From Dumb Documents to Intelligent Data

Transcript

1. © 2024 XSB, Inc. All rights reserved Better Decisions, Faster © 2024 XSB, Inc. All rights reserved THE DIGITAL THREAD FOR ENGINEERING DOCUMENTS Smart Connected Data Invented by Better Decisions, Faster
2. © 2024 XSB, Inc. All rights reserved Better Decisions, Faster Must comply with ASTM B104. Cm shall be calculated in accordance with AGMA 908-B89. 1.2.6 Tank wall must withstand 800psi at 900C. Coverage (percent) = (2F – F2) x 100 Hundreds of $millions spent on avoidable costs and inefficiencies. Why are Most Engineering Documents and Drawings Still in PDF? !!! Cadmium!!! !!! Steel Casting !!! How much time do you spend searching for and extracting data you need to do your job? Why can’t that data be extracted for you automatically?
3. © 2024 XSB, Inc. All rights reserved Better Decisions, Faster From Dumb Documents to Intelligent Data Part Information PART NAME Hinge Mount NSN 1560-00-8858662 CAGE 77272 PART NUMBER 114S1875-1 PRICING DATA Click to view Material Information MATERIAL MAGNESIUM ALLOY SPECIFICATION QQ-M-40 STATUS CANCELLED VIEW FULL-TEXT http://swiss.xsb.com... SPECIFICATION REPLACEMENT ASTM B91 Process Information PROCESS1 FORGING PROCESS2 PENETRANT INSPECTION PROCESS3 VAPOR DEGREASING Document Information REFERENCES QQ-M-40 ASTM B91 SAE AMS 4352 AWS D1.1 REQUIREMENTS Click to view TEST METHODS Click to view DOCUMENT TREE Click to view 12.3 Invariant coding methodology shall be according to ITU-T H.222.0. 1.2.1.1. Type number The type designation will be as per the specification ASME B1.1. 1.2. Tank wall must withstand 800psi at 900C. Must comply with ASTM B104. Cm shall be calculated in accordance with AWS D1.1. Wavefront surfaces shall be the standard ophthalmic coordinate system as per ISO 9429:1986. Corporate Knowledge Graphs Content Management Build or Connect Anything Calculators, Checklists, Lookups, and more. Machines, IoT, software PLM and ERP
4. © 2024 XSB, Inc. All rights reserved Better Decisions, Faster Our Experience oUsed by 3 of top 5 aerospace companies oAdopted by U.S. Dept of Defense, ASTM, ASME, and others o20 years of AI and data science achievements
5. © 2024 XSB, Inc. All rights reserved Better Decisions, Faster LET’S TALK Andrew Bank Strategy & Business Development 734-476-8489 a.bank@xsb.com www.xsb.com/swiss Smart Connected Data Invented by Better Decisions, Faster
