THEMEN AI Development Business App Development Frontend
Technologies Development, Consulting, Coaching, Training KONTAKT Mail: [email protected] LinkedIn: www.linkedin.com/in/jörgneumann X: @JoergNeumann Web: www.neogeeks.de JÖRG NEUMANN Founder & CEO NeoGeeks GmbH Azure OpenAI Service, Azure Machine Learning Platform -
WEB UX DEVELOPMENT ZIELE großartige UX entwerfen guter
Designer-/Entwickler-Workflow Oberfläche mit Animationen anreichern Performant auf allen Plattformen -
„Animationen machen den Screen lebendig!“ Geben Feedback zu Benutzerinteraktionen
Lenken die Aufmerksamkeit auf ein bestimmtes Detail Helfen beim Übergang zwischen Seiten oder Zuständen -
CSS ANIMATIONS <html> <head> <style> div { width: 100px; height:
100px; background-color: red; position: relative; animation-name: example; animation-duration: 4s; animation-iteration-count: 3; } @keyframes example { 0% {background-color:red; left:0px; top:0px;} 25% {background-color:yellow; left:200px; top:0px;} 50% {background-color:blue; left:200px; top:200px;} 75% {background-color:green; left:0px; top:200px;} 100% {background-color:red; left:0px; top:0px;} } </style> </head> <body> <div></div> </body> </html> Synchronisation mit anderen Animationen schwierig anwendbar auf HTML und nur begrenzt auf SVG flexible Steuerung zur Laufzeit schwierig -
SVG DEFINITION Scalable Vector Graphics Abbildung 2-dimensionaler Vektorgrafiken
Skalierbarkeit ohne Qualitätsverlust XML-basiertes Markup Wird von allen Browsern unterstützt <svg id="svg" width="210" height="210" transform="scale(1.2)"> <g id="layer1"> <circle style="fill:#bfc5cc;fill-opacity:1;…" id="path4142-7" cx="80" cy="80" r="80"></g> <path style="fill:#ffffff;fill-opacity:1;…" type="arc" cx="80" cy="80" rx="65" ry="65" start="2.7246043" end="0.40454034" d="M 20.569666,106.32557 A 65,65 0 0 1…" open="true"></path> … -
SVG VORTEILE Hat eine klare Semantik Erstellung geometrischer
Formen Grafischer Effekte (SVG Filter Effects, Typografie, Animation, Transparency Masks, …) Dynamische Image-Erstellung Export aus Grafik-Tools möglich <svg id="svg" width="210" height="210" transform="scale(1.2)"> <g id="layer1"> <circle style="fill:#bfc5cc;fill-opacity:1;…" id="path4142-7" cx="80" cy="80" r="80"></g> <path style="fill:#ffffff;fill-opacity:1;…" type="arc" cx="80" cy="80" rx="65" ry="65" start="2.7246043" end="0.40454034" d="M 20.569666,106.32557 A 65,65 0 0 1…" open="true"></path> … -
GRUNDELEMENTE Rechteck Ellipse Polygon Text Polygonzug Bild Linie Kreis <rect
x="10" y="10" width="10" height="10" /> <circle cx="10" cy="10" r="10" /> <ellipse cx="10" cy="10" rx="10" ry="5" /> <line x1="10" y1="10" x2="50" y2="100" /> <polygon points="10,10 20,20 30,30 20,20 10,10" /> <polyline points="10,10 20,20 30,30 20,20 10,10" /> <image width="10" height="10" xlink:href="image.png" /> <Text x="10" y="10" font-size="10">SVG</Text > -
PFADE M L Z C Q A move to line
to close path curve to curve to (quadratic bézier) elliptical arc <path d="M 100 100 L 300 100 L 200 300 z"/> -
SVG ANIMATIONS <svg width="140" height="140" viewBox="0 0 140 140"> <g>
<circle cx="70" cy="70" r="60" style="fill:none;" /> <circle cx="70" cy="70" r="60" fill="none" stroke="url(#gra)" stroke-width="10" /> <animateTransform attributeName="transform" begin="0s" dur="2s" type="rotate" from="0 70 70" to="360 70 70" repeatCount="indefinite" /> </g> <defs> <linearGradient id="gra"> <stop offset="0%" stop-color="#186aab" /> <stop offset="30%" stop-color="#186aab" /> <stop offset="30%" stop-color="#e2e2e2" /> <stop offset="100%" stop-color="#e2e2e2" /> </linearGradient> </defs> </svg> Funktioniert nur mit SVG- und nicht mit HTML-Elementen SVG kann auch per CSS animiert werden (aber nur rudimentär) Es können auch Pfade animiert werden (Morphing möglich) -
D3 DEFINITION Library zur effizienten Erzeugung und Manipulation von
SVG Visualisierung von Daten in Form von Charts, Diagrammen, … Entwicklung komplexer UI Komponenten Enthält auch ein Animations- und ein Interaktionsmodell -
