SDK and Scripting: Challenges 15 Imperative Step-by-step provisioning process Complex Depend on both the current and the target state Error-prone How to handle failures?
var resourceGroup = new ResourceGroup("rg"); var storageAccount = new Account("storage", new AccountArgs { ResourceGroupName = resourceGroup.Name, AccountReplicationType = "LRS", AccountTier = "Standard", }); C# Example
Desired State! var resourceGroup = new ResourceGroup("rg"); var storageAccount = new Account("storage", new AccountArgs { ResourceGroupName = resourceGroup.Name, AccountReplicationType = "LRS", AccountTier = "Standard", });
Markup Authoring Experience 22 Tooling Lack of tooling on day 1. No fast feedback from editors. Discovery Which properties can be set, and which values are valid? Size Thousands of lines of markup are hard to write, read, and maintain
Example App: Serverless URL Shortener KV Store Table “URLs” Function “Add URL” Function “Open URL” Tool Lines of code Function Code ~20 CloudFormation ~240 ARM Templates ~160 Terraform ~220 Estimates based on public examples
' Create an Azure Resource Group Dim resourceGroup = New ResourceGroup("resourceGroup") ' Create an Azure Storage Account Dim storageAccount = New Account("storage", New AccountArgs With { .ResourceGroupName = resourceGroup.Name, .AccountReplicationType = "LRS", .AccountTier = "Standard" }) Cloud Resources with VB.NET
// A resource group to contain our Azure Functions var resourceGroup = new ResourceGroup("functions-rg"); // A .NET Azure Function var dotnet = new ArchiveFunctionApp("http", new ArchiveFunctionAppArgs { ResourceGroup = resourceGroup, Archive = new FileArchive("./dotnet/bin/Debug/netcoreapp3.1/publish") }); .NET Azure Function
// A Node.js Azure Function var js = new ArchiveFunctionApp("js", new ArchiveFunctionAppArgs { ResourceGroup = resourceGroup, Archive = new FileArchive("./javascript"), Runtime = "node" }); Node.js Azure Function
var linuxResourceGroup = new ResourceGroup("linux-rg"); var linuxPlan = new Plan("linux-asp", new PlanArgs { ResourceGroupName = linuxResourceGroup.Name, Kind = "Linux", Reserved = true, Sku = new PlanSkuArgs { Tier = "Dynamic", Size = "Y1" } }); var python = new ArchiveFunctionApp(...); Python Azure Function on Linux
var linuxResourceGroup = new ResourceGroup("linux-rg"); var linuxPlan = new Plan("linux-asp", new PlanArgs { ... }); var python = new ArchiveFunctionApp("py", new ArchiveFunctionAppArgs { ResourceGroup = linuxResourceGroup, Archive = new FileArchive("./python"), Plan = linuxPlan, Runtime = "python" }); Python Azure Function on Linux
[Fact] public async Task InstancesMustNotHaveSshPortOpenToInternet() { var resources = await Deployment.TestAsync(); var resource = resources.OfType().Single(); var ingress = await resource.GetAsync(sg => sg.Ingress); foreach (var rule in ingress) foreach (var cidrBlock in rule.CidrBlocks) { Assert.False(rule.FromPort == 22 && cidrBlock == "0.0.0.0/0", "Illegal SSH port 22 open to the Internet (CIDR 0.0.0.0/0)"); } } Unit Testing
[Fact] public async Task InstancesMustNotHaveSshPortOpenToInternet() { var resources = await Deployment.TestAsync(); var resource = resources.OfType().Single(); var ingress = await resource.GetAsync(sg => sg.Ingress); foreach (var rule in ingress) foreach (var cidrBlock in rule.CidrBlocks) { Assert.False(rule.FromPort == 22 && cidrBlock == "0.0.0.0/0", "Illegal SSH port 22 open to the Internet (CIDR 0.0.0.0/0)"); } } Unit Testing
[Fact] public async Task InstancesMustNotHaveSshPortOpenToInternet() { var resources = await Deployment.TestAsync(); var resource = resources.OfType().Single(); var ingress = await resource.GetAsync(sg => sg.Ingress); foreach (var rule in ingress) foreach (var cidrBlock in rule.CidrBlocks) { Assert.False(rule.FromPort == 22 && cidrBlock == "0.0.0.0/0", "Illegal SSH port 22 open to the Internet (CIDR 0.0.0.0/0)"); } } Unit Testing
State Management CLI and Engine Last deployed state Program.cs Language host AWS Azure GCP Kubernetes new Resource() CRUD Pulumi Service S3 / Blob Storage Local disk
Pulumi Components 51 CLI Open-source Free for any use Cross-platform Written in Go Providers Open-source Free for any use Can be created by 1st or 3rd party SaaS backend Web API + portal “GitHub for infra” Free for individuals Paid plans for teams Useful but not required
Cloud Transition 53 Kubernetes Azure Functions AWS S3 Azure Analytics Google ML MySQL DataDog App Docker DataDog New Relic App MySQL EARLY CLOUD Mostly Static N-Tier Apps VMs Private Cloud CURRENT CLOUD Partly Dynamic Less Monolithic VMs and Containers* Hybrid - Public/Private *ExperimentaDon FUTURE CLOUD Fully Dynamic Hyper-Connected Services Containers and Serverless Mostly Public Cloud
Stack References Org: acme-corp vpc Stack: dev env: dev region: us-east-1 k8s-cluster Stack: dev env: dev region: us-east-1 svc-userprofile Stack: dev env: dev region: us-east-1 svc-email Stack: dev env: dev region: us-east-1
PROVISIONING Developer-friendly Familiar language experience, toolchain, packages – applied to cloud infrastructure. Developers and operators working in a team. Cloud Engineering Transformed TESTING Confidence and quality Unit testing and TDD with battle-tested tools to ensure correctness. Policy as Code for compliance, cost control, and company-wide best practices. ARCHITECTURE Logic and abstractions Conditionals, loops, functions, classes, and packages out of the box. Reusable components that encapsulate complex logic and provider the right level of abstraction. Modern Infrastructure as Code Capabilities to ship faster and with confidence
