ArangoDB at Monsters on Rails

Slides from my talk at the Münster Ruby UG

Transcript

1. 1 Lucas Dohmen @moonbeamlabs ! the multi-purpose NoSQL Database ! www.arangodb.org
2. Lucas Dohmen ‣ ArangoDB Core Team ‣ ArangoDB Foxx & Ruby Adapter ‣ Student on the master branch ‣ hacken.in & nerdkun.de 2 /\ (~( ) ) /\_/\ ( _-----_(@ @) ( \ / /|/--\|\ V " " " "
3. Why did we start ArangoDB? How should an ideal multi-purpose database look like? Is it already out there? ! ‣ Second Generation NoSQL DB ‣ Unique feature set ‣ Solves some problems of other NoSQL DBs ‣ Greenfield project ‣ Experienced team building NoSQL DBs for more than 10 years 3
4. Main Features 4 ‣ Open source and free ‣ Multi model database ‣ Convenient querying ‣ Extendable through JS & MRuby ‣ High performance & space efficiency ‣ Easy to use ‣ Started in Sep 2011 ‣ Current Version: 1.4
5. Free and Open Source ‣ Apache 2 License ‣ On Github ‣ Do what you want with it ‣ ... and don‘t pay a dime!
6. Multi model database 6 Key/Value Store Document Store Graph Database Source: Andrew Carol Polyglot Persistence
7. Key-Value Store ‣ Map value data to unique string keys (identifiers) ‣ Treat data as opaque (data has no structure) ‣ Can implement scaling and partitioning easily due to simplistic data model ‣ Key-value can be seen as a special case of documents. For many applications this is sufficient, but not for all cases. ! ArangoDB ‣ It‘s currently supported as a key-value document. ‣ In the near future it supports special key-value collection. ‣ One of the optimization will be the elimination of JSON in this case, so the value need not be parsed. ‣ Sharding capabilities of Key-Value Collections will differ from Document Collections
8. Document Store ‣ Normally based on key-value stores (each document still has a unique key) ‣ Allow to save documents with logical similarity in „collections“ ‣ Treat data records as attribute-structured documents (data is no longer opaque) ‣ Often allows querying and indexing document attributes ! ArangoDB ‣ It supports both. A database can contain collections from different types. ‣ For efficient memory handling we have an automatic schema recognition. ‣ It has different ways to retrieve data. CRUD via RESTful Interface, QueryByExample, JS for graph traversals and AQL.
9. ‣ Example: Computer Science Bibliography ! ! ! ! ! ArangoDB ‣ Supports Property Graphs ‣ Vertices and edges are documents ‣ Query them using geo-index, full-text, SQL-like queries ‣ Edges are directed relations between vertices ‣ Custom traversals and built-in graph algorithms Graph Store
10. Analytic Processing DBs Transaction Processing DBs Managing the evolving state of an IT system Complex Queries Map/Reduce Graphs Extensibility Key/Value Column-
 Stores Documents Massively Distributed Structured Data NoSQL Map
12. *) Source: Martin Fowler, http://martinfowler.com/articles/nosql-intro.pdf Reporting RDBMS User activity log Cassandra Product Catalog MongoDB Analytics Cassandra Shopping Cart Riak Recommendations Neo4J Financial Data RDBMS User Sessions Redis Polyglot Persistence Example*
 Polyglot Persistence with ArangoDB Reporting RDBMS User activity log Cassandra Product Catalog ArangoDB Analytics Cassandra Shopping Cart ArangoDB Recommendations ArangoDB Financial Data ArangoDB User Sessions ArangoDB
13. Convenient querying Different scenarios require different access methods: ‣ Query a document by its unique id / key: GET /_api/document/users/12345 ‣ Query by providing an example document: PUT /_api/simple/by-example { "name": "Jan", "age": 38 } ‣ Query via AQL: FOR user IN users FILTER user.active == true RETURN { name: user.name } ‣ Graph Traversals und JS for your own traversals ‣ JS Actions for “intelligent” DB request
14. Why another query language?
15. Other Document Stores ‣ MongoDB uses JSON/BSON as its “query language” ‣ Limited ‣ Hard to read & write for more complex queries ‣ Complex queries, joins and transactions not possible ‣ CouchDB uses Map/Reduces ‣ It‘s not a relational algebra, and therefore hard to generate ‣ Not easy to learn ‣ Complex queries, joins and transactions not possible
16. ArangoDB Query Language (AQL)
17. Example for Aggregation ‣ Retrieve cities with the number of users: FOR u IN users COLLECT city = u.city INTO g RETURN { "city" : city, "numUsersInCity": LENGTH(g) }
