AWS IoT ExpressLink はじめの一歩
2023/8/3開催 JAWS-UG IoT 専門支部 「AWS IoT ExpressLinkって何だろう」の発表資料です。
okamotoaws
August 03, 2023
Tweet
Share
More Decks by okamotoaws
See All by okamotoaws
生成AIユースケースを考え倒すためのGenerative AI Use Cases JP (GenU)の魅力と使い方
okamotoaws
13
9.3k
Other Decks in Technology
See All in Technology
Talk to Someone At Delta Airlines™️ USA Contact Numbers
travelcarecenter
0
160
【あのMCPって、どんな処理してるの?】 AWS CDKでの開発で便利なAWS MCP Servers特集
yoshimi0227
6
1.1k
BEYOND THE RAG🚀 ~とりあえずRAG?を超えていけ! 本当に使えるAIエージェント&生成AIプロダクトを目指して~ / BEYOND-THE-RAG-Toward Practical-GenerativeAI-Products-AOAI-DevDay-2025
jnymyk
4
180
Transformerを用いたアイテム間の 相互影響を考慮したレコメンドリスト生成
recruitengineers
PRO
2
580
The Madness of Multiple Gemini CLIs Developing Simultaneously with Jujutsu
gunta
0
320
無理しない AI 活用サービス / #jazug
koudaiii
0
110
データ駆動経営の道しるべ:プロダクト開発指標の戦略的活用法
ham0215
2
210
AWS 怖い話 WAF編 @fillz_noh #AWSStartup #AWSStartup_Kansai
fillznoh
0
140
RapidPen: AIエージェントによる高度なペネトレーションテスト自動化の研究開発
laysakura
1
330
All About Sansan – for New Global Engineers
sansan33
PRO
1
1.2k
室長の逆襲 :データ活用の陣地を増やすためのヒント
masatoshi0205
0
140
Introduction to Sansan, inc / Sansan Global Development Center, Inc.
sansan33
PRO
0
2.7k
Featured
See All Featured
Responsive Adventures: Dirty Tricks From The Dark Corners of Front-End
smashingmag
251
21k
The Web Performance Landscape in 2024 [PerfNow 2024]
tammyeverts
8
710
Build The Right Thing And Hit Your Dates
maggiecrowley
37
2.8k
RailsConf & Balkan Ruby 2019: The Past, Present, and Future of Rails at GitHub
eileencodes
138
34k
Chrome DevTools: State of the Union 2024 - Debugging React & Beyond
addyosmani
7
750
Save Time (by Creating Custom Rails Generators)
garrettdimon
PRO
31
1.3k
Statistics for Hackers
jakevdp
799
220k
The Cost Of JavaScript in 2023
addyosmani
51
8.6k
Unsuck your backbone
ammeep
671
58k
Designing Dashboards & Data Visualisations in Web Apps
destraynor
231
53k
Put a Button on it: Removing Barriers to Going Fast.
kastner
60
3.9k
How to Think Like a Performance Engineer
csswizardry
25
1.8k
Transcript
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. JAWS-UG IoT 専門支部 「AWS IoT ExpressLinkって何だろう」 AWS IoT ExpressLink はじめの一歩 Shintaro Okamoto Solutions Architect Amazon Web Services Japan G.K.
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 自己紹介 名前:岡本 晋太朗 (おかもと しんたろう) 所属: アマゾン ウェブ サービス ジャパン合同会社 技術統括本部 ソリューションアーキテクト 経歴: プラント計装エンジニアおよび、工場向けの デジタルツインプラットフォーム構築を経て AWS ジャパンにて製造業のお客様をご支援 推しの AWS サービス: AWS IoT TwinMaker
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 本日説明すること・しないこと • 説明すること • AWS IoT ExpressLink って何? • AWS IoT ExpressLink を始めるには? • 説明しないこと • AWS IoT ExpressLink 以外のサービスについて
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. お客様が AWS IoT を使って実現していること コネクテッドカー 在庫追跡 倉庫業務の見える化 工業における生産性の向上 作物の収率向上 健康状態のリモート監視 アセット管理の効率化 作業者の安全確保 スマートホーム・ スマートビルディング
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. スマート製品を迅速に構築して AWS IoT に安全に接続するには ?
