Better call Google Pay

Александр Смирнов, PapaJobs – MOSDROID #16 Sulfur

Детально погрузимся в то, как устроен Google Pay под капотом. Узнаем, как просто встроить возможность оплаты в ваше приложение и когда его можно (и главное, нужно) использовать.

Transcript

1. Better Call Google Pay ALEXANDER SMIRNOV 30.03.2019
2. WHOAMI ANDROID DEVELOPER SINCE 2012 @ANDROIDINFACES CTO IN PAPAJOBS @MOSDROID GDE PAYMENTS
3. LET’S GO
4. LET’S GO https://g.co/pay/webdemo
5. FOR USER
6. PROBLEMS
7. IT’S EASY
8. IT’S EASY: FROM
9. IT’S EASY: TO
10. INTEGRATION
11. INTEGRATION
12. FEATURES
13. FOR BUSINESS
14. PROBLEMS
15. USERS READY Billions of Users
 across Google Hundreds of millions
 of forms of payment saved
 to their Accounts Users ready
 to pay everywhere
16. CONVERSION 28%
17. CONVERSION of cart abandonments
 due to “too long/complicated checkout process” 28%
18. RIVALS
19. RIVALS
20. RIVALS APPLICATION Google Pay Integration LAMODA + Joom + WildBerries – Юлмарт ?
21. FOR DEVELOPER
22. DESIGN • Display Google Pay early and prominently as payment method
 • Display all relevant purchase information including final price
 and items/services purchased, before confirming an order
 • If you display payment information on confirmation screens
 or emails, you may display the payment card description
 returned by Google Pay API
 • Use only the official button styles and logo assets in your app
23. HOW IT’S WORKS?
24. FAST DIVE 1. Add dependencies + Configure
 2.Initiate PaymentsClient
 3.isReadyToPay()
 4.loadPaymentData()
 5.Handle the PaymentData response object
25. 1. ADD DEPENDENCIES + CONFIGURE dependencies { implementation 'com.google.android.gms:play-services-wallet:16.0.0' implementation 'com.android.support:appcompat-v7:24.1.1' } <meta-data android:name="com.google.android.gms.wallet.api.enabled" android:value="true" />
26. 2. Create PaymentsClient Instance PaymentsClient mPaymentsClient = Wallet.getPaymentsClient( this, new Wallet.WalletOptions.Builder() .setEnvironment(WalletConstants.ENVIRONMENT_TEST) .build());
27. 3. Call isReadyToPay() Determines if the user can make payments using the Pay APIs
28. 3. Call isReadyToPay() public static JSONObject getIsReadyToPayRequest() { JSONObject isReadyToPayRequest = getBaseRequest(); isReadyToPayRequest.put("allowedPaymentMethods", new JSONArray().put(getBaseCardPaymentMethod())); return isReadyToPayRequest; }
29. 3. Call isReadyToPay() { "apiVersion": 2, "apiVersionMinor": 0, "allowedPaymentMethods": [ { "type": "CARD", "parameters": { "allowedAuthMethods": ["PAN_ONLY", "CRYPTOGRAM_3DS"], "allowedCardNetworks": ["AMEX", "DISCOVER", "JCB", "MASTERCARD", "VISA"] } } ] }
30. 3. Call isReadyToPay() IsReadyToPayRequest request = IsReadyToPayRequest.fromJson(getIsReadyToPayRequest().toString()); Task<Boolean> task = mPaymentsClient.isReadyToPay(request); task.addOnCompleteListener( new OnCompleteListener<Boolean>() { @Override public void onComplete(@NonNull Task<Boolean> task) { try { boolean result = task.getResult(ApiException.class); if (result) { // show Google Pay as a payment option } } catch (ApiException e) { } } });
31. 4. Create PaymentDataRequest object public static JSONObject getPaymentDataRequest() { JSONObject paymentDataRequest = getBaseRequest(); paymentDataRequest.put( "allowedPaymentMethods", new JSONArray() .put(getCardPaymentMethod())); paymentDataRequest.put("transactionInfo", getTransactionInfo()); paymentDataRequest.put("merchantInfo", getMerchantInfo()); return paymentDataRequest; }