18. Example for Graph Query ‣ Paths: FOR u IN users LET userRelations = ( FOR p IN PATHS( users, relations, "OUTBOUND" ) FILTER p._from == u._id RETURN p ) RETURN { "user" : u, "relations" : userRelations }
19. Extendable through JS & MRuby ‣ Scripting-Languages enrich ArangoDB ‣ Multi Collection Transactions ‣ Building small and efficient Apps - Foxx App Framework ‣ Individually Graph Traversals ‣ Cascading deletes/updates ‣ Assign permissions to actions ‣ Aggregate data from multiple queries into a single response ‣ Carry out data-intensive operations ‣ Help to create efficient Push Services - in the near Future ! ‣ Currently supported ‣ Javascript (Google V8) ‣ Mruby (experimental, not fully integrated yet)
20. Action Server - kind of Application Server ‣ ArangoDB can answer arbitrary HTTP requests directly ‣ You can write your own JavaScript functions (“actions”) that will be executed server-side ‣ Includes a permission system ! ➡ You can use it as a database or as a combined database/app server
21. ‣ Single Page Web Applications ‣ Native Mobile Applications ‣ ext. Developer APIs APIs - will become more & more important
22. ArangoDB Foxx ‣ What if you could talk to the database directly? ‣ It would only need an API. ‣ What if we could define this API in JavaScript? ! ! ! ! ! ! ‣ ArangoDB Foxx is streamlined for API creation – not a jack of all trades ‣ It is designed for front end developers: Use JavaScript, which you already know (without running into callback hell)
23. Foxx - Simple Example
24. Foxx - More features ‣ Full access to ArangoDB‘s internal APIs: ‣ Simple Queries ‣ AQL ‣ Traversals ‣ Automatic generation of interactive documentation ‣ Models and Repositories ‣ Central repository of Foxx apps for re-use and inspiration ‣ Authentication Module
25. High performance & space efficiency RAM is cheap, but it's still not free and data volume is growing fast. Requests volumes are also growing. So performance and space efficiency are key features of a multi-purpose database. ! ‣ ArangoDB supports automatic schema recognition, so it is one of the most space efficient document stores. ‣ It offers a performance oriented architecture with a C database core, a C++ communication layer, JS and C++ for additional functionalities. ‣ Performance critical points can be transformed to C oder C++. ‣ Although ArangoDB has a wide range of functions, such as MVCC real ACID, schema recognition, etc., it can compete with popular stores documents.
26. Space Efficiency ‣ Measure the space on disk of different data sets ‣ First in the standard config, then with some optimization ‣ We measured a bunch of different tasks
27. Store 50,000 Wiki Articles
28. 3,459,421 AOL Search Queries
29. Performance: Disclaimer ‣ Always take performance tests with a grain of salt ‣ Performance is very dependent on a lot of factors including the specific task at hand ‣ This is just to give you a glimpse at the performance ‣ Always do your own performance tests (and if you do, report back to us :) ) ‣ But now: Let‘s see some numbers
30. Execution Time:
    Bulk Insert of 10,000,000 documents
31. Conclusion from Tests ‣ ArangoDB is really space efficient ‣ ArangoDB is “fast enough” ‣ Please test it for your own use case
32. Easy to use ‣ Easy to use admin interface ‣ Simple Queries for simple queries, AQL for complex queries ‣ Simplify your setup: ArangoDB only – no Application Server etc. – on a single server is sufficient for some use cases ‣ You need graph queries or key value storage? You don't need to add another component to the mix. ‣ No external dependencies like the JVM – just install ArangoDB ‣ HTTP interface – use your load balancer
33. Admin Frontend
    Dashboard
34. Admin Frontend
    Collections & Documents
35. Admin Frontend
    AQL development
36. Admin Frontend
    complete V8 access
37. ArangoShell
38. Join the growing community
39. ArangoDB.explain() { "type": "2nd generation NoSQL database", "model": [ "document", "graph", "key-value" ], "openSource": true, "license“: "apache 2", "version": [ "1.3 stable", "1.4 alpha" ], "builtWith": [ "C", "C++", "JS" ], "uses": [ "Google V8" ], "mainFeatures": [ "Multi-Collection-Transaction", "Foxx API Framework", "ArangoDB Query Language", "Various Indexes", "API Server", "Automatic Schema Recognition" ] }
