Infrastructure as Software

Infrastructure as Software

n this talk, Mikhail will demonstrate why writing infrastructure in general programming languages is a better way to is a better choice for infrastructure management. Pulumi is an open source tool that allows users to write their infrastructure code in TypeScript, Python, .NET or Go.

General-purpose languages allow infrastructure code to have integrated testing, compile-time checks as well as being able to create infrastructure APIs and is more suited to infrastructure management than DSLs, JSON or YAML. In addition, he will demonstrate how to build infrastructure that manages Serverless, Kubernetes, PaaS and IaaS systems across multiple cloud providers.

Mikhail Shilkov

March 25, 2020
Tweet

More Decks by Mikhail Shilkov

Other Decks in Programming

Transcript

  1. Infrastructure
    as Software
    DevOps Pro Europe | 25 March 2020
    Mikhail Shilkov

    View Slide

  2. My first DevOps team
    Developer
    Cloud Infrastructure
    User
    IT

    View Slide

  3. • Software engineer at Pulumi:
    .NET SDK, Azure, Core platform
    • Cloud, Serverless
    • Functional programming, F#
    • Microsoft Azure MVP
    https://mikhail.io
    @MikhailShilkov
    About me

    View Slide

  4. Agenda

    View Slide

  5. Agenda

    View Slide

  6. Agenda

    View Slide

  7. Cloud
    Automation
    3

    View Slide

  8. Unified Management API
    Management API (e.g., Azure Resource Manager)
    Cloud Service Cloud Service Cloud Service
    Web Portal CLI SDK 3rd Party

    View Slide

  9. REST calls
    Content-Type: application/x-www-form-urlencoded; charset=UTF-8
    X-Amz-Date: 20130813T150211Z
    Host: ec2.amazonaws.com
    Authorization: AWS4-HMAC-SHA256 Credential=AKIDEXAMPLE/20130813/us-east-
    1/ec2/aws4_request, SignedHeaders=content-type;host;x-amz-
    date, Signature=ced6826de92d2bdeed8f846f0bf508e8559e98e4b0194b84example54174deb456c
    http://ec2.amazonaws.com/?Action=RunInstances
    ImageId=ami-2bb65342
    &MaxCount=3
    &MinCount=1
    &Monitoring.Enabled=true
    &Placement.AvailabilityZone=us-east-1a
    &Version=2016-11-15

    View Slide

  10. var launchRequest = new RunInstancesRequest()
    {
    ImageId = amiID,
    InstanceType = "t1.micro",
    MinCount = 1,
    MaxCount = 1,
    KeyName = keyPairName,
    SecurityGroupIds = groups
    };
    var launchResponse = ec2Client.RunInstances(launchRequest);
    var instances = launchResponse.Reservation.Instances;
    SDKs to call those REST endpoints

    View Slide

  11. aws ec2 run-instances \
    --image-id ami-5ec1673e \
    --key-name MyKey \
    --security-groups EC2SecurityGroup \
    --instance-type t2.micro \
    --placement AvailabilityZone=us-west-2b
    Command-line Tools

    View Slide

  12. Step-by-step
    provisioning
    process
    Depend on both
    the current and
    the target state
    How to handle
    failures?
    Imperative Complex Error-prone
    Scripting: Challenges

    View Slide

  13. Desired State
    Configuration
    5

    View Slide

  14. Desired State Configuration
    Target Current
    Tool

    View Slide

  15. Managing Resource Graphs
    Target Current
    Tool

    View Slide

  16. Be able to describe
    the desired state in
    full, concisely, and
    correctly
    Determine the
    correct order of
    creation and
    destruction
    Preview the changes
    before running the
    deployment
    Expressiveness Dependencies Transparency
    Challenges

    View Slide

  17. AWS
    CloudFormation
    Azure
    Resource
    Manager
    Google Cloud
    Deployment
    Manager
    Vendor Tools

    View Slide

  18. Markup
    Languages
    8
    YET
    ANOTHER
    MARKUP
    LANGUAGE

    View Slide

  19. Azure ARM Templates: JSON
    "resources": [
    {
    "apiVersion": "2016-01-01",
    "type": "Microsoft.Storage/storageAccounts",
    "name": "mystorageaccount",
    "location": "westus",
    "sku": {
    "name": "Standard_LRS"
    },
    "kind": "Storage",
    "properties": {
    }
    }
    ]

