Ruleguard vs Semgrep vs CodeQL

```
| Topic | Ruleguard vs Semgrep vs CodeQL |
| Location | online |
| Date | October 17, 202 0 |
```

Sub-topics:

- go/analysis example
- Ruleguard example
- Semgrep example
- CodeQL example
- Using ruleguard from golagnci-lint
- Ruleguard guide
- How ast matching works
- Type matching examples
- Side-by-side comparison

Transcript

1. Ruleguard
   CodeQL
   Semgrep
   Iskander (pronounced as “Alex”) @quasilyte
   vs
   vs


   View Slide

2. Me & static analysis
   go-critic NoVerify Ruleguard
   .-


   View Slide

3. Our starting point
   We assume that:
   ● You know that static analysis is cool


   View Slide

4. Our starting point
   We assume that:
   ● You know that static analysis is cool
   ● You’re using golangci-lint


   View Slide

5. Our starting point
   We assume that:
   ● You know that static analysis is cool
   ● You’re using golangci-lint
   ● You want to create custom code checkers


   View Slide

6. /browsing memes/
   Trying to come up
   with linting idea...


   View Slide

7. !


   View Slide

8. Somewhere on Twitter...
   Excellent!


   View Slide

9. func f(w io.Writer, b []byte) {
   - io.WriteString(w, string(b))
   + w.Write(b)
   }
   Bad code example


   View Slide

10. 6 hours later...


    View Slide

11. 6 hours later...
    W
    hy?!
    WDYM
    AST type types are not “types”?!
    No results on
    stackoverflow?!
    How?!


    View Slide

12. Let’s create our own linter!
    We’ll use a fancy go/analysis framework
    -...


    View Slide

13. var analyzer = &analysis.Analyzer{
    Name: "writestring",
    Doc: "find sloppy io.WriteString() usages",
    Run: run,
    }
    func run(pass *analysis.Pass) (interface{}, error) {
    // Analyzer implementation...
    return nil, nil
    }
    Analyzer definition


    View Slide

14. for _, f := range pass.Files {
    ast.Inspect(f, func(n ast.Node) bool {
    // Check n node...
    })
    }
    Analyzer implementation


    View Slide

15. // 1. Is it a call expression?
    call, ok := n.(*ast.CallExpr)
    if !ok || len(call.Args) != 2 {
    return true
    }
    Check n node: part 1


    View Slide

16. // 2. Is it io.WriteString() call?
    fn, ok := call.Fun.(*ast.SelectorExpr)
    if !ok || fn.Sel.Name != "WriteString" {
    return true
    }
    pkg, ok := fn.X.(*ast.Ident)
    if !ok || pkg.Name != "io" {
    return true
    }
    Check n node: part 2


    View Slide

17. // 3. Is second arg a string(b) expr?
    stringCall, ok := call.Args[1].(*ast.CallExpr)
    if !ok || len(stringCall.Args) != 1 {
    return true
    }
    stringFn, ok := stringCall.Fun.(*ast.Ident)
    if !ok || stringFn.Name != "string" {
    return true
    }
    Check n node: part 3


    View Slide

18. // 4. Does b has a type of []byte?
    b := stringCall.Args[0]
    if pass.TypesInfo.TypeOf(b).String() != "[]byte" {
    return true
    }
    Check n node: part 4


    View Slide

19. // 5. Report the issue
    msg := "io.WriteString(w, string(b)) -> w.Write(b)"
    pass.Reportf(call.Pos(), msg)
    Check n node: part 5


    View Slide

20. func main() {
    singlechecker.Main(analyzer)
    }
    Main function definition


    View Slide

21. It works
    But not without problems...
    .-


    View Slide

22. func f(io InputController, b []byte) {
    io.WriteString(w, string(b))
    }
    io could be something else!


