Speeding up tests with machine learning and distributed execution

Speeding up tests with machine learning and distributed execution

Test time is one of the key drivers of build times. There are many contributing factors, including the growing number of integration and functional tests to cover a wide range of inputs, running tests sequentially, and dependencies on expensive external services. This often leads to developers only running tests on CI thereby considerably lengthening the feedback loop. And even then, running all tests for every change can be a challenge both in terms of cost and build time. Gradle Enterprise provides two groundbreaking new technologies that allow to run tests earlier and more frequently: Predictive Test Selection and Test Distribution.

Predictive Test Selection saves testing time by identifying, prioritizing, and running only tests that are likely to provide useful feedback. This is accomplished this by applying a machine learning model that uniquely incorporates fine-grained code snapshots, comprehensive test analytics, and flaky test data.

Test Distribution expands test parallelism by fanning out test execution to remote agents takes your existing test suites and distributes them – based on historical execution times – across remote agents to execute them faster.

Marc Philipp

December 06, 2022
Tweet

More Decks by Marc Philipp

Other Decks in Technology

Transcript

  1. Speeding up tests
    with machine learning and
    distributed execution

    View Slide

  2. ⬢ Sr. Principal Software Engineer at
    Gradle Inc.
    ⬢ JUnit team lead
    Marc Philipp
    Email:
    [email protected]
    Mastodon:
    @[email protected]
    About me

    View Slide

  3. Open Source
    Build Automation
    Commercial Offering
    Developer Productivity Engineering
    Supports Gradle, Maven, and Bazel
    Gradle Inc.

    View Slide

  4. What is Developer Productivity Engineering?
    Tomorrow
    15:15

    View Slide

  5. Gradle
    Enterprise
    API
    Gradle Enterprise Technical Overview

    View Slide

  6. Table of Contents
    Motivation
    Test Distribution
    Predictive Test Selection

    View Slide

  7. Motivation
    1

    View Slide

  8. Testing usually dominates build times

    View Slide

  9. Why is testing so slow?
    Databases
    Web servers
    Directories
    Virtual machines
    Network
    latency
    Network
    latency

    View Slide

  10. Reduced test time yields increase in productivity
    More build and test executions
    Shift-left testing from CI to local builds
    Less context-switching

    View Slide

  11. Local parallelization lacks historical information

    View Slide

  12. Single-machine parallelism does not scale

    View Slide

  13. CI Fanout
    Idea: run subset of tests on CI agents
    in parallel
    ⬢ Grouping of tests often manual
    ⬢ Large overhead because each
    CI agent has to run build up to
    test task
    ⬢ Test results are scattered over
    multiple CI jobs
    ⬢ Does not support local builds

    View Slide

  14. Test Distribution
    2

    View Slide

  15. Test Distribution Overview
    ⬢ Broker component included in Gradle Enterprise server
    ⬢ Agents connect to the broker
    ⬢ Builds connect to the broker and request agents
    ⬢ Works for local and CI builds
    On-premises inside your network

    View Slide

  16. Running Test Distribution agents
    ⬢ The agent comes in two flavors: Jar and Docker image
    ⬢ Runs on Java 11+, requires about 128 MB of memory
    ⬢ Runs on Windows, macOS, and Linux
    ⬢ Detects its environment (JDKs, OS) during startup
    ⬢ Administrators can pass additional capabilities as command line parameters
    java -jar gradle-enterprise-test-distribution-agent.jar \
    --server https://ge.example.com \
    --api-key «api-key» \
    --capabilities docker,postgres=14
    docker run \
    --env TEST_DISTRIBUTION_AGENT_SERVER=https://ge.example.com \
    --env TEST_DISTRIBUTION_AGENT_API_KEY=«api-key» \
    --env TEST_DISTRIBUTION_AGENT_CAPABILITIES=postgres=14 \
    gradle/gradle-enterprise-test-distribution-agent
    Runs on-premises inside your
    own network infrastructure

    View Slide

  17. Gradle: Integrates with default Test task
    tasks.test {
    useJUnitPlatform()
    distribution {
    enabled.set(true)
    }
    }
    Code coverage and other output
    files are transferred back and
    merged automatically
    Input files (e.g. classpath) are
    automatically transferred to
    remote agents
    plugins {
    id("com.gradle.enterprise") version "3.11.4"
    }

    View Slide

  18. Maven: integrates with Surefire/Failsafe plugins





    maven-surefire-plugin
    2.22.2



    true







    ⬢ Requires Gradle Enterprise
    Maven extension
    ⬢ Integrates with Surefire and
    Failsafe plugins

    View Slide

  19. Test Distribution requires JUnit Platform
    ⬢ Most test frameworks with JUnit Platform test engines are supported:
    ○ JUnit 5 (Jupiter) ✔
    ○ JUnit 3/4 and Spock 1.x (via junit-vintage-engine included in JUnit 5) ✔
    ○ Spock 2.x ✔
    ○ TestNG (via testng-engine) ✔
    ○ ScalaTest (via scalatest-junit-runner) ✔
    ○ ArchUnit ✔
    ○ jqwik ✔
    ⬢ Currently unsupported (we have plans to add support where possible):
    ○ Kotest
    ○ Spek
    ○ Cucumber

    View Slide

  20. Checking compatibility
    ⬢ Compatibility can be checked before adopting Test Distribution by applying a custom
    build script that adds custom values to the Build Scan
    https://github.com/gradle/gradle-enterprise-build-config-samples/pull/469