    View Slide

  20. AWS CloudFormation: YAML
    Resources:
    S3BucketForURLs:
    Type: "AWS::S3::Bucket"
    DeletionPolicy: Delete
    Properties:
    BucketName: !If [ "CreateNewBucket", !Ref "AWS::NoValue", !Ref S3BucketName ]
    WebsiteConfiguration:
    IndexDocument: "index.html"
    LifecycleConfiguration:
    Rules:
    -
    Id: DisposeShortUrls
    ExpirationInDays: !Ref URLExpiration
    Prefix: "u"
    Status: Enabled

    View Slide

  21. resource "azurerm_storage_account" "sa" {
    name = "mysa"
    location = azurerm_resource_group.rg.location
    resource_group_name = azurerm_resource_group.rg.name
    account_tier = "Standard"
    account_replication_type = "LRS"
    }
    Terraform: DSL
    (HashiCorp Configuration Language)

    View Slide

  22. Lack of fast
    feedback about
    errors
    Which options need
    to be filled and
    which values are
    possible
    Thousands of lines of
    markup are hard to
    write, read, and
    navigate
    Tooling Discovery Size
    Markup Authoring Experience

    View Slide

  23. Example: Code to infrastructure ratio
    KV Store
    Table “URLs”
    Function
    “Add URL”
    Function
    “Open URL”
    Lines of code
    Function Code ~20
    CloudFormation ~240
    ARM Templates ~160
    Terraform ~220
    Estimates based on public examples

    View Slide

  24. {
    "Resources": {
    "InstanceSecurityGroup": {
    "Type": "AWS::EC2::SecurityGroup",
    "Properties": {
    "SecurityGroupIngress": [ ... ]
    }
    },
    "EC2Instance": {
    "Type": "AWS::EC2::Instance",
    "Properties": {
    "InstanceType": "t2.micro",
    "SecurityGroups": [ { "Ref": "InstanceSecurityGroup" } ],
    "ImageId": "ami-0080e4c5bc078760e"
    }
    }
    }
    }
    References
    Example for AWS CloudFormation

    View Slide

  25. {
    "condition": "[equals(parameters('production'), 'Yes')]",
    "type": "Microsoft.Compute/availabilitySets",
    "apiVersion": "2017-03-30",
    "name": "[variables('availabilitySetName')]",
    "location": "[resourceGroup().location]",
    "properties": {
    "platformFaultDomainCount": 2,
    "platformUpdateDomainCount": 3
    }
    }
    Conditionals
    Example for Azure RM Templates

    View Slide

  26. locals {
    files = ["index.php","main.php"]
    }
    resource "aws_s3_bucket_object" "files" {
    count = "${length(local.files)}"
    key = "${local.files[count.index]}"
    bucket = "${aws_s3_bucket.examplebucket.id}"
    source = "./src/${local.files[count.index]}"
    }
    Loops
    Example for Terraform

    View Slide

  27. Different shape of
    infrastructure for
    different
    environments
    Bundling several
    related resources
    together for a
    higher-level
    component
    Sharing libraries of
    components within
    the company or in
    community
    Configuration Abstraction Packages
    Reusability

    View Slide

  28. Inspect the resulting
    resource tree before
    deployment
    (against mocks)
    Deploy a part of
    your graph to a test
    environment, inspect
    the result
    Test the result of
    a complete
    deployment
    Unit Integration End-to-end
    Testability

    View Slide

  29. I think we
    solved
    these
    problems
    before?

    View Slide

  30. IDEs
    Code completion
    Unit tests
    Types
    Functions
    Package managers
    Versioning
    Classes
    Code reviews
    Contracts
    SDKs
    Workflows
    Refactoring

    View Slide

  31. Pulumi
    Developers and operators working
    on infrastructure together
    12

    View Slide

  32. General-Purpose Programming Languages
    Node.js
    Go
    Python
    .NET

    View Slide

  33. • AWS
    • Azure
    • GCP
    • Digital Ocean
    • Cloudflare
    … and more
    Providers
    • Docker
    • Kubernetes
    • OpenStack
    • PostgreSQL
    • New Relic