    View Slide

23. func f(io InputController, b []byte) {
    io.WriteString(w, string(b))
    }
    io could be something else!
    Need to check that io is a package


    View Slide

24. import "github.com/quasilyte/io" // not stdlib!
    func f(b []byte) {
    io.WriteString(w, string(b))
    }
    io could be something else!
    But even if it is a package we can get confused


    View Slide

25. The warning message is not perfect


    View Slide

26. The warning message is not perfect
    [ ]byte variable is called “x”, not “b”


    View Slide

27. It could be worse
    .-


    View Slide

28. Let’s try again
    Now with ruleguard
    -...


    View Slide

29. func writeString(m fluent.Matcher) {
    m.Match(`io.WriteString($w, string($b))`).
    Where(m["b"].Type.Is("[]byte")).
    Report("$$ -> $w.Write($b)")
    }
    writeString rule


    View Slide

30. func writeString(m fluent.Matcher) {
    m.Match(`io.WriteString($w, string($b))`).
    Where(m["b"].Type.Is("[]byte")).
    Report("$$ -> $w.Write($b)")
    }
    writeString rule
    A rules group named writeString
    (May include several rules)


    View Slide

31. func writeString(m fluent.Matcher) {
    m.Match(`io.WriteString($w, string($b))`).
    Where(m["b"].Type.Is("[]byte")).
    Report("$$ -> $w.Write($b)")
    }
    writeString rule
    AST pattern


    View Slide

32. func writeString(m fluent.Matcher) {
    m.Match(`io.WriteString($w, string($b))`).
    Where(m["b"].Type.Is("[]byte")).
    Report("$$ -> $w.Write($b)")
    }
    writeString rule
    Result filter


    View Slide

33. func writeString(m fluent.Matcher) {
    m.Match(`io.WriteString($w, string($b))`).
    Where(m["b"].Type.Is("[]byte")).
    Report("$$ -> $w.Write($b)")
    }
    writeString rule
    Warning message template


    View Slide

34. The warning message is perfect!


    View Slide

35. func writeString(m fluent.Matcher) {
    m.Match(`io.WriteString($w, string($b))`).
    Where(m["b"].Type.Is("[]byte")).
    Suggest("$w.Write($b)")
    }
    writeString rule
    Auto fix replacement template
    (can be combined with Report)


    View Slide

36. With -fix, suggestions are applied automagically


    View Slide

37. Let’s try semgrep
    -...


    View Slide

38. rules:
    - id: writestring
    patterns:
    - pattern: io.WriteString($W, string($B))
    message: "use $W.Write($B)"
    languages: [go]
    severity: ERROR
    writestring.yml


    View Slide

39. Something went wrong...


    View Slide

40. Something went wrong...
    False positive!


    View Slide

41. rules:
    - id: writestring
    patterns:
    - pattern: io.WriteString($W, string($B))
    message: "use $W.Write($B)"
    languages: [go]
    severity: ERROR
    writestring.yml
    TODO: type filters


    View Slide

42. By the way...
    Have you heard of YAML5?
    -...


    View Slide

43. {
    rules: [
    {
    id: 'writestring',
    patterns: [
    {pattern: 'io.WriteString($W, string($B))'},
    ],
    message: 'use $W.Write($B)',
    languages: ['go'],
    severity: 'ERROR',
    },
    ],
    }
    Using YAML5 format for semgrep rules


    View Slide

44. Let’s try CodeQL
    .-


    View Slide

45. View Slide

46. View Slide

47. View Slide

48. View Slide

49. View Slide

50. import go
    from CallExpr c,
    Expr w,
    ConversionExpr conv,
    SelectorExpr fn
    where w = c.getArgument(0)
    and conv = c.getArgument(1)
    and fn = c.getCalleeExpr()
    and fn.getSelector().getName() = "WriteString"
    and fn.getBase().toString() = "io"
    and conv.getOperand().getType() instanceof ByteSliceType
    and conv.getType() instanceof StringType
    select c, "use " + w + ".Write(" + conv.getOperand() + ")"
    CodeQL query


    View Slide

51. How to run?
    ● Use the online query console
    ● Select quasilyte/codeql-test project
    ● Copy/paste query from the previous slide