32. 4. Create PaymentDataRequest object private static JSONObject getTransactionInfo() { JSONObject transactionInfo = new JSONObject(); transactionInfo.put("totalPrice", "12.34"); transactionInfo.put("totalPriceStatus", "FINAL"); transactionInfo.put("currencyCode", "USD"); return transactionInfo; }
33. 4. Create PaymentDataRequest object private static JSONObject getMerchantInfo() { return new JSONObject() .put("merchantName", "Example Merchant"); }
34. 4. Create PaymentDataRequest object "apiVersion": 2, "apiVersionMinor": 0, "merchantInfo": {"merchantName": "Example Merchant"}, "allowedPaymentMethods": [ { "type": "CARD", "parameters": { "allowedAuthMethods": ["PAN_ONLY", "CRYPTOGRAM_3DS"], "allowedCardNetworks": ["AMEX", "DISCOVER", "JCB", "MASTERCARD", "VISA"] }, "tokenizationSpecification": { "type": "PAYMENT_GATEWAY", "parameters": { "gateway": "example", "gatewayMerchantId": "exampleGatewayMerchantId" } } } ], "transactionInfo": { "totalPriceStatus": "FINAL", "totalPrice": "12.34", "currencyCode": “USD”}
35. 4. REGISTER EVENT HANDLER findViewById(R.id.googlepay) .setOnClickListener( new View.OnClickListener() { @Override public void onClick(View v) { PaymentDataRequest request = PaymentDataRequest.fromJson(paymentDataRequest.toString()); if (request != null) { AutoResolveHelper.resolveTask( mPaymentsClient.loadPaymentData(request), this, // LOAD_PAYMENT_DATA_REQUEST_CODE is a constant integer value you define LOAD_PAYMENT_DATA_REQUEST_CODE); } } });
36. 5. HANDLE THE RESPONSE OBJECT protected void onActivityResult(int requestCode, int resultCode, Intent data) { switch (requestCode) { // value passed in AutoResolveHelper case LOAD_PAYMENT_DATA_REQUEST_CODE: switch (resultCode) { case Activity.RESULT_OK: PaymentData paymentData = PaymentData.getFromIntent(data); String json = paymentData.toJson(); // if using gateway tokenization, pass this token without modification String paymentMethodData = new JSONObject(json).getJSONObject(“paymentMethodData”); String paymentToken = paymentMethodData.getJSONObject("tokenizationData").getString("token"); break; case Activity.RESULT_CANCELED: break; case AutoResolveHelper.RESULT_ERROR: Status status = AutoResolveHelper.getStatusFromIntent(data); // Log the status for debugging. // Generally, there is no need to show an error to the user. // The Google Pay payment sheet will present any account errors. break; } break; } }
37. TEST & DEPLOY •Testing ◦ Test environment does not return live chargeable tokens in the PaymentData response ◦ The environment value can be one of the following:
 WalletConstants.ENVIRONMENT_TEST
 WalletConstants.ENVIRONMENT_PRODUCTION ◦ Review branding requirements
 •Deploying to your production ◦ Get access to the production environment – https://services.google.com/fb/forms/googlepaymentAPI/ ◦ Sign your app with release keys ◦ Configure your app for production
38. ONE MORE TIME
39. REFERENCES Google Pay API Android Sample App
 https://github.com/google-pay/paymentsapi-quickstart

 Google Pay API Developer Site – https://g.co/pay/developers
 Demo – https://g.co/pay/demo
 One more reference
 https://g.co/pay/processors https://g.co/pay/autofill https://g.co/pay/loyalty https://g.co/pay/passes
40. ENJOY @mosdroid @smred noreply@papajobs.ru
