Apache Zeppelin, the missing component for your BigData eco-system by DuyHai Doan

Transcript

1. Apache Zeppelin, the missing GUI for your BigData eco-system DuyHai DOAN, Apache Cassandra Evangelist
2. @doanduyhai Who Am I ? Duy Hai DOAN Cassandra technical advocate •  talks, meetups, confs •  open-source devs (Achilles, …) •  OSS Cassandra point of contact ☞ duy_hai.doan@datastax.com ☞ @doanduyhai 2
3. @doanduyhai Datastax •  Founded in April 2010 •  We contribute a lot to Apache Cassandra™ •  400+ customers (25 of the Fortune 100), 400+ employees •  Headquarter in San Francisco Bay area •  EU headquarter in London, offices in France and Germany •  Datastax Enterprise = OSS Cassandra + extra features 3
4. @doanduyhai What is Apache Zeppelin ? •  Presentation •  Architecture
5. @doanduyhai Zeppelin Presentation 5
6. @doanduyhai Demo https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
7. @doanduyhai Zeppelin Architecture Zeppelin Server Zeppelin Engine 7 R E S T WebSocket Spark Interpreter Group Spark SparkSQL Zeppelin Interpreter Factory Tajo Interpreter Flink Interpreter Cassandra Interpreter JVM JVM JVM JVM JVM
8. @doanduyhai What does Zeppelin provide ? Front-end & display system for free Generic back-end with REST APIs & WebSocket Pluggable interpreters system Task scheduler (à la CRON) 8
9. @doanduyhai Zeppelin UI Layout •  Notes •  Paragraphs •  UI Elements
10. @doanduyhai Demo https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
11. @doanduyhai Zeppelin Display System •  Raw, Table, HTML, AngularJS with Scala •  Graphs •  Dynamic Forms •  View modes •  Export as Iframe
12. @doanduyhai Demo https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
13. @doanduyhai Interpreter to Front-End Streaming
14. @doanduyhai Interpreter to front-end streaming Zeppelin Server 14 WebSocket Interpreter JVM JVM
15. @doanduyhai Demo https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
16. @doanduyhai Interpreter System •  Core interpreters •  Third-party interpreters •  Interpreter conf & usage
17. @doanduyhai Interpreter processing lifecycle ①  Receive input commands/data •  as raw text •  from form data ②  Process the input commands/data by the external back-end ③  Format the response using Zeppelin display system ④  Send response back to the Zeppelin engine 17
18. @doanduyhai Core interpreters •  Spark (Spark core, SparkSQL/DataFrame, PySpark) •  Spark core = default (or %spark) •  SparkSQL = %sql •  Shell (%sh) •  Markdown (%md) •  AngularJS (%angular) 18
19. @doanduyhai Third-parties interpreters •  Hive •  Phoenix •  Tajo •  Flink •  Ignite •  Lens •  Cassandra •  Geode •  PostgreSQL •  Kylin •  ElasticSearch 19
20. @doanduyhai Interpreter conf & usage https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
21. @doanduyhai Writing an interpreter •  How To •  Simple interpreter (AsciiDoc) •  Complex interpreter (Cassandra)
22. @doanduyhai Steps to write your own interpreter •  Create a class that extends Interpreter base class •  Register it in a static block •  Optionnally define default config params 22 static { Interpreter.register("MyInterpreterName", MyClassName.class.getName()); } static { Interpreter.register("MyInterpreterName", MyClassName.class.getName(), new InterpreterPropertyBuilder() .add("property1", "default value", "Description of property1").build()); }
23. @doanduyhai To register your interpreter as default •  Edit the enum ZeppelinConfiguration.ConfVars •  Add your interpreter FQCN in the property ZEPPELIN_INTERPRETERS 23
24. @doanduyhai To register your interpreter in config files •  Create conf/zeppelin-site.xml from conf/zeppelin-site.xml.template •  Add your interpreter FQCN in the property zeppelin.interpreters 24 <property> <name>zeppelin.interpreters</name> <value>org.apache.zeppelin.spark.SparkInterpreter,org.apache.zeppelin.spark.PySparkInterpreter, org.apache.zeppelin.spark.SparkSqlInterpreter,org.apache.zeppelin.spark.DepInterpreter, org.apache.zeppelin.markdown.Markdown,org.apache.zeppelin.shell.ShellInterpreter, org.apache.zeppelin.hive.HiveInterpreter,com.me.MyNewInterpreter </value> </property>
25. @doanduyhai Update interpreter pom.xml 25
26. @doanduyhai Update main pom.xml 26
27. @doanduyhai Simple AsciiDoc Interpreter 27 Zeppelin Server AsciiDoc Interpreter JVM Zeppelin Engine Raw Text Block Raw Text Block Converted To HTML HTML Output ① ② ③ ④ JVM
28. @doanduyhai Simple interpreter (AsciiDoc) https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
29. @doanduyhai Cassandra Interpreter Architecture 29 Cassandra Interpreter JVM Display Results as HTML ① ② ⑤ Zeppelin Server JVM Raw Text Block Raw Text Block Cassandra Cassandra Java Driver ③ Async CQL statements ④ Render HTML ⑥
30. @doanduyhai Cassandra Interpreter Commands 30 Native CQL statements SELECT * FROM …; INSERT INTO …; … Schema commands DESCRIBE TABLE …; DESCRIBE KEYSPACE …; … Prepared statements Commands @prepare …; @bind …; @remove_prepared …; Help command HELP; Options Commands @consistency …; @retryPolicy …; @fetchSize …;
31. @doanduyhai Complex interpreter (Cassandra) https://github.com/doanduyhai/incubator-zeppelin/tree/ZeppelinPresentation
32. @doanduyhai Cassandra Online Interpreter Docs 32 •  http://zeppelin.incubator.apache.org/docs/interpreter/cassandra.html
33. @doanduyhai Zeppelin Future •  Road Map
34. @doanduyhai Enterprise Ready •  Apache Shiro authentication (ZEPPELIN-548) •  Note authorization (PR #681) •  Multi-tenancy 34
35. @doanduyhai Usability •  UX improvement •  Better table data support •  Export data as CSV etc . (PR #725, PR #714, PR #6, PR #89) •  Table pagination … 35
36. @doanduyhai Pluggability •  Pluggable visualization •  Pluggable interpreter •  Repository and registry for pluggable components 36
37. @doanduyhai More interpreters 37
38. @doanduyhai Q & R ! "
39. @doanduyhai Thank You @doanduyhai duy_hai.doan@datastax.com http://zeppelin.incubator.apache.org/
