Codemotion 2015 - Functional Reactive Programming: FP, Javascript con extra de bacon

Transcript

1. Functional Reactive Programming FP, Javascript y extra de bacon
2. Javier Onielfa Belenguer Software Engineer @ R&D Astellia Spain @onielfadev
3. Summary 1. Functional Programming 2. Theory a. Classical FRP b. Transformations 3. Coding a. Architecture b. Examples 4. Implementations and problems a. Advantages/Disavantages b. Implementation 5. References
4. Functional Programming?
5. FP Crash Course
6. Functional Programming • Functional programming is programming with functions • Functions are first class citizens: You can pass them, return them and store them in datastructures. • Functions tend to be pure. The evaluation of a function ONLY depends on its inputs. • Equational reasoning. • Embraces a data-oriented view. You are transforming data.
7. Let’s begin
8. Programming viewed as transforming data INPUT COMPUTER PROGRAM DATA DATA OUTPUT
9. Examples INPUT WEB SERVER PROCESS HTTP REQ HTTP RES OUTPUT INPUT ALGORITHM PROCESS PROBLEM SOLUTION OUTPUT INPUT WEB APP PROCESS UI EVENT HTML REDRAW OUTPUT
10. Real world apps don’t receive only one piece of data. What’s missing?
11. Real world apps don’t receive only one piece of data. What’s missing? TIME
12. Facing values that change over time app.post('/process-file', function(req, res) { var inputFile = 'input.txt'; var outputFile = 'output.txt'; fs.readFile(inputFile, function(err, data) { if (err) return res.status(500).send(err); process1(data, function(err, data) { if (err) return res.status(500).send(err); process2(data, function(err, data) { if (err) return res.status(500).send(err); process3(data, function(err, data) { if (err) return res.status(500).send(err); fs.writeFile(outputFile, data, function(err) { if (err) return res.status(500).send(err); res.status(200).send('processed successfully using callback hell'); }); }); }); }); }); });
13. Classic FRP As semantically defined in Functional Reactive Animation, Conal Elliot et al, 1998. Behavior • It’s a function of time ◦ type Behavior :: T -> a • Continuous time-varying values. • Sample rate independent. • Introduced for modelling animation/physics (velocity, gravity,etc) • Inefficient implementation. Led to space leaks.
14. Classic FRP As semantically defined in Functional Reactive Animation, Conal Elliot et al, 1998. EventSource • Stream of timed values. ◦ type EventSource :: [(T,a)] where Tn < Tn+1 • Discrete time values. • It’s like you are in another dimension where you can see the past, present and future. The whole timeline. • Fits perfectly for heavily event oriented applications.
15. “There is no future. There is no past… Time is simultaneous, an intricately structured jewel that humans insist on viewing one edge at a time, when the whole design is visible in every facet.” Dr. Manhattan, Watchmen
16. C 1s Keystrokes O 3s D E 7s M 9s O 12s 4s Keystrokes = [(1,’C’),(3,’O’),(4,’D’),(7,’E’),(9,’M’),(12,’O’), (14,’T’),(17,’I’)] I 17s T 14s Event Source
17. Wait!
18. Semantically, EventStream is a list, what if I use...
19. C 1s Ks O 3s D E 7s M 9s O 12s 4s Map f(v) = toLowerCase(v) c 1s Ks.map(f) o 3s d e 7s m 9s o 12s 4s 14s t 14s T
20. C 1s Ks O 3s D E 7s M 9s O 12s 4s Filter f(v) = return v == ‘o’; ks.filter(f) o 3s o 12s 14s T
21. Es1 1 3s 2 12s Merge 14s 3 Es2 B C 7s D 9s 4s A 1s Es1.merge(Es2) 1 3s B C 7s D 9s 2 12s 4s 14s 3 A 1s
22. 1 1s c 1 3s 1 1 7s 1 9s 1 12s 4s Scan plus(a,b) = return a+b; c.scan(0,plus) 14s 1 1 1s 2 3s 3 4 7s 5 9s 6 12s 4s 14s 7
