GitOps Happy Hour - Operators in a GitOps World

Join Christian Hernandez, GitOps Extraordinaire, for a journey through how to achieve GitOps in any number of ways. The occasional Red Hatters and special guest will join us too.

https://openshift.tv

Transcript

1. Operators in a GitOps World
   1
   Christian Hernandez
   Senior Principal Technical Marketing Manager
   Cloud Platforms Business Unit
   @christianh814


   View Slide

2. ● Overview of Operators
   ● Overview of Operator Lifecycle Management
   ● Where Operators fit in the bigger GitOps picture
   It’s a GitOps World
   2


   View Slide

3. 3
   Operators: A cloud-like
   experience, everywhere


   View Slide

4. Flexible app
   architectures
   Uniform deploy
   and debug
   No reinvention
   of core concepts
   Truly hybrid
   Operators codify operational knowledge and workflows to automate
   life-cycle management of containerized applications with Kubernetes
   Kubernetes-native day 2 management


   View Slide

5. ● Codify operational knowledge and software lifecycle
   ● Software-as-a-Service consumption model
   The purpose of Operators
   5
   Embed ops knowledge from the
   experts
   Operator v1.1.2 Deployments
   StatefulSets
   Autoscalers
   Secrets
   Config maps


   View Slide

6. Capability levels
   6


   View Slide

7. Operators in action
   7
   Custom Resource
   Developer /
   OpenShift User
   Deployments
   StatefulSets
   Autoscalers
   Secrets
   ConfigMaps
   PersistentVolumes
   K8s API
   apiVersion:
   etcd.database.coreos.com/v1beta2
   kind: EtcdCluster
   metadata:
   name: example-etcd-cluster
   spec:
   size: 5
   version: 3.2.13
   Custom Kubernetes
   Controller
   Watch Events
   Reconciliation
   +
   Custom Resource
   Definition
   Kubernetes Operator
   Native
   Kubernetes
   Resources


   View Slide

8. Operator updates
   8
   OPERATOR
   LIFECYCLE
   MANAGER
   YourOperator v1.2
   YourOperator
   v1.3
   YourOperator
   v2.0
   YourOperator v2.1
   Subscription for
   YourOperator
   Time
   Version
   YourApp
   v3.0
   YourApp
   v3.1
   YourApp
   v3.1
   Operator
   Catalog


   View Slide

9. ● OperatorHub.io launched by Red Hat, AWS,
   Microsoft and Google
   ● OpenShift Operator Certification
   ● OperatorHub integrated into OpenShift 4
   COMMUNITY OPERATORS
   OperatorHub and certified Operators
   OPENSHIFT CERTIFIED OPERATORS


   View Slide

10. ● Operators
    ○ Codify Operational/Software-lifecycle knowledge
    ○ Built on Kubernetes primitives (CRDs)
    ○ SDK: Golang, Ansible, Helm, more to come!
    ○ Meant for Automating applications
    ○ OpenShift 4 is built on top of Operators
    ● Manage Operators with OLM
    ○ An operator for Operators
    ○ Control versions and upgrades
    ○ Catalog/SaaS experience
    In Summary
    10


    View Slide

11. 11
    GitOps and Operators,
    like peanut butter and
    chocolate.


    View Slide

12. ● What are Operators, really?
    ○ Custom Resource saved in YAML
    ○ Automation triggered by the CR (the YAML)
    ○ Changes are made by editing the CR (YAML)
    ○ Other changes are reconciled back to the desired
    state
    ○ Easily Replicated to other clusters
    ● What is GitOps?
    ○ Manifests are saved in git (YAML)
    ○ Automation/sync tool reads manifest (YAML)
    ○ Changes are made by PRing the YAML
    ○ Other changes are reconciled back to the desired
    state.
    ○ Easily Replicated to other clusters
    So Many Automation Tools!
    12


    View Slide

13. How To Interface with Operators/OLM
    13
    CLUSTER VERSION
    OPERATOR
    YAML
    MACHINE CONFIG
    OPERATOR
    CLUSTER
    OPERATORS
    DNS, Authentication,
    Console, Ingress,
    Network, Registry,
    Monitoring, Logging, etc.
    OpenShift Nodes


    View Slide

14. It’s Just YAML!
    14
    CLUSTER VERSION
    OPERATOR
    YAML
    MACHINE CONFIG
    OPERATOR
    CLUSTER
    OPERATORS
    DNS, Authentication,
    Console, Ingress,
    Network, Registry,
    Monitoring, Logging, etc.
    OpenShift Nodes


    View Slide

15. ● Operators are YAML Driven
    ● YAML for the Operator function should live in Git
    ● The point of demarcation is the handoff of this YAML
    You manage the manifest with GitOps as you normally would, while allowing the automation
    of Operators to be performed.
    The Point Of Demarcation
    15


    View Slide

16. ● Cluster Operators and the CVO
    ● Machine Config Operators
    ○ RHCOS MachineSet Configs
    ○ Windows MachineSet Configs
    ○ MachineSet Autoscalers
    ● Machine Configs
    ● Machine Config Pools
    Other Things To Consider
    16


    View Slide

17. linkedin.com/company/red-hat
    youtube.com/user/RedHatVideos
    facebook.com/redhatinc
    twitter.com/RedHat
    Thank You
    17


    View Slide
