libGDX: Screens, Fonts , Preferences and Scene2d

Transcript

1. libGDX: Screens, Fonts , Preferences, I18 and Scene2d Jussi Pohjolainen Tampere University of Applied Sciences
2. SCREENS
3. Screen and Game • Screen – Use to add different screens to your game – Screen is a interface and contains all the same methods than ApplicationListener. Also show() and hide() when screen is shown and hidden • Game – Game is an ApplicationListener that holds also methods for changing the screen: setScreen(Screen s)
4. public class ScreensFontsPref extends Game { private MainMenuScreen mainmenu; // Common objects to all screens! private SpriteBatch batch; // Returns the SpriteBatch public SpriteBatch getBatch() { return batch; } @Override public void create () { batch = new SpriteBatch(); // Create MainMenuScreen mainmenu = new MainMenuScreen(this); // Set it visible setScreen(mainmenu); } @Override public void render () { super.render(); // Remember this, otherwise nothing is shown! } }
5. public class GameScreen implements Screen { private ScreensFontsPref game; private SpriteBatch batch; private OrthographicCamera camera; public GameScreen(ScreensFontsPref g) { game = g; batch = game.getBatch(); camera = new OrthographicCamera(); camera.setToOrtho(false, 800, 480); } @Override public void render(float delta) { batch.setProjectionMatrix(camera.combined); Gdx.gl.glClearColor(1, 0, 0, 1); Gdx.gl.glClear(GL20.GL_COLOR_BUFFER_BIT); batch.begin(); // Do same drawing Gdx.app.log("GameScreen", "render"); batch.end(); if (Gdx.input.isTouched()) { game.setScreen(new LevelScreen(game)); } } ...
6. FONTS
7. About Fonts • libGDX does not support TrueType Fonts (TTF) – Rendering vector graphics is costly – Although you can use Freetype - extension • libGDX makes use of bitmap files (pngs) to render fonts • Use external tool to convert TTF to PNG! • Each glyph in the font has a corresponding TextureRegion • Default font Arial provided, other fonts you have to create! • If you use same font in different screens, create font once and share it with other screens.
8. Simple to Use BitmapFont f = new BitmapFont(); f.draw(batch, "Hello World", 10, 10); f.dispose();
9. Tools for Creating own Fonts • Hiero (http://bit.ly/16EpREP) – Free and buggy? Java app • Glyphite (https://www.glyphite.com/) – Free web app • Littera (http://kvazars.com/littera/) – Free web app
10. Littera Usage 1. Upload some .ttf font 2. Export format .txt 3. Add to assets (.png and .txt) to libGDX project
11. Simple to Use BitmapFont f = new new BitmapFont(Gdx.files.internal("font.txt")); f.draw(batch, "Hello World", 10, 10); f.dispose();
12. Calculate Position GlyphLayout layout = new GlyphLayout(); layout.setText(someFont, "Some text"); int width = layout.width; int height = layout.heigth;
13. Freetype Extension • Generate bitmap font from ttf in runtime @Override public void create () { generator = new FreeTypeFontGenerator(Gdx.files.internal("font.ttf")); FreeTypeFontParameter parameter = new FreeTypeFontParameter(); parameter.size = 12; parameter.borderColor = Color.BLACK; parameter.borderWidth = 3; font12 = generator.generateFont(parameter); // Generates BitmapFont }
14. Fonts and Meters • Fonts don't work very well with meters • Create two cameras, one with a world with pixel resolution and on with a world of meter resolution • In render – use the resolution of the fontcamera – draw fonts – use the resolution of the "normal" camera – draw your game objects
15. PREF
16. Persistent Storage • Simple preferences mechanism for storing and retrieving • Windows, Linux, OS X: xml-file in home dir – Windows: %UserProfile%/.prefs/My Preferences – Mac: ~/.prefs/My Preferences • On Android, the system's SharedPreferences class is used. – Preferences will survive app updates, but are deleted when the app is uninstalled.
