[RubyWine #1] Event-Driven Architecture and Messaging Patterns for Ruby Microservices

How to choose a communication protocol for services? Synchronous vs Asynchronous approach. HTTP, Brokered Messaging and gRPC. Issues when working with Threads and asynchronous message queues in Ruby and their solutions. Logging and monitoring of transactional integrity. Publish/Subscribe messaging systems and a brief comparison of them.

Video - https://youtu.be/e9AAUy4kkek

Transcript

1. Event-Driven Architecture
   Event-Driven Architecture
   Messaging Patterns for Ruby Microservices
   https://bit.ly/2RSudnT
   Kirill Shevchenko
   Kirill Shevchenko


   View Slide

2. Who I am
   Who I am
   Ruby/JS developer, Tech Lead at


   View Slide

3. Who I am
   Who I am
   Ruby/JS developer, Tech Lead at
   Two years with Microservices


   View Slide

4. Who I am
   Who I am
   Ruby/JS developer, Tech Lead at
   Two years with Microservices
   Maintainer of Ruby/Rails digest on


   View Slide

5. Who I am
   Who I am
   Ruby/JS developer, Tech Lead at
   Two years with Microservices
   Maintainer of Ruby/Rails digest on
   Live in Dnipro, Ukraine


   View Slide

6. Who I am
   Who I am
   Ruby/JS developer, Tech Lead at
   Two years with Microservices
   Maintainer of Ruby/Rails digest on
   Live in Dnipro, Ukraine
   kirill_shevch


   View Slide

7. Who I am
   Who I am
   Ruby/JS developer, Tech Lead at
   Two years with Microservices
   Maintainer of Ruby/Rails digest on
   Live in Dnipro, Ukraine
   kirillshevch
   kirill_shevch


   View Slide

8. Agenda
   Agenda
   Road from Monolith to Microservices
   Communication Patterns
   Message Brokers
   Publish/Subscribe
   Testing and Monitoring


   View Slide

9. Microservices Are
   Microservices Are
   Something You Grow Into,
   Something You Grow Into,
   Not Begin With
   Not Begin With


   View Slide

10. Let The Adventure
    Let The Adventure
    Begin
    Begin


    View Slide

11. "Hello World" Setup
    "Hello World" Setup
    +


    View Slide

12. "Hello World" Setup
    "Hello World" Setup


    View Slide

13. Background Jobs
    Background Jobs
    +


    View Slide

14. Background Jobs
    Background Jobs


    View Slide

15. Cache
    Cache


    View Slide

16. Business logic size
    Business logic size
    Orders?


    View Slide

17. Business logic size
    Business logic size
    Products?
    Orders?


    View Slide

18. Business logic size
    Business logic size
    Analytics?
    Products?
    Orders?


    View Slide

19. Business logic size
    Business logic size
    Analytics?
    Products?
    Orders?
    Users?


    View Slide

20. Applying DDD to Microservices
    Applying DDD to Microservices


    View Slide

21. Pattern: Database Per Service
    Pattern: Database Per Service


    View Slide

22. Pattern: Database Per Service
    Pattern: Database Per Service


    View Slide

23. Pattern: Database Per Service
    Pattern: Database Per Service


    View Slide

24. Messaging Patterns
    Messaging Patterns


    View Slide

25. Sync vs Async Approach
    Sync vs Async Approach
    Two Ways
    Two Ways


    View Slide

26. Sync vs Async Approach
    Sync vs Async Approach
    Two Ways
    Two Ways
    The publisher writes a message and waits until reader
    confirm the reading


    View Slide

27. Sync vs Async Approach
    Sync vs Async Approach
    Two Ways
    Two Ways
    The publisher writes a message and waits until reader
    confirm the reading
    The writer doesn't wait for the reader, you can read
    the message at any time


    View Slide

28. Synchronous Calls
    Synchronous Calls
    Probably, easiest communication pattern to
    Probably, easiest communication pattern to
    implement is simply calling another service
    implement is simply calling another service
    synchronously, usually via REST.
    synchronously, usually via REST.
    Service 1 Service 2
    REST


    View Slide

29. Synchronous Calls
    Synchronous Calls
    Protocols
    Protocols
    HTTP/RPC
    HTTP/RPC


    View Slide

30. Synchronous Calls
    Synchronous Calls
    Protocols
    Protocols
    HTTP/RPC
    HTTP/RPC
    except for
    except for
    streaming
    streaming


    View Slide

31. HTTP/REST IS GREAT
    HTTP/REST IS GREAT
    Easy to understand (text protocol)
    Web infrastructure already built on top of HTTP
    Great tooling for testing, inspection, modification
    Loose coupling between clients/server makes changes easy
    High-quality http implementations in every language


    View Slide

32. Synchronous Calls
    Synchronous Calls
    Problems?
    Problems?
    You need wait for a response
    You need to handle errors (like timeouts)
    You work with many different APIs
    You you use a lot of different API wrappers


