Scaling Time-Series Data to Infinity: A Kubernetes-Powered Solution with Envoy

This material is from the session at KubeDay Japan 2024.

1. Scaling Time-Series Data to Infinity: A Kubernetes-Powered Solution with Envoy Hiroki Sakamoto Senior Software Engineer - LY Corporation
2. Have you ever dealt with Petabyte scale of metrics? 2
3. Hiroki Sakamoto — Senior Software Engineer@LY Corp Observability Engineering Team @taisho6339 @taisho6339 3
4. Observability is getting expensive 4 As data increases, several issues happen • Cost • Scalability • Capacity
5. Our Storage 5 Several OSS Petabyte scale of Metrics Object Storage
6. Background 6
7. 7 Prometheus Metrics Agent OTel Collector User clients
8. 8 Prometheus Metrics Agent OTel Collector User clients Ingestion API Time-Series DB
9. 9 Prometheus Metrics Agent OTel Collector User clients Ingestion API Time-Series DB Query API Prometheus Grafana User clients
10. 10 Prometheus Metrics Agent OTel Collector User clients Ingestion API Time-Series DB Query API Prometheus Grafana User clients IMON Flash
11. What is Metrics? 11 Metadata Sample cpu_usage { pod="app-0", environment="prod", node="node-x" } T: 1697530930 V: 80 T: 1697563930 V: 92 T: 1697566930 V: 76 T: 1697569930 V: 64 T: 1697572930 V: 51
12. 12 Client Query API Metadata Database Sample Database PromQL
13. 13 Client Query API Metadata Database Sample Database PromQL Metric IDs Retrieve target metrics IDs with given PromQL
14. 14 Client Query API Metadata Database Sample Database PromQL Retrieve target metrics IDs with given PromQL Retrieve samples with the IDs & time-range Metric IDs Samples
15. 15 Client Query API Metadata Database Sample Database PromQL Metric IDs Samples Evaluate PromQL with the samples and return results Retrieve samples with the IDs & time-range Retrieve target metrics IDs with given PromQL
16. 16 In-Memory Layer for data within 1d Metadata Persistent Layer for data after 1d Sample Custom-built Custom-built Elasticsearch Cassandra
17. Number of Metrics 1 Billion Sample Data Size with Replication 1 PB Ingested Sample Size / a day 2.7TB Ingested Samples / a day 1.8 trillion
18. Cassandra was the bottleneck for us • Cost ◦ Expensive due to 1PB samples • Scalability ◦ Take 6h to scale-out only a Node ◦ Repair never completes • Capacity ◦ Not allowed to obtain more Nodes 18
19. New Storage is required for Sample 19
20. Why not use Object Storage? • Cost-effective • Storage concerns are NOT an issue • Sufficient Capacity and Scalability • Real-world samples (Cortex, Mimir, Thanos) 20
21. Object Storage 21 Cassandra on k8s Maintenability Maintenability Scalability Scalability Storage cost Storage cost Performance Performance VS
22. 22 In-Memory Layer for data within 1d Persistent Layer 1 for data 1d ~ 2w Custom-built Cassandra Persistent Layer 2 for data 2w ~ S3-compatible Object Storage New!
23. 23 1. Data Structure 2. Distributed Write 3. Distributed Read How to construct DB on Object Storage
24. 1. Data Structure 24
25. Requirements 25 S3-compatible Object Storage T: 1697530930 V: 80 T: 1697563930 V: 92 T: 1697566930 V: 76 T: 1697569930 V: 64 T: 1697572930 V: 51 Time Range: 2024-08-04 12:00 - 17:00 ID: 1, 9, 200, 320 Input Output
26. Data Sharding is important • 1B metrics ◦ Inevitable to merge multiple samples using a rule • For concurrency ◦ Efficient write processing ◦ Efficient read processing 26
27. Data Sharding Strategy • 1 Bucket ◦ 1 week Time-Window • 1 Directory ◦ 4 hours Time-Window ◦ Tenant ◦ Shard factor: Metrics ID % numShards 27
28. 28 1 Week Data of Bucket shard-1_from-timestamp_to-timestamp (4h of Data) ------------------------------------------- 0x001 | ID:1 of Samples ------------------------------------------- 0x014 | ID:10 of Samples ------------------------------------------- 0x032 | ID:20 of Samples ------------------------------------------- 0x036 | ID:32 of Samples ------------------------------------------- Same shard of samples
29. 29 1 Week Data of Bucket shard-1_from-timestamp_to-timestamp (4h of Data) ------------------------------------------- 0x001 | ID:1 of Samples ------------------------------------------- 0x014 | ID:10 of Samples ------------------------------------------- 0x032 | ID:20 of Samples ------------------------------------------- 0x036 | ID:32 of Samples ------------------------------------------- Same shard of samples Index ------------------------------------------- ID = 1 | 0x001 ------------------------------------------- ID = 10 | 0x014 ------------------------------------------- ID = 20 | 0x032 ------------------------------------------- ID = 32 | 0x036 -------------------------------------------
30. 2. Distributed Write 30
31. 31 In-Memory DB Data Node 1 Data Node 150 Batch Node 1 Batch Node 16 How to write samples to Cassandra Retrieve 4h of data
32. 32 In-Memory DB Data Node 1 Data Node 150 Batch Node 1 Batch Node 16 Cassandra How to write samples to Cassandra Retrieve 4h of data Compress & Save Inserted Rows — ID=1 : compressed samples in 4h ID=2 : compressed samples in 4h ID=3 : compressed samples in 4h …
33. 33 In-Memory DB Data Node 1 Data Node 150 Batch Node 1 Batch Node 16 How to write samples to Object Storage S3-Compatible Object Storage Retrieve 4h of data How?