    View Slide

  21. Run build only once, distribute test execution

    View Slide

  22. Automatic distribution based on previous execution
    times

    View Slide

  23. Resilience against temporary network failures
    ⬢ Actively manage connections using
    WebSocket pings
    ⬢ Reconnect if connection is lost or
    unresponsive
    ⬢ Reschedule work on other agents if agent
    disappears
    ⬢ Retry file uploads on non-client errors
    ⬢ Avoid builds from breaking and causing
    disruption

    View Slide

  24. Adaptive scheduling
    ⬢ Be able to react to additional agents becoming available during test execution
    ⬢ Increases agent utilization
    ⬢ Reduces testing time

    View Slide

  25. Auto-scaling Test Distribution agents
    ⬢ Agent pools with min/max size and
    capabilities for horizontal scaling
    ⬢ HTTP endpoint provides metrics
    indicating the target number of agents
    for each pool, based on demand.
    ⬢ Step-by-step instructions for
    Kubernetes in docs
    ⬢ Real-time and historical usage can be
    visualized by Gradle Enterprise
    administrators
    {
    "id": "sosmbpbr",
    "name": "Linux",
    "capabilities": [
    "jdk=8",
    "os=linux"
    ],
    "minimumAgents": 1,
    "maximumAgents": 90,
    "connectedAgents": 2,
    "idleAgents": 0,
    "desiredAgents": 8
    }

    View Slide

  26. Demo

    View Slide

  27. PR Build w/ Integration tests
    30 min → 3 min

    View Slide

  28. PR Build Times with Integration
    Tests went from 60 minutes to 5
    Danny Thomas
    Developer Productivity Team
    For one project we reduced the build
    time from 62 minutes to under 5
    minutes just using Test Distribution
    across multiple machines. So we think
    that Test Distribution will really move
    the needle and improve the test
    experience for everyone.

    View Slide

  29. Local Build Times: From 54 min
    to 5. CI PR Builds: Way More
    Reliable
    Cédric Champeau
    Technical Staff, Oracle
    (former Gradle Build Tool engineer)
    My test suites finished in 5
    minutes instead of 54. The 10X
    developer is finally here!

    View Slide

  30. Gradle Enterprise Acceleration Features

    View Slide

  31. Gradle Enterprise Acceleration Features
    Gradle
    Enterprise
    2022.2

    View Slide

  32. Predictive Test Selection
    (PTS)
    3

    View Slide

  33. Avoid wasting time and resources
    ⬢ Typically less than 1% of codebase affected
    by any given change
    ⬢ Typically fewer than 1% of tests affected
    by any given change
    ⬢ Yet, most reported test failures are not
    regressions
    💡 Skip irrelevant tests for a given change set using machine learning

    View Slide

  34. Not a new concept
    ⬢ Predictive Test Selection — Meta 2019
    ⬢ Improving Test Effectiveness Using Test Executions History: An
    Industrial Experience Report — Ericsson 2019
    ⬢ Taming Google-Scale Continuous Testing — Google 2017
    ⬢ Test Re-prioritization in Continuous Testing Environments —
    Concordia Univ. 2016
    ⬢ The Art of Testing Less without Sacrificing Quality — Microsoft
    2015
    ⬢ Improving the effectiveness of test suite through mining historical
    data — ACM 2014
    ⬢ … and more

    View Slide

  35. 1. When a test run starts, Gradle Enterprise
    submits a test input snapshot and test set to a
    machine learning model.
    2. Gradle Enterprise automatically develops a
    test selection strategy by learning from
    historical code changes and test outcomes
    from your Build Scan™ data to predict a
    subset of relevant tests, which are then
    executed by your build.
    3. Code change and test results data are
    processed immediately after a Build Scan is
    uploaded to Gradle Enterprise and updates
    the test selection strategy based on new
    results.
    How it works…

    View Slide

  36. Predictive Test Selection Simulator
    ⬢ Simulates what tests would have been
    selected had PTS been enabled
    ⬢ Compares full test results to selected test
    results
    ⬢ Allows to assess risk and savings of PTS per
    task/goal before adopting it
    ⬢ Requires at least 50 executions over a
    14-day period before starting to make
    predictions

    View Slide

  37. View Slide

  38. View Slide

  39. View Slide

  40. View Slide




  41. maven-surefire-plugin
    2.22.2



    true






    Enabling Predictive Test Selection
    tasks.test {
    predictiveSelection {
    enabled.set(true)
    }
    }
    plugins {
    id("com.gradle.enterprise") version "3.11.4"
    }

    View Slide

  42. Must-run tests
    import com.gradle.enterprise.testing.annotations.MustRun;
    @MustRun
    public class ImportantTests {
    // ...
    }
    Using gradle-enterprise-testing-annotations
    from Maven Central.
    tasks.test {
    predictiveSelection {
    mustRun {
    includeClasses.add("example.ImportantTests")
    }
    }
    }



    example.ImportantTests



    View Slide

  43. View Slide

  44. View Slide

  45. Usage patterns
    Our recommendation is to run all tests post-merge or at least periodically.
    1. Apply to existing pre-merge verification (run all tests post-merge)
    2. Apply to existing pre- and post-merge verification (move “all tests” run to nightly build)
    3. Run some high value tests pre-merge (change CI jobs to run costly tests sooner)
    4. Two-pass pre-merge (split pre-merge CI jobs into two steps to get faster feedback)

    View Slide

  46. https://ge.spring.io https://ge.junit.org
    https://ge.micronaut.io https://ge.gradle.org
    Predictive Test Selection in Action

    View Slide

  47. Blank background use at will
    Questions?

    View Slide

  48. Thank you!
    Visit us at our booth if you have
    additional questions

    View Slide