    View Slide

33. A gem for building API Wrappers in Ruby
    A gem for building API Wrappers in Ruby


    View Slide

34. ApiStruct: Configuration
    ApiStruct: Configuration
    ApiStruct::Settings.configure do |config|
    config.endpoints = {
    some_api: {
    root: 'https://someapi.dev/v1'
    }
    }
    end


    View Slide

35. ApiStruct: Client
    ApiStruct: Client
    class OrdersClients < ApiStruct::Client
    some_api :orders
    def index
    get
    end
    def show(id)
    get(id)
    end
    end


    View Slide

36. ApiStruct: Entity
    ApiStruct: Entity
    class Order < ApiStruct::Entity
    client_service OrdersClient
    attr_entity :id, :state, :total_price
    end


    View Slide

37. ApiStruct: Entity
    ApiStruct: Entity
    class Order < ApiStruct::Entity
    client_service OrdersClient
    attr_entity :id, :state, :total_price
    end
    order = Order.show(1)
    # => {"id"=>1, "state"=>"shipping",
    "total_price"=>"99"}


    View Slide

38. Event-Driven Architecture
    Event-Driven Architecture
    (
    (EDA
    EDA)
    )


    View Slide

39. Сommunication Сoncepts
    Сommunication Сoncepts
    Messages
    Messages
    Events
    Events
    Commands
    Commands


    View Slide

40. Messages
    Messages
    The basic unit of communication in Message Brokers
    The basic unit of communication in Message Brokers


    View Slide

41. Messages
    Messages
    The basic unit of communication in Message Brokers
    The basic unit of communication in Message Brokers
    Literally can be anything
    Literally can be anything


    View Slide

42. Messages
    Messages
    The basic unit of communication in Message Brokers
    The basic unit of communication in Message Brokers
    Literally can be anything
    Literally can be anything
    An ID, a string, an object, a
    An ID, a string, an object, a
    command, an event or whatever.
    command, an event or whatever.


    View Slide

43. Commands
    Commands
    It's a one-to-one communication between publisher
    It's a one-to-one communication between publisher
    and subscriber
    and subscriber


    View Slide

44. Commands
    Commands
    It's a one-to-one communication between publisher
    It's a one-to-one communication between publisher
    and subscriber
    and subscriber
    Event
    Publisher
    Subscriber


    View Slide

45. Events
    Events
    An event is a message which informs listeners about
    An event is a message which informs listeners about
    something which has happened
    something which has happened


    View Slide

46. Events
    Events
    An event is a message which informs listeners about
    An event is a message which informs listeners about
    something which has happened
    something which has happened
    Event
    Publisher
    Subscriber 1 Subscriber 2


    View Slide

47. Topic
    Topic Queue
    Queue
    vs


    View Slide

48. Topic
    Topic Queue
    Queue
    vs
    All subscribers will receive a
    All subscribers will receive a
    copy of the message
    copy of the message


    View Slide

49. All subscribers will receive a
    All subscribers will receive a
    copy of the message
    copy of the message
    A single message will be
    A single message will be
    received by exactly one
    received by exactly one
    consumer
    consumer
    Topic
    Topic Queue
    Queue
    vs


    View Slide

50. Queues
    Queues
    Pros
    Pros
    Simple messaging pattern with a
    transparent communication flow
    Messages can be recovered by
    putting them back on the queue


    View Slide

51. Cons
    Cons
    Only one consumer can get the
    message
    Implies a coupling between
    producer and consumer as it’s
    an one-to-one relation
    Queues
    Queues


    View Slide

52. Topics
    Topics
    Pros
    Pros
    Multiple consumers can get a
    message
    Decoupling between producer
    and consumers (publish-and-
    subscribe pattern)


    View Slide

53. Cons
    Cons
    More complicated
    communication flow
    A message cannot be recovered
    for a single listener
    Topics
    Topics


    View Slide

54. Virtual Topics
    Virtual Topics
    Pros
    Pros
    Multiple consumers can get a message
    Decoupling between producer and
    consumers (publish-and-subscribe
    pattern)
    Messages can be recovered by putting
    them back on the queue


    View Slide

55. Virtual Topics
    Virtual Topics
    Cons
    Cons
    Might require additional
    configuration in the broker


    View Slide

56. FIFO (First-In-First-Out)
    FIFO (First-In-First-Out)
    Queues
    Queues
    The order in which messages are sent
    and received is strictly preserved.


    View Slide

57. Message Brokers
    Message Brokers


    View Slide

58. Checklist
    Checklist
    Services discovery
    Messaging
    Load balancing
    Logging
    Queuing


    View Slide

59. ACTIVE
    Apache
    MQ


    View Slide

60. Amazon SQS
    Amazon SQS
    Fully managed message queue
    Fully managed message queue


    View Slide

61. Amazon SQS
    Amazon SQS
    Fully managed message queue
    Fully managed message queue
    Pros
    Pros Cons
    Cons


    View Slide

62. Amazon SQS
    Amazon SQS
    Fully managed message queue
    Fully managed message queue
    Pros
    Pros
    Available as a cloud service
    Cons
    Cons