    View Slide

52. CodeQL pros
    ● SSA support


    View Slide

53. CodeQL pros
    ● SSA support
    ● Taint analysis (source-sink)


    View Slide

54. CodeQL pros
    ● SSA support
    ● Taint analysis (source-sink)
    ● Not limited by (Go) syntax rules


    View Slide

55. CodeQL pros
    ● SSA support
    ● Taint analysis (source-sink)
    ● Not limited by (Go) syntax rules
    ● Real declarative programming language


    View Slide

56. CodeQL pros
    ● SSA support
    ● Taint analysis (source-sink)
    ● Not limited by (Go) syntax rules
    ● Real declarative programming language
    ● Backed by GitHub


    View Slide

57. CodeQL pros
    ● SSA support
    ● Taint analysis (source-sink)
    ● Not limited by (Go) syntax rules
    ● Real declarative programming language
    ● Backed by GitHub Microsoft


    View Slide

58. CodeQL pros
    ● SSA support
    ● Taint analysis (source-sink)
    ● Not limited by (Go) syntax rules
    ● Real declarative programming language
    ● Backed by GitHub Microsoft
    ● 1st class GitHub integration


    View Slide

59. Truth be told...
    Ruleguard
    and
    Semgrep
    CodeQL


    View Slide

60. CodeQL cons
    The main points that I want to cover:
    1. Steep learning curve
    2. Simple things are not simple
    3. Non-trivial QL may look alien for many people


    View Slide

61. Why Ruleguard then?
    ● Very easy to get started (just “go get” it)


    View Slide

62. Why Ruleguard then?
    ● Very easy to get started (just “go get” it)
    ● Rules are written in pure Go


    View Slide

63. Why Ruleguard then?
    ● Very easy to get started (just “go get” it)
    ● Rules are written in pure Go
    ● Integrated in golangci-lint and go-critic


    View Slide

64. Why Ruleguard then?
    ● Very easy to get started (just “go get” it)
    ● Rules are written in pure Go
    ● Integrated in golangci-lint and go-critic
    ● Simple things are simple


    View Slide

65. Why Ruleguard then?
    ● Very easy to get started (just “go get” it)
    ● Rules are written in pure Go
    ● Integrated in golangci-lint and go-critic
    ● Simple things are simple
    ● Very Go-centric (both pro and con)


    View Slide

66. Using ruleguard from golangci
    -...


    View Slide

67. Enabling Ruleguard
    1. Install golangci-lint on your pipeline (if not yet)
    2. Prepare a rules file (a Go file with ruleguard rules)
    3. Enable ruleguard in golangci-lint config
    You can also use Ruleguard directly or via go-critic.


    View Slide

68. ruleguard


    View Slide

69. go-critic ruleguard


    View Slide

70. go-critic
    golangci ruleguard


    View Slide

71. linters:
    enable:
    - gocritic
    linters-settings:
    gocritic:
    enabled-checks:
    - ruleguard
    settings:
    ruleguard:
    rules: "rules.go"
    .golangci.yml checklist


    View Slide

72. linters:
    enable:
    - gocritic
    linters-settings:
    gocritic:
    enabled-checks:
    - ruleguard
    settings:
    ruleguard:
    rules: "rules.go"
    .golangci.yml checklist
    go-critic linter
    should be enabled


    View Slide

73. linters:
    enable:
    - gocritic
    linters-settings:
    gocritic:
    enabled-checks:
    - ruleguard
    settings:
    ruleguard:
    rules: "rules.go"
    .golangci.yml checklist
    ruleguard checker
    should be enabled


    View Slide

74. linters:
    enable:
    - gocritic
    linters-settings:
    gocritic:
    enabled-checks:
    - ruleguard
    settings:
    ruleguard:
    rules: "rules.go"
    .golangci.yml checklist
    rules param should
    be set