    View Slide

  34. const resourceGroup = new azure.core.ResourceGroup("rg");
    const storageAccount = new azure.storage.Account("storage", {
    resourceGroupName: resourceGroup.name,
    accountReplicationType: "LRS",
    accountTier: "Standard",
    });
    TypeScript example

    View Slide

  35. const resourceGroup = new azure.core.ResourceGroup("rg");
    const storageAccount = new azure.storage.Account("storage", {
    resourceGroupName: resourceGroup.name,
    accountReplicationType: "LRS",
    accountTier: "Standard",
    });
    Still,
    Desired
    State!

    View Slide

  36. Command-Line Interface (CLI) drives the deployment
    How Pulumi
    works
    CLI & engine
    Last
    deployed
    state
    Program.cs
    Language host
    AWS
    Azure
    GCP
    Kubernetes
    new Resource()
    CRUD

    View Slide

  37. Demo!
    An S3 website with Pulumi
    16

    View Slide

  38. Serverless
    Functions
    on Azure
    a.k.a. Azure Functions
    21

    View Slide

  39. Resources to Provision an Azure Function
    Blob
    Plan
    Container
    Storage
    Account
    Function
    App

    View Slide

  40. • Encapsulate low-level resources into a higher-level abstraction
    • Reuse, shared abstractions, versioning, package management
    • Grouping and structure
    Component Resources

    View Slide

  41. // A resource group to contain our Azure Functions
    const resourceGroup = new azure.core.ResourceGroup("rg");
    // A Node.js Azure Function
    const nodeApp = new azure.appservice.ArchiveFunctionApp("http", {
    resourceGroup,
    archive: new pulumi.asset.FileArchive("./javascript"),
    });
    export const nodeEndpoint = nodeApp.endpoint;
    Node.js Azure Function

    View Slide

  42. Let’s run pulumi up …
    Type Name Plan
    + pulumi:pulumi:Stack functions-dev create
    + ├─ azure:appservice:ArchiveFunctionApp http create
    + │ ├─ azure:storage:Account http create
    + │ ├─ azure:appservice:Plan http create
    + │ ├─ azure:storage:Container http create
    + │ ├─ azure:storage:ZipBlob http create
    + │ └─ azure:appservice:FunctionApp http create
    + └─ azure:core:ResourceGroup rg create

    View Slide

  43. // A .NET (C#) Azure Function
    const dotnetApp = new azure.appservice.ArchiveFunctionApp("dotnet", {
    resourceGroup,
    archive: new pulumi.asset.FileArchive("./dotnet/bin/Debug/"),
    appSettings: {
    runtime: "dotnet",
    },
    });
    .NET Azure Function

    View Slide

  44. const linuxResourceGroup = new azure.core.ResourceGroup("linuxrg");
    const linuxPlan = new azure.appservice.Plan("linux-asp", {
    resourceGroupName: linuxResourceGroup.name,
    kind: "Linux",
    sku: { tier: "Dynamic", size: "Y1" },
    reserved: true,
    });
    const pythonApp = new azure.appservice.ArchiveFunctionApp(...);
    Azure Function in Python on Linux

    View Slide

  45. const linuxResourceGroup = new azure.core.ResourceGroup("linuxrg");
    const linuxPlan = new azure.appservice.Plan("linux-asp", {...});
    const pythonApp = new azure.appservice.ArchiveFunctionApp("http", {
    resourceGroup: linuxResourceGroup,
    plan: linuxPlan,
    archive: new pulumi.asset.FileArchive("./python"),
    appSettings: {
    runtime: "python",
    },
    });
    Azure Function in Python on Linux

    View Slide

  46. const f = new azure.appservice.HttpEventSubscription("greeting", {
    resourceGroup,
    callback: async (context, req) => {
    return {
    status: 200,
    body: `Hello ${req.params.name}!`,
    };
    },
    });
    Serverless Functions as Callbacks

    View Slide

  47. const queue = new azure.storage.Queue("myqueue", {
    storageAccountName: storageAccount.name,
    });
    queue.onEvent("MyMessageHandler", {
    callback: async (context, msg) => {
    doWork(msg);
    },
    });
    Serverless Functions as Callbacks

