Présentation Vert.x et Microservices avec Scala, Java, Kotlin
pour le DevFest Toulouse 2017 - 28 Septembre

Philippe CHARRIERE

October 08, 2017
Tweet

More Decks by Philippe CHARRIERE

Other Decks in Programming

Transcript

  1. #BSGTHEPLAN @DevFestToulouse bonjour Philippe Charrière @clever_cloud ! @k33g_org G @k33g

    I ❤JavaScript, I Java, I JVM, I Golo, I Scala (depuis peu…)
  2. #BSGTHEPLAN @DevFestToulouse pourquoi ce talk? Trouver un sujet de talk

    Le préparer pendant les heures de travail (démos) monter en compétence sur les microservices (et vert.x) partager ce que j’ai appris
  3. #BSGTHEPLAN @DevFestToulouse microservices? A microservice application is a collection of

    autonomous services that, individually, "do one thing well", but work together to perform more intricate operations. Instead of a single complex system, you build and manage a suite of relatively simple services that might interact in complex ways. These services collaborate with each other through technology-agnostic messaging protocols, either point-to-point or asynchronously.
  4. #BSGTHEPLAN @DevFestToulouse micro, m’ouais … Distribuer les fonctionnalités et les

    données Identifier les microservices, les trouver, … Gérer la cohérence et la fiabilité du réseau pour chacun Composants distribués + Technologies différentes = “new modes of failure” Quand ça ne marche pas … Complexité d’investigation
  5. #BSGTHEPLAN @DevFestToulouse microservices vert.x Simplicité, Polyglotte C’est un framework simple:

    Maîtrise de ce que vous faites BackendDiscovery / Service Discovery (ex: Hazelcast, Redis, …) Stabilité & Résilience Circuit Breakers Health Checks
  6. #BSGTHEPLAN @DevFestToulouse 1 microservice REST Vert.x public class BaseStar extends

    AbstractVerticle { public void start() { Router router = Router.router(vertx); router.route().handler(BodyHandler.create()); router.get("/api/hello").handler(context -> { context.response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "hello").encodePrettily()); }); Integer httpPort = 8080; HttpServer server = vertx.createHttpServer(); server.requestHandler(router::accept).listen(httpPort, result -> { System.out.println(" Listening on " + httpPort); }); } }
  7. #BSGTHEPLAN @DevFestToulouse s’enregistrer - ServiceDiscovery public class BaseStar extends AbstractVerticle

    { public void start() { // Discovery settings ServiceDiscoveryOptions serviceDiscoveryOptions = new ServiceDiscoveryOptions(); // Redis settings with the standard Redis Backend Integer redisPort = Integer.parseInt(Optional.ofNullable(System.getenv("REDIS_PORT")).orElse("6379")); String redisHost = Optional.ofNullable(System.getenv("REDIS_HOST")).orElse("127.0.0.1"); String redisAuth = Optional.ofNullable(System.getenv("REDIS_PASSWORD")).orElse(null); String redisRecordsKey = Optional.ofNullable(System.getenv("REDIS_RECORDS_KEY")).orElse("vert.x.ms"); discovery = ServiceDiscovery.create( vertx, serviceDiscoveryOptions.setBackendConfiguration( new JsonObject() .put("host", redisHost) .put("port", redisPort) .put("auth", redisAuth) .put("key", redisRecordsKey) )); } }
  8. #BSGTHEPLAN @DevFestToulouse s’enregistrer - ServiceDiscovery public class BaseStar extends AbstractVerticle

    { public void start() { // Discovery settings ServiceDiscoveryOptions serviceDiscoveryOptions = new ServiceDiscoveryOptions(); // Redis settings with the standard Redis Backend Integer redisPort = Integer.parseInt(Optional.ofNullable(System.getenv("REDIS_PORT")).orElse("6379")); String redisHost = Optional.ofNullable(System.getenv("REDIS_HOST")).orElse("127.0.0.1"); String redisAuth = Optional.ofNullable(System.getenv("REDIS_PASSWORD")).orElse(null); String redisRecordsKey = Optional.ofNullable(System.getenv("REDIS_RECORDS_KEY")).orElse("vert.x.ms"); discovery = ServiceDiscovery.create( vertx, serviceDiscoveryOptions.setBackendConfiguration( new JsonObject() .put("host", redisHost) .put("port", redisPort) .put("auth", redisAuth) .put("key", redisRecordsKey) )); } }
  9. #BSGTHEPLAN @DevFestToulouse s’enregistrer - Record public class BaseStar extends AbstractVerticle

    { public void start() { // microservice options Haikunator haikunator = new HaikunatorBuilder().setTokenLength(6).build(); String niceName = haikunator.haikunate(); String serviceName = Optional.ofNullable(System.getenv("SERVICE_NAME")).orElse("the-plan")+"-"+niceName; String serviceHost = Optional.ofNullable(System.getenv("SERVICE_HOST")).orElse("localhost"); Integer servicePort = Integer.parseInt(Optional.ofNullable(System.getenv("SERVICE_PORT")).orElse("80")); String serviceRoot = Optional.ofNullable(System.getenv("SERVICE_ROOT")).orElse("/api"); String color = Optional.ofNullable(System.getenv("COLOR")).orElse("FFD433"); // create the microservice record record = HttpEndpoint.createRecord( serviceName, serviceHost, servicePort, serviceRoot ); } }
  10. #BSGTHEPLAN @DevFestToulouse s’enregistrer - Record public class BaseStar extends AbstractVerticle