    View Slide

75. Ruleguard guide


    View Slide

76. m.Match(`pattern1`, `pattern2`)
    Match() does the syntax matching


    View Slide

77. m.Match(`pattern1`, `pattern2`)
    Match() does the syntax matching
    Matching alternations:
    pattern1|pattern2


    View Slide

78. `$x = $x` pattern string


    View Slide

79. `$x = $x` pattern string
    Parsed AST


    View Slide

80. `$x = $x` pattern string
    Parsed AST
    Modified AST (with meta nodes)


    View Slide

81. func match(pat, n ast.Node) bool
    pat is a compiled pattern
    n is a node being matched
    AST matching engine


    View Slide

82. Algorithm
    ● Both pat and n are traversed
    ● Non-meta nodes are compared normally
    ● pat meta nodes are separate cases
    ● Named matches are collected (capture)
    ● Some patterns may involve backtracking


    View Slide

83. ● $x is a simple “match any” named match
    ● $_ is a “match any” unnamed match
    ● $*_ matches zero or more nodes
    Meta node examples


    View Slide

84. Pattern matching
    =
    $x $x
    +=
    a 10
    Pattern $x=$x Target a+=10


    View Slide

85. Pattern matching
    =
    $x $x
    +=
    a 10
    Pattern $x=$x Target a+=10


    View Slide

86. Pattern matching
    =
    $x $x
    =
    a 10
    Pattern $x=$x Target a=10


    View Slide

87. Pattern matching
    =
    $x $x
    =
    a 10
    Pattern $x=$x Target a=10


    View Slide

88. Pattern matching
    =
    $x $x
    =
    a 10
    Pattern $x=$x Target a=10
    $x is bound to a


    View Slide

89. Pattern matching
    =
    $x $x
    =
    a 10
    Pattern $x=$x Target a=10
    a != 10


    View Slide

90. Pattern matching
    =
    $x $x
    =
    a a
    Pattern $x=$x Target a=a


    View Slide

91. Pattern matching
    =
    $x $x
    =
    a a
    Pattern $x=$x Target a=a


    View Slide

92. Pattern matching
    =
    $x $x
    =
    a a
    Pattern $x=$x Target a=a
    $x is bound to a


    View Slide

93. Pattern matching
    =
    $x $x
    =
    a a
    Pattern $x=$x Target a=a
    a = a, pattern matched


    View Slide

94. m.Where(cond1 && cond2)
    Where() is for the match filtering


    View Slide

95. m.Where(cond1 && cond2)
    Where() is for the match filtering
    Where expression


    View Slide

96. m.Where(cond1 && cond2)
    Where() is for the match filtering
    Where expression operands


    View Slide

97. Where() expression operands
    ● Matched text predicates


    View Slide

98. Where() expression operands
    ● Matched text predicates
    ● Properties like AssignableTo/ConvertibleTo/Pure


    View Slide

99. Where() expression operands
    ● Matched text predicates
    ● Properties like AssignableTo/ConvertibleTo/Pure
    ● Check whether a value implements interface


    View Slide

100. Where() expression operands
     ● Matched text predicates
     ● Properties like AssignableTo/ConvertibleTo/Pure
     ● Check whether a value implements interface
     ● Type matching expressions


     View Slide

101. Where() expression operands
     ● Matched text predicates
     ● Properties like AssignableTo/ConvertibleTo/Pure
     ● Check whether a value implements interface
     ● Type matching expressions
     ● File-related filters (like “file imports X”)


     View Slide

102. $t Arbitrary type
     []byte Byte slice type
     []$t Arbitrary slice type
     map[$t]$t Map with $t key and value types
     map[$t]struct{} Any set-like map
     func($_) $_ Any T1->T2 function type
     Type matching examples


     View Slide

103. struct{$*_} Arbitrary struct
     struct{$x; $x} Struct of 2 $x-typed fields
     struct{$_; $_} Struct with any 2 fields
     struct{$x; $*_} Struct that starts with $x field
     struct{$*_; $x} Struct that ends with $x field
     struct{$*_; $x; $*_} Struct that contains $x field
     Type matching examples (cont.)