WEB ANIMATIONS API DEFINTION Ein einheitliches Modell zur Steuerung
von Animationen (CSS Transitions, CSS Animations, SVG Animation) Animationen per Script erzeugen und steuern Effizienter als window.requestAnimationFrame(), �.animate() und co. Hardware Accelerated Keine Abhängigkeit zu Frameworks erforderlich -
WEB ANIMATIONS API DEFINITION Animationen per JavaScript erstellen und
steuern Basiert auf CSS Animation und CSS Transitions BROWSER SUPPORT -
WEB ANIMATIONS API var animation = element.animate(keyframes, options); SYNTAX ball.animate([
{ opacity: 1, backgroundColor: 'green' }, { opacity: 0, backgroundColor: 'red' } ], 2000); BEISPIEL ball.animate([ { opacity: 1, backgroundColor: 'green' }, { opacity: 0, backgroundColor: 'red' } ], { duration: 2000, fill: 'forwards', iterations: '3', easing: 'ease-in'}); -
KEYFRAMES STEUERN element.animate([ { opacity: 1, offset: 1 }, {
opacity: 0.5, offset: 0.3 } ], { opacity: 0, offset: 1 } ], 2000); EXPLIZITE OFFSETS element.animate([ { opacity: 1, easing: 'ease-out' }, { opacity: 0.5, easing: 'ease-in' } ], { opacity: 1 } ], 2000); EASING -
ANIMATION STEUERN element.animate([ { opacity: 1, offset: 1 }, {
opacity: 0.5, offset: 0.3 } ], { opacity: 0, offset: 1 } ], { duration: 1000, iterations: '2', direction: 'alternate', easing: 'ease-in' }); WEITERE OPTIONEN -
EFFECT TIMING OPTIONS ATTRIBUTE Delay: Verzögerung bis zum Start
in Millisekunden Direction: Richtung (normal, reverse, alternate, alternate-reverse) Duration: Anzahl an Millisekunden bis zum Ende der Iteration Easing: Funktion (linear, ease, ease-in, ease-out, ease-in-out, cubic-bezier) endDelay: Verzögerung am Ende der Animation Fill: wann der Effekt angewandt wird (backwards, forwards, both, none) iterationStart: Wann soll die Iteration starten? Iterations: Anzahl der Wiederholungen oder “Infinity” -
TRANSFORMATION TYPEN Translate Rotate Scale Transform
| Bewegen | Drehen | Größenänderung | Formänderung -
TRANSFORMATIONEN ball.animate([ { transform: 'translateX(0%) translateY(0%) rotate(0deg)' }, { transform:
'translateX(1000%) translateY(100%) rotate(360deg)' }, ], { duration: 1000, iterations: '2', direction: 'alternate', easing: 'ease-in' }); BEISPIEL -
ANIMATIONEN GLOBAL DEFINIEREN var ballKeyframes = new KeyframeEffect( ball, [
{ transform: 'translateX(0%) translateY(0%) rotate(0deg)' }, { transform: 'translateX(1000%) translateY(100%) rotate(360deg)' }, ], { duration: 1000, fill: 'forwards', iterations: '2', direction: 'alternate'} ); BEISPIEL var ballAnimation = new Animation(ballKeyframes, document.timeline); function clickHandler(event) { ballAnimation.play(); } -
WEITERE FUNKTIONEN ANIMATION STEUERN Animation.finish() geht zum Ende der
Animation Animation.cancel() unterbricht die Animation Animation.reverse() wechselt die Richtung der Animation GESCHWINDIGKEIT STEUERN Animation.playbackRate steuert die Ablaufgeschwindigkeit, wobei 1 Normalgeschwindigkeit darstellt -
CALLBACKS AND PROMISES HANDLER onFinish(): Handler für Finish Event
onCancel(): Handler für Cancel Event function startAnimation() { ballAnimation.onfinish = finishAnimation; ballAnimation.play(); } function finishAnimation(event) { alert("Finish!"); } -
ANIMATION LIBRARIES & TOOLS SNAP.SVG snapsvg.io D3.JS d3js.org
GSAP greensock.com/gsap SVGATOR https://www.svgator.com -
FAZIT Lessons learned Animationen machen Frontends lebendig CSS
ist nicht immer die optimal Bei komplexen UI Widgets hilft SVG Das richtige Tooling ist entscheidend Die Web Animations API hilft -
WEB ANIMATIONS RESOURCES SPECS & REFERENCES W3C Spec: Web
Animations MDN: Using the Web Animations API Can I Use: Browser Support von Web Animations -
SVG TOOLS SVG-Edit https://code.google.com/archive/p/svg-edit/ GSAP DrawSVGPlugin https://greensock.com/drawsvg
Paint Code https://www.paintcodeapp.com -
ANIMATION LIBRARIES SNAP.SVG snapsvg.io D3.JS d3js.org GSAP
greensock.com/gsap
