Nextflow CRG tutorial

Transcript

1. Paolo Di Tommaso

   Comparative bioinformatics

   Notredame Lab - CRG

   !
   26 Feb 2015


   View Slide

2. WHAT NEXTFLOW IS
   • A computing runtime which executes Nextflow
   pipeline scripts

   • A programming DSL that simplify writing of highly
   parallel computational pipelines reusing your
   existing scripts and tools


   View Slide

3. NEXTFLOW DSL
   • It is NOT a new programming language

   • It extends the Groovy scripting language

   • It provides a multi-paradigm programming
   environment


   View Slide

4. MULTI-PARADIGM
   Imperative

   Object-oriented programming

   +

   Declarative concurrency

   Dataflow programming model


   View Slide

5. VFS Groovy Runtime
   Executors
   Tasks dispatcher
   Dataflow parallelisation &
   synchronisation
   Script interpreter
   Java VM 7+


   View Slide

6. HOW TO INSTALL
   Use the following command:
   wget  -­‐qO-­‐  get.nextflow.io  |  bash
   nextflow


   View Slide

7. GET STARTED
   $  cd  ~/crg-­‐course
   $  vagrant  up

   $  vagrant  ssh
   Login in your course laptop
   Once in the virtual machine
   $  cd  ~/nextflow-­‐tutorial
   $  git  pull
   $  nextflow  info


   View Slide

8. THE BASIC
   Variables and assignments
   x  =  1
   y  =  10.5
   str  =  'hello  world!'
   p  =  x;  q  =  y


   View Slide

9. THE BASIC
   Printing values
   x  =  1
   y  =  10.5
   str  =  'hello  world!'
   print  x
   print  str
   print  str  +  '\n'
   println  str


   View Slide

10. THE BASIC
    Printing values
    x  =  1
    y  =  10.5
    str  =  'hello  world!'
    print(x)
    print(str)
    print(str  +  '\n')
    println(str)


    View Slide

11. MORE ON STRINGS
    str  =  'bioinformatics'
    print  str[0]
    !
    print  "$str  is  cool!"
    print  "Current  path:  $PWD"
    str  =  '''
               multi
               line
               string
        '''
    !
    str  =  """
               User:  $USER
               Home:  $HOME
               """


    View Slide

12. COMMON STRUCTURES &
    PROGRAMMING IDIOMS
    • Data structures: Lists & Maps

    • Control statements: if, for, while, etc.

    • Functions and classes

    • File I/O operations


    View Slide

13. 6 PAGES PRIMER
    http://refcardz.dzone.com/refcardz/groovy


    View Slide

14. MAIN ABSTRACTIONS
    • Processes: run any piece of script

    • Channels: unidirectional async queues that
    allows the processes to comunicate

    • Operators: transform channels content


    View Slide

15. CHANNELS
    • It connects two processes/operators

    • Write operations is NOT blocking

    • Read operation is blocking

    • Once an item is read is removed from the queue


    View Slide

16. CHANNELS
    some_items  =  Channel.from(10,  20,  30,  ..)
    my_channel  =  Channel.create()
    single_file  =  Channel.fromPath('some/file/name')
    more_files  =  Channel.fromPath('some/data/path/*')
    file x
    file y
    file z


    View Slide

17. OPERATORS
    • Functions applied to channels

    • Transform channels content

    • Can be used also to filter, fork and combine
    channels

    • Operators can be chained to implement custom
    behaviours


    View Slide

18. OPERATORS
    nums  =  Channel.from(1,2,3,4)
    square  =  nums.map  {  it  -­‐>  it  *  it  }
    4            3              2            1
    16          9              4            1
    nums
    square
    map


    View Slide

19. OPERATORS CHAINING
    Channel.from(1,2,3,4)
        .map  {  it  -­‐>  [it,  it*it]  }
        .subscribe  {  num,  sqr  -­‐>  println  "Square  of:  $num  is  $sqr"  }
    //  it  prints
    Square  of:  1  is  1
    Square  of:  2  is  4
    Square  of:  3  is  9
    Square  of:  4  is  16


