The Little Lawyer

A Semi-Intelligent Scaling Technique for Predictable Load Patterns

Transcript

1. The Little Lawyer A Semi-Intelligent Scaling Technique for Predictable Load Patterns
2. I’m Alan.
3. I work with these fine people.
5. What is MealPal?
8. Why, oh why, did I wait in line?
9. <$6 In New York City, get lunch for less than $6 every weekday.
11. Meals On Rails
12. Clockwork & Delayed::Job
14. Rails Apps • PostgreSQL • Heroku • Core Engine • Legacy API Engine • Consumer App • Restaurant App • CX + Ops App
16. The Hungriest Timeline
17. • Mon 17:00 - “Kitchen Open” ◦ 17:00 - Send “Kitchen is Open” notifications to users • Tue 09:30 - “Kitchen Close” ◦ 09:15 - Send “Kitchen Is Closing” notifications to users ◦ 09:30 - Send orders to restaurants • Tue 15:00 - Last pickup-window ends • Tue 17:00 - “Kitchen Open”
18. 4:59 PM
19. 5:00 PM
20. 5:05 PM
25. NYC CHI SFO
27. A Naive Approach
28. # subscriber/lib/clock.rb module Clockwork evening_reservation_day = ->(t) { (0..4).cover? t.wday } City.real.with_location.distinct.pluck(:time_zone_name).each do |tz| every(1.day, 'web_scale_high', at: '16:45', tz: tz, if: evening_reservation_day) do HerokuSubscriberScale.new(web: 40, worker: 30).save end every(1.day, 'web_scale_low', at: '17:15', tz: tz, if: evening_reservation_day) do HerokuSubscriberScale.new(web: 15, worker: 10).save end end end
29. # subscriber/app/models/heroku_scale.rb class HerokuScale include ActiveModel::Model attr_accessor :env, :web, :worker def save! heroku.formation.update(heroku_application_name, :web, quantity: web) if web heroku.formation.update(heroku_application_name, :worker, quantity: worker) if worker SlackMessage.new(text: scale_status_message, channel: slack_channel_name).save Rails.logger.info(scale_status_message) true end # ... end
31. “soz, mate”
32. March 2018 UTC Timeline
33. A Less Naive Approach
34. March 2018 UTC Timeline Hotspots
35. Request Count / 15m Timeslices, 7-day Comparison _source=subscriber-production "heroku router - at=info" | timeslice 15m | count by _timeslice | order by _timeslice
36. Expected Hotspots vs Request Frequency
38. Little’s Law Little's Law tells us that the average number of customers in the store L, is the effective arrival rate λ, times the average time that a customer spends in the store W L = λW
39. 1/s = x 5 5s duration rate of arrival in-system
40. 1/s = x 20 20s duration rate of arrival in-system
41. 500/s = x 50 100ms duration rate of arrival in-system / (processes x threads )
43. _source=subscriber-production "app web." AND "method=" | parse "duration=* " as ms | timeslice 30m | count(_timeslice) as requests_per_30min, max(ms) as max_duration_ms by _timeslice | outlier max_duration_ms | requests_per_30min / 30 / 60 / 1000 as requests_per_ms | 16 as threads_per_dyno | (requests_per_ms * (max_duration_ms_mean)) as required_thread_count | required_thread_count / threads_per_dyno as required_web_dyno_count | fields _timeslice, required_web_dyno_count | compare with timeshift 1d 7 | sort by _timeslice desc | limit 48
45. =MAX(IF(B3 > B2, ROUNDUP(B2 + ((B3-B2)/ 2)), B2), $D$51)
47. $webscale { "UTC": [ { "duration": "0000-0030", "web": 33, "worker": 13 }, { "duration": "0030-0100", "web": 35, "worker": 5 }, { "duration": "0100-0130", "web": 20, "worker": 5 }, { "duration": "0130-0200", "web": 18, "worker": 5 }, { "duration": "0200-0230", "web": 16, "worker": 5 }, { "duration": "0230-0300", "web": 15, "worker": 8 }, { "duration": "0300-0330", "web": 15, "worker": 14 }, { "duration": "0330-0400", "web": 15, "worker": 7 }, { "duration": "0400-0430", "web": 15, "worker": 8 }, { "duration": "0430-0500", "web": 15, "worker": 6 }, { "duration": "0500-0530", "web": 15, "worker": 6 }, { "duration": "0530-1230", "web": 15, "worker": 5 }, { "duration": "1230-1300", "web": 21, "worker": 5 }, { "duration": "1300-1330", "web": 25, "worker": 5 }, { "duration": "1330-1400", "web": 20, "worker": 5 }, { "duration": "1400-1430", "web": 22, "worker": 5 }, { "duration": "1430-1500", "web": 18, "worker": 5 }, { "duration": "1500-1530", "web": 24, "worker": 5 }, { "duration": "1530-1600", "web": 39, "worker": 5 }, { "duration": "1600-1630", "web": 49, "worker": 5 }, { "duration": "1630-1700", "web": 45, "worker": 5 }, { "duration": "1700-1730", "web": 48, "worker": 7 }, { "duration": "1730-1800", "web": 26, "worker": 5 }, { "duration": "1800-1830", "web": 25, "worker": 5 }, { "duration": "1830-1900", "web": 30, "worker": 8 }, { "duration": "1900-1930", "web": 32, "worker": 12 }, { "duration": "1930-2000", "web": 25, "worker": 5 }, { "duration": "2000-2030", "web": 24, "worker": 5 }, { "duration": "2030-2100", "web": 41, "worker": 8 }, { "duration": "2100-2130", "web": 60, "worker": 15 }, { "duration": "2130-2200", "web": 37, "worker": 5 }, { "duration": "2200-2230", "web": 32, "worker": 6 }, { "duration": "2230-2300", "web": 30, "worker": 5 }, { "duration": "2300-2330", "web": 30, "worker": 5 }, { "duration": "2330-2359", "web": 30, "worker": 7 } ] }
