Build your first ownCloud App!

Slides of the Workshop I conducted at openSUSE Asia Summit 2014 Beijing, China.

Transcript

1. Build your first ownCloud App openSUSE Summit Asia Beijing - October 2014 Raghu Nayyar - @raghunayyar Google Summer of Code - 2013, 2014 - ownCloud (under openSUSE) Photo by : Baron Reznik
2. ownCloud.org 1. beyond file hosting and sharing 2. one click install self hosted applications • Calendar • Contacts • News • Notes • Bookmarks • Mail • Gallery …. and many many more
3. Why should you make an ownCloud App? Miss an feature set? Implement it. Share it. But check if it already exists at apps.owncloud.com
4. What do you need? 1. A webserver (Apache, NGINX) 2. PHP (> 5.3.8) 3. Web browser (preferably not IE8 or less) 4. A code editor of your choice.
5. What should you know? Basic knowledge of • HTML • CSS • JavaScript • PHP • SQL • ownCloud API
6. Getting Started 1. setup an ownCloud instance 2. create a folder within the app directory* 3. enable debugging mode DEFINE('DEBUG',  true);  (config/config.php) * folder name should be same as app id.
7. Two Approaches • Basic • Advanced
8. The Basic Approach
9. Directory Structure 3rdparty/ js/ lib/ templates/ css/ img/ appinfo/ l10n/ tests/ build/
10. appinfo/ Requires ! • app.php register navigation entry & connect to hooks ! • info.xml description, authors, license, etc. ! • version plain text file with your version number
11. appinfo/ Optional: ! • database.xml • install.php • update.php • migrate.php • routes.php • classpath.php
12. appinfo/app.php add navigation entry for your app: ! <?php     $l  =  OCP\Util::getL10N('myapp');     \OCP\App::addNavigationEntry(array(     'id'  =>  'myapp',  //must  equal  folder-­‐name     'order'  =>  74,  //sorting  weight  for  the  navigation     'href'  =>  \OCP\Util::linkTo('myapp',  ‘index.php'),     'icon'  =>  \OCP\Util::imagePath('myapp',  'nav-­‐icon.png'),     'name'  =>  $l-­‐>t(‘My  App’),   ));
13. appinfo/info.xml Requires: ! • id - appId • name - human-readable name • description • license - must be AGPL compatible • author • require - minimal ownCloud version required
14. appinfo/info.xml Optional: ! • public - provides public interface - no login • remote - provides public interface - with login • documentation - link to doc • website - link to project website • standalone - whether or not it’s a standalone app
15. appinfo/routes.php Register Routes ! <?php   !   $this-­‐>create(“myapp_index”,  ‘/‘)       -­‐>actionInclude(“myapp/index.php”);
16. /index.php <?php     OCP\User::checkLoggedIn();     OCP\App::checkAppEnabled(‘myapp’);     OCP\App::setActiveNavigationEntry(‘myapp’);     $tmpl  =  new  OCP\Template(‘myapp’,  ‘main’,     ‘user’);     $tmpl-­‐>assign(‘name’,  OCP\User::getDisplayName());     $tmpl-­‐>printPage();
17. template files $_ is an array containing variables assigned to template ! • never ever use echo, print, whatsoever • use p() • or print_unescaped() if you are 100% sure that the string can not be affected by XSS attacks
18. templates/main.php <p  class=“infobox”>     You  are  logged  in  as:     <?php       p($_['name']);     ?>   </p>
19. Refresh!
20. css/main.css .infobox  {     font-­‐size:  20px;     text-­‐align:  center;     padding-­‐top:  50px;     color:  #1D2D44;   } index.php   OCP\Util::addStyle(‘myapp’,  ‘main’);
21. Refresh!
22. Pre-defined Styles top-bar <div  id=“controls”></div> ! left-sidebar <div  id=“app-­‐navigation”></div>
23. ajax/getnum.php <?php     OCP\JSON::checkLoggedIn();     OCP\JSON::checkAppEnabled('myapp');     OCP\JSON::callCheck();     $number  =  OCP\Config::getUserValue(OCP\USER::getUser(),       'myapp',  'number',  null);     if($number  ===  null)  {       OCP\JSON::error(array(         'message'  =>  'No  number  stored’,       ));       exit;     }     OCP\JSON::success(array(       'number'  =>  $number,     ));
24. ajax/setnum.php <?php     OCP\JSON::checkLoggedIn();     OCP\JSON::checkAppEnabled('myapp');     OCP\JSON::callCheck();   !   if(!array_key_exists('number',  $_GET))  {       OCP\JSON::error(array(         'message'  =>  'No  number  given',       ));       exit;     }   !   $number  =  floatval($_GET['number']);     OCP\Config::setUserValue(OCP\USER::getUser(),         'myapp',  'number',  $number);     OCP\JSON::success(array(       'number'  =>  $number,     ));
