UNIX File Architecture

UNIX File Architecture

One of the first talks I ever made. It was held in front of a committee as a final task of a course for becoming a technical trainer. This one sealed the deal.

Preslav Mihaylov

April 11, 2015

Transcript

10 slides
  1. Agenda 1. Difference between an inode, file and file data

    2. Filesystem redundancy – Superblocks, Datablocks 3. Directory entries in UNIX 4. File contents 5. File redundancy – Symlinks, Hardlinks 6. Deleting files in UNIX
  2. Inodes, files and file data 1. Inode • An element,

    that keeps a reference to a given file/inode as well as metadata about it • Similar to pointers in programming languages 2. File data • The physical content of a given file on the PC storage (HDD/SSD) 3. File • An abstract element • The logical representation of the file data, as well as the inode pointing to it. • Contains information about its inodes, data, file type, etc
  3. File System Redundancy Two types of Inodes in UNIX –

    Superblocks, Datablocks 1. Superblock – Inode, containing File system metadata 2. Datablock – Regular Inode, containing file metadata as well as a pointer to the file data location.
  4. Directory entries in UNIX • In UNIX, there are no

    directories • There are inodes, that point to other inodes. These are called directory entries (Dentry)
  5. File contents • Every inode contains file metadata • File

    type – designates how the file system should treat the file • Link count – shows how many inodes point to this file • Owner/Group ID – shows who does this file belong to • LAT/LMT/LIAT – Timestamps (Not trustworthy) • Pointers – keep reference of the data location
  6. File Redundancy • In UNIX, there are two types of

    links – symlinks, hardlinks • Symlink – A regular file, that keeps the file location of another one (Similar to shortcuts in Windows) • Hardlink – An inode, that points to a file data location of another inode(s)
  7. Deleting files in UNIX • In UNIX, files do not

    get deleted, they get overwritten • When a file is “deleted” from the file system, you delete the inode pointing to the file data, not the actual file data. • A file is considered “deleted”, when the last inode pointing to it is removed. (Despite that, they can still be restored) • Similar to deleting reference objects in programming languages. (In UNIX, there is no garbage collector )
  8. Summary • Difference between a file, inode and file data

    • Superblocks/Datablocks in UNIX. File system redundancy • “Directories”/Directory entries in UNIX • File contents/metadata • Redundancy of files – Symlinks, Hardlinks • “Deleting”/Overwriting files in UNIX