    View Slide

63. Amazon SQS
    Amazon SQS
    Fully managed message queue
    Fully managed message queue
    Pros
    Pros
    Available as a cloud service
    Cons
    Cons
    FIFO queues support only 300
    messages per second


    View Slide

64. Amazon SQS
    Amazon SQS
    Fully managed message queue
    Fully managed message queue
    Pros
    Pros
    Available as a cloud service
    Cons
    Cons
    FIFO queues support only 300
    messages per second
    No ability to use FIFO with
    Pub/Sub (SNS)


    View Slide

65. ACTIVE
    Apache
    MQ


    View Slide

66. ActiveMQ
    ActiveMQ
    Pros
    Pros
    It has two main concepts: topics
    and queues


    View Slide

67. ActiveMQ
    ActiveMQ
    Pros
    Pros
    It has two main concepts: topics
    and queues
    Load Balancing: replication,
    horizontal scaling


    View Slide

68. ActiveMQ
    ActiveMQ
    Pros
    Pros
    It has two main concepts: topics
    and queues
    Load Balancing: replication,
    horizontal scaling
    Support for most protocols


    View Slide

69. ActiveMQ
    ActiveMQ
    Pros
    Pros
    It has two main concepts: topics
    and queues
    Load Balancing: replication,
    horizontal scaling
    Support for most protocols
    Cons
    Cons
    Need backups


    View Slide

70. ActiveMQ
    ActiveMQ
    Pros
    Pros
    It has two main concepts: topics
    and queues
    Load Balancing: replication,
    horizontal scaling
    Support for most protocols
    Cons
    Cons
    Need backups
    Might require additional
    configuration(FIFO, Virtual Topics)


    View Slide

71. Protocols
    Protocols


    View Slide

72. Protocols
    Protocols
    OpenWire
    OpenWire
    STOMP
    STOMP
    AMQP
    AMQP
    MQTT
    MQTT
    What to сhoose?
    What to сhoose?
    WebSocket
    WebSocket
    XMPP
    XMPP


    View Slide

73. ActiveMQ
    ActiveMQ
    Instance can provide
    Instance can provide
    all protocols at the
    all protocols at the
    same time
    same time


    View Slide

74. ActiveMQ
    ActiveMQ
    Endpoints
    Endpoints


    View Slide

75. Publish/Subscribe
    Publish/Subscribe
    pattern and Ruby
    pattern and Ruby


    View Slide

76. Publishing is simply
    Publishing is simply
    options = {
    command: 'update_order',
    data: { order_id: 1, state: :paid }
    }
    redis = Redis.new
    redis.publish(:orders, options.to_json)


    View Slide

77. But we need handle
    But we need handle
    pubishing result
    pubishing result
    options = {
    command: 'update_order',
    data: { order_id: 1, state: :paid }
    }
    redis = Redis.new
    redis.publish(:orders, options.to_json).tap do |r|
    Raven.capture_message('Publish failed', extra: options) if r.zero?
    end


    View Slide

78. Pub/Sub pattern
    Pub/Sub pattern
    redis = Redis.new
    redis.subscribe(:orders) do |on|
    on.message do |channel, message|
    # call the command
    end
    end


    View Slide

79. Pub/Sub pattern
    Pub/Sub pattern
    redis = Redis.new
    Thread.new do
    redis.subscribe(:orders) do |on|
    on.message do |channel, message|
    begin
    # call the command
    rescue StandardError => e
    Raven.capture_exception(e)
    end
    end
    end
    end


    View Slide

80. Testing
    Testing


    View Slide

81. View Slide

82. Real life problems
    Real life problems
    No one really knows how to test
    microservices


    View Slide

83. Real life problems
    Real life problems
    No one really knows how to test
    microservices
    No one really knows how to test
    infrastructure for microservices


    View Slide

84. Solutions?
    Solutions?
    Unit testing for each service with hard
    mocking


    View Slide

85. Solutions?
    Solutions?
    Unit testing for each service with hard
    mocking
    Up the server with all services for
    running integration testing


    View Slide

86. Monitoring
    Monitoring
    No more single system, no more centralized
    monitoring


    View Slide

87. Monitoring
    Monitoring
    No more single system, no more centralized
    monitoring
    Logs and metrics collecting (Beats, Statsd,
    Elasticsearch)


    View Slide

88. Monitoring
    Monitoring
    No more single system, no more centralized
    monitoring
    Logs and metrics collecting (Beats, Statsd,
    Elasticsearch)
    Aggregation (Logstash)


    View Slide

89. Monitoring
    Monitoring
    No more single system, no more centralized
    monitoring
    Logs and metrics collecting (Beats, Statsd,
    Elasticsearch)
    Aggregation (Logstash)
    Visualization (Kibana, Grafana)


    View Slide

90. Monitoring
    Monitoring
    No more single system, no more centralized
    monitoring
    Logs and metrics collecting (Beats, Statsd,
    Elasticsearch)
    Aggregation (Logstash)
    Visualization (Kibana, Grafana)
    Store and maintain all this data and systems


    View Slide

91. Thanks!
    Thanks!


    View Slide