34. 34 In-Memory DB Data Node 1 Data Node 150 Batch Node 1 Batch Node 16 How to write samples to Object Storage Shard Aggregator1 Shard Aggregator32 Compress & Aggregate S3-Compatible Object Storage Retrieve 4h of data
35. New process - Shard Aggregator • Aggregate samples according to the sharding strategy • Allow scale-out when increasing number of shards • Persist samples once receiving samples for resiliency (WAL) 35
36. Start using k8s for new services • Infrastructure abstraction • Self-Healing • Unified Observability • Unified deployment flow 36
37. 37 Batch Node 1 Batch Node 16 Shard Aggregator1 Shard Aggregator32
38. 38 Batch Node 1 Batch Node 16 Shard Aggregator1 Shard Aggregator32 Set shard factor in gRPC Header
39. 39 Batch Node 1 Batch Node 16 Shard Aggregator1 Shard Aggregator32 Route to corresponding Pod using the header Set shard factor in gRPC Header
40. 40 Batch Node 1 Batch Node 16 Shard Aggregator1 Shard Aggregator32 LevelDB LevelDB LSM-Tree Set shard factor in gRPC Header Route to corresponding Pod using the header Persist samples in local DB
41. LevelDB 41 Batch Node 1 Batch Node 16 Shard Aggregator1 LevelDB Shard Aggregator32 Export aggregated samples Set shard factor in gRPC Header Route to corresponding Pod using the header
42. 42 LSM-Tree (LevelDB, RocksDB) B+Tree (etcd.io/bbolt) Write Performance Vary in cases Read Performance Vary in cases Choose correct Key-Value Store
43. 43 LSM-Tree (LevelDB, RocksDB) B+Tree (etcd.io/bbolt) Write Performance Vary in cases Read Performance Vary in cases Choose correct Key-Value Store
44. Optimizations on LSM-Tree Since only read once when uploading • Disabled compaction • Disabled page cache as possible (fadvise) 44
45. Optimizations on LSM-Tree Fsync once in multiple requests for better performance 45 kernel space (page cache here) Even though a Pod is killed, Dirty page cache remains
46. Write Performance • With 32 Shard Aggregator Pods ◦ Take 40 mins to aggregate & write 450GB every 4 hours ◦ Consume only 3GB memory on each Pod ◦ No outage so far 46
47. 3. Distributed Read 47
48. 48 Query API How?
49. 49 Query API Storage Gateway
50. New process - Storage Gateway • Communicate directly with Object Storage • Return samples stored in Object Storage • Cache data ◦ Reduce RPS for Object Storage ◦ Return results faster 50
51. Request for Samples 51 Query API Storage Gateway
52. Request for Samples 52 Query API Storage Gateway Download Index Identify byte locations in the sample file
53. 53 Query API Storage Gateway Download samples with Byte-Range request Return Samples Request for Samples Download Index Identify byte locations in the sample file
54. 54 Query API Storage Gateway What about Cache?
55. 55 LSM-Tree (LevelDB, RocksDB) B+Tree (etcd.io/bbolt) Write Performance Vary in cases Read Performance Vary in cases Choose correct Key-Value Store
56. Distributed Cache with bbolt & Envoy • etcd-io/bbolt ◦ On-disk B+Tree Key-Value store ◦ Better read performance ◦ Page cache works well • Envoy ◦ L7 LB to route requests to fixed Pods ◦ Active health-check supported ◦ Maglev supported and optimized on even distribution 56
57. 57 Query API Storage Gateway 1 Storage Gateway 32 Split a query into multiple small ones by 4h of shard
58. 58 Storage Gateway 1 Storage Gateway 32 Route a shard request to a fixed Pod by Maglev Query API Split a query into multiple small ones by 4h of shard
59. 59 Storage Gateway 1 Storage Gateway 32 Download Index & Samples Route a shard request to a fixed Pod by Maglev Query API Split a query into multiple small ones by 4h of shard
60. 60 bbolt Storage Gateway 1 bbolt Storage Gateway 32 Cache downloaded indices & samples Route a shard request to a fixed Pod by Maglev Query API Split a query into multiple small ones by 4h of shard
61. 61 bbolt Storage Gateway 1 bbolt Storage Gateway 32 Query API Return each result
62. 62 bbolt Storage Gateway 1 bbolt Storage Gateway 32 Query API Merge all results Return each result
63. 63 But, still slow…
64. 64 Download Index Decode Index Identify byte location Download Sample Return Pinpoint the bottleneck with trace & profile Grafana Tempo Pyroscope Consume too much time from profiling and tracing
65. 65 Download Index Decode Index Identify byte location Download Sample Return Index is too big to decode or download Cry icons created by Vectors Market - Flaticon: https://www.flaticon.com/free-icons/cry
66. 66 Index of Index
67. 67 Download Index Decode Index Reduce the index size to be dealt with Identify byte location Download Sample Return
68. Read Performance • With 64 Storage Gateway Pods ◦ Comparable Performance to Cassandra ▪ 2ms at p99 for 4h data ▪ 6s ~ 9s at p99 for 1 month data ◦ Cache 1.9TB 68
69. Obtain Unlimited Capacity 69
70. 70 Storage Gateway Shard Aggregator Default Storage Bring Your Own Buckets! User A’s Storage User B’s Storage
71. Petabyte scale is NOT an issue anymore Thanks Everyone in the Commnunity 71 Distributed Write Level DB Nginx Distributed Read bbolt Envoy Obervability
72. What can we do for the community? 72 Introduced Loki in our org 2021 Contributed to Loki 2022 Success of this project leveraging knowledge of Loki 2023 - 2024 Contribute to Community Future Always seeking opportunities of contributions