    View Slide

  48. Containers
    Simple AWS Fargate deployment
    25

    View Slide

  49. Crosswalk for AWS

    View Slide

  50. Load-
    balanced
    container
    instances
    Load
    Balancer
    Container
    Container

    View Slide

  51. const listener = new awsx.elasticloadbalancingv2.NetworkListener("lb",{
    port: 80 });
    const service = new awsx.ecs.FargateService("nginx", {
    desiredCount: 2,
    taskDefinitionArgs: {
    containers: {
    nginx: {
    image: "jonashackt/spring-boot-vuejs",
    memory: 512,
    portMappings: [listener],
    }}}});
    Nginx on Fargate with a Load Balancer

    View Slide

  52. Let’s run pulumi up …
    Type Name Status
    + pulumi:pulumi:Stack pulumi-typescript-aws-fargate-dev created
    + ├─ awsx:x:ec2:SecurityGroup nginx created
    + │ └─ aws:ec2:SecurityGroup nginx created
    + ├─ awsx:x:ec2:Vpc default-vpc-accd9bc5 created
    + │ ├─ awsx:x:ec2:Subnet default-vpc-accd9bc5-public-1 created
    + │ └─ awsx:x:ec2:Subnet default-vpc-accd9bc5-public-0 created
    + ├─ awsx:x:ecs:FargateService spring-boot-vuejs created
    + │ └─ aws:ecs:Service spring-boot-vuejs created
    + ├─ awsx:x:ecs:FargateTaskDefinition spring-boot-vuejs created
    + │ ├─ aws:cloudwatch:LogGroup spring-boot-vuejs created
    + │ ├─ aws:iam:Role spring-boot-vuejs-execution created
    + │ ├─ aws:iam:Role spring-boot-vuejs-task created
    + │ ├─ aws:iam:RolePolicyAttachment spring-boot-vuejs-execution-9a42f520 created
    + │ ├─ aws:iam:RolePolicyAttachment spring-boot-vuejs-task-32be53a2 created
    + │ ├─ aws:iam:RolePolicyAttachment spring-boot-vuejs-task-fd1a00e5 created
    + │ └─ aws:ecs:TaskDefinition spring-boot-vuejs created
    + ├─ awsx:x:ecs:Cluster default-cluster created
    + │ ├─ awsx:x:ec2:SecurityGroup default-cluster created
    + │ │ ├─ awsx:x:ec2:IngressSecurityGroupRule default-cluster-ssh created
    + │ │ │ └─ aws:ec2:SecurityGroupRule default-cluster-ssh created
    + │ │ ├─ awsx:x:ec2:IngressSecurityGroupRule default-cluster-containers created
    + │ │ │ └─ aws:ec2:SecurityGroupRule default-cluster-containers created
    + │ │ ├─ awsx:x:ec2:EgressSecurityGroupRule default-cluster-egress created
    + │ │ │ └─ aws:ec2:SecurityGroupRule default-cluster-egress created
    + │ │ └─ aws:ec2:SecurityGroup default-cluster created
    + │ └─ aws:ecs:Cluster default-cluster created
    + └─ aws:lb:ApplicationLoadBalancer nginx created
    + ├─ awsx:lb:ApplicationTargetGroup nginx created
    + │ └─ aws:lb:TargetGroup nginx created
    + ├─ awsx:lb:ApplicationListener nginx created
    + │ ├─ awsx:x:ec2:IngressSecurityGroupRule nginx-external-0-ingress created
    + │ │ └─ aws:ec2:SecurityGroupRule nginx-external-0-ingress created
    + │ ├─ awsx:x:ec2:EgressSecurityGroupRule nginx-external-0-egress created
    + │ │ └─ aws:ec2:SecurityGroupRule nginx-external-0-egress created
    + │ └─ aws:lb:Listener nginx created
    + └─ aws:lb:LoadBalancer nginx created

