Surviving an Amazon Outage

Transcript

1. ©Continuent 2012. Surviving An Amazon Outage Neil Armitage, Cluster implementation Engineer, Continuent Sunday, 21 April 13
2. ©Continuent 2012 2 Overview • Continuent’s external/internal infrastructure is built in AWS • Review carried out in the Summer of 2012 after several AWS Outages • Treated the review as a Customer engagement • Further review in Autumn of 2012 leading to the Multi-Cloud deployment Sunday, 21 April 13
3. ©Continuent 2012 What is AWS Amazon Web Services is a collection of remote computing services (also called web services) that together make up a cloud computing platform. The central services are EC2 (Compute) and S3 (Storage) Services. 3 Sunday, 21 April 13
4. ©Continuent 2012 AWS Regions 4 Ireland (3 AZ) Sao Paulo (2 AZ) Northern Virginia (5 AZ) Oregon (3 AZ) California (3 AZ) Singapore (2 AZ) Tokyo (3 AZ) Sydney (2 AZ) Sunday, 21 April 13
5. ©Continuent 2012 AWS Availability Zones 5 Region Availability Zone Availability Zone Availability Zone Region Availability Zone Availability Zone Sunday, 21 April 13
6. ©Continuent 2012 AWS Services • Compute EC2 • Network - Route 53 and Virtual Private Cloud (VPC) • Content Delivery - Cloudfront • Storage - S3, Glacier, EBS • Database - DynamoDB, RDS, RedShift, SimpleDB • Deployment - Cloudformation, Beanstalk, OpsWorks 6 Sunday, 21 April 13
7. ©Continuent 2012 AWS Size* • Between 100K and 500K physical servers • 1.5million Public IP Addresses • S3 holds > 2 Trillion objects - 1.1m requests per second • 1/3 of daily users access a site running on AWS • 1% of internet tra!c goes through Amazon Infrastructure 7 * Estimates based on various internet sources Sunday, 21 April 13
8. ©Continuent 2012 Continuent Systems • External facing website • Jira/Con"uence internal systems • Subversion • Jenkins build system 8 Sunday, 21 April 13
9. ©Continuent 2012 External Website 9 Internet Elastic IP Web Server DB Server Region Availability Zone Sunday, 21 April 13
10. ©Continuent 2012 Jira/Con"uence/Subversion 10 Internet Elastic IP App Server Jira Confluence SVN Server MySQL Availability Zone Region Sunday, 21 April 13
11. ©Continuent 2012 AWS Problems Summer 2012 “Amazon Cloud Hit by Real Clouds, Downing Net"ix, Instagram, Other Sites” Severe Storms caused power outages at AWS US-East Data centers, generators failed taking out 7% of EC2 instances. http://www.pcworld.com/article/258627/ amazon_cloud_hit_by_real_clouds_knocking_out_popular_sites_like_netflix_instagram.html 11 Sunday, 21 April 13
12. ©Continuent 2012 Migration Plan • Move to a clustered Continuent Tungsten environment • Ensure all components are replicated into at least one other AWS Region • Limited downtime on Customer facing systems • Minimal downtime on internal systems 12 Sunday, 21 April 13
13. ©Continuent 2012 13 Master Slave Slave App Logic Tungsten Connector Replicator Replicator Replicator App Logic Tungsten Connector Manager Manager Manager Data Service: nyc Sunday, 21 April 13
14. ©Continuent 2012 13 Master Slave Slave App Logic Tungsten Connector Replicator Replicator Replicator App Logic Tungsten Connector Manager Manager Manager Monitoring and control Monitoring and control Data Service: nyc Sunday, 21 April 13
15. ©Continuent 2012 13 Master Slave Slave App Logic Tungsten Connector Replicator Replicator Replicator App Logic Tungsten Connector Manager Manager Manager Monitoring and control Monitoring and control Data Service: nyc Sunday, 21 April 13
16. ©Continuent 2012 13 Master Slave Slave App Logic Tungsten Connector Replicator Replicator Replicator App Logic Tungsten Connector Manager Manager Manager Monitoring and control Monitoring and control Data Service: nyc Sunday, 21 April 13
17. ©Continuent 2012 Website Database Tier - Round 1 14 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Connectors Sunday, 21 April 13
18. ©Continuent 2012 DB Failures - Failure in US-EAST-1C 15 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Connectors Sunday, 21 April 13
19. ©Continuent 2012 DB Failures - Failure in US-EAST 16 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Connectors Sunday, 21 April 13
20. ©Continuent 2012 17 DEMO Sunday, 21 April 13
21. ©Continuent 2012 Website Web Tier - Round 1 18 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Internet EIP Sunday, 21 April 13
22. ©Continuent 2012 Web Failures - Failure in US-EAST-1C 19 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Internet EIP Sunday, 21 April 13
23. ©Continuent 2012 Web Failures - Failure in US-EAST 20 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Internet EIP DNS Update Sunday, 21 April 13
24. ©Continuent 2012 Jira/Con"uence/SVN - Round 1 21 Region Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1C 1C S3 Backups S3 Backups Internet EIP Sunday, 21 April 13
25. ©Continuent 2012 AWS Failures - Autumn 2012 “Amazon Web Services outage takes out popular websites again” •EBS degraded performance •Problems allocating new volumes http://www.pcworld.com/article/2012852/amazon-web-services-outage-takes-out-popular- websites-again.html 22 Sunday, 21 April 13
26. ©Continuent 2012 Website Database Tier - Round 2 23 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups RackSpace Sunday, 21 April 13
27. ©Continuent 2012 Website Web Tier - Round 2 24 Region Availability Zone Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1B 1C 1C S3 Backups S3 Backups Internet EIP RackSpace Sunday, 21 April 13
28. ©Continuent 2012 Jira/Con"uence/SVN - Round 2 25 Region Availability Zone Region Availability Zone US-EAST-1 US-WEST-1 1C 1C S3 Backups S3 Backups Internet EIP RackSpace Sunday, 21 April 13
29. ©Continuent 2012 Best Practices • RAID EBS Volumes (RAID1) • Backups • xtrabackup (backed up into S3) • EBS Snapshot 26 ec2-­‐consistent-­‐snapshot  \  -­‐-­‐mysql  -­‐-­‐freeze-­‐filesystem  /vol  \  -­‐-­‐region  eu-­‐west-­‐1    \  -­‐-­‐description  "$(hostanme)  RAID  snapshot   $(date  +'%Y-­‐%m-­‐%d  %H:%M:%S')"  \  vol-­‐1f9a6446  vol-­‐649a643d Sunday, 21 April 13
30. ©Continuent 2012 Best Practices • Monitoring • Nagios scripts converted to email alerts • New Relic 27 Sunday, 21 April 13
31. ©Continuent 2012 Lesson Learnt • EC2 Instances fail • One of anything is never enough • Don’t assume you can spin up more resources instantly • Think multi-cloud, public/private 28 Sunday, 21 April 13
32. ©Continuent 2012 Further Plans • Realtime replication of web assets (glusterFS?) • Introduce a Elastic Load Balancer in front of US-EAST Web servers to allow for auto web failover • Migrate into a VPC 29 Sunday, 21 April 13
