ChatOps with Hubot

Presentation for Leeds DevOps user group

Transcript

1. ChatOps with Hubot
   Lorna Mitchell, October 2015


   View Slide

2. Think of DevOps


   View Slide

3. This is ChatOps


   View Slide

4. ChatOps
   Puts the "S" in CAMS
   A Culture of Automation, Measurement and Sharing


   View Slide

5. ChatOps
   Brings the automation into the conversation.
   Team is in channel; information needs to be there too


   View Slide

6. Choose Your Bot
   • Lita (ruby) https://www.lita.io/
   • Err (python) http://errbot.net/
   • Hubot (coffeescript) https://hubot.github.com/


   View Slide

7. Hubot
   "Friendly chat robot from GitHub"
   • Shared plugins
   • Good community


   View Slide

8. Supported Channels
   • Slack
   • Campfire
   • Hipchat
   • IRC
   • Shell
   • ... pluggable adapters


   View Slide

9. Installation
   Very easy install via yeoman:
   https://hubot.github.com/docs/
   Bonus blog post: http://lrnja.net/1KugmaC
   Then: ./bin/hubot


   View Slide

10. Meet Hugh
    Hugh is a hubot.
    Here, I'm running:
    • IRC server: miniircd
    https://github.com/jrosdahl/miniircd
    • IRC client: irssi http://irssi.org/


    View Slide

11. Simply Deployable
    Designed to run on Heroku, easy to run elsewhere
    • Get Heroku toolchain
    • heroku create
    • Set environment variables
    • Configure Procfile
    • git push heroku master


    View Slide

12. Many Plugins
    Search for "hubot [thing]" on https://www.npmjs.com/
    Install and add to list in external-scripts.json
    Or add your own code to scripts/


    View Slide

13. Plugins
    Very easy scripting, make a scripts/*.coffee file and
    export a function:
    module.exports = (robot) ->
    # your code here


    View Slide

14. Plugins
    Simple plugin: use cron to do a timed feature
    Also: happy hour, standup meetings


    View Slide

15. Plugin Code
    ROOM = process.env.HUBOT_TIMESHEET_REMINDER_ROOM
    cronJob = require('cron').CronJob
    module.exports = (robot) ->
    doReminder = ->
    robot.messageRoom(ROOM, "This is a polite reminder.
    Fill in your timesheets for the week, please");
    job = new cronJob("0 0 17 * * 5", doReminder, null, true)
    https://github.com/lornajane/hubot-timesheet-reminder


    View Slide

16. Managing Plugins


    View Slide

17. robot.respond
    rules = [
    "1. A robot may not injure a human being or, through inaction, allow a hu
    "2. A robot must obey any orders given to it by human beings, except wher
    "3. A robot must protect its own existence as long as such protection doe
    ]
    module.exports = (robot) ->
    robot.respond /(what are )?the (three |3 )?(rules|laws)/i, (msg) ->
    text = msg.message.text
    msg.send rules.join('\n')


    View Slide

18. robot.hear
    quotes = [
    "Life! Don't talk to me about life",
    "Life, loathe it or ignore it, you can't like it",
    "Life's bad enough as it is without wanting to invent any more of it",
    "Funny, how just when you think life can't possibly get any worse it sudd
    ]
    module.exports = (robot) ->
    robot.hear /(.*)(life)(.*)/i, (msg) ->
    msg.send msg.random quotes


    View Slide

19. Webhooks
    Collate events from all tools into your chat rooms
    Alerts from:
    • monitoring/logs
    • commits
    • issues/pull requests
    • deploys


    View Slide

20. Webhooks


    View Slide

21. Webhooks In Practice


    View Slide

22. Webhooks In Practice


    View Slide

23. Webhooks In Practice


    View Slide

24. Webhooks In Practice


    View Slide

25. Developing for Webhooks
    To test webhooks on a dev platform, try ngrok
    (https://ngrok.com/)
    Secure tunnel to a port on your machine, with:
    • ability to inspect traffic
    • option to replay (rather than having to retrigger)


    View Slide

26. API Calls
    Command your bot


    View Slide

27. Team Relations
    • Thanks plugin
    • Karma
    • Ship It
    • The Rules


    View Slide

28. ChatOps in Teams
    Unsolicited advice from me:
    • Works for open source and commercial teams
    • Build on existing plugins
    • Don't take it too seriously


    View Slide

29. ChatOps in Teams
    Unsolicited advice from me:
    • Works for open source and commercial teams
    • Build on existing plugins
    • Don't take it too seriously
    • Never ask permission


    View Slide

30. Thanks!


    View Slide