    { public void start() { // microservice options Haikunator haikunator = new HaikunatorBuilder().setTokenLength(6).build(); String niceName = haikunator.haikunate(); String serviceName = Optional.ofNullable(System.getenv("SERVICE_NAME")).orElse("the-plan")+"-"+niceName; String serviceHost = Optional.ofNullable(System.getenv("SERVICE_HOST")).orElse("localhost"); Integer servicePort = Integer.parseInt(Optional.ofNullable(System.getenv("SERVICE_PORT")).orElse("80")); String serviceRoot = Optional.ofNullable(System.getenv("SERVICE_ROOT")).orElse("/api"); String color = Optional.ofNullable(System.getenv("COLOR")).orElse("FFD433"); // create the microservice record record = HttpEndpoint.createRecord( serviceName, serviceHost, servicePort, serviceRoot ); } }
  11. #BSGTHEPLAN @DevFestToulouse s’enregistrer - MetaData public class BaseStar extends AbstractVerticle

    { public void start() { // add some metadata record.setMetadata(new JsonObject() .put("kind", "basestar") .put("message", "Hello ") .put("uri", "/coordinates") .put("raiders_counter", raidersCounter) .put("color", color) .put("app_id", Optional.ofNullable(System.getenv("APP_ID")).orElse("")) .put("instance_id", Optional.ofNullable(System.getenv("INSTANCE_ID")).orElse("")) .put("instance_type", Optional.ofNullable(System.getenv("INSTANCE_TYPE")).orElse("production")) .put("instance_number", Integer.parseInt(Optional.ofNullable(System.getenv("INSTANCE_NUMBER")).orElse("0"))) ); } }
  12. #BSGTHEPLAN @DevFestToulouse s’enregistrer & démarrer public class BaseStar extends AbstractVerticle

    { public void start() { Integer httpPort = Integer.parseInt(Optional.ofNullable(System.getenv("PORT")).orElse("8080")); HttpServer server = vertx.createHttpServer(); server.requestHandler(router::accept).listen(httpPort, result -> { if(result.succeeded()) { System.out.println(" Listening on " + httpPort); //publish the microservice to the discovery backend discovery.publish(record, asyncResult -> { if(asyncResult.succeeded()) { System.out.println("" + record.getRegistration()); } else { System.out.println("" + asyncResult.cause().getMessage()); } }); } else { System.out.println(" Houston, we have a problem: " + result.cause().getMessage()); } }); } }
  13. #BSGTHEPLAN @DevFestToulouse s’enregistrer & démarrer public class BaseStar extends AbstractVerticle

    { public void start() { Integer httpPort = Integer.parseInt(Optional.ofNullable(System.getenv("PORT")).orElse("8080")); HttpServer server = vertx.createHttpServer(); server.requestHandler(router::accept).listen(httpPort, result -> { if(result.succeeded()) { System.out.println(" Listening on " + httpPort); //publish the microservice to the discovery backend discovery.publish(record, asyncResult -> { if(asyncResult.succeeded()) { System.out.println("" + record.getRegistration()); } else { System.out.println("" + asyncResult.cause().getMessage()); } }); } else { System.out.println(" Houston, we have a problem: " + result.cause().getMessage()); } }); } }
  14. #BSGTHEPLAN @DevFestToulouse Routes | Router public class BaseStar extends AbstractVerticle

