Antman: Saving storage from a multimedia perspective

Antman: Saving storage from a multimedia perspective

Eebedc2ee7ff95ffb9d9102c6d4a065c?s=128

LINE DevDay 2020

November 25, 2020
Tweet

Transcript

  1. None
  2. None
  3. None
  4. None
  5. HEIF JPEG 540 KB 360 KB 970 KB 204 KB

    85 KB 490 KB
  6. File size (bytes) 0 200 400 600 800 1000 1200

    File Size JPEG HEIF
  7. File size (bytes) 0 200 400 600 800 1000 1200

    JPEG HEIF File Size x2 ▲ Compression rate
  8. Antman: Saving Storage from a multimedia perspective Seunghoon, Baek /

    LINE Platform Engineering 4
  9. How LINE Handles Media Files OBS (OBject Storage) LINE Family

    Services Storage Delivery Processing In-house Server Platform
  10. LINE Family Services How LINE Handles Media Files In-house Server

    Platform Delivery Processing OBS (OBject Storage) Storage 60 PB ▲ 1 PB = 1,024 TB 1 TB = 1,024 GB
  11. What Happens If Storage Gets Bigger? Operation Cost ▲ $1.4

    million/ Month Space in Data Center ▼ 1) Figure the cost out using Amazon S3 storage pricing. 1)
  12. OBS Storage LINE Services That Use Storage Intensively LINE Album

    feature LINE Timeline … LINE Messenger
  13. OBS Storage LINE Services That Use Storage Intensively LINE Album

    feature LINE Timeline … LINE Messenger Numerous JPEG files stored
  14. Goals Operation Cost ▼ Space in Data Center ▲ Text

    File JPEG JPEG JPEG JPEG … HEIF Text File … HEIF HEIF HEIF
  15. Goals User Mobile Network Cost ▼ User Experience ▲ JPEG

    100 KB HEIF 50 KB
  16. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Results The usage of Media Storage for LINE Album feature Antman Started
  17. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Antman exists If Antman not existed Results Antman Started The usage of Media Storage for LINE Album feature
  18. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Antman exists If Antman not existed Results Antman Started 21 PB Saved The usage of Media Storage for LINE Album feature
  19. Agenda › Struggling for Image Format Compatibility › Obsession with

    Image Quality › Antman Operation Cost › Results
  20. Struggling for Image Format Compatibility

  21. Original JPEG Reducing Storage Usage HEIF 1) https://en.wikipedia.org/wiki/High_Efficiency_Image_File_Format 1)

  22. Deleted = Reduce Storage Usage Reducing Storage Usage Original JPEG

    HEIF 1) https://en.wikipedia.org/wiki/High_Efficiency_Image_File_Format 1)
  23. Reducing Storage Usage Original JPEG HEIF Introduced in 2015 Can

    reduce file size by about 50% of JPEG The latest image format compared to JPEG(1992) Maintaining equivalent image quality 1) https://en.wikipedia.org/wiki/High_Efficiency_Image_File_Format 2) https://en.wikipedia.org/wiki/High_Efficiency_Image_File_Format#JPEG_and_HEIF 1) 2)
  24. ! Device A (Support HEIF) OK Reducing Storage Usage HEIF

  25. ! Device A (Support HEIF) OK ?? Reducing Storage Usage

    " Device B (Not support HEIF) HEIF
  26. ! Device A (Support HEIF) OK ! Device B (Not

    support HEIF) Reducing Storage Usage Restored JPEG Convert OK HEIF
  27. Reducing Storage Usage ! User A (can read HEIF) OK

    ! User B (can’t read HEIF) OK Needs to figure out the most optimal Quality Factor Convert Restored JPEG HEIF
  28. Disk Low Quality Factor High Quality Factor Disk Disk Disk

    Disk Disk Disk Disk Disk Disk HEIF JPEG JPEG JPEG
  29. Disk Low Quality Factor High Quality Factor Disk Disk Disk

    Disk Disk Disk HEIF JPEG JPEG Optimal Quality Factor Disk Disk Disk JPEG
  30. JPEG Format 40* 4UBSU0G*NBHF %25 %FpOF2VBOUJ[BUJPO5BCMF ʜ $PNQSFTTFE%BUB &0* &OE0G*NBHF

    Quality Factor
  31. DQT Backup Original JPEG %25 HEIF

  32. DQT Backup Original JPEG %25 ‘Free’ Box HEIF

  33. HEIF DQT Backup Original JPEG %25 ‘Free’ Box %25 Backup

  34. HEIF DQT Backup ‘Free’ Box %25

  35. HEIF DQT Backup ‘Free’ Box %25 Restored JPEG %25 Transcoding

    * LINE Engineering Blog (EN) https://engineering.linecorp.com/en/blog/developing-the-antman-project
  36. Obsession with Image Quality

  37. Original JPEG Preserve Image Quality Image Quality in HEIF HEIF

  38. Original JPEG Preserve Image Quality Image Quality in HEIF HEIF

    ???
  39. Disk Low Quality Factor High Quality Factor Disk Disk Disk

    Disk Disk Disk Disk Disk Disk JPEG HEIF HEIF HEIF
  40. Disk Low Quality Factor High Quality Factor Disk Disk Disk

    Disk Disk Disk Disk Disk Disk JPEG HEIF HEIF HEIF
  41. Original JPEG Fixed Compression Ratio Use Fixed Compression Ratio 50%