17. Usage Preferences prefs = Gdx.app.getPreferences("MyPreferences"); prefs.putString("name", "Donald Duck"); String name = prefs.getString("name", "No name stored"); prefs.putBoolean("soundOn", true); prefs.putInteger("highscore", 10); prefs.flush();
18. file <?xml version="1.0" encoding="UTF-8" standalone="no"?> <!DOCTYPE properties SYSTEM "http://java.sun.com/dtd/properties.dtd"> <properties> <entry key="score">221</entry> </properties>
19. LIBGDX: INTERNALIZATION AND SCENE 2D
20. INTERNALIZATION
21. Support for Multiple Languages • Create defaults properties file: – MyBundle.properties • Create other language files: – MyBundle_fi_FI.properties
22. MyBundle.properties title=My Game score=You score {0}
23. MyBundle_fi.properties title=Pelini score=Pisteesi {0}
24. In Java Locale locale = new Locale("en", "UK"); Locale defaultLocale = Locale.getDefault(); I18NBundle myBundle = I18NBundle.createBundle(Gdx.files.internal("MyBundle"), locale); String title = myBundle.get("title"); String score = myBundle.format("score");
25. Notes • If you don't specify locale, default locale is used • Charset is UTF-8 (without BOM) • See: – https://github.com/libgdx/libgdx/wiki/Internation alization-and-Localization
26. SCENE2D
27. Scene2D? • It’s optional, you don’t need it. But you may want to use it. • May be useful for "board games" • Higher level framework for creating games • Provides UI Toolkit also: Scene2d.ui • Tutorial – https://github.com/libgdx/libgdx/wiki/Scene2d
28. Concepts • Stage – “Screens”, “Stages”, “Levels” – Camera watching the stage – Contains group of actors • Actors – “Sprites”
29. Roughly the Idea in Code Stage gameStage = new Stage(new FitViewport(width, heigth), batch); // PlayerActor extends Actor { .. } PlayerActor player = new PlayerActor(); // Let's add the actor to the stage gameStage.addActor(player);
30. Possibilities • Event system for actors; when actor is touched, dragged .. – Hit detection; dragging / touching within the bounds of actor • Action system: rotate, move, scale actors in parallel – Also rotation and scaling of group of actors
31. Stage • Stage implements InputProcessor, so it can directly input events from keyboard and touch • Add to your ApplicationAdapter – Gdx.input.setInputProcessor(myStage); • Stage distributes input to actors • Stage has act method, by calling this, every act method of every actor is called
32. Actors • Actor has an position, rect size, scale, rotation… • Position is the left corner of the actor • Position is relative to the actor’s parent • Actor may have actions – Change the presentation of the actor (move, resize) • Actor can react to events
33. public class StageGame extends ApplicationAdapter { // Stage contains hierarcy of actors private Stage stage; // We will have player actor in the stage private BlueBirdActor playerActor; private float width = 8.0f; private float heigth = 4.8f; @Override public void create () { // Creating the stage stage = new Stage(new FitViewport(width, height), batch); // Creating the actors playerActor = new BlueBirdActor(); // add actors to stage stage.addActor(playerActor); } @Override public void render () { Gdx.gl.glClearColor(1, 0, 0, 1); Gdx.gl.glClear(GL20.GL_COLOR_BUFFER_BIT); // Call act on every actor stage.act(Gdx.graphics.getDeltaTime()); // Call draw on every actor stage.draw(); } }
34. public class BlueBirdActor extends Actor { private Texture texture; public BlueBirdActor() { texture = new Texture(Gdx.files.internal("blue-bird-icon.png")); } @Override public void draw(Batch batch, float alpha) { batch.draw(texture, getX(), getY(), getWidth(), getHeigth()); } @Override public void act(float delta) { super.act(delta); } }
35. Event System • Stage will be responsible for getting user input – Gdx.input.setInputProcessor(stage); • Stage will fire events to actors • Actor may receive events if it has a listener – actor.addListener(new InputListener() { … } ); • Actor must specify bounds in order to receive input events within those bounds! • To handle key input, actor has to have keyboard focus
36. Specify Bounds public class PlayerActor extends Actor { private Texture texture; public PlayerActor() { texture = new Texture(Gdx.files.internal("badlogic.jpg")); setWidth(texture.getWidth() / 100f); setHeight(texture.getHeight() / 100f); setBounds(0, 0, getWidth(), getHeight()); ...