    { public void start() { Router router = Router.router(vertx); router.route().handler(BodyHandler.create()); router.get("/api/raiders").handler(context -> { discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if (ar.succeeded()) { context.response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonArray(ar.result()).encodePrettily()); } }); }); // serve static assets, see /resources/webroot directory router.route("/*").handler(StaticHandler.create()); Integer httpPort = Integer.parseInt(Optional.ofNullable(System.getenv("PORT")).orElse("8080")); HttpServer server = vertx.createHttpServer(); server.requestHandler(router::accept).listen(httpPort, result -> { }); } }
  15. #BSGTHEPLAN @DevFestToulouse GET | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { Router router = Router.router(vertx); router.route().handler(BodyHandler.create()); router.get("/api/raiders").handler(context -> { discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if (ar.succeeded()) { context.response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonArray(ar.result()).encodePrettily()); } }); }); // serve static assets, see /resources/webroot directory router.route("/*").handler(StaticHandler.create()); Integer httpPort = Integer.parseInt(Optional.ofNullable(System.getenv("PORT")).orElse("8080")); HttpServer server = vertx.createHttpServer(); server.requestHandler(router::accept).listen(httpPort, result -> { }); } }
  16. #BSGTHEPLAN @DevFestToulouse GET | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { Router router = Router.router(vertx); router.route().handler(BodyHandler.create()); router.get("/api/raiders").handler(context -> { discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if (ar.succeeded()) { context.response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonArray(ar.result()).encodePrettily()); } }); }); // serve static assets, see /resources/webroot directory router.route("/*").handler(StaticHandler.create()); Integer httpPort = Integer.parseInt(Optional.ofNullable(System.getenv("PORT")).orElse("8080")); HttpServer server = vertx.createHttpServer(); server.requestHandler(router::accept).listen(httpPort, result -> { }); } }
  17. #BSGTHEPLAN @DevFestToulouse POST | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { router.post("/api/raiders").handler(context -> { // I'm a new raider String registationId = Optional.ofNullable(context.getBodyAsJson().getString("registration")).orElse("unknown"); discovery.getRecord(r -> r.getRegistration().equals(registationId), asyncResRecord -> { // = raider's record if(asyncResRecord.succeeded()) { Record raiderRecord = asyncResRecord.result(); ServiceReference reference = discovery.getReference(raiderRecord); WebClient raiderClient = reference.getAs(WebClient.class); // ⚠ get a web client this.raidersCounter += 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, ar -> { }); this.raiderWorker(raiderRecord,raiderClient); // this is a worker context.response() // ✉ message to the raider .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "ok, registered").encodePrettily()); } }); }); } }
  18. #BSGTHEPLAN @DevFestToulouse POST | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { router.post("/api/raiders").handler(context -> { // I'm a new raider String registationId = Optional.ofNullable(context.getBodyAsJson().getString("registration")).orElse("unknown"); discovery.getRecord(r -> r.getRegistration().equals(registationId), asyncResRecord -> { // = raider's record if(asyncResRecord.succeeded()) { Record raiderRecord = asyncResRecord.result(); ServiceReference reference = discovery.getReference(raiderRecord); WebClient raiderClient = reference.getAs(WebClient.class); // ⚠ get a web client this.raidersCounter += 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, ar -> { }); this.raiderWorker(raiderRecord,raiderClient); // this is a worker context.response() // ✉ message to the raider .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "ok, registered").encodePrettily()); } }); }); } }
  19. #BSGTHEPLAN @DevFestToulouse POST | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { router.post("/api/raiders").handler(context -> { // I'm a new raider String registationId = Optional.ofNullable(context.getBodyAsJson().getString("registration")).orElse("unknown"); discovery.getRecord(r -> r.getRegistration().equals(registationId), asyncResRecord -> { // = raider's record if(asyncResRecord.succeeded()) { Record raiderRecord = asyncResRecord.result(); ServiceReference reference = discovery.getReference(raiderRecord); WebClient raiderClient = reference.getAs(WebClient.class); // ⚠ get a web client this.raidersCounter += 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, ar -> { }); this.raiderWorker(raiderRecord,raiderClient); // this is a worker context.response() // ✉ message to the raider .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "ok, registered").encodePrettily()); } }); }); } }
  20. #BSGTHEPLAN @DevFestToulouse POST | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { router.post("/api/raiders").handler(context -> { // I'm a new raider String registationId = Optional.ofNullable(context.getBodyAsJson().getString("registration")).orElse("unknown"); discovery.getRecord(r -> r.getRegistration().equals(registationId), asyncResRecord -> { // = raider's record if(asyncResRecord.succeeded()) { Record raiderRecord = asyncResRecord.result(); ServiceReference reference = discovery.getReference(raiderRecord); WebClient raiderClient = reference.getAs(WebClient.class); // ⚠ get a web client this.raidersCounter += 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, ar -> { }); this.raiderWorker(raiderRecord,raiderClient); // this is a worker context.response() // ✉ message to the raider .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "ok, registered").encodePrettily()); } }); }); } }
  21. #BSGTHEPLAN @DevFestToulouse POST | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { router.post("/api/raiders").handler(context -> { // I'm a new raider String registationId = Optional.ofNullable(context.getBodyAsJson().getString("registration")).orElse("unknown"); discovery.getRecord(r -> r.getRegistration().equals(registationId), asyncResRecord -> { // = raider's record if(asyncResRecord.succeeded()) { Record raiderRecord = asyncResRecord.result(); ServiceReference reference = discovery.getReference(raiderRecord); WebClient raiderClient = reference.getAs(WebClient.class); // ⚠ get a web client this.raidersCounter += 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, ar -> { }); this.raiderWorker(raiderRecord,raiderClient); // this is a worker context.response() // ✉ message to the raider .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "ok, registered").encodePrettily()); } }); }); } }
  22. #BSGTHEPLAN @DevFestToulouse POST | /api/raiders public class BaseStar extends AbstractVerticle

    { public void start() { router.post("/api/raiders").handler(context -> { // I'm a new raider String registationId = Optional.ofNullable(context.getBodyAsJson().getString("registration")).orElse("unknown"); discovery.getRecord(r -> r.getRegistration().equals(registationId), asyncResRecord -> { // = raider's record if(asyncResRecord.succeeded()) { Record raiderRecord = asyncResRecord.result(); ServiceReference reference = discovery.getReference(raiderRecord); WebClient raiderClient = reference.getAs(WebClient.class); // ⚠ get a web client this.raidersCounter += 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, ar -> { }); this.raiderWorker(raiderRecord,raiderClient); // this is a worker context.response() // ✉ message to the raider .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("message", "ok, registered").encodePrettily()); } }); }); } }
  23. #BSGTHEPLAN @DevFestToulouse HealthCheck ❤ public class BaseStar extends AbstractVerticle {

    public void start() { // health check of existing basestars HealthCheckHandler hch = HealthCheckHandler.create(vertx); hch.register("iamok", future -> discovery.getRecord(r -> r.getRegistration().equals(record.getRegistration()), ar -> { if(ar.succeeded()) { future.complete(); } else { // future.fail(ar.cause()); } }) ); router.get("/health").handler(hch); } }
  24. #BSGTHEPLAN @DevFestToulouse HealthCheck ❤ public class BaseStar extends AbstractVerticle {

    public void start() { // health check of existing basestars HealthCheckHandler hch = HealthCheckHandler.create(vertx); hch.register("iamok", future -> discovery.getRecord(r -> r.getRegistration().equals(record.getRegistration()), ar -> { if(ar.succeeded()) { future.complete(); } else { // future.fail(ar.cause()); } }) ); router.get("/health").handler(hch); } }
  25. #BSGTHEPLAN @DevFestToulouse HealthCheck ❤ public class BaseStar extends AbstractVerticle {

    public void start() { // health check of existing basestars HealthCheckHandler hch = HealthCheckHandler.create(vertx); hch.register("iamok", future -> discovery.getRecord(r -> r.getRegistration().equals(record.getRegistration()), ar -> { if(ar.succeeded()) { future.complete(); } else { // future.fail(ar.cause()); } }) ); router.get("/health").handler(hch); } }
  26. #BSGTHEPLAN @DevFestToulouse Worker private void raiderWorker(Record raiderRecord, WebClient raiderClient) {

    Raider thatRaider = new Raider( raiderRecord.getRegistration(), raiderRecord.getName(), raiderRecord.getMetadata().getJsonObject("coordinates").getDouble("x"), raiderRecord.getMetadata().getJsonObject("coordinates").getDouble("y"), new Constraints(5.0, 600.0, 600.0, 5.0) ); //… }
  27. #BSGTHEPLAN @DevFestToulouse Worker private void raiderWorker(Record raiderRecord, WebClient raiderClient) {

