gRPC: A high performance, open-source, universal RPC framework

Transcript

1. A high performance, open-source, universal RPC framework Mete Atamel Developer Advocate for Google Cloud @meteatamel
2. Google Cloud Platform Agenda Introduction RPC, motivation for gRPC gRPC Basics What is gRPC? Design goals Some me the code! HelloWorld gRPC sample and demo gRPC Benefits HTTP/2, Protocol Buffers, multi-language support, connection options Some me more code! Streaming gRPC sample and demo @meteatamel
3. Google Cloud Platform Introduction @meteatamel
4. Google Cloud Platform class GreeterService { String greeating(String text); } class GreeterClient { var greeter = new GreeterService(); greeter.greeting(“World”); } Regular Procedure Call @meteatamel
5. Google Cloud Platform In distributed computing a remote procedure call (RPC) is when a computer program causes a procedure (subroutine) to execute in another address space (commonly on another computer on a shared network), which is coded as if it were a normal (local) procedure call, without the programmer explicitly coding the details for the remote interaction That is, the programmer writes essentially the same code whether the subroutine is local to the executing program, or remote* Remote Procedure Call (RPC) *Wikipedia @meteatamel
6. Google Cloud Platform GreeterClient RPC GreetService @meteatamel
7. Google Cloud Platform How do clients call the service? How does the server expose the service? How does the data serialized/deserialized over the wire? XML, JSON, Binary? What is the nature of the connection? Request/reply, streaming? What about authentication? RPC Questions @meteatamel
8. Google Cloud Platform 1. Build your own custom RPC framework ++ Exactly how you like it: I did this with Adobe Flex Data Services! -- You need to answer the questions earlier & code 2. Use gRPC: A high performance, open-source universal RPC framework ++ Many of the questions already answered & implemented by community -- You need to buy into gRPC style, gRPC generated code Choices @meteatamel
9. Google Cloud Platform For simple services, HTTP REST is probably enough → HTTP verbs (GET, POST, PUT, DELETE etc.) are rich enough → REST semantics are well understood For more complex services where efficiency is important, RPC can help → Domain specific: imagine a bank transfer scenario → More strongly typed experience via stubs → Efficiency with HTTP/2, Protocol Buffer Why not REST? @meteatamel
10. Google Cloud Platform Basics @meteatamel
11. Google Cloud Platform Stands for gRPC Remote Procedure Calls A high performance, open source, general purpose standards-based, feature-rich RPC framework Open sourced version of Stubby RPC used in Google Actively developed and production-ready, current version is 1.3.4 What is gRPC? @meteatamel
12. Google Cloud Platform Services not Objects, Messages not References Coverage & Simplicity Free & Open Interoperability & Reach General Purpose & Performant Layered Payload Agnostic Streaming Blocking & Non-Blocking Cancellation & Timeout Motivation and Design Principles grpc.io/blog/principles @meteatamel
13. Google Cloud Platform A high level service definition to describe the API using Protocol Buffers Client and server code generated from the service definition in 10+ languages Efficiency in serialization with Protocol Buffers and connection with HTTP/2 Connection options: Unary, server-side streaming, client-side streaming, bi-directional streaming Authentication options: SSL/TLS, token based authentication How does it work? @meteatamel
14. Google Cloud Platform At the high level Java Service gRPC Service Python Service gRPC Stub gRPC Service gRPC Service GoLang Service C++ Service gRPC Stub gRPC Stub gRPC Service gRPC Stub gRPC Stub @meteatamel
15. Google Cloud Platform Show me the code: 4 easy steps @meteatamel
16. Google Cloud Platform service GreetingService { rpc greeting (HelloRequest) returns (HelloResponse) {} } Step 1: Create greeter.proto message HelloRequest { string name = 1; } message HelloResponse { string message = 1; } @meteatamel
17. Google Cloud Platform Generate client and server code to extend from using proto3 compiler For Java, there is protobuf-maven-plugin for Maven and protobuf-gradle-plugin for Gradl to help For .NET, Grpc.Tools.1.0.1 NuGet package has protoc.exe Step 2: Generate client and server stubs @meteatamel
18. Google Cloud Platform Create a service implementation extending from generated base class Create a server with port and using the service implementation Start the server Step 3: Create server @meteatamel
19. Google Cloud Platform Create a channel for the connection Create a blocking or non-blocking client stub with the channel Create a request Send the request using the stub Handle the responses in sync or async mode Step 4: Create client @meteatamel
20. Google Cloud Platform Demo: Greeter Server & Client (Java) @meteatamel https://github.com/meteatamel/grpc-samples-java
21. Google Cloud Platform gRPC Benefits @meteatamel
22. Google Cloud Platform HTTP/2: low latency transport of content Protocol Buffers (or Bond): efficient serialization Multi-language Support Connection Options: Unary, server, client, bi-directional streaming Main benefits @meteatamel