    View Slide

20. SPLIT FASTA FILE(S)
    Channel.fromPath('/some/path/fasta.fa')
        .splitFasta()
        .view()
    Channel.fromPath('/some/path/fasta.fa')
        .splitFasta(by:  3)
        .view()
    Channel.fromPath('/some/path/*.fa')
        .splitFasta(by:  3)
        .view()


    View Slide

21. SPLITTING OPERATORS
    You can split text object or files using the splitting methods:

    • splitText - line by line

    • splitCsv - comma separated values format

    • splitFasta - by FASTA sequences

    • splitFastq - by FASTQ sequences


    View Slide

22. EXAMPLE 1
    • Split a FASTA file in sequence

    • Parse a FASTA file and count number of
    sequences matching specified ID


    View Slide

23. EXAMPLE 1
    $  nextflow  run  channel_split.nf
    !
    !
    $  nextflow  run  channel_filter.nf


    View Slide

24. PROCESS
    process  sayHello  {
    !
         input:
         val  str
    !
         output:
         stdout  into  result
    !
         script:
         """
         echo  $str  world!
         """
    }
    !
    str  =  Channel.from('hello',  'hola',  'bonjour',  'ciao')
    result.subscribe  {  print  it  }


    View Slide

25. PROCESS INPUTS
    input:
           [from  ]  [attributes]
    process  procName  {
    !
    !
    !
    !
    !
    !
    !
    !
    !
         """

         """
    !
    }


    View Slide

26. PROCESS INPUTS
    input:
       val    x  from  ch_1
       file  y  from  ch_2
       file  'data.fa'  from  ch_3
       stdin  from  from  ch_4
       set  (x,  'file.txt')  from  ch_5
    process  procName  {
    !
    !
    !
    !
    !
    !
    !
    !
    !
         """

         """
    !
    }


    View Slide

27. PROCESS INPUTS
    proteins  =  Channel.fromPath(  '/some/path/data.fa'  )
    !
    !
    !
    process  blastThemAll  {
    !
       input:
       file  'query.fa'  from  proteins
    !
       "blastp  -­‐query  query.fa  -­‐db  nr"
    !
    }
    !


    View Slide

28. PROCESS OUTPUTS
    process  randomNum  {
    !
         output:
         file  'result.txt'  into  numbers
    !
    !
         '''
         echo  $RANDOM  >  result.txt
         '''
    !
    }
    !
    !
    numbers.subscribe  {  println  "Received:  "  +  it.text  }


    View Slide

29. USE YOUR FAVOURITE

    PROGRAMMING LANG
    process  pyStuff  {
    !
           script:
           """
           #!/usr/bin/env  python
    !
           x  =  'Hello'
           y  =  'world!'
           print  "%s  -­‐  %s"  %  (x,y)
           """
    }


    View Slide

30. EXAMPLE 2
    • Execute a process running a BLAST job given an
    input file

    • Execute a BLAST job emitting the produced
    output


    View Slide

31. EXAMPLE 2
    $  nextflow  run  process_input.nf
    !
    !
    $  nextflow  run  process_output.nf


    View Slide

32. PIPELINES PARAMETERS
    params.p1  =  'alpha'
    params.p2  =  'beta'
    :
    Simply declares some variables prefixed by params
    When launching your script you can override

    the default values
    $  nextflow  run    -­‐-­‐p1  'delta'  -­‐-­‐p2  'gamma'<br/>

    View Slide

33. COLLECT FILE
    The operator collectFile allows to gather

    items produced by upstream processes
    my_results.collectFile(name:'result.txt')
    Collect all items to a single file


    View Slide

34. COLLECT FILE
    The operator collectFile allows to gather

    items produced by upstream processes
    my_items.collectFile(storeDir:'path/name')  {
    !
          def  key  =  get_a_key_from_the_item(it)
          def  content  =  get_the_item_value(it)
          [  key,  content  ]
    !
    }
    Collect the items and group them into files

    having a names defined by a grouping criteria


    View Slide

35. EXAMPLE 3
    • Split a FASTA file, execute a BLAST query for
    each chunk and gather the results

    • Split multiple FASTA file and execute a BLAST
    query for each chunk


    View Slide

36. EXAMPLE 3
    $  nextflow  run  split_fasta.nf
    !
    !
    $  nextflow  run  split_fasta.nf  -­‐-­‐chunkSize  2
    !
    !
    $  nextflow  run  split_fasta.nf  -­‐-­‐chunkSize  2  -­‐-­‐query  data/p\*.fa
    !
    !
    $  nextflow  run  split_and_collect.nf