    //… vertx.setPeriodic(1000, timerID -> { // this is a worker // get the raiders list discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if(ar.succeeded()) { List<Record> raidersRecords = ar.result(); thatRaider.moveWith(raidersRecords, 300.0); thatRaider.moveCloser(raidersRecords, 300.0); thatRaider.moveAway(raidersRecords, 15.0); thatRaider.move(); // === try to contact the raider and post coordinates === raiderClient.post("/api/coordinates").sendJsonObject( new JsonObject() .put("x",thatRaider.x) .put("y",thatRaider.y) .put("xVelocity",thatRaider.xVelocity) .put("yVelocity",thatRaider.yVelocity), asyncPostRes -> { if(asyncPostRes.succeeded()) { System.out.println(" " + asyncPostRes.result().bodyAsJsonObject().encodePrettily()); } else { // ouch raidersCounter -= 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, asyncRecUpdateRes -> { vertx.cancelTimer(timerID);}); } } ); }); }); }
  28. #BSGTHEPLAN @DevFestToulouse Worker private void raiderWorker(Record raiderRecord, WebClient raiderClient) {

    //… vertx.setPeriodic(1000, timerID -> { // this is a worker // get the raiders list discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if(ar.succeeded()) { List<Record> raidersRecords = ar.result(); thatRaider.moveWith(raidersRecords, 300.0); thatRaider.moveCloser(raidersRecords, 300.0); thatRaider.moveAway(raidersRecords, 15.0); thatRaider.move(); // === try to contact the raider and post coordinates === raiderClient.post("/api/coordinates").sendJsonObject( new JsonObject() .put("x",thatRaider.x) .put("y",thatRaider.y) .put("xVelocity",thatRaider.xVelocity) .put("yVelocity",thatRaider.yVelocity), asyncPostRes -> { if(asyncPostRes.succeeded()) { System.out.println(" " + asyncPostRes.result().bodyAsJsonObject().encodePrettily()); } else { // ouch raidersCounter -= 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, asyncRecUpdateRes -> { vertx.cancelTimer(timerID);}); } } ); }); }); }
  29. #BSGTHEPLAN @DevFestToulouse Worker private void raiderWorker(Record raiderRecord, WebClient raiderClient) {

    //… vertx.setPeriodic(1000, timerID -> { // this is a worker // get the raiders list discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if(ar.succeeded()) { List<Record> raidersRecords = ar.result(); thatRaider.moveWith(raidersRecords, 300.0); thatRaider.moveCloser(raidersRecords, 300.0); thatRaider.moveAway(raidersRecords, 15.0); thatRaider.move(); // === try to contact the raider and post coordinates === raiderClient.post("/api/coordinates").sendJsonObject( new JsonObject() .put("x",thatRaider.x) .put("y",thatRaider.y) .put("xVelocity",thatRaider.xVelocity) .put("yVelocity",thatRaider.yVelocity), asyncPostRes -> { if(asyncPostRes.succeeded()) { System.out.println(" " + asyncPostRes.result().bodyAsJsonObject().encodePrettily()); } else { // ouch raidersCounter -= 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, asyncRecUpdateRes -> { vertx.cancelTimer(timerID);}); } } ); }); }); }
  30. #BSGTHEPLAN @DevFestToulouse Worker private void raiderWorker(Record raiderRecord, WebClient raiderClient) {

    //… vertx.setPeriodic(1000, timerID -> { // this is a worker // get the raiders list discovery.getRecords(r -> r.getMetadata().getString("kind").equals("raider") , ar -> { if(ar.succeeded()) { List<Record> raidersRecords = ar.result(); thatRaider.moveWith(raidersRecords, 300.0); thatRaider.moveCloser(raidersRecords, 300.0); thatRaider.moveAway(raidersRecords, 15.0); thatRaider.move(); // === try to contact the raider and post coordinates === raiderClient.post("/api/coordinates").sendJsonObject( new JsonObject() .put("x",thatRaider.x) .put("y",thatRaider.y) .put("xVelocity",thatRaider.xVelocity) .put("yVelocity",thatRaider.yVelocity), asyncPostRes -> { if(asyncPostRes.succeeded()) { System.out.println(" " + asyncPostRes.result().bodyAsJsonObject().encodePrettily()); } else { // ouch raidersCounter -= 1; record.getMetadata().put("raiders_counter", raidersCounter); discovery.update(record, asyncRecUpdateRes -> { vertx.cancelTimer(timerID);}); } } ); }); }); }
  31. #BSGTHEPLAN @DevFestToulouse Récapitulatif BaseStar JAVA BaseStar JAVA BaseStar JAVA BaseStar

    JAVA REDIS BaseStar JAVA GET http://localhost:808N/api/raiders POST http://localhost:808N/api/raiders GET http://localhost:808N/health Raider KOTLIN Raider KOTLIN Raider GROOVY Raider GROOVY POST http://localhost:909N/api/coordinates
  32. #BSGTHEPLAN @DevFestToulouse WebApp BaseStar JAVA BaseStar JAVA BaseStar JAVA REDIS

    BaseStar JAVA GET http://localhost:808N/api/raiders POST http://localhost:808N/api/raiders GET http://localhost:808N/health BSG monitor SCALA GET http://localhost:8080/api/raiders BSG map JS http://localhost:7070 BaseStar JAVA Raider KOTLIN Raider KOTLIN Raider GROOVY Raider GROOVY POST http://localhost:909N/api/coordinates
  33. #BSGTHEPLAN @DevFestToulouse WebApp | Backend Scala val server = vertx.createHttpServer()

    val router = Router.router(vertx) // Settings for the Redis backend val redisHost = sys.env.getOrElse("REDIS_HOST", "127.0.0.1") val redisPort = sys.env.getOrElse("REDIS_PORT", "6379").toInt val redisAuth = sys.env.getOrElse("REDIS_PASSWORD", null) val redisRecordsKey = sys.env.getOrElse("REDIS_RECORDS_KEY", "vert.x.ms") // Mount the service discovery backend (Redis) val discovery = ServiceDiscovery.create(vertx, ServiceDiscoveryOptions() .setBackendConfiguration( new JsonObject() .put("host", redisHost) .put("port", redisPort) .put("auth", redisAuth) .put("key", redisRecordsKey) ) )
  34. #BSGTHEPLAN @DevFestToulouse WebApp | Backend Scala val httpPort = sys.env.getOrElse("PORT",