37. public class StageGame extends ApplicationAdapter { // Stage contains hierarcy of actors private Stage stage; // We will have player actor in the stage private BlueBirdActor playerActor; @Override public void create () { // Creating the stage stage = new Stage(...); // Sets the InputProcessor that will receive all touch and key input events. // It will be called before the ApplicationListener.render() method each frame. // // Stage handles the calling the inputlisteners for each actor. Gdx.input.setInputProcessor(stage); // Creating the actors playerActor = new BlueBirdActor(); // add actors to stage stage.addActor(playerActor); stage.setKeyboardFocus(playerActor); } @Override public void render () { Gdx.gl.glClearColor(1, 0, 0, 1); Gdx.gl.glClear(GL20.GL_COLOR_BUFFER_BIT); // Call act on every actor stage.act(Gdx.graphics.getDeltaTime()); // Call draw on every actor stage.draw(); } }
38. public class BlueBirdActor extends Actor { private boolean up, down, left, right public BlueBirdActor() { addListener(new PlayerListener()); } @Override public void act(float delta) { if(up) { setY(getY() + speed * delta); } } // InputListener implements EventListener, just override the methods you need // Also ActorGestureListener available: fling, pan, zoom, pinch.. class PlayerListener extends InputListener { @Override public void touchDown(...) { } } }
39. Actions • Each actor has a list of actions • Updated on every frame (act-method) • Many actions available – MoveToAction – RotateToAction – ScaleToAction • Example – MoveToAction action = new MoveToAction(); – action.setPosition(300f, 700f); – action.setDuration(2f); – actor.addAction(action);
40. Grouping Actions in Sequence SequenceAction sequenceAction = new SequenceAction(); MoveToAction moveAction = new MoveToAction(); RotateToAction rotateAction = new RotateToAction(); ScaleToAction scaleAction = new ScaleToAction(); moveAction.setPosition(200f, 400f); moveAction.setDuration(1f); rotateAction.setRotation(45f); rotateAction.setDuration(1f); scaleAction.setScale(0.5f); scaleAction.setDuration(1f); sequenceAction.addAction(moveAction); sequenceAction.addAction(rotateAction); sequenceAction.addAction(scaleAction); actor.addAction(sequenceAction);
41. Grouping Actions in Parallel ParallelAction parallel = new ParallelAction (); MoveToAction moveAction = new MoveToAction(); RotateToAction rotateAction = new RotateToAction(); ScaleToAction scaleAction = new ScaleToAction(); moveAction.setPosition(200f, 400f); moveAction.setDuration(1f); rotateAction.setRotation(rotate); rotateAction.setDuration(1f); scaleAction.setScale(0.5f); scaleAction.setDuration(1f); parallel.addAction(moveAction); parallel.addAction(rotateAction); parallel.addAction(scaleAction); actor.addAction(parallel);
42. Actions Complete? SequenceAction sequenceAction = new SequenceAction(); ParallelAction parallelAction = new ParallelAction(); MoveToAction moveAction = new MoveToAction(); RotateToAction rotateAction = new RotateToAction(); RunnableAction runnableAction = new RunnableAction(); moveAction.setPosition(200f, 400f); moveAction.setDuration(1f); moveAction.setInterpolation(Interpolation.bounceOut); rotateAction.setRotation(rotate); rotateAction.setDuration(1f); runnableAction.setRunnable(new Runnable() { public void run() { System.out.println("done!"); } }); parallelAction.addAction(rotateAction); parallelAction.addAction(moveAction); sequenceAction.addAction(parallelAction); sequenceAction.addAction(runnableAction);
43. Enable rotate and scale in drawing @Override public void draw(Batch batch, float alpha){ batch.draw(texture, this.getX(), this.getY(), this.getOriginX(), this.getOriginY(), this.getWidth(), this.getHeight(), this.getScaleX(), this.getScaleY(), this.getRotation(),0,0, texture.getWidth(), texture.getHeight(), false, false); }
44. Grouping Group group = new Group(); group.addActor(playerActor); group.addActor(monsterActor); group.addAction( ... ); stage.addActor(group);
45. CREATING UI: SCENE2D.UI
46. Scene2D.UI • Tutorial – https://github.com/libgdx/libgdx/wiki/Scene2d.ui • To quickly get started, add following to your project – uiskin.png, uiskin.atlas, uiskin.json, default.fnt, https://github.com/libgdx/libgdx/tree/master/test s/gdx-tests-android/assets/data • More skins available – https://github.com/libgdx/libgdx/wiki/Skin
47. TextButton example Skin skin = new Skin( Gdx.files.internal("uiskin.json") ); final TextButton button = new TextButton("Hello", skin); button.setWidth(200f); button.setHeight(20f); button.setPosition(Gdx.graphics.getWidth() /2 - 100f, Gdx.graphics.getHeight()/2 - 10f); startStage.addActor(button); Gdx.input.setInputProcessor(startStage); button.addListener(new ClickListener(){ @Override public void clicked(InputEvent event, float x, float y){ whichScreen = !whichScreen; Gdx.input.setInputProcessor(gameStage); } });