25. templates/main.php <p  class=“infobox”>     Enter  a  number  and  we’ll  store  it!     <input  type=“number”  id=“numberinput”>   </p>
26. $(document).ready(function()  {     $.get(OC.filePath('myapp',  'ajax',  ‘getnum.php'),     {},  function(result)  {       if  (result.status  ==  'success')  {         $(“#numberinput”).val(escapeHTML(result.number));       }     }   );   !   $("#numberinput").change(function(event)  {       var  input  =  $(“#numberinput”).val();       $.get(OC.filePath('myapp',  'ajax',  ‘setnum.php'),         {number:  input},  function(result)  {           if  (result.status  !=  'success')  {             OC.Notification.show(result.message);           }       });     });   }); js/main.js
27. /index.php <?php     OCP\User::checkLoggedIn();     OCP\App::checkAppEnabled('myapp');     OCP\Util::addStyle('myapp',  'main');     OCP\Util::addScript('myapp',  'main');     OCP\App::setActiveNavigationEntry('myapp');     $tmpl  =  new  OCP\Template('myapp',  'main',     'user');     $tmpl-­‐>printPage();
28. A ‘very’ basic app set up!
29. ownCloud API
30. • addNavigationEntry(  $data  );   • setActiveNavigationEntry(  $id  );   • isEnabled(  $app  ); OCP\App
31. OCP\Config • getSystemValue  (  $key,  $default  =  null  )   • setSystemValue  (  $key,  $value  )   • getAppValue  (  $app,  $key,  $default  =  null  );   • setAppValue  (  $app,  $key,  $value  );   • getUserValue  (  $user,  $app,  $key,  $default  =  null  );   • setUserValue  (  $user,  $app,  $key,  $value  );
32. OCP\JSON •  checkLoggedIn();   •  checkAppEnabled();   •  checkAdminUser();   •  callCheck();   • success();   • error();
33. OCP\Template • __construct(  $app,  $name,  $renderas  =  ""  );   • addHeader(  $tag,  $attributes,  $text=‘’);   • assign  (  $key,  $value);   • printPage();   • fetchPage();
34. Template Helpers • image_path(  $app,  $image  );   • human_file_size(  $bytes  );   • relative_modified_date(  $timestamp,  $dateOnly  =  false  );   • html_select_options  ($options,  $selected,  $params=array())
35. OCP\User • getUser()   • getUsers(  $search  =  '',  $limit  =  null,  $offset  =  null  )   • getDisplayName(  $user  =  null  )   • getDisplayNames(  $search  =  '',  $limit  =  null,  $offset  =  null  )   • isLoggedIn()   • userExists(  $uid,  $excludingBackend  =  null  )
36. Databases
37. appinfo/database.xml <?xml  version="1.0"  encoding="ISO-­‐8859-­‐1"  ?>   <database>     <name>*dbname*</name>     <create>true</create>     <overwrite>false</overwrite>     <charset>utf8</charset>     <table>       <name>*dbprefix*yourapp_items</name>       <declaration>         <field>           <name>id</name>           <type>integer</type>           <default>0</default>           <notnull>true</notnull>           <autoincrement>1</autoincrement>           <length>4</length>         </field>         <!-­‐-­‐  ...  -­‐-­‐>       </declaration>     </table>   </database>
38. OCP\DB • prepare  (  $query,  $limit=null,$offset=null  )   • execute($params  =  null)   ! Don’t  put  variables  into  $query,  use  the  ?   placeholder  and  hand  over  the  variable  in  $params!   This  will  protect  you  from  SQL  Injections.   ! • insertid  ($table=null)
39. The Advanced Approach Overview
40. Benefits • Build-In Dependency Injection • proper MVC abstraction • easier integration with routes • opt-out for security checks • easier testing
41. More Info Developer center owncloud.org/developer ! Contribution guidelines owncloud.org/contribute ! Dev manual doc.owncloud.org/server/7.0/developer_manual
42. Got Stuck? Have doubts? We help each other. ! IRC : freenode #ownCloud (users) #ownCloud-dev (developers) #ownCloud-design (designers) #ownCloud-testing (testing)
43. Contribute to core? For Developers and Designers start by fixing issues marked as “Junior Job” ! • easy to implement • help you to get familiar with ownCloud’s code
44. Contribute to core? Other ways to contribute ! translate ownCloud transifex.com/projects/p/owncloud/ ! write high-quality bug reports ! testing
45. Looking forward to see your app! Slides : speakerdeck.com/raghunayyar Credits : Georg Ehrke, ownCloud Community Special Thanks : Jos Poortvliet, ownCloud Inc.