    "8080").toInt router.get("/api/raiders").handler(context => { discovery .getRecordsFuture(record => record.getMetadata.getString("kind").equals("raider")) .onComplete { case Success(results) => { context .response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonArray(results.toList.asJava).encodePrettily()) } case Failure(cause) => { context .response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("error", cause.getMessage).encodePrettily()) } } }) router.route("/*").handler(StaticHandler.create()) println(s" Listening on $httpPort - Enjoy ") server.requestHandler(router.accept _).listen(httpPort)
  35. #BSGTHEPLAN @DevFestToulouse WebApp | Backend Scala val httpPort = sys.env.getOrElse("PORT",

    "8080").toInt router.get("/api/raiders").handler(context => { discovery .getRecordsFuture(record => record.getMetadata.getString("kind").equals("raider")) .onComplete { case Success(results) => { context .response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonArray(results.toList.asJava).encodePrettily()) } case Failure(cause) => { context .response() .putHeader("content-type", "application/json;charset=UTF-8") .end(new JsonObject().put("error", cause.getMessage).encodePrettily()) } } }) router.route("/*").handler(StaticHandler.create()) println(s" Listening on $httpPort - Enjoy ") server.requestHandler(router.accept _).listen(httpPort)
  36. #BSGTHEPLAN @DevFestToulouse WebApp | Backend Node const express = require("express");

    const bodyParser = require("body-parser"); const fetch = require('node-fetch'); let port = process.env.PORT || 7070; let app = express(); app.use(bodyParser.json()) app.use(bodyParser.urlencoded({extended: false})) app.use(express.static('public')); app.get('/raiders', (req, res) => { //http://localhost:8080/api/raiders fetch(`${process.env.RAIDERS_SERVICE}`, { method:'GET', headers: {"Content-Type": "application/json;charset=UTF-8"} }) .then(response => response.json()) .then(jsonData => res.send({raiders: jsonData})) .catch(error => res.send({error: error})) }) app.listen(port) console.log(" Discovery Server is started - listening on ", port)
  37. #BSGTHEPLAN @DevFestToulouse checklist ✅ Démarrer les BaseStars ✅ cf Base

    Redis - MEDIS ✅ Démarrer Redis ✅ Démarrer BSG Monitor ✅ Démarrer BSG Map
  38. #BSGTHEPLAN @DevFestToulouse Raider(s) BaseStar JAVA BaseStar JAVA BaseStar JAVA REDIS

    BaseStar JAVA GET http://localhost:808N/api/raiders POST http://localhost:808N/api/raiders GET http://localhost:808N/health BSG monitor SCALA GET http://localhost:8080/api/raiders BSG map JS http://localhost:7070 BaseStar JAVA Raider KOTLIN Raider KOTLIN Raider GROOVY Raider GROOVY POST http://localhost:909N/api/coordinates Raider GROOVY Raider KOTLIN Raider GROOVY
  39. #BSGTHEPLAN @DevFestToulouse Raider(s) | main + stop fun main(args: Array<String>)

    { val vertx = Vertx.vertx() vertx.deployVerticle(Raider()) } class Raider : AbstractVerticle() { override fun stop(stopFuture: Future<Void>) { super.stop() println("Unregistration process is started (${record?.registration})...") discovery?.unpublish(record?.registration, { ar -> when { ar.failed() -> { println(" Unable to unpublish the microservice: ${ar.cause().message}") stopFuture.fail(ar.cause()) } ar.succeeded() -> { println(" bye bye ${record?.registration}") stopFuture.complete() } } }) } override fun start() { … } }
  40. #BSGTHEPLAN @DevFestToulouse Raider(s) | main + stop fun main(args: Array<String>)

    { val vertx = Vertx.vertx() vertx.deployVerticle(Raider()) } class Raider : AbstractVerticle() { override fun stop(stopFuture: Future<Void>) { super.stop() println("Unregistration process is started (${record?.registration})...") discovery?.unpublish(record?.registration, { ar -> when { ar.failed() -> { println(" Unable to unpublish the microservice: ${ar.cause().message}") stopFuture.fail(ar.cause()) } ar.succeeded() -> { println(" bye bye ${record?.registration}") stopFuture.complete() } } }) } override fun start() { … } }
  41. #BSGTHEPLAN @DevFestToulouse Raider(s) | s’enregistrer / ServiceDiscovery class Raider :

    AbstractVerticle() { override fun start() { /* === Discovery part === */ val redisPort= System.getenv("REDIS_PORT")?.toInt() ?: 6379 val redisHost = System.getenv("REDIS_HOST") ?: "127.0.0.1" val redisAuth = System.getenv("REDIS_PASSWORD") ?: null val redisRecordsKey = System.getenv("REDIS_RECORDS_KEY") ?: "vert.x.ms" val serviceDiscoveryOptions = ServiceDiscoveryOptions() discovery = ServiceDiscovery.create(vertx, serviceDiscoveryOptions.setBackendConfiguration( json { obj( "host" to redisHost, "port" to redisPort, "auth" to redisAuth, "key" to redisRecordsKey ) } )) } }
  42. #BSGTHEPLAN @DevFestToulouse Raider(s) | s’enregistrer / Record class Raider :

