1. A DSL FOR DATA-DRIVEN
   PIPELINES
   Paolo Di Tommaso

   ACGT retreat - 29 May '14


   View Slide

2. WHAT IS NEXTFLOW
   A fluent DSL modelled around

   the UNIX pipe concept

   that simplifies writing parallel

   pipelines in a portable manner


   View Slide

3. View Slide

4. View Slide

5. WAT?!

   YET ANOTHER .. !?


   View Slide

6. PLENTY OF PIPELINES
   FRAMEWORKS!


   View Slide

7. ANY BIOINFORMATICIANS

   IS A LINUX HACKER


   View Slide

8. cat sequence | blast -in - | head 10 | t_coffee > result


   View Slide

9. THE RATIONALE
   • Fast prototyping

   • Smoothly integration with Linux world

   • High-level parallelisation model


   View Slide

10. NEXTFLOW
    • Portable across different execution platforms
    (clusters and cloud) i.e. enable reproducibility

    • Error handling and crash recovery

    • Simplify debugging making possible to reproduce
    errors


    View Slide

11. VFS Groovy Runtime
    Executors
    Tasks dispatcher
    Dataflow parallelisation &
    synchronisation
    Script interpreter
    Java VM 7+


    View Slide

12. DATAFLOW
    • Declarative computational model for concurrent processes
    execution

    • Processes wait for data, when an input set is ready the
    process is executed

    • They communicate by using dataflow variable i.e. async
    FIFO queues called channels

    • The synchronization is managed automatically


    View Slide

13. p1


    View Slide

14. p2
    p1


    View Slide

15. – Henri E. Bal , Jennifer G. Steiner , Andrew S. Tanenbaum.

    Programming languages for distributed computing systems (1989)
    “Dataflow variables are spectacularly expressive in
    concurrent programming when compared to explicit
    synchronisation”


    View Slide

16. MAIN PRIMITIVES
    • Processes: run any piece of script

    • Channels: unidirectional async queues that
    allows the processes to comunicate

    • Operators: transform channels content


    View Slide

17. input dataset
    splitting
    collectFile
    map map map
    filter filter
    task task task
    task task task


    View Slide

18. GET STARTED
    Prerequisites:

    Java 7 or 8
    Install by using the following command
    wget  -­‐qO-­‐  get.nextflow.io  |  bash
    nextflow


    View Slide

19. THE BASIC
    Variables and assignments
    x  =  1
    y  =  10.5
    str  =  'hello  world!'
    p  =  x;  q  =  y
    int  x  =1
    double  y  =  10.5
    String  str  =  'hello  world!'


    View Slide

20. THE BASIC
    Printing values
    x  =  1
    y  =  10.5
    str  =  'hello  world!'
    print  x
    print  str
    print  str  +  '\n'
    println  str


    View Slide

21. THE BASIC
    Printing values
    x  =  1
    y  =  10.5
    str  =  'hello  world!'
    print(x)
    print(str)
    print(str  +  '\n')
    println(str)


    View Slide

22. MORE ON STRINGS
    str  =  'bioinformatics'
    print  str[0]
    !
    print  "$str  is  cool!"
    print  "Current  path:  $PWD"
    str  =  '''
               multi
               line
               string
        '''
    !
    str  =  """
               User:  $USER
               Home:  $HOME
               """


    View Slide

23. LISTS
    simpleList  =  [1,2,5]
    strList  =  ['a','z']
    emptyList  =  []
    !
    simpleList.add(anyValue)
    simpleList  <<  anyValue
    !
    print  simpleList[0]
    print  simpleList[1]
    print  simpleList[0..3]
    !
    print  simpleList.size()


    View Slide

24. MAPS
    map  =  [:]
    !
    map  =  [  k1:  10,  k2:  20,  k3:  'str'  ]
    !
    print  map.k1
    print  map['k1']
    print  map.get('k1')
    !
    map.k1  =  'Hello'
    map['k1']  =  'Hello'
    map.put('k1',  'Hello')
    !
    print  map.size()


    View Slide

25. CONTROL STATEMENTS
    if(  x  )  {
       print  x
    }

    if(  x  ==  1  )  {
       print  x
    }
    !
    if(  x  >  2  )  {
       //  do  this
    }
    else  {
       //  to  that
    }


    View Slide

26. CONTROL STATEMENTS
    for(  int  i=0,n=10;  i    ..
    }
    !
    list  =  [1,2,3]
    for(  x  :  list  )  {
         print  x
    }
    !
    list.each  {
       print  it
    }
    !
    map.each  {  k,  v  -­‐>
       println  "$k  contains  $v"
    }


