Get Ready for Parallel Programming Featuring Parallella

Presented at Groupon's Geekfest on Tuesday, March 8, 2016.

This talk is the sequel to Ray Hightower's Parallella presentation from 2015. For a quick intro, check out Part One: https://www.youtube.com/watch?v=BHZCCUEzK0s

Curious about the Internet of Things? Check out http://WindyCityThings.com.

Transcript

1. Get Ready for Parallel Programming Featuring Geekfest at Groupon Chicago, IL, USA March 8, 2016 RayHightower.com
2. RayHightower.com
3. •Why? •Concurrency vs Parallelism •Parallella vs Mac •FPGAs •Questions Journey
4. Why?
5. What can we do now that we could not do before?
 How do we show the difference visually?
6. What can we do in parallel that we cannot do serially?
 How do we show the difference visually? Parallel: So what?
7. Moore’s Law: 2x every 18 months
8. Moore’s Law: 2x every 18 months 1993 http://www.washingtonpost.com/blogs/innovations/wp/ 2015/04/14/10-images-that-explain-the-incredible-power-of- moores-law/ 2013
9. Parallelism
10. If one ox could not do the job they did not try to grow a bigger ox, but used two oxen. When we need greater computer power, the answer is not to get a bigger computer, but to build systems of computers and operate them in parallel. -Grace Hopper
11. Concurrency is not Parallelism. https://www.youtube.com/watch?v=cN_DpYBzKso&list=PLOnWKC1gI_OPU8SDIBnCLHsgzNLSbnPJQ&index=3 -Rob Pike, Go
12. Concurrency At least two threads are making progress. Parallelism At least two threads are executing simultaneously. Oracle Multithreaded Programming Guide http://docs.oracle.com/cd/E19455-01/806-5257/6je9h032b/index.html vs.
14. RISC ARM + FPGA 18 cores: 2 ARM + 16 RISC
15. RJ-45 Power μUSB μHDMI μSD
19. Watts & Dollars
21. 17.8 million watts $17.8 million per year
22. 5 watts for Parallella?
23. http://rayhightower.com/blog/2014/09/09/solar-powered-parallella/
24. http://rayhightower.com/blog/2014/09/09/solar-powered-parallella/ 5 volts 1 amp 5 watts Solar!
25. Reduced Instruction Set Computer RISC
26. Advanced (or Acorn) RISC Machine ARM
27. Field Programmable Gate Array FPGA
29. Find all primes up to 16,000,000. Serial on Parallella.
30. 1 #include <stdio.h> 2 #include <stdlib.h> 3 #include <math.h> 4 #include <time.h> 5 6 #define DEFAULT_MAX_TESTS 16000000 7 8 inline int isprime(unsigned long number) 9 { 10 unsigned long i; 11 unsigned long s = sqrt(number); 12 for(i=3;i<=s;i+=2) 13 { 14 if(number % i == 0) 15 return 0; 16 } 17 return 1; 18 } /* Copyright (c) Adapteva, contributed by M. Thompson with modifications by T. Malthouse. */
31. 8 inline int isprime(unsigned long number) 9 { 10 unsigned long i; 11 unsigned long s = sqrt(number); 12 for(i=3;i<=s;i+=2) 13 { 14 if(number % i == 0) 15 return 0; 16 } 17 return 1; 18 } /* Copyright (c) Adapteva, contributed by M. Thompson with modifications by T. Malthouse. */
33. 237.1 sec
34. Find all primes up to 16,000,000. Serial on Mac OS X.
35. Same serial code, written in C. Build it on OS X.
37. 14.4 sec
38. Find all primes up to 16,000,000. Parallel on Parallella.
39. 27 #include <e-hal.h> 28 29 // Default max number of prime tests per core 30 // Used if a limit it not provided in argv[1] 31 #define DEFAULT_MAX_TESTS 500000 32 33 int main(int argc, char *argv[]) 34 { 35 unsigned row, col, coreid, i, j; 36 e_platform_t platform; 37 e_epiphany_t dev; 38 /* Copyright (c) Adapteva, contributed by M. Thompson with modifications by T. Malthouse.*/
41. 18.6 sec
42. Summary: Finding Primes 0" 50" 100" 150" 200" 250" Parallel Parallella Serial Mac Serial Parallella 18.6 sec 14.4 sec 237.1 sec ($2,000.00 Apple MacBook Pro) ($150.00 Parallella)
43. Embarrassingly parallel problem.
44. Mandelbrot Set
46. Why?
47. https://www.e-education.psu.edu/worldofweather/node/2029 Grid spacing influences accuracy. Weather Prediction
48. Finite Element Analysis http://www.ce.ncsu.edu/news/article/21550/making-bridges-more-robust-to-earthquakes/
49. break? wear out? work? Finite Element Analysis Will it {
50. Free Body Diagram F F applied friction F gravity F normal
51. Finite Element Analysis http://www.ce.ncsu.edu/news/article/21550/making-bridges-more-robust-to-earthquakes/
52. Where can Ruby (or Python, Node.js, Erlang, etc.) fit?
53. Ruby
 +
 Sinatra
 +
 WebSockets
54. Original example by The Hybrid Group and Engine Yard. Modified by WisdomGroup.
55. Field Programmable Gate Array FPGA
57. AB 00 01 10 11 Q 1 1 1 0
58. WebPACK Edition
59. •Finance: High-freq trading •Routers •Health care: MRIs, CAT scanners •Cell phone towers •Anything with lots of connections •HDMI interface on Parallella. FPGA Uses…
60. Embedded Systems
63. https://www.parallella.org/2015/06/01/the-open-camera-project-1000-bounty-for-open-firmwaredrivers-for-raspberry-pi-camera-module/
64. Parallella vs GPU
65. 384 cores MacBook Pro Video
66. Specialized vs. General
67. Something new for you… Pine A64 4 cores 64-bit $15.00
69. Thanks! RayHightower.com