23. Google Cloud Platform Let’s talk about HTTP/2 @meteatamel
24. Google Cloud Platform History of HTTP 1991 1993 1995 1997 1999 HTTP/0.9 2001 2003 2005 2007 2009 2011 2013 HTTP/1.0 2015 2017 HTTP/1.1 ? @meteatamel
25. Google Cloud Platform New TCP connection per HTTP connection Number of parallel HTTP requests = Number of TCP connections. HTTP 1.x: Limited Parallelism @meteatamel
26. Google Cloud Platform HTTP 1.0: Head of line blocking Without pipelining @meteatamel
27. Google Cloud Platform HTTP 1.1: Head of line blocking With pipelining @meteatamel
28. Google Cloud Platform HTTP 1.1: Head of line blocking HTTP/1.1 HOL Blocking With pipelining @meteatamel
29. Google Cloud Platform HTTP Headers Uncompressed plain text headers for each and every HTTP request HTTP 1.x: Protocol Overhead @meteatamel
30. Google Cloud Platform History of HTTP 1991 1993 1995 1997 1999 HTTP/0.9 2001 2003 2005 2007 2009 2011 2013 HTTP/1.0 2015 2017 HTTP/1.1 @meteatamel SPDY HTTP/2.0
31. Google Cloud Platform Released in 2015. Extend (not replace) the semantics of HTTP/1.1 Improve end-user perceived latency Address the "head of line blocking" Not require multiple connections Minimize protocol overhead HTTP/2 @meteatamel
32. Google Cloud Platform HTTP/2 Single TCP connection No Head-of-line blocking Binary framing layer Request –> Stream Header Compression Transport(TCP) Application (HTTP/2) Network (IP) Session (TLS) [optional] Binary Framing HEADERS Frame DATA Frame HTTP/2 POST: /upload HTTP/1.1 Host: www.javaday.org.ua Content-Type: application/json Content-Length: 27 HTTP/1.x {“msg”: “Welcome to 2016!”} @meteatamel
33. Google Cloud Platform Stream is a bidirectional flow of bytes within an established connection, which may carry one or more messages. Message is a complete sequence of frames that map to a logical request or response message. Frame is the smallest unit of communication in HTTP/2, each containing a frame header, which at a minimum identifies the stream to which the frame belongs: HEADERS for metadata, DATA for payload, RST_STREAM SETTINGS, PUSH_PROMISE, PING, GOAWAY, WINDOW_UPDATE, etc. HTTP/2 Binary Framing @meteatamel
34. Google Cloud Platform Interleave multiple requests and responses in parallel without blocking on any one Use a single TCP connection to deliver multiple requests and responses in parallel. Enable flow-control, server push, etc. HTTP/2 Request/Response Multiplexing Stream 1 HEADERS Stream 2 DATA Stream 3 HEADERS Stream 3 DATA Stream 1 DATA Stream Y HEADERS Stream X DATA Requests Responses HTTP/2 connection Client Server @meteatamel
35. Google Cloud Platform Client and server maintain and update an indexed list of previously seen header fields Indexes are sent for already seen headers Values are encoded with a static Huffman code HPACK: Header compression for HTTP/2 :method GET :scheme HTTPS :host myhost.com :path /image custom_header some_value :method GET :scheme HTTPS :host myhost.com :path /image custom_header some_value HEADERS Frame :method GET :scheme HTTPS :host myhost.com :path /resource custom_header some_value Request #2 Request #1 :method GET :scheme HTTPS :host myhost.com :path /resource custom_header some_value :path /resource + indexes for already seen values HEADERS Frame @meteatamel
36. Google Cloud Platform HTTP/2: What it means for you? HTTP/2 HTTP/1.1 http2demo.io/ @meteatamel
37. Google Cloud Platform Protocol Buffers Publishing 50KB messages at maximum throughput from a single n1-highcpu-16 GPE VM instance, using 9 gRPC channels. More impressive than the almost 3x increase in throughput, is that it took only 1/4 of the CPU resources. 11x difference per CPU 3x increase in throughput https://cloud.google.com/blog/big-data/2016/03/announcing-grpc-alpha-for-google-cloud-pubsub gRPC vs JSON/HTTP for Google Cloud Pub/Sub @meteatamel
38. Google Cloud Platform Multi-Language Support Java/Android Go C/C++ C# Node.js PHP Ruby Python Objective-C Service definitions and client libraries MacOS Linux Windows Android iOS Platforms supported @meteatamel
39. Google Cloud Platform Demo: Greeter Server & Client (C#) @meteatamel https://github.com/meteatamel/grpc-samples-dotnet
40. Google Cloud Platform Connection Options The client send a sequence of messages to the server using a provided stream. Once the client has finished writing the messages, it waits for the server to read them and return its response. Client streaming Both sides send a sequence of messages using a read-write stream. The two streams operate independently. The order of messages in each stream is preserved. Bi-di streaming Unary RPCs where the client sends a single request to the server and gets a single response back, just like a normal function call. Unary The client sends a request to the server and gets a stream to read a sequence of messages back. The client reads from the returned stream until there are no more messages. Server streaming @meteatamel
41. Google Cloud Platform Demo: Chat app using gRPC streaming @meteatamel
42. Confidential & Proprietary Google Cloud Platform 42 grpc.io Mete Atamel @meteatamel atamel.dev Thank You Send talk feedback bit.ly/atamel