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 組み込み機器の安全な クラウド接続には考慮点が多い 社内におけるクラウド スペシャリスト不足 50,000 行以上の埋め 込み C コードが必要 安全な接続の実現は 車輪の再発明? 独自実装に脆弱性を 含んでしまうリスク デバイス群の 健全性確保に一苦労 機器の接続に関するお客様の課題
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. AWS IoT と連携するデバイスを簡単に構築 AWS IoT Greengrass そして C-SDK マイクロコントローラー マイクロプロセッサ ワイヤレスモジュール IoT ExpressLink IoT デバイス AWS IoT Device SDK または AWS IoT Device Client
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. IoT library Hardware security Radio library Applications Host processor Hardware security Radio library Applications Wireless module IoT library AWS IoT ExpressLink Host processor Hardware security library AWS IoT ExpressLink なし AWS IoT ExpressLink あり ソリューション
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. AWS IoT ExpressLink A W S に 安 全 に 接 続 す る I O T デ バ イ ス を 迅 速 か つ 簡 単 に 開 発 AWS IoT ExpressLink AWS IoT Core AWS IoT Events AWS IoT Analysis AWS IoT SiteWise AWS IoT Device Management AWS IoT Device Defender マイクロコントローラ/ マイクロプロセッサ
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. AWS IoT ExpressLink のメリット AWS IoT ExpressLink 接続モジュールには、AWS が義務付けているセキュリティ 要件を実装するソフトウェアが含まれているため、デバイスをクラウドに安全かつ 迅速に接続できます ファームウェア更新を 遠隔から配信 セキュリティ要件を 満たしたソフトウェア実装 200 以上の AWS サービス との統合が可能 複雑なクラウド連携を モジュールにオフロード クイック シームレス デバイスフリートを 大規模に管理 セキュア セキュリティ証明書の事前 プロビジョニングにより 委託製造業者との機密情報 授受の軽減が可能 IP保護・製造の柔軟性・ コスト削減
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. デバイスをすばやく接続 AWS IoT ExpressLink は セキュアなクラウド接続に必要なコードを 1 つのハードウェアコンポーネントにパッ ケージ化しています 3線式シリアルインターフェースだけで あらゆる組み込みデバイスをクラウドに接 続できます TX RX GND WAKE INT RST
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. シンプルな実装 数行のコードでクラウドアプリケーションを 実装可能 使用するのは数十個の AT コマンドのみ 通信方式に依存しない実装 モジュールによって下記方式に対応 • Wi-Fi • LTE-M (Cat.M1)
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 実装例…センサー値をMQTTで送信 int main() { print(“AT+CONNECT¥n”); while(1){ print(“AT+SEND data {¥“A¥”=%d}”, getSensorA()); delays(1); } }
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. セキュリティ AWS IoT ExpressLink は 出荷時にセキュアな設定が完了しています AWS が義務付けているセキュリティ要件と セキュリティベストプラクティスを実装済: • Hardware root of trust • Secure secrets storage • 相互認証済 • すべてのクラウド通信の暗号化 • AWS IoT OTA ライブラリを使用した 遠隔更新対応 • Secure boot • ホストプロセッサの OTA をサポート
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 大規模な導入と管理 モジュールはすぐにクラウド接続可能 モジュールには固有 ID と証明書をプロビジョ ニング済。大規模な導入が容易に 製造時間を短縮し、コスト削減と柔軟性の向上 を実現する late-binding をサポート AWS IoT Device Management とAWS IoT Device Defender を使用して、デバイス群の状 態を大規模に監視・管理可能
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 製造の柔軟性・コスト削減 AWS IoT ExpressLink なし 部品調達 プリント基板 組み立て 固有 ID と証明 書の焼き込み 最終製品 組み立て 出荷前 検査 契約メーカー Design, Firmware 一意の識別子 と証明書 OEM 契約メーカーに証明書 焼き込みのための秘密鍵 を預ける必要あり 安全な環境での プロビジョニングが必要… 複雑さとコストが増大する AWS IoT ExpressLink あり 部品調達 プリント基板 組み立て 最終製品 組み立て 出荷前 検査 契約メーカー Design, Firmware プロビジョニング済 証明書 OEM すぐに使えるモジュール – メーカーへの秘密鍵開示不要 契約メーカーでの証明書の 焼き込みが不要となるため 製造コストを圧縮可能
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. コネクテッド家電 産業機器の 監視と制御 農業用機器 医療機器 リソースに制約のある あらゆる機器 アセットトラッキング & モニタリング 主なユースケース
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. パートナーと対応モジュール AIROC - CCM AWS IoT ExpressLink Wi-Fi/BLE Wi-Fi/BLE Wi-Fi/BLE Cellular Cellular Wi-Fi/BLE ESP32-C3-Mini AWS IoT ExpressLink Ameba Z2 AWS IoT ExpressLink SARA-R5 AWS IoT ExpressLink NORA-W2 AWS IoT ExpressLink LE910C1 AWS IoT ExpressLink ※日本国内での使用には技適の確認が必要です
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. 評価キット Vendor Evaluation kit Technology Espressif ESP32-C3-DevKitM-1 Wi-Fi/BLE Infineon CCM evaluation kit Wi-Fi/BLE Realtek Ameba Z2 AWS IoT ExpressLink dev kit Wi-Fi/BLE Telit Cinterion Bravo LE910C1 dev kit Cellular Cat 1 u-blox NORA-W2 mini evaluation kit Wi-Fi/BLE u-blox SARA-R5 AWS evaluation kit Cellular LTE-M ※日本国内での使用には技適の確認が必要です
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. Technical Specification のバージョン 2022/06 version 1.0 2022/11 version 1.1 • AWS IoT Device Defender のサポート • カスタムメトリクスの自動送信 • デバイスシャドウ操作用の SHADOW コマンドの追加 • クレームによるオンボーディング プロセスへの対応 など OTA・OTW機能により最新firmwareへ アップグレードが可能 各モジュールの対応状況は、デバイスカタログを参照ください
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. AWS IoT ExpressLink はじめの一歩 1.評価キット・必要な周辺機器類を購入する 2.AWS IoT ExpressLink Workshop で遊んでみる • https://catalog.us-east-1.prod.workshops.aws/workshops/285e5274- ec78-4fe6-9f53-9a497c3d1d8f/en-US 3.あとは自由なIoTジャーニーを!
© 2023, Amazon Web Services, Inc. or its affiliates. All
rights reserved. References • AWS IoT ExpressLink 対応機器一覧 (デバイスカタログ) • AWS IoT ExpressLink Workshop • AWS IoT ExpressLink Programmer’s guide v1.1