    AbstractVerticle() { override fun start() { // microservice informations val haikunator = HaikunatorBuilder().setTokenLength(3).build() val niceName = haikunator.haikunate() val serviceName = "${System.getenv("SERVICE_NAME") ?: "the-plan"}-$niceName" val serviceHost = System.getenv("SERVICE_HOST") ?: "localhost" val servicePort = System.getenv("SERVICE_PORT")?.toInt() ?: 80 val serviceRoot = System.getenv("SERVICE_ROOT") ?: "/api" // create the microservice record record = HttpEndpoint.createRecord( serviceName, serviceHost, servicePort, serviceRoot ) } }
  43. #BSGTHEPLAN @DevFestToulouse Raider(s) | s’enregistrer / metadata class Raider :

    AbstractVerticle() { override fun start() { // add metadata record?.metadata = json { obj( "kind" to "raider", "message" to " ready to fight", "basestar" to null, "coordinates" to obj( "x" to random(0.0, 400.0), "y" to random(0.0, 400.0) ), "app_id" to (System.getenv("APP_ID") ?: ""), "instance_id" to (System.getenv("INSTANCE_ID") ?: ""), "instance_type" to (System.getenv("INSTANCE_TYPE") ?: "production"), "instance_number" to (Integer.parseInt(System.getenv("INSTANCE_NUMBER") ?: "0")) ) } } }
  44. #BSGTHEPLAN @DevFestToulouse Raider(s) | s’enregistrer / démarrer class Raider :

    AbstractVerticle() { override fun start() { val httpPort = System.getenv("PORT")?.toInt() ?: 8080 vertx.createHttpServer(HttpServerOptions(port = httpPort)) .requestHandler { router.accept(it) } .listen { ar -> when { ar.failed() -> println(" Houston?") ar.succeeded() -> { println(" Raider started on $httpPort") /* === publish the microservice record to the discovery backend === */ discovery?.publish(record, { asyncRes -> when { asyncRes.failed() -> println(" ${asyncRes.cause().message}") asyncRes.succeeded() -> { println(" ${asyncRes.result().registration}") /* === search for a baseStar === */ searchAndSelectOneBaseStar() } } }) /* === end of publish === } } } } }
  45. #BSGTHEPLAN @DevFestToulouse Raider(s) | s’enregistrer / démarrer class Raider :

    AbstractVerticle() { override fun start() { val httpPort = System.getenv("PORT")?.toInt() ?: 8080 vertx.createHttpServer(HttpServerOptions(port = httpPort)) .requestHandler { router.accept(it) } .listen { ar -> when { ar.failed() -> println(" Houston?") ar.succeeded() -> { println(" Raider started on $httpPort") /* === publish the microservice record to the discovery backend === */ discovery?.publish(record, { asyncRes -> when { asyncRes.failed() -> println(" ${asyncRes.cause().message}") asyncRes.succeeded() -> { println(" ${asyncRes.result().registration}") /* === search for a baseStar === */ searchAndSelectOneBaseStar() } } }) /* === end of publish === } } } } }
  46. #BSGTHEPLAN @DevFestToulouse Raider(s) // ⚠ call by a basestar router.post("/api/coordinates").handler

    { context -> // check data -> if null, don't move val computedX = context.bodyAsJson.getDouble("x") ?: x val computedY = context.bodyAsJson.getDouble("y") ?: y val computedXVelocity = context.bodyAsJson.getDouble("xVelocity") ?: xVelocity val computedYVelocity = context.bodyAsJson.getDouble("yVelocity") ?: yVelocity /* === updating record of the service === */ record?.metadata?.getJsonObject("coordinates") ?.put("x", computedX) ?.put("y",computedY) ?.put("xVelocity",computedXVelocity) ?.put("yVelocity",computedYVelocity) record?.metadata?.put("basestar", json {obj( "name:" to baseStar?.record?.name, "color" to baseStar?.record?.metadata?.get("color") )}) discovery?.update(record, {asyncUpdateResult -> }) context .response().putHeader("content-type", "application/json;charset=UTF-8") .end(json {obj( "message" to "", "x" to computedX, "y" to computedY )}.toString()) }
  47. #BSGTHEPLAN @DevFestToulouse Raider(s) // ⚠ call by a basestar router.post("/api/coordinates").handler

    { context -> // check data -> if null, don't move val computedX = context.bodyAsJson.getDouble("x") ?: x val computedY = context.bodyAsJson.getDouble("y") ?: y val computedXVelocity = context.bodyAsJson.getDouble("xVelocity") ?: xVelocity val computedYVelocity = context.bodyAsJson.getDouble("yVelocity") ?: yVelocity /* === updating record of the service === */ record?.metadata?.getJsonObject("coordinates") ?.put("x", computedX) ?.put("y",computedY) ?.put("xVelocity",computedXVelocity) ?.put("yVelocity",computedYVelocity) record?.metadata?.put("basestar", json {obj( "name:" to baseStar?.record?.name, "color" to baseStar?.record?.metadata?.get("color") )}) discovery?.update(record, {asyncUpdateResult -> }) context .response().putHeader("content-type", "application/json;charset=UTF-8") .end(json {obj( "message" to "", "x" to computedX, "y" to computedY )}.toString()) }
  48. #BSGTHEPLAN @DevFestToulouse Raider(s) | healthcheck /* === health check ===

