1. Cloud Native Java Development with Quarkus
2. Zineb Bendhiba Who’s on stage today? 🤘 Senior Software Engineer at Red Hat 🤘 Apache Camel PMC 🤘 International Speaker 🤘 15+ years professional software development experience 🤘 Speak English, French, Moroccan Darija, Arabic 🤘 Cadi Ayyad University Alumn 🤘 Twitter: @ZinebBendhiba @zbendhiba.bsky.social zbendhiba @zinebbendhiba
3. Kevin Dubois Who’s on stage today? 🤘 Principal Developer Advocate at Red Hat 🤘 International Speaker 🤘 18+ years professional software development experience 🤘 Speak English, Dutch, French, Italian 🤘 Open Source Contributor (Quarkus, Camel, Knative, ..) 🤘 Open Source Community Member (Belgian JUG, Belgian CNCF chapter) @kevindubois@mastodon.social youtube.com/@thekevindubois linkedin.com/in/kevindubois @kevindubois.com
4. 4 “Traditional Java”
5. Designed for Throughput At the expense of footprint
6. Designed to be long-running At the expense of startup speed
7. Rich dynamic behavior built for mutable systems Yet containers are primarily immutable
8. Build Time Runtime Packaging (maven, etc) gradle…) Load config file from file system Parse it Classpath scanning to find annotated classes Attempt to load class to enable/disable features Build its model of the world. Start the management (thread, pool…) @ @ </> How Does “Traditional Java” Start?
9. JVM Scaling on Kubernetes
10. Building blocks: Java-based runtime Platform resources quick resources starvation Resources Optimization Trend (Origins of Containerisation)
11. Resources Optimization Trend (New & Lighter Runtimes) Building blocks: Platform resources Java-based runtime non-Java runtime 1 non-Java runtime 2 New blocks Improved utilization
12. What about our Existing Java Skills?
13. Supersonic. Subatomic. Java
14. Build Time Runtime @ @ </> The Quarkus Way Runtime Build Time @ @ </> Package model Build Time Runtime @ @ </>
15. The Quarkus Way enables Native Compilation JVM Build Time @ @ </> Package model Native
16. Quarkus + Native (via GraalVM) 0.016 Seconds Quarkus + JVM (via OpenJDK) 0.943 Seconds Traditional Cloud-Native Stack 4.3 Seconds Supersonic Java
17. Java warmup time https://youtu.be/bWmuqh6wHgE (first 13 minutes)
18. Quarkus + Native (via GraalVM) 12 MB Quarkus + JVM (via OpenJDK) 73 MB Traditional Cloud-Native Stack 136 MB Subatomic Java
19. Resources Optimization Trend (Quarkus making Java Relevant) Building blocks: Platform resources Java-based runtime non-Java runtime 1 non-Java runtime 2 Quarkus runtime high application density “Lufthansa Technik AVIATAR experiences significant cloud resources savings by moving to Kubernetes-native Quarkus” - Quarkus.io
20. https://www.redhat.com/en/resources/greener-java-applications-detail https://hollycummins.com/writing-greener-java-applications Setup / Assumptions 🤘 AWS (us-east-1) 🤘 SLA > 99% 🤘 800 req/sec over 20 days 🤘 50% load The Cost / Carbon Impact
21. 🤘 Zero-config Live coding 🤘 Extensions 🤘 Auto-provision services 🤘 Continuous testing 🤘 Dev UI 🤘 CLI Enhancing Developer Joy
22. IT’S STILL JAVA!
23. 🤘 Red Hat sits on the GraalVM advisory board 🤘 Red Hat contributes to GraalVM ◦ Debugging support ◦ ARM support ◦ Java Flight Recorder 🤘 Quarkus is part of the GraalVM test suite Native Compilation
24. AOT/Native-image vs VM mode
25. Command Line Job Github App Cloud / Container Native Serverless & Functions Micro services EDA Kube Operator Traditional Apps CRUD Monoliths GitHub Actions Admin Tools Reactive Systems
26. Jam Time! 👉red.ht/quarkus-tutorial👈 https://quarkus.io/guides/podman
27. Quarkus 3 Highlights PERFORMANCE Hibernate ORM 6 STANDARDS Java 11 & 17 Aligns with MicroProfile 6 & Jakarta EE Core Profile 10 Kubernetes DevService Quarkus CLI deploy to Kubernetes KUBE-NATIVE PRODUCTIVITY Pact contract testing support New Dev UI Azure Functions extension Learn more at Quarkus.io/quarkus3
28. https://github.com/kdubois/CamelQuarkusVoter Camel Quarkus Voter App
29. 29 Quarkus Performance
30. Quarkus IDC Lab Validation https://www.redhat.com/en/blog/key-findings-idc-red-hat-quarkus-lab-validation
31. https://www.techempower.com/benchmarks/#section=data-r21&test=db&f=zijunz-zik0zj-zik0zj-zik0zj-zik0zj-zik0zj-zik0zj-v2qiv3-xamxa7-zik0zj-zik0zj-zik0zj-zik0zj-35r https://www.redhat.com/en/blog/key-findings-idc-red-hat-quarkus-lab-validation https://www.reddit.com/r/java/comments/o0ewar/do_quarkus_performance_benefits_scale 31