    View Slide

37. UNDERSTANDING

    MULTIPLE INPUTS
    task 1
    process
    a
    out x
    d a
    c
    β
    ..
    /END/ task 2
    out y
    β
    d



    View Slide

38. UNDERSTANDING

    MULTIPLE INPUTS
    process
    a
    out x
    d a
    c
    ..
    β
    β
    d
    out y
    β
    c
    out z
    β
    task 1
    task 2
    task 3
    :

    task n


    View Slide

39. CONFIG FILE
    • Pipeline configuration can be externalised to a file
    named nextflow.config

    • parameters

    • environment variables

    • required resources (mem, cpus, queue, etc)

    • modules/containers


    View Slide

40. CONFIG FILE
    params.p1  =  'alpha'
    params.p2  =  'beta'
    !
    env.VAR_1  =  'some_value'
    env.CACHE_4_TCOFFEE  =  '/some/path/cache'
    env.LOCKDIR_4_TCOFFEE  =  '/some/path/lock'
    !
    process.executor  =  'sge'


    View Slide

41. CONFIG FILE
    params  {
       p1  =  'alpha'
       p2  =  'beta'
    }
    !
    env  {
       VAR_1  =  'some_value'
       CACHE_4_TCOFFEE  =  '/some/path/cache'
       LOCKDIR_4_TCOFFEE  =  '/some/path/lock'
    }
    !
    process  {
       executor  =  'sge'
    }
    Alternate syntax (almost) equivalent


    View Slide

42. HOW USE DOCKER
    Specify in the config file the Docker image to use
    !
    process  {
        container  =
    }
    Add the with-docker flag when launching it
    !
    $  nextflow  run    -­‐with-­‐docker  <br/>

    View Slide

43. EXAMPLE 4
    Launch a pipeline using a Docker container


    View Slide

44. EXAMPLE 4
    !
    $  nextflow  run  blast_extract.nf  -­‐with-­‐docker


    View Slide

45. HOW USE THE CLUSTER
    //  default  properties  for  any  process
    process  {
      executor  =  'crg'
      queue  =  'short'
      cpus  =  2
      memory  =  '4GB'
      scratch  =  true
    }
    !
    !
    Define the CRG executor in nextflow.config


    View Slide

46. PROCESS RESOURCES
    //  default  properties  for  any  process
    process  {
      executor  =  'crg'
      queue  =  'short'
      scratch  =  true
    }
    !
    //  cpus  for  process  'foo'
    process.$foo.cpus  =  2
    !
    //  resources  for  'bar'
    process.$bar.queue  =  'long'
    process.$bar.cpus  =  4
    process.$bar.memory  =  '4GB'
    !


    View Slide

47. ENVIRONMENT MODULE
    !
    process.$foo.module  =  'Bowtie2/2.2.3'
    !
    process.$bar.module  =  'TopHat/2.0.12:Boost/1.55.0'
    Specify in the config file the modules required


    View Slide

48. EXAMPLE 5
    Executes a pipeline in the cluster


    View Slide

49. EXAMPLE 5
    $  ssh  username@ant-­‐login.linux.crg.es
    $  module  avail
    $  module  purge
    $  module  load  nextflow/0.12.3-­‐goolf-­‐1.4.10-­‐no-­‐OFED-­‐Java-­‐1.7.0_21
    $  curl  -­‐fsSL  get.nextflow.io  |  bash
    Login in ANT-LOGIN
    If you have module configured:
    Otherwise install it downloading from internet


    View Slide

50. EXAMPLE 5
    Create the following nextflow.config file:
    process  {
       executor  =  'crg'
       queue  =  'course'
       scratch  =  true
    }
    $  nextflow  run  rnatoy  -­‐with-­‐docker  -­‐with-­‐trace
    Launch the pipeline execution:


    View Slide

51. RESOURCES
    project home

    http://nextflow.io

    tutorials

    https://github.com/nextflow-io/examples

    community

    http://groups.google.com/forum/#!forum/nextflow
