Kafka Streams from the grounds up to the Cloud

[Talk given at Spring One Platform, Dec 5, 2017, San Francisco]

In this session we will introduce the Kafka Streams API and the Kafka Streams processing engine, followed by the Kafka Streams support in the Spring portfolio - showing how to easily write and deploy Kafka Streams applications using Spring Cloud Stream and deploy them on various cloud platforms using Spring Cloud Data Flow.

Transcript

1. Kafka Streams:
   From the grounds up to the Cloud
   Marius Bogoevici, Chief Architect, Red Hat
   Spring One Platform, Dec 4, 2017
   @mariusbogoevici


   View Slide

2. Marius Bogoevici
   ● Chief Architect, Data Streaming at Red Hat
   ● Spring ecosystem contributor since 2008
   ○ Spring Integration
   ● Spring team member between 2014 and 2017
   ○ Spring XD, Spring Integration Kafka
   ○ Spring Cloud Stream project lead
   ● Co-author “Spring Integration in Action”, Manning, 2012


   View Slide

3. Kafka: from messaging system to streaming platform
   (based on https://www.confluent.io/blog/apache-kafka-goes-1-0/)
   Distributed
   log
   Replication,
   Fault
   tolerance
   Connect and
   Streams
   Transactions,
   Exactly once


   View Slide

4. How about
   applications that are
   both producers and
   consumers and
   perform complex
   computations?
   Kafka as a distributed messaging system


   View Slide

5. Kafka Streams
   ● Client library for stream processing
   ○ Embed stream processing features into
   regular Java applications (microservice
   model)
   ○ Create sophisticated topologies of
   independent applications
   ● Functional transformations via DSL:
   ○ Mapping, filtering, flatMap
   ○ Aggregation, joins (multiple topics)
   ○ Windowing
   ● Kafka-to-Kafka semantics
   ● One-record-at-a-time processing (no
   microbatching)
   ● Stateful processing support
   ● Transactions/exactly once
   Kafka Cluster
   Application
   Kafka Streams


   View Slide

6. Kafka Streams - important concepts
   ● KStream
   ○ Record stream abstraction
   ○ Read from/written to external topic or produced from other KStream via operators such as
   map/filter
   ● KTable/GlobalKTable
   ○ Changelog stream abstraction (key is meaningful)
   ○ Read from external topic as a sequence of updates
   ○ Produced from other tables or stream joins, aggregations etc
   ● State Store
   ○ Key-value store for intermediate aggregation data, KTable materialized views, arbitrary
   key-value data produced during
   ○ Replicated externally
   ● Time windowing


   View Slide

7. Kafka Streams - high level DSL
   KStream words = builder.stream(“words”)
   KTable countsTable = words.flatMapValues(value -> Arrays.asList(value.toLowerCase().split("\\W+")))
   .map((key, value) -> new KeyValue<>(value, value))
   .groupByKey(Serdes.String(), Serdes.String())
   .count(timeWindows, "WordCounts");
   KStream counts = counts.toStream()
   counts.to(“counts”)


   View Slide

8. Kafka Streams stateful processing (default stores)
   Kafka Cluster
   Application
   Kafka Streams
   In-memory
   state store
   Local disk
   ● Pluggable state store model
   ● Key-value data store
   ● Default strategy:
   ○ In-memory (fast access)
   ○ Local disk (for fast recovery)
   ○ Replicated to Kafka (for resilience)
   ● Tightly integrated with Kafka: state
   updates are correlated with offset commits
   changelog


   View Slide

9. Spring Cloud Stream
   ● Event-driven microservice framework
   ● Developer focus on writing business code
   ● Middleware-agnostic programming model
   ● Binders:
   ○ Kafka
   ○ RabbitMQ
   ○ AWS Kinesis
   ○ Google Pub Sub
   ○ Apache Artemis (community)
   ● Easy to deploy with Spring Cloud Data
   Flow


   View Slide

10. Spring Cloud Stream KStream Processor (since 1.3)
    counts
    words
    Spring Cloud Stream
    KStream API output
    input
    Spring Boot
    Programming
    model (developer
    focus)
    Application model (configuration
    options, StreamConfig based on Spring
    Boot properties, KStreamBuilder,
    KStream binder)
    Externalized configuration,
    uberjar construction, health
    monitoring endpoints


    View Slide

11. Kafka Streams in the Cloud
    Application
    Kafka Streams
    Application
    Kafka Streams
    Docker
    uberjar
    Spring Cloud Data Flow


    View Slide

12. Kafka Streams stateful and stateless deployments
    Kafka Cluster
    Application
    Kafka Streams
    In-memory
    state store
    Local disk
    ● Changes propagated to changelog topic
    ● Stored locally for recovery/restart
    ● Fully stateless deployments require to
    replay the topic on restart/failover
    ● State store recovery can be optimized by
    providing access to stateful deployments
    changelog


    View Slide

13. Kafka Streams with Kubernetes StatefulSets
    Application
    Kafka Streams
    Pod
    Application
    Kafka Streams
    Pod
    Application
    Kafka Streams
    Pod
    volume-word-count-0
    word-count-1 word-count-2
    volume-word-count-1 volume-word-count-2
    word-count-0


    View Slide

14. Demo time!
    twitter:@mariusbogoevici
    Email: mariusb@redhat.com
    http://cloud.spring.io/spring-cloud-stream/
    https://github.com/EnMasseProject/barnabas


    View Slide