    */ healthCheck = HealthCheckHandler.create(vertx) healthCheck?.register("iamok",{ future -> discovery?.getRecord({ r -> r.registration == record?.registration}, { asyncRes -> when { asyncRes.failed() -> future.fail(asyncRes.cause()) asyncRes.succeeded() -> future.complete(Status.OK()) } }) })
  49. #BSGTHEPLAN @DevFestToulouse Raider(s) | circuitbreaker /* === Define a circuit

    breaker === */ breaker = CircuitBreaker.create("bsg-circuit-breaker", vertx, CircuitBreakerOptions( maxFailures = 5, timeout = 20000, fallbackOnFailure = true, resetTimeout = 100000))
  50. #BSGTHEPLAN @DevFestToulouse Raider(s) fun searchAndSelectOneBaseStar() { /* === search for

    a baseStar in the discovery backend === */ discovery?.getRecords( {r -> r.metadata.getString("kind") == "basestar" && r.status == io.vertx.servicediscovery.Status.UP }, { asyncResult -> when { asyncResult.failed() -> { } // asyncResult.succeeded() -> { // val baseStarsRecords = asyncResult.result() // === choose randomly a basestar === baseStarsRecords.size.let { when(it) { 0 -> { /* oh oh no basestar online ?!!! */ } else -> { val selectedRecord = baseStarsRecords.get(Random().nextInt(it)) subscribeToBaseStar(selectedRecord) // } } } } } } ) // ⬅ end of the discovery }
  51. #BSGTHEPLAN @DevFestToulouse Raider(s) fun searchAndSelectOneBaseStar() { /* === search for

    a baseStar in the discovery backend === */ discovery?.getRecords( {r -> r.metadata.getString("kind") == "basestar" && r.status == io.vertx.servicediscovery.Status.UP }, { asyncResult -> when { asyncResult.failed() -> { } // asyncResult.succeeded() -> { // val baseStarsRecords = asyncResult.result() // === choose randomly a basestar === baseStarsRecords.size.let { when(it) { 0 -> { /* oh oh no basestar online ?!!! */ } else -> { val selectedRecord = baseStarsRecords.get(Random().nextInt(it)) subscribeToBaseStar(selectedRecord) // } } } } } } ) // ⬅ end of the discovery }
  52. #BSGTHEPLAN @DevFestToulouse Raider(s) fun subscribeToBaseStar(selectedRecord: Record) { val serviceReference =

    discovery?.getReference(selectedRecord) val webClient = serviceReference?.getAs(WebClient::class.java) // === CIRCUIT BREAKER === try to register to the basestar breaker?.execute<String>({ future -> webClient?.post("/api/raiders")?.sendJson(json { obj("registration" to record?.registration )}, { baseStarResponse -> when { baseStarResponse.failed() -> { this.baseStar = null // remove the basestar future.fail(" ouch something bad happened") } baseStarResponse.succeeded() -> { println(" you found a basestar") val selectedBaseStar = BaseStar(selectedRecord, webClient) this.baseStar = selectedBaseStar // time to check the health of my basestar watchingMyBaseStar(selectedBaseStar) future.complete(" yesss!") } } }) })?.setHandler({ breakerResult -> }) }
  53. #BSGTHEPLAN @DevFestToulouse Raider(s) fun subscribeToBaseStar(selectedRecord: Record) { val serviceReference =

    discovery?.getReference(selectedRecord) val webClient = serviceReference?.getAs(WebClient::class.java) // === CIRCUIT BREAKER === try to register to the basestar breaker?.execute<String>({ future -> webClient?.post("/api/raiders")?.sendJson(json { obj("registration" to record?.registration )}, { baseStarResponse -> when { baseStarResponse.failed() -> { this.baseStar = null // remove the basestar future.fail(" ouch something bad happened") } baseStarResponse.succeeded() -> { println(" you found a basestar") val selectedBaseStar = BaseStar(selectedRecord, webClient) this.baseStar = selectedBaseStar // time to check the health of my basestar watchingMyBaseStar(selectedBaseStar) future.complete(" yesss!") } } }) })?.setHandler({ breakerResult -> }) }
  54. #BSGTHEPLAN @DevFestToulouse Raider(s) fun subscribeToBaseStar(selectedRecord: Record) { val serviceReference =

    discovery?.getReference(selectedRecord) val webClient = serviceReference?.getAs(WebClient::class.java) // === CIRCUIT BREAKER === try to register to the basestar breaker?.execute<String>({ future -> webClient?.post("/api/raiders")?.sendJson(json { obj("registration" to record?.registration )}, { baseStarResponse -> when { baseStarResponse.failed() -> { this.baseStar = null // remove the basestar future.fail(" ouch something bad happened") } baseStarResponse.succeeded() -> { println(" you found a basestar") val selectedBaseStar = BaseStar(selectedRecord, webClient) this.baseStar = selectedBaseStar // time to check the health of my basestar watchingMyBaseStar(selectedBaseStar) future.complete(" yesss!") } } }) })?.setHandler({ breakerResult -> }) }
  55. #BSGTHEPLAN @DevFestToulouse Raider(s) fun subscribeToBaseStar(selectedRecord: Record) { val serviceReference =

    discovery?.getReference(selectedRecord) val webClient = serviceReference?.getAs(WebClient::class.java) // === CIRCUIT BREAKER === try to register to the basestar breaker?.execute<String>({ future -> webClient?.post("/api/raiders")?.sendJson(json { obj("registration" to record?.registration )}, { baseStarResponse -> when { baseStarResponse.failed() -> { this.baseStar = null // remove the basestar future.fail(" ouch something bad happened") } baseStarResponse.succeeded() -> { println(" you found a basestar") val selectedBaseStar = BaseStar(selectedRecord, webClient) this.baseStar = selectedBaseStar // time to check the health of my basestar watchingMyBaseStar(selectedBaseStar) future.complete(" yesss!") } } }) })?.setHandler({ breakerResult -> }) } ⚠⚠⚠
  56. #BSGTHEPLAN @DevFestToulouse Raider // time to check the health of

    my basestar watchingMyBaseStar(selectedBaseStar)
  57. #BSGTHEPLAN @DevFestToulouse Raider(s) fun watchingMyBaseStar(baseStar: BaseStar) { // oh oh