48. # subscriber/lib/clock.rb module Clockwork on_the_fives = ["**:00", "**:05", "**:10", "**:15", "**:20", "**:25", "**:30", "**:35", "**:40", "**:45", "**:50", "**:55"] if Rails.env.production? every(5.minutes, 'heroku_scale_schedule', at: on_the_fives) do HerokuScaleSchedule.new.scale_now! if ENV['CLOCK_HEROKU_SCALE_SCHEDULE'] == 'true' end end end
51. class HerokuScaleSchedule attr_reader :as_of delegate :events, to: :timeline def initialize(opts = {}) @as_of = (opts.delete(:as_of) || Time.current).utc @durations = JSON.parse(IO.read(Rails.root.join('config', 'heroku_scale_schedule.json'))).deep_symbolize_keys end def scale_now! HerokuScaleJob.set(wait_until: as_of.utc).perform_later(scale) end def scale @scale ||= { web: active_durations.sort_by(&:web).last.web, worker: active_durations.sort_by(&:worker).last.worker } end private def active_durations @active_durations ||= raw_durations.select { |d| d.active_window.cover? as_of } + [LocalScaleDuration.default] end def raw_durations durations.map do |tz_name, duration_config| tz = ActiveSupport::TimeZone.new(tz_name.to_s) duration_config.map do |conf| LocalScaleDuration.new(conf.merge(tz: tz, today_in_tz: as_of.in_time_zone(tz).to_date)) end end.flatten end end
52. class LocalScaleDuration include ActiveModel::Model attr_accessor :tz, :today_in_tz, :duration attr_writer :web, :worker validate :duration_must_start_before_it_ends # not shown def initialize(attrs) super(attrs) validate! end class << self def default new( tz: ActiveSupport::TimeZone['UTC'], today_in_tz: Time.now.utc.to_date, duration: '0000-2359', web: default_web_dynos, worker: default_worker_dynos ) end end def active_window @active_window ||= (starts_at...ends_at) end def starts_at @starts_at ||= Tod::TimeOfDay.parse(duration.split('-')[0]).on(today_in_tz, tz).utc end def ends_at @ends_at ||= Tod::TimeOfDay.parse(duration.split('-')[1]).on(today_in_tz, tz).utc end end
53. { "America/Chicago": [ { "duration": "0830-0930", "web": 20 }, { "duration": "1645-1730", "web": 20, "worker": 10 }, { "duration": "0900-0920", "worker": 20 } ], "America/Los_Angeles": [ { "duration": "0900-0930", "web": 30 }, { "duration": "1645-1730", "web": 40, "worker": 20 }, { "duration": "0900-0920", "worker": 20 } ], "America/New_York": [ { "duration": "0900-0930", "web": 20 }, { "duration": "1200-1300", "web": 30 }, { "duration": "1645-1715", "web": 60, "worker": 10 }, { "duration": "1700-1710", "worker": 50 }, { "duration": "1715-1830", "web": 40, "worker": 10 }, { "duration": "0900-0920", "worker": 20 } ], "Australia/Sydney": [ { "duration": "0900-0930", "web": 20 }, { "duration": "1645-1730", "web": 20, "worker": 10 }, { "duration": "0900-0920", "worker": 20 } ], "Europe/London": [ { "duration": "0900-0930", "web": 20 }, { "duration": "1645-1730", "web": 30, "worker": 15 }, { "duration": "0900-0920", "worker": 20 } ], "Europe/Paris": [ { "duration": "0900-0930", "web": 20 }, { "duration": "1645-1730", "web": 20, "worker": 10 }, { "duration": "0900-0920", "worker": 20 } ] } Bonus Time Zone Overrides
54. Drawbacks? Sure. • Daylight Savings Time • Config susceptible to outliers / outages ◦ No true autoscaling • Clunky ENV on/off ◦ heroku feature:preboot helps • Needs periodic “refresh”
55. _source=subscriber-production "heroku router - at=info" | parse "service=*ms" as ms | timeslice 30m | count(_timeslice) as requests_per_30min, max(ms) as max_duration_ms by _timeslice | outlier max_duration_ms | requests_per_30min / 30 / 60 / 1000 as requests_per_ms | 16 as threads_per_dyno | (requests_per_ms * (max_duration_ms_mean)) as required_thread_count | required_thread_count / threads_per_dyno as required_web_dyno_count | fields _timeslice, required_web_dyno_count | compare with timeshift 1d 7 | sort by _timeslice desc | limit 48
57. • Database Config • Calculate scale from active customer count in TimeZone • Automatically react to trends in period response time ◦ Or just Perf-M Dynos • More & better caching What’s next?
59. @nonrational github.com/nonrational alan@mealpal.com github.com/bymealpal boards.greenhouse.io/mealpal