    Attempt #1 | HEIF
  42. Result (Good) Attempt #1 | JPEG (540 KB) HEIF (204

    KB)
  43. Result (Bad) Attempt #1 | JPEG (141 KB) HEIF (71

    KB)
  44. HEIF (71 KB) Result (Bad) Attempt #1 | JPEG (141

    KB)
  45. Find Best Quality Factor Quality Factor Attempt #2 | Original

    JPEG HEIF PSNR 1) PSNR: Peak Signal-to-Noise Ratio 1)
  46. Find Best Quality Factor 1) PSNR: Peak Signal-to-Noise Ratio PSNR

    1) Quality Factor Attempt #2 | Original JPEG Recovered JPEG HEIF
  47. Find Best Quality Factor 1) PSNR: Peak Signal-to-Noise Ratio PSNR

    1) Answer Good or Bad Attempt #2 |
  48. Corner Case of PSNR Attempt #2 | JPEG HEIF (PSNR:

    40.21 dB)
  49. Corner Case of PSNR Attempt #2 | HEIF JPEG (PSNR:

    40.21 dB)
  50. Grid PSNR Attempt #3 |

  51. Grid PSNR Attempt #3 |

  52. Grid PSNR Attempt #3 |

  53. Grid PSNR Attempt #3 | Noise detection ability ▲

  54. Grid Area Problem Attempt #3 |

  55. 14/3 E# Grid Area Problem 14/3 E# Attempt #3 |

  56. Grid Area Problem Attempt #3 | 14/3 E#

  57. Grid Area Problem Attempt #3 | Noise Not Detected 14/3

    E#
  58. Scan window Image Sliding Window Attempt #4 | PSNR

  59. Scan window Image Sliding Window Attempt #4 | PSNR

  60. Image Scan Window P Good or Bad Sliding Window Summarize

    PSNR Results * LINE Engineering Blog (EN) https://engineering.linecorp.com/en/blog/developing-the-antman-project Attempt #4 |
  61. Process for Most Optimal Quality Factor 1 Low High Initial

    Quality Factor No quality loss Quality loss
  62. Process for Most Optimal Quality Factor 2 1 Low High

    Adjust Quality Factor No quality loss Quality loss
  63. Process for Most Optimal Quality Factor 3 2 1 Low

    High Adjust Quality Factor No quality loss Quality loss
  64. Process for Most Optimal Quality Factor 3 4 2 1

    Low High Adjust Quality Factor No quality loss Quality loss
  65. Process for Most Optimal Quality Factor 3 4 2 5

    1 Low High No quality loss Quality loss Adjust Quality Factor
  66. Process for Most Optimal Quality Factor 3 4 2 5

    1 Low High No quality loss Quality loss Best Quality Factor
  67. HEIF File Size Distribution # Samples HEIF bytes / JPEG

    bytes (percent) 10% 20% 30% 40% 50% 60% 70% 80%
  68. HEIF File Size Distribution # Samples HEIF bytes / JPEG

    bytes (percent) 10% 20% 30% 40% 50% 60% 70% 80% Generally 30% ~ 40%
  69. 50%

  70. 50% 65%

  71. Antman Operation Cost

  72. GPU Parallel Processing JPEG Transcoding HEIF Transcoding Detecting Quality Loss

    Antman Operation Cost
  73. Years 7+ Max image resolution 4K Images /day 60 million

    LINE Album feature Antman Operation Cost
  74. LINE Album feature Years 7+ Max image resolution 4K Images

    /day 60 million Antman Operation Cost JPEG HEIF CPU CPU CPU CPU CPU CPU CPU
  75. Antman Operation Cost GPU (Expensive equipments… ##)

  76. Video Transcoder Server Group GPU Server GPU Server GPU Server

    Antman Server Group GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server Busy state Share GPU Equipments
  77. Video Transcoder Server Group GPU Server GPU Server GPU Server

    Antman Server Group GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server Idle state Share GPU Equipments
  78. Video Transcoder Server Group GPU Server GPU Server GPU Server

    Antman Server Group GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server Rent ! Share GPU Equipments
  79. Video Transcoder Server Group GPU Server GPU Server GPU Server

    Antman Server Group GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server Need more GPU ! Share GPU Equipments
  80. Video Transcoder Server Group GPU Server GPU Server GPU Server

    Antman Server Group GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server GPU Server Return ! Share GPU Equipments
  81. * LINE Engineering Blog (EN) https://engineering.linecorp.com/en/blog/developing-the-antman-project Zero Infrastructure Cost 0%

    25% 50% 75% 100% 24 Hours 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Transcoder Antman
  82. Results

  83. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Antman exists If Antman not existed Results Completed processing JPEG files stored before Antman Antman started The usage of Media Storage for LINE Album feature
  84. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Antman exists If Antman not existed Results Antman started 21 PB Saved The usage of Media Storage for LINE Album feature
  85. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Antman exists If Antman not existed Results Antman started 1) Figure the cost out using Amazon S3 storage pricing. $ 470K / Month Storage Operation Cost 1) The usage of Media Storage for LINE Album feature
  86. 15 PB 22.5 PB 30 PB 37.5 PB 45 PB

    Feb '19 Apr '19 Jun '19 Aug '19 Oct '19 Dec '19 Mar '20 May '20 Jul '20 Sep '20 Antman exists If Antman not existed Results $2 million ▲ saved 1) Figure the cost out using Amazon S3 storage pricing. 1) The usage of Media Storage for LINE Album feature
  87. Future Work Video (H264) ??? Image (JPEG) Image (HEIF)

  88. Thank you