    a B vertx.setPeriodic(1000, { timerId -> baseStar.client.get("/health").send { asyncGetRes -> when { asyncGetRes.failed() -> { record?.metadata?.getJsonObject("coordinates") ?.put("xVelocity",0) ?.put("yVelocity",0) // btw, you never stop in space discovery?.update(record, {asyncUpdateResult -> println("${record?.name} I'm alone ?") // time to search a new basestar searchAndSelectOneBaseStar() vertx.setTimer(3000, { id -> vertx.cancelTimer(timerId) }) }) } asyncGetRes.succeeded() -> { // === all is fine === } } } }) }
  58. #BSGTHEPLAN @DevFestToulouse Raider(s) fun watchingMyBaseStar(baseStar: BaseStar) { // oh oh

    a B vertx.setPeriodic(1000, { timerId -> baseStar.client.get("/health").send { asyncGetRes -> when { asyncGetRes.failed() -> { record?.metadata?.getJsonObject("coordinates") ?.put("xVelocity",0) ?.put("yVelocity",0) // btw, you never stop in space discovery?.update(record, {asyncUpdateResult -> println("${record?.name} I'm alone ?") // time to search a new basestar searchAndSelectOneBaseStar() vertx.setTimer(3000, { id -> vertx.cancelTimer(timerId) }) }) } asyncGetRes.succeeded() -> { // === all is fine === } } } }) }
  59. #BSGTHEPLAN @DevFestToulouse Raider(s) fun watchingMyBaseStar(baseStar: BaseStar) { // oh oh

    a B vertx.setPeriodic(1000, { timerId -> baseStar.client.get("/health").send { asyncGetRes -> when { asyncGetRes.failed() -> { record?.metadata?.getJsonObject("coordinates") ?.put("xVelocity",0) ?.put("yVelocity",0) // btw, you never stop in space discovery?.update(record, {asyncUpdateResult -> println("${record?.name} I'm alone ?") // time to search a new basestar searchAndSelectOneBaseStar() vertx.setTimer(3000, { id -> vertx.cancelTimer(timerId) }) }) } asyncGetRes.succeeded() -> { // === all is fine === } } } }) }
  60. #BSGTHEPLAN @DevFestToulouse Raider(s) fun watchingMyBaseStar(baseStar: BaseStar) { // oh oh

    a B vertx.setPeriodic(1000, { timerId -> baseStar.client.get("/health").send { asyncGetRes -> when { asyncGetRes.failed() -> { record?.metadata?.getJsonObject("coordinates") ?.put("xVelocity",0) ?.put("yVelocity",0) // btw, you never stop in space discovery?.update(record, {asyncUpdateResult -> println("${record?.name} I'm alone ?") // time to search a new basestar searchAndSelectOneBaseStar() vertx.setTimer(3000, { id -> vertx.cancelTimer(timerId) }) }) } asyncGetRes.succeeded() -> { // === all is fine === } } } }) }
  61. #BSGTHEPLAN @DevFestToulouse Raider(s) // call by a basestar router.post("/api/coordinates").handler {

    context -> def computedX = context.bodyAsJson.getDouble("x") ?: x def computedY = context.bodyAsJson.getDouble("y") ?: y def computedXVelocity = context.bodyAsJson.getDouble("xVelocity") ?: xVelocity def computedYVelocity = context.bodyAsJson.getDouble("yVelocity") ?: yVelocity /* === updating record of the service === */ record.metadata.getJsonObject("coordinates") .put("x", computedX) .put("y",computedY) .put("xVelocity",computedXVelocity) .put("yVelocity",computedYVelocity) record.metadata.put("basestar", [ "name:" : baseStar.record.name, "color" : baseStar.record.metadata.getString("color") ]) discovery.update(record, {asyncUpdateResult -> }) context .response() .putHeader("content-type", "application/json;charset=UTF-8") .end(JsonOutput.toJson([ "message" : "", "x" : computedX, "y" : computedY ])) }
  62. #BSGTHEPLAN @DevFestToulouse Récapitulatif BaseStar JAVA BaseStar JAVA BaseStar JAVA REDIS

    BaseStar JAVA GET http://localhost:808N/api/raiders POST http://localhost:808N/api/raiders GET http://localhost:808N/health BSG monitor SCALA GET http://localhost:8080/api/raiders BSG map JS http://localhost:7070 BaseStar JAVA Raider KOTLIN Raider KOTLIN Raider GROOVY Raider GROOVY POST http://localhost:909N/api/coordinates Raider GROOVY Raider KOTLIN Raider GROOVY GET http://localhost:909N/health POST http://localhost:808N/api/raiders POST http://localhost:909N/api/coordinates GET http://localhost:808N/health
  63. #BSGTHEPLAN @DevFestToulouse checklist ✅ Démarrer les BaseStars ✅ cf Base

    Redis - MEDIS ✅ Démarrer Redis ✅ Démarrer BSG Monitor ✅ Démarrer BSG Map ✅ Démarrer Raiders (kotlin) ✅ Démarrer Raiders (groovy) ✅ Tuer des BaseStars ✅ Ajouter des BaseStars
  64. #BSGTHEPLAN @DevFestToulouse checklist ✅ Démarrer les BaseStars ✅ cf Base

    Redis - MEDIS ✅ Démarrer Redis ✅ Démarrer BSG Monitor ✅ Démarrer BSG Map ✅ Démarrer Raiders (kotlin) ✅ Démarrer Raiders (groovy) ✅ Tuer des BaseStars ✅ Ajouter des BaseStars ✅ http://localhost:8080/discovery ✅ Démarrer Fake-Raider (Node) ✅ http://localhost:8083/discovery
  65. #BSGTHEPLAN @DevFestToulouse Perspectives • Déploiement sur le cloud, j’ai eu

    des surprises • Remettre à plat mon code | Refactoring • Ecrire un autre ServiceDiscoveryBackend (Redis PubSub, MQTT, …) • Utilisation d’un reverse proxy (peut-être) • Ajouter les 12 colonies dans la démo https://github.com/botsgarden/vertx-service-discovery-backend-redisson
  66. #BSGTHEPLAN @DevFestToulouse Merci D • Vous • DevFest Toulouse •

    Clément Escoffier | Julien Viet | Julien Ponge