     View Slide

104. // Just report a message
     m.Report("warning message")
     // Report + do an auto fix in -fix mode
     m.Suggest("autofix template")
     Report() and Suggest() handle a match


     View Slide

105. More ruleguard examples
     .-


     View Slide

106. func printFmt(m fluent.Matcher) {
     m.Match(`fmt.Println($s, $*_)`).
     Where(m["s"].Text.Matches(`%[sdv]`)).
     Report("found formatting directives")
     }
     Find formatting directives in a
     non-formatting fmt calls


     View Slide

107. func badLock(m fluent.Matcher) {
     m.Match(`$mu.Lock(); $mu.Unlock()`).
     Report(`$mu unlocked immediately`)
     m.Match(`$mu.Lock(); defer $mu.RUnlock()`).
     Report(`maybe $mu.RLock() is intended?`)
     }
     Find mutex usage issues
     (real-world example)


     View Slide

108. func sprintErr(m fluent.Matcher) {
     m.Match(`fmt.Sprint($err)`,
     `fmt.Sprintf("%s", $err)`,
     `fmt.Sprintf("%v", $err)`).
     Where(m["err"].Type.Is(`error)).
     Suggest(`$err.Error()`)
     }
     Suggest error.Error() instead


     View Slide

109. func arrayDeref(m fluent.Matcher) {
     m.Match(`(*$arr)[$i]`).
     Where(m["arr"].Type.Is(`*[$_]$_`)).
     Suggest(`$arr[$i]`)
     }
     Find redundant explicit array
     dereference expressions


     View Slide

110. func osFilepath(m fluent.Matcher) {
     m.Match(`os.PathSeparator`).
     Where(m.File().Imports("path/filepath")).
     Suggest(`filepath.Separator`)
     }
     Suggest filepath.Separator instead of
     os.PathSeparator


     View Slide

111. # -e runs a single inline rule
     ruleguard -e 'm.Match(`!($x != $y)`)' file.go
     Running ruleguard with -e


     View Slide

112. Side-by-side comparison


     View Slide

113. Written in
     go-ruleguard Go
     Semgrep Mostly OCaml
     CodeQL ??? (Compler+Runtime are closed source)
     Ruleguard vs Semgrep vs CodeQL


     View Slide

114. Written in
     go-ruleguard Go
     Semgrep Not Go
     CodeQL Probably not Go
     Ruleguard vs Semgrep vs CodeQL


     View Slide

115. Matching mechanism
     go-ruleguard AST patterns
     Semgrep AST patterns
     CodeQL Dedicated query language
     Ruleguard vs Semgrep vs CodeQL


     View Slide

116. Type matching mechanism
     go-ruleguard Typematch patterns + predicates
     Semgrep N/A (planned, but not implemented yet)
     CodeQL Type assertion-like API
     Ruleguard vs Semgrep vs CodeQL


     View Slide

117. DSL
     go-ruleguard Go
     Semgrep YAML files
     CodeQL Dedicated query language
     Ruleguard vs Semgrep vs CodeQL


     View Slide

118. Supported languages
     go-ruleguard Go
     Semgrep Go + other languages
     CodeQL Go + other languages
     Ruleguard vs Semgrep vs CodeQL


     View Slide

119. How much you can do
     go-ruleguard Simple-medium diagnostics
     Semgrep Simple-medium diagnostics
     CodeQL Almost whatever you want
     Ruleguard vs Semgrep vs CodeQL


     View Slide

120. Links
     ● Ruleguard quickstart: EN, RU
     ● Ruleguard DSL documentation
     ● Ruleguard examples: one, two
     ● gogrep - AST patterns matching library for Go
     ● A list of similar tools
     ● .golangci.yml from go-critic (uses ruleguard)


     View Slide

121. Ruleguard
     CodeQL
     Semgrep
     Искандер (Alex) Шарипов @quasilyte
     vs
     vs


     View Slide