32. The importance of density JVM Quarkus Spring Boot Ratio (Quarkus / SB) Framework version 2.7.5.ER4 2.6.3 Build time (s) 6.69 17.65 37.92% Av. RSS after startup (MB) 506.56 913.01 55.48% Av. time to 1st req (ms) 2,287.67 4,653.67 49.16% Av. RSS after 1st req (MB) 534.49 973.8 54.89% Av. throughput (req/sec) 28,904.46 10,758.41 268.67% Av. RSS for max throughput (MB) 1,933.16 2,578.3 74.98% Max throughput density (req/sec/MB) 14.97 4.54 329.8% Native Quarkus Spring Boot Ratio (Quarkus / SB) Framework version 2.7.5.ER4 2.6.3 Build time (s) 89.25 213.78 41.75% Av. RSS after startup (MB) 58.3 160.17 36.4% Av. time to 1st req (ms) 37.33 175.33 21.29% Av. RSS after 1st req (MB) 63.79 167.4 38.1% Av. throughput (req/sec) 21,683.95 9,045.15 239.73% Av. RSS for max throughput (MB) 413.63 599.89 68.95% Max throughput density (req/sec/MB) 53.73 15.13 355.19% Some real numbers (8 cores, 12GB RAM, GraalVM 21.3.0.r11)
33. https://twitter.com/mraible/status/1585225154094764034 https://github.com/oktadev/native-java-examples/pull/54 Don’t take my word for it!
34. 34 Additional Resources
35. https://github.com/quarkusio/quarkus-super-heroes Quarkus Superheroes
36. “We went from 1 min startup times to 400 ms.” RH Press Release Community “We became increasingly worried about resource consumption that Spring Boot was having while being deployed on the Kubernetes cluster… It became increasingly cumbersome to find ways to circumvent the methodology we were using just to squeeze every little bit of performance out of Spring Boot” - Christos Sotiriou DXL Backend Chapter Lead, Vodafone Greece Information Week Community “We could run 3x denser deployments without sacrificing availability and response times of service.” “Quarkus is close to what our developers are already doing with Spring and it’s familiar to them. This is a big benefit” Community “Before we introduced Quarkus, many of our customers had started to look at alternative stacks like Go and node.js to improve performance and efficiency. These customers were weary of selecting a new language and having to hire new developers or retrain their existing Java developers.” - Arijit Mazumdar “There was a low learning curve with Quarkus. It took one of our developers one week to get up to speed on Quarkus and another week to migrate a Spring application to Quarkus.” - Arijit Mazumdar “Quarkus and the Spring API compatibility reduced the migration time and complexity which is critically important for our customers.” - Arijit Mazumdar Community Orgs experiencing Quarkus Joy https://quarkus.io/blog/tag/user-story
37. Orgs experiencing Quarkus Joy “using Spring with AWS Lambda would have been prohibitive because the startup time of Spring in AWS Lambda is too big from my research” - Dennis Baerten “As costs increase, this is when the benefit of using Quarkus will be experienced due to its more efficient use of cloud resources and fast startup time compared to plain Java and Spring Boot” - Dennis Baerten “It took me about 3 days to get familiar with the Quarkus stack” - Dennis Berten, Spring Developer Blog “Some of Payair’s developers had mainly Spring experience, we were concerned that it would be difficult for them to “switch sides”. It turned out that our fear of the unknown was completely unfounded. Quarkus leverages some good old Jakarta EE standards that all Java developers are familiar with. We did not have to learn a bunch of new APIs.” - Hubert Lewandowski “As a long term Spring developer I realized that Spring is slowly becoming the very thing it swore to destroy. The initial premises of Spring (which basically can be summed up as a lightweight alternative to Jakarta EE) are way past the expiry date now. Spring is the undisputed heavyweight champion that can handle everything you imagine but is not your best option for fast and light services. And that applies to Spring Boot as well. - Hubert Lewandowski Blog “When you adopt Quarkus, you will be productive from day one since you don’t really need to learn new technologies.” -TalkDesk Blog “After deploying, we found that Quarkus used about 15% of the CPU, 12% of the memory compared to Spring Boot. So far, we are sticking with Quarkus!” - Sam Dacanay, Lead Software Engineer Blog https://quarkus.io/blog/tag/user-story
38. Free Developer e-Books! https://developers.redhat.com/eventtutorials
39. Start exploring in the OpenShift Sandbox. Learn containers, Kubernetes, and OpenShift in your browser. developers.redhat.com/developer-sandbox Try Red Hat's products and technologies without setup or configuration.
40. Had a good time? let everyone know! @kevindubois @ZinebBendhiba #quarkusrocks Want to know more? Links are in the jam doc below Web quarkus.io Talk quarkus.io/community Twitter @quarkusio More developers.redhat.com dn.dev/quarkus-tutorial
41. Thank You! @thekevindubois kdubois @kevindubois