23. LET’S CODE!
25. How do I create an EventStream? • From jQuery/Zepto object: ◦ $(‘#mydiv’).asEventStream(‘click’) • From promise object: ◦ Bacon.fromPromise($.ajax(“/search/”+query”)) • From DOM event: ◦ Bacon.fromEvent(document.body, ‘click’) • One-event eventstream: ◦ Bacon.once(‘Hello’) • Interval: ◦ Bacon.interval(1000, ‘Tick’)
26. Architecture of an FRP app Event Stream ... Event Stream Event Stream Merge Model Transformation Side Effects ... Side Effects Side Effects
27. Simple Up/Down example
28. Simple Up/Down example Up Click Stream Down Click Stream Transform Merge Div Content Transform
29. Simple Up/Down example var up = $('#upButton').asEventStream('click'); var down = $('#downButton').asEventStream('click'); var counter = up .map(1) .merge(down.map(-1)) .scan(0, (acc, val) => return acc + val;); counter.assign($('#result'), 'text');
30. Form validation example
31. Name Keyup Stream Min Keyup Stream Merge to Model Filter Valid Form validation example Max Keyup Stream Enable Submit Show error msg
32. Form validation example // Input streams var nameStream = $('#name') .asEventStream('keyup') .map(event => return event.target.value;) .skipDuplicates() .toProperty($('#name').val()); var minStream = $('#min') .asEventStream('keyup') .map(event => return parseInt(event.target.value);) .skipDuplicates() .toProperty(parseInt($('#min').val()));
33. Form validation example // Model Stream var modelStream = Bacon.combineTemplate({ name: nameStream, min: minStream, max: maxStream });
34. Form validation example //Side effects evaluateStream.map(m => return !m.valid;) .assign($('#submitButton'), 'attr', 'disabled'); evaluateStream.map(m => return m.message;) .assign($('#error'), 'text');
35. Shape designer example
36. Shape Stream Color Stream Merge to Model Transform Shape designer example Size Stream Canvas Drawing
37. Shape designer example // Input streams var colorStream = $('#color').asEventStream('change') .map(event => return event.target.value;) .skipDuplicates() .toProperty($('#color').val()) .map(c => transformColor(c));
38. Shape designer example //ModelStream var modelStream = Bacon.combineTemplate({ shape: shapeStream, size: sizeStream, color: colorStream });
39. Shape designer example // SideEffects var canvas = document.getElementById("canvas"); var ctx = canvas.getContext('2d'); modelStream.onValue(m => { drawModel(ctx, m); });
40. Twitter Map example
41. Tweet Stream Twitter Map example (Server) WS Connection Stream Socket Send
42. function randomTweet(v){ return { pos: { lat: getRandomArbitrary(38.46975,40.46975), lng: getRandomArbitrary(-0.7,1.37739), }, text: 'Hola' }; } Twitter Map example (Server)
43. io.on('connection', socket => { bacon.interval(1000, {}) .map(randomTweet) .onValue(t => socket.emit('tweet', t)); }); Twitter Map example (Server)
44. Tweet Stream North Filter Transform Twitter Map example (Client) Merge South Filter Transform Put Marker Write Tweet
45. var tweetStream = Bacon.fromEvent(socket, 'tweet'); var northStream = tweetStream.filter(inNorth) .map(t => return t.text + ' (N)';); var southStream = tweetStream.filter(inSouth) .map(t => return t.text + ' (S)';); var finalStream = northStream.merge(southStream); finalStream.onValue(t => { putMarker(t); writeTweet(t); }); Twitter Map example (Client)
46. Conclusion
47. Advantages • It allows you to define time-dependent application in a declarative way. • Time-varying values are first class citizen. • It allows you to use a data transformation style using mostly pure functions. • Side-effects are confined to one part of the application
48. Problems • What if one transformation function consumes too much time? • What if one EventStream is too fast for the system to process? • What if one EventStream in a zip is way faster than the other one?
49. Implementation • Pull-based ◦ Demand-driven. Sampling of the reactive EventStreams. • Push-based ◦ It can be implemented on top of event loops. • Infinite vs finite ◦ (Bacon.js) Streams are finite: They can start and end at arbitrary moments. ◦ (Elm) Streams are infinite: Stream are always “producing” values (Hot/Cold).
50. Libraries • JS : Bacon.js, RxJs, “Elm” • Java: RxJava • C#: Rx.Net • Objective-C: ReactiveCocoa • Ruby: Frapuccino • Python: RxPy
51. References, Links and Videos • Functional Reactive Animation, Conal Elliot et al, 1998 • Push-Pull Functional Reactive Programming, Conal Elliot • Deprecating the observer pattern, Martin Odersky et al • React 2014: Erik Meijer - What does it mean to be Reactive? • “Controlling Time and Space: understanding the many formulations of FRP” by Evan Czaplicki (Elm creator) • Ryan Trinkle - Reflex: Practical Functional Reactive Programming (Haskell) • Lambda Jam 2014 - Conal Elliot - The Essence and Origins of Functional Reactive Programming
52. Thanks!
53. Questions?
