52. Building everything from
    source can be painful
    (I’m looking at you Gentoo)


    View Slide

53. Where to keep
    compiled artifacts?


    View Slide

54. Artifact Repository


    View Slide

55. Modular
    Infrastructure


    View Slide

56. Many frameworks are
    not modular-friendly…


    View Slide

57. … and the language
    doesn’t help.
    Java 9, prove me wrong!


    View Slide

58. Fenix Framework


    View Slide

59. Fenix Framework 1.x
    FenixFramework.initialize(new Config() {
    {
    dbAlias = "//localhost:3306/hellodb";
    dbUsername = "hello";
    dbPassword = "world";
    domainModelPath = "src/main/dml/domain.dml";
    rootClass = MyRootClass.class;
    }
    });


    View Slide

60. Single Domain Model!


    View Slide

61. No bidirectional
    relations


    View Slide

62. No encapsulation


    View Slide

63. How to allow modules to
    define their own DMLs?


    View Slide

64. Fenix Framework 2.0


    View Slide

65. Make modularity a
    core concern


    View Slide

66. Creates the complete
    domain from the
    dependency graph


    View Slide

67. Bidirectional
    Dependencies


    View Slide

68. Each module can only
    see its sub-graph
    Which is different for every module


    View Slide

69. Fenix Framework 2.0
    dbAlias=//localhost:3306/fenix1
    dbUsername=root
    dbPassword=
    fenix-framework.properties


    View Slide

70. Presentation


    View Slide

71. • Structure and styling
    • Menus and navigation
    • Multiple presentation technologies


    View Slide

72. Bennu Portal


    View Slide

73. It’s magic!


    View Slide

74. Integration framework


    View Slide

75. Uniform styling across
    the entire application


    View Slide

76. Dynamic menu
    construction/rendering


    View Slide

77. Functionalities only
    render their body


    View Slide

78. Out of the box scaffolding
    for web applications


    View Slide

79. Build your own
    application in 2 minutes


    View Slide

80. Q?


    View Slide

81. Join Us
    http://fenixedu.org/dev
    github.com/fenixedu!
    facebook.com/fenixedu
    hello@fenixedu.org


    View Slide

82. Developing modular
    (Web) Applications
    Using the Fenix Framework
    Luis Cruz & João Carvalho
    April 2014