    View Slide

27. FUNCTIONS
    def  foo()  {
       print  'Hello'
    }
    !
    foo()
    !
    def  bar(  x,  y  )  {
       x+y
    }
    !
    print  bar(1,2)


    View Slide

28. CLOSURES
    Allows you to reference functions as variables
    sayHello  =  {
         print  'Hello'
    }
    sayHello()
    sayHello.call()
    printSum  =  {  a,  b  -­‐>  print  a+b  }
    printSum(  5,  7  )


    View Slide

29. CLOSURES
    Pass closure as argument
    def  foo(  f  )  {
         x  =  Random.nextInt()
         f.call(x)
    }
    foo(  {  println  it  +1  }  )
    foo    {  println  it*it  }


    View Slide

30. CLOSURES
    for(  x  :  list  )  {
         print  x
    }
    !
    list.each  {
       print  it
    }
    !
    map.each  {  k,  v  -­‐>
       println  "$k  equals  $v"
    }


    View Slide

31. FILES
    my_file  =  file('any/path/to/file.txt')
    !
    print  my_file.text
    //  save  file  content
    my_file.text  =  'some  content  ..'
    //  read  line  by  file
    my_file.eachLine  {
       println  it
    }


    View Slide

32. READING FASTA FILES
    my_file  =  file('any/path/to/file.txt')
    !
    //  split  sequence  by  sequence
    my_file.splitFasta()  {
         print  it
    }
    !
    //  chunk  of  10  sequences
    my_file.splitFasta(by:  10)  {
         print  it
    }
    !
    //  parse  into  map  objects
    my_file.splitFasta(record:  [id:  true,  sequence:  true])  {
         print  it.id
         print  it.sequence
    }


    View Slide

33. EXAMPLE 1
    • Print the content of a file

    • Read FASTA file and print sequences

    • Read a FASTA file and print only the IDs


    View Slide

34. HOW READ IT
    process  sayHello  {
    !
         input:
         val  str
    !
         output:
         stdout  into  result
    !
         """
         echo  $str  world!
         """
    }
    !
    str  =  Channel.from('hello',  'hola',  'bonjour',  'ciao')
    result.subscribe  {  print  it  }


    View Slide

35. PROCESS INPUTS
    input:
           [from  ]  [attributes]
    process  procName  {
    !
    !
    !
    !
    !
    !
    !
    !
    !
         """

         """
    !
    }


    View Slide

36. PROCESS INPUTS
    input:
       val    x  from  ch_1
       file  y  from  ch_2
       file  'data.fa'  from  ch_3
       stdin  from  from  ch_4
       set  (x,  'file.txt')  from  ch_5
    process  procName  {
    !
    !
    !
    !
    !
    !
    !
    !
    !
         """

         """
    !
    }


    View Slide

37. PROCESS INPUTS
    num  =  Channel.from(  1,  2,  3  )
    !
    !
    process  basicExample  {

       input:
       val  x  from  num
    !
       """
       echo  process  job  $x
       """
    !
    }


    View Slide

38. PROCESS INPUTS
    proteins  =  Channel.fromPath(  '/some/path/data.fa'  )
    !
    !
    !
    process  blastThemAll  {
    !
       input:
       file  'query.fa'  from  proteins
    !
       "blastp  -­‐query  query.fa  -­‐db  nr"
    !
    }
    !


    View Slide

39. PROCESS OUTPUTS
    process  randomNum  {
    !
         output:
         file  'result.txt'  into  numbers
    !
    !
         '''
         echo  $RANDOM  >  result.txt
         '''
    !
    }
    !
    !
    numbers.subscribe  {  println  "Received:  "  +  it.text  }


    View Slide

40. EXAMPLE 2
    • Execute a process running a BLAST job given an
    input file

    • Execute a BLAST job emitting the produced
    output


    View Slide

41. PIPELINES PARAMETERS
    params.p1  =  'alpha'
    params.p2  =  'beta'
    :
    Simply declares some variables prefixed by params
    When launching your script you can override

    the default values
    $  nextflow    -­‐-­‐p1  'delta'  -­‐-­‐p2  'gamma'