    View Slide

  53. Cosmos App
    Creating custom abstractions
    28

    View Slide

  54. Cosmos App
    (1)

    View Slide

  55. Cosmos App
    (2)

    View Slide

  56. Cosmos App
    (3)

    View Slide

  57. Cosmos App
    (4)

    View Slide

  58. export const functions = new CosmosApp("urls", {
    resourceGroup,
    locations: ["WestEurope", "WestUS", "SouthEastAsia"],
    factory: ({location, cosmosdb}) => {
    const app = new azure.appservice.ArchiveFunctionApp("app", {
    location,
    archive: new pulumi.asset.FileArchive("./app"),
    appSettings: {
    COSMOSDB_ENDPOINT: cosmosdb.endpoint,
    },
    });
    return { id: app.functionApp.id };
    }});
    Global Applications

    View Slide

  59. export const functions = new CosmosApp("urls", {
    resourceGroup,
    locations: ["WestEurope", "WestUS", "SouthEastAsia"],
    factory: ({location, cosmosdb}) => {
    const app = new azure.appservice.ArchiveFunctionApp("app", {
    location,
    archive: new pulumi.asset.FileArchive("./app"),
    appSettings: {
    COSMOSDB_ENDPOINT: cosmosdb.endpoint,
    },
    });
    return { id: app.functionApp.id };
    }});
    Global Applications

    View Slide

  60. Kubernetes
    Deploy to multiple clouds
    32

    View Slide

  61. Kubernetes layers
    Managed Kubernetes cluster
    Infrastructure Resources (networking, storage, identity)
    Managed Service Managed Service
    Application Application Application

    View Slide

  62. Crosswalk
    for
    Kubernetes

    View Slide

  63. // Define the application Pod.
    const appPod = new kx.PodBuilder({
    containers: [{
    image: "app:1.0.0",
    env: { "APP_CONFIG_PATH": "/app/config" },
    volumeMounts: [configs.mount("/app/config")],
    }],
    });
    // Create a Kubernetes Deployment using the previous Pod definition.
    const deployment = new kx.Deployment("nginx", {
    spec: appPod.asDeploymentSpec({ replicas: 3 }),
    });
    // Expose the Deployment with a load balancer using a Kubernetes Service.
    const service = deployment.createService({
    type: kx.types.ServiceType.LoadBalancer,
    });
    Kubernetesx Library

    View Slide

  64. Quality Control
    34

    View Slide

  65. Programming
    Languages for
    Infrastructure?
    You sure?

    View Slide

  66. const group = require("./index").group;
    // check: Instances must not have SSH open to the Internet.
    it("must not open port 22 (SSH) to the Internet", done => {
    pulumi.all([ group.urn, group.ingress ]).apply(([ urn, ingress ]) => {
    if (ingress.find(rule =>
    rule.fromPort == 22 && rule.cidrBlocks.find(block => block === "0.0.0.0/0"))) {
    done(new Error(`Illegal SSH port 22 open to the Internet on group ${urn}`));
    } else {
    done();
    }
    });
    });
    Unit Testing

    View Slide

  67. Policy as Code
    const policies = new PolicyPack("aws", {
    policies: [
    {
    name: "prohibited-public-internet",
    description: "Ingress rules with public internet access are prohibited.",
    enforcementLevel: "mandatory",
    validateResource: validateTypedResource(aws.ec2.SecurityGroup, (sg, args, report) => {
    const publicInternetRules = (sg.ingress || []).find(ingressRule =>
    (ingressRule.cidrBlocks || []).find(cidr => cidr === "0.0.0.0/0"));
    if (publicInternetRules) {
    report("Ingress rules with public internet access are prohibited.");
    }
    }),
    },
    ],
    });

    View Slide

  68. Conclusions
    37

    View Slide

  69. Define
    Infrastructure
    as Code
    Making
    Cloud
    Apps?

    View Slide

  70. Familiar language,
    experience,
    toolchain, packages
    Conditionals, loops,
    functions, classes,
    components,
    modules
    Reusable
    components that
    encapsulate
    complex logic and
    provide the right
    level of abstraction
    Developer-friendly Logic Abstractions
    Benefits of Real Code

    View Slide

  71. м
    Infrastructure
    as Code
    Architecture
    as Code

    View Slide

  72. http://bit.ly/pulumilinks
    Useful Links

    View Slide

  73. @MikhailShilkov
    https://mikhail.io

    View Slide
