.NET Core IoT para Linux Embarcado com Containers

.NET Core pode ser utilizado em sistemas embarcados para aplicações de IoT. Pensando em extender e facilitar essa utilização a comunidade da .NET Foundation desenvolveu o dotnet/iot que fornece APIs e utilitários de acesso a GPIO e periféricos utilizando o .NET Core framework. Nessa talk apresento na prática, em placas de desenvolvimento, o dotnet/iot e a facilidade de deploy de uma aplicação .NET Core utilizando containers para Linux ARM.

Transcript

2. WHO I AM ? MATHEUS DE BARROS CASTELLO 28 year old, BS in Computer Science Embedded SW Engineer
3. WHO I AM ? Linux Kernel v4.18 BCM2835 Pinctrl dotnet/iot .Net Core 3.0 Preview Libgpiod / PWM MAIN CONTRIBUTIONS
4. WHO I AM ? CHANNELS
5. ME AND .NET WHY AM I TALKING ABOUT THIS?
7. ME AND .NET WHY AM I TALKING ABOUT THIS?
8. .NET CORE FOR EMBEDDED LINUX EMBEDDED LINUX - PERFECT FOR IOT APPLICATIONS
9. .NET CORE FOR EMBEDDED LINUX HARDWARE FOR THE DEMOS - COLIBRI IMX6DL DUAL CORE - ARM A9 @1Ghz 512MB DDR3 4GB eMMC Vivante GC880 - GPU 3D Graphics UP TO 154 GPIOs 4X ANALOG INPUTS I2C / PWM / USB / UART
10. .NET CORE FOR EMBEDDED LINUX RUNNING ON EMBEDDED LINUX
11. .NET CORE FOR EMBEDDED LINUX RUNNING ON EMBEDDED LINUX .NET CORE SDK dotnet new console dotnet build
12. .NET CORE FOR EMBEDDED LINUX RUNNING ON EMBEDDED LINUX dotnet build -r linux-arm
13. .NET CORE FOR EMBEDDED LINUX RUNNING ON EMBEDDED LINUX - WITH CONTAINERS PUSH PULL
14. .NET CORE FOR EMBEDDED LINUX RUNNING ON EMBEDDED DEVICES - WITH CONTAINERS Edge
15. .NET CORE FOR EMBEDDED LINUX GPIO - GENERAL PURPOSE INPUT OUTPUT
16. .NET CORE FOR EMBEDDED LINUX LINUX KERNEL - USER SPACE
17. DOTNET/IOT GPIO ACCESS
18. .NET CORE FOR EMBEDDED LINUX GPIO ACCESS libgpiod ioctl(/dev/gpiochip0) /drivers/pinctrl/core.c /drivers/pinctrl/freescale/
19. DOTNET/IOT .NET FOUNDATION PROJECT https://github.com/dotnet/iot
20. DOTNET/IOT .NET FOUNDATION PROJECT
21. DOTNET/IOT LIBGPIOD INTEROP GpioControlle.cs GpioController.Linux.cs LibGpiodDriver.Linux.cs Interop.libgpiod.cs libgpiod.c System.Device.Gpio.Native.so libgpiod.so
22. DOTNET/IOT MY CONTRIBUTIONS /dev/gpiochip0 28 pins /dev/gpiochip0 32 lines /dev/gpiochip1 32 lines ... /dev/gpiochip6 32 lines
24. DOTNET/IOT DEMO TIME
26. /microhobby /in/matheuscastello @matheus_castello