    View Slide

42. SPLITTING CONTENT
    You can split text object or files using the splitting methods:

    • splitText - line by line

    • splitCsv - comma separated values format

    • splitFasta - by FASTA sequences

    • splitFastq - by FASTQ sequences


    View Slide

43. SPLITTING CONTENT
    params.query  =  "$HOME/sample.fa"
    params.chunkSize  =  5
    !
    fasta  =  file(params.query)
    seq  =  Channel.from(fasta).splitFasta(by:  params.chunkSize)
    !
    process  blast  {
           input:
           file  'seq.fa'  from  seq
    !
           output:
           file  'out'  into  blast_result
    !
           """
           blastp  -­‐db  $DB  -­‐query  seq.fa  -­‐outfmt  6  >  out
           """
    }


    View Slide

44. COLLECT FILE
    The operator collectFile allows to gather

    items produced by upstream processes
    my_items.collectFile(name:'result.txt')
    Collect all items to a single item


    View Slide

45. COLLECT FILE
    The operator collectFile allows to gather

    items produced by upstream processes
    my_items.collectFile(storeDir:'path/name')  {
    !
       def  key  =  getKeyByItem(it)
       def  content  =  getContentByItem(it)
       [  key,  content  ]
    !
    }
    Collect the items and group them into files

    having a names defined by a grouping criteria


    View Slide

46. EXAMPLE 3
    Split a FASTA file, execute a BLAST query for each chunk

    and gather the results


    View Slide

47. MULTIPLE INPUT FILES
    Simply use Channel.fromPath method instead of Channel.from
    Channel.fromPath('any/path/file.txt')
    Channel.fromPath('any/path/*.txt')
    Channel.fromPath('any/path/**.txt')
    Channel.fromPath('any/path/**/*.txt')
    Channel.fromPath('any/path/**/*.txt',  maxDepth:  3)


    View Slide

48. EXAMPLE 4
    Split many FASTA files and execute BLAST query

    for each of them


    View Slide

49. CONFIG FILE
    Allows you to save into a file

    commons options and environment settings.

    By default it uses nextflow.config in current path
    params.p1  =  'alpha'
    params.p2  =  'beta'
    !
    env.VAR_1  =  'some_value'
    env.CACHE_4_TCOFFEE  =  '/some/path/cache'
    env.LOCKDIR_4_TCOFFEE  =  '/some/path/lock'
    !
    process.executor  =  'sge'


    View Slide

50. CONFIG FILE
    params  {
       p1  =  'alpha'
       p2  =  'beta'
    }
    !
    env  {
       VAR_1  =  'some_value'
       CACHE_4_TCOFFEE  =  '/some/path/cache'
       LOCKDIR_4_TCOFFEE  =  '/some/path/lock'
    }
    !
    process  {
       executor  =  'sge'
    }
    Alternate syntax (almost) equivalent


    View Slide

51. USING THE CLUSTER
    //  default  properties  for  any  process
    process.executor  =  'sge'
    process.queue  =  'short'
    process.clusterOptions  =  '-­‐pe  smp  2'
    process.scratch  =  true
    !
    //  specific  process  settings
    process.$procName.queue  =  'long'
    process.$procName.clusterOptions  =  '-­‐l  h_rt=12:00:0'
    !
    //  set  the  max  number  SGE  jobs
    executor.$sge.queueSize  =  100
    Simply define the SGE executor in nextflow.config


    View Slide

52. MORE ON OPERATORS
    Operators are commonly used to transforms channels content
    Channel
           .from(  1,  2,  3,  4,  5  )
           .map  {  it  *  it  }

    1
    4
    9
    16
    25
    //  it  prints


    View Slide

53. MORE ON OPERATORS
    target1  =  Channel.create()
    target2  =  Channel.create()
    Operators can be used also to filter, fork and combine channels

    Moreover they can be chained in order

    to implement a custom behaviour
    Channel
             .fromPath('misc/sample.fa')
             .splitFasta(  record:  [id:  true,  seqString:  true  ])
             .filter  {  record  -­‐>
                     record.id  =~  /^ENST0.*/
             }
             .into(target1,  target2)



    View Slide

54. EXAMPLE 5
    A toy RNAseq pipeline that:

    • Index a reference genome

    • Maps a collection of read-pairs

    • Assemble a transcript for each read pair

    This example will run using a Docker container


    View Slide

55. DOCKER
    • Enable to run processes in a isolated environment

    • You can package and distribute a self-contained
    executable environment

    • Up today it runs only on Linux (partially OSX),
    Docker plans to support Windows as well.


    View Slide

56. RESOURCES
    • nextflow.io

    • nextflow.readthedocs.org

    • groups.google.com/forum/#!forum/nextflow

    • github.com/nextflow-io/ACGT14-tutorial


    View Slide

57. THANKS!
